Encore ENUHDE-IFP User Manual

Fingerprint security hdd enclosure
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ENUHDE-IFP
Fingerprint Security HDD Enclosure
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENUHDE-IFP and is the answer not in the manual?

Questions and answers

Related Manuals for Encore ENUHDE-IFP

Summary of Contents for Encore ENUHDE-IFP

  • Page 1 ENUHDE-IFP Fingerprint Security HDD Enclosure User Manual...

  • Page 2: Important Notice

    Manual updates are represented by the third digit in the manual revision number. Copyright © 2009 ENCORE ELECTRONICS, INC. All Rights Reserved.

  • Page 3: Table Of Contents

    ENUHDE-IFP - User Manual Contents: Chapter1: Introduction ........................... 4 1.1 Features ........................5 1.2 Requirements ......................5 1.3 Specifications ......................5 Chapter2: Physical Characteristics ........................ 6 2.1 Product Views ......................6 2.2 Package Contents ....................6 2.3 Hard Disk Drive Installation ..................7 Chapter3: Getting Started ..........................

  • Page 4: Chapter1: Introduction

    ENUHDE-IFP - User Guide Chapter1: Introduction Thank you for purchasing our Fingerprint Security HDD Enclosure. This product is a hard disk enclosure integrated with fingerprint verification technology to provide maximum security for your data. Featuring a USB 2.0 interface, this product offers true plug and play functionality, providing a fast and efficient data transfer speed.

  • Page 5: Features

    ENUHDE-IFP - User Guide 1.1 Features • Protect Sensitive Data with Fingerprint Access • Safely Travel with Your Data • Transport Music, Movies, Photos and Documents with Ease • Easy to Use with Plug-and-Play Feature 1.2 Requirements • Operating System: Windows® XP / 2000; Windows Vista®...

  • Page 6: Chapter2: Physical Characteristics

    ENUHDE-IFP - User Guide Chapter2: Physical Characteristics 2.1 Product Views LED Power Indicator LED Activity Indicator Fingerprint Scanner Screw Cover Mini USB Port Power Port Activity Indicator Status: Status Description On (Red) Power is on Blinking (Green) Data is being transferred 2.2 Package Contents...

  • Page 7: Hard Disk Drive Installation

    ENUHDE-IFP - User Guide 2.3 Hard Disk Drive Installation 1. Take off the screw cover as shown. 2. Remove the two screws fastening the cover. 3. Remove the cover. 4. Slide the hard disk into the enclosure as shown, until the IDE connector sits firmly into place.

  • Page 8: Chapter3: Getting Started

    (if any). All existing data will be erased during the partition process. 1. Connect the ENUHDE-IFP to any free USB port on your PC using the supplied USB cable. Insert the supplied Setup CD in your CD-ROM drive.
  • Page 9 ENUHDE-IFP - User Guide 4. A warning message appears. This is to remind you to back up any existing data. Then click OK to begin partitioning the hard disk. 5. After partitioning is complete, the following message appears. Click OK to complete the process.

  • Page 10: Setup Fingerprint & Password

    ENUHDE-IFP - User Guide 3.2 Setup Fingerprint & Password After disk partitioning, you can set up Fingerprint Verification protection for AP Drive (Secured Drive). 1. Double click My Computer on your desktop. Then double click on the drive named 2. Double click the FingerVerify.exe file.
  • Page 11 ENUHDE-IFP - User Guide 5. Once the fingerprint is accepted, you must enter a password. Enter a hint to help you remember the password in the Hint field, and new password twice. Then click Confirm. 6. Scan your fingerprint or key in the password again to confirm your setting.

  • Page 12: Fingerprint Access Setting

    ENUHDE-IFP - User Guide 3.3 Fingerprint Access Setting You can save up to 10 fingerprints and use any one to access data. 1. Click the FingerVerify icon in the system tray. Then FingerVerify menu appears. 2. Choose Fingerprint Registration. 3. Scan your fingerprint or enter your password.

  • Page 13: Password Access Setting

    ENUHDE-IFP - User Guide 3.4 Password Access Setting 1. Click the FingerVerify icon in the system tray. Then FingerVerify menu appears. 2. Click User Setting => Choose Fingerprint Software Password Setting. 3. Enter hint, original password, and new password twice. Then click Confirm.

  • Page 14: Access Validity Time Setting

    ENUHDE-IFP - User Guide 3.5 Access Validity Time Setting You can set a period of time in which you have to scan your fingerprint or enter the password to access the Secured Drive of the hard disk. 1. Click the FingerVerify icon in the system tray.

  • Page 15: Using Your Hard Disk

    ENUHDE-IFP - User Guide 3.6 Using Your Hard Disk 3.6.1 Accessing the Public Drive 1. Double click My Computer on your desktop. 2. You will see both Public and AP drives. Double click the Public Drive to get into the Public Drive.

  • Page 16: Chapter4: Encrypting And Decrypting Files

    ENUHDE-IFP - User Guide Chapter4: Encrypting and Decrypting Files You can encrypt / decrypt files on both Public Drive and Secured Drive on this hard disk using the Finger-Verify software. You also can encrypt and decrypt files in other hard drives on your computer.

  • Page 17: Decrypting Files

    ENUHDE-IFP - User Guide 4.2 Decrypting Files 1. Double click My Computer on your desktop. Then choose the files you want to encrypt. 2. Click the Right mouse button, and then select Decrypting from the menu that appears. 3. Scan your fingerprint or enter password.

  • Page 18: Chapter5: Q&A

    ENUHDE-IFP - User Guide Chapter5: Q&A Q1: Why does the computer not recognize my hard disk? Answer: • Make sure the right USB port on the Y-cable is connected to your hard disk. Not only plug the auxiliary power cable.
