- Page 1 ENUWI-NX2 IEEE 802.11n draft 2.0 Wireless USB 2.0 Adapter Users Guide...
- Page 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 3 Hereby, Encore Electronics Inc., declares that this ENUWI-NX2 is in compliance with the essential English requirements and other relevant provisions of Directive 1999/5/EC. Por medio de la presente Encore Electronics Inc declara que el ENUWI-NX2 cumple con los requisitos Español esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
- Page 4 [Polish] oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC. Português Encore Electronics Inc declara que este ENUWI-NX2 está conforme com os requisitos essenciais e outras [Portuguese] disposições da Directiva 1999/5/CE. Encore Electronics Inc izjavlja, da je ta ENUWI-NX2 v skladu z bistvenimi zahtevami in ostalimi Slovensko relevantnimi določili direktive 1999/5/ES.
- Page 5 Niniejszym Encore Electronics Inc oświadcza, że ENPWI-NX2 jest zgodny z zasadniczymi wymogami Polski oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC. [Polish] Encore Electronics Inc declara que este ENPWI-NX2 está conforme com os requisitos essenciais e outras Português disposições da Directiva 1999/5/CE. [Portuguese]...
-
Page 6: Table Of Contents
TABLE OF CONTENT Introduction ....................1 Overview of this User’s Guide ................1 Unpacking and Setup.................. 2 Unpacking ......................2 Setup........................2 IDentifying external components ............... 3 LED ........................3 Check the installation ..................... 3 Software Installation................... 4 Windows Based Utility Installation................ 4 Wireless Utility Setting ................ -
Page 7: Introduction
This manual contains detailed instructions regarding the operation of this product. Please keep this manual for future reference. With the ENUWI-NX2 Wireless 802.11n USB Adapter, a desktop or laptop computer can communicate with another computer wirelessly. An easy-to-use utility is bundled with the ENUWI-NX2 Wireless 802.11n USB Adapter for configuration, monitoring, and diagnostic purposes. -
Page 8: Unpacking And Setup
Make sure your computer is running at least a 300MHz or above processor with 256MB RAM or above Make sure the USB port where the ENUWI-NX2 Wireless 802.11n USB Adapter is to be used is a USB 2.0 port The operating system on your computer must be any of the following: Windows®... -
Page 9: Identifying External Components
Wireless Ethernet network. Check the installation The LED of the ENUWI-NX2 Wireless 802.11n USB Adapter is clearly visible and the status of the network link can be seen instantly: 1. When connected to the USB port and the driver were installed, the LINK LED will start blinking, and it means that the device is starting to scan a wireless device near the ENUWI-NX2 Wireless 802.11n USB Adapter. -
Page 10: Software Installation
SOFTWARE INSTALLATION This section describes how to install the driver and utility for the ENUWI-NX2 Wireless 802.11n. Windows Based Utility Installation 1) Insert the Utility and Driver CD-ROM into your computer’s CD-ROM Drive and then click the Setup Wizard. 2) Follow the Install Shield Wizard Instructions... - Page 11 3) Click Finish to restart the computer. 4) Plug the ENUWI-NX2 Wireless 802.11n into an available USB slot on your computer.
-
Page 12: Wireless Utility Setting
WIRELESS UTILITY SETTING The user can configure the wireless settings using the Wireless Adapter Configuration Utility. Double-click the utility icon that appears in the taskbar. The Wireless Adapter Configuration Utility is divided into six sections: Link Info, Configuration, Site Survey, Profile, WPS and About. Link Information This is the default screen after launching the Utility program. -
Page 13: Configuration
Data Rate: Shows the statistics of data transfer, and the calculation is based on the number of packets transmitted and received. Configuration This screen is where you set the basic wireless settings for the ENUWI-NX2 Wireless 802.11n. Profile Name: Shows the Profile Name. - Page 14 Authentication and Security: The following options are available: Open System, Shared Key, WPA-PSK, WPA2-PSK, WPA EAP-TLS, WPA2 EPA-TLS . Select Open System, Shared Key for WEP data encryption feature. Open or Shared Key Open System and Shared Key require the user to set a WEP key to exchange data with other wireless clients that have the same WEP key.
- Page 15 WPA EAP-TLS If using the WPA/WPA2 EAP-TLS authentication method, please select the Encryption type for TKIP or AES then select the WPA/WPA2 Certificate from drop down list.
-
Page 16: Site Survey
Site Survey This screen allows the user to scan for available wireless networks (wireless clients and Access Points). It also allows the user to establish wireless communications with an available wireless network. Available Network – displays the wireless networks (wireless clients and access points) that are within range. -
Page 17: Profile
Profile Profile – The user can create and manage the created profiles for home, work or public areas. By double-clicking on one of the created profile, the setting will adjust to the specific setting such as SSID, channel, and encryption as saved by that particular profile. -
Page 18: Wps
WiFi Protected Setup (WPS) is an optional certification program from the Wi-Fi Alliance that is designed to ease the task of setting up and configuring security on a wireless network. There are two methods used in the WPS as below instruction. Push the button on my access point Using the WPS configuration with the “Push the button on my access point”... - Page 19 4) If the WPS configuration was successful, the follow window will show on. 5) If the WPS configuration was failed, the follow window will show on.
- Page 21 Enter a PIN into my access point Using the WPS configuration with the “Enter a PIN into my access point” method, the configuration steps as below: 1) Selected the “Enter a PIN into my access point”, the PIN will be show on the button of the windows.
- Page 22 4) If the WPS configuration was successful, the follow window will show on. 5) If the WPS configuration was failed, the follow window will show on.
-
Page 23: About
About This screen displays information about the Wireless N USB Adapter, such as the Driver and Utility version. When a new version of the utility becomes available for upgrade, users will be able to identify by version numbers. -
Page 24: Technical Specifications
TECHNICAL SPECIFICATIONS Hardware Interface USB 2.0 Compliant Standards IEEE 802.11n draft v2..0, IEEE 802.11b and IEEE 802.11g Antenna 2X Integrated Printed Antenna LED Indicator Activity Supported OS Windows® 2000, XP, Windows Vista™ Dimensions 86.5 x 30 x 13 mm (LxWxH) Temperature Operating: 0°...
