Summary of Contents for Encore ENPUH-302
- Page 1 ENPUH-302 SuperSpeed USB 3.0 ExpressCard User’s Manual...
- Page 2 ABOUT THIS MANUAL This manual is designed for use with the SuperSpeed USB 3.0 ExpressCard. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any commercial damage, including but not limited to special, incidental,...
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ........................3 ..........................3 EATURES ........................3 ACKAGE ONTENTS ......................3 YSTEM EQUIREMENTS INSTALLATION ........................4 7 / XP / W ....................4 INDOW INDOWS ISTA HARDWARE INSTALLATION ....................9 INSTALLATION VERIFICATION ..................11 XP..........................11 INDOW 7 ..................... -
Page 4: Introduction
1. Introduction Encore Electronics’ SuperSpeed USB 3.0 ExpressCard adds two USB 3.0 ports to your notebook computer. The data transfer rate is at an amazing speed up to 5 Gbps — 10 times faster than USB 2.0 (480 Mbps). Now, you can connect to the latest USB devices, such as external hard drives, Blu-ray burners, external video adapters and camcorders. -
Page 5: System Requirements
You will need to install the driver for your SuperSpeed USB 3.0 ExpressCard to your laptop first. Please follow the procedures as below. Window 7 / XP / Windows Vista Insert the provided Driver into CD-ROM. The following screen will show up and please choose the correct product model, ENPUH-302. - Page 6 Click “Driver Setup” to install driver, then press Next to continue.
- Page 7 After reading End-User License Agreement, please select “I accept the terms in the License Agreement” and click Next.
- Page 8 Please click Browse to choose the Destination Folder. After that, please click Next. Click Install to install NEC Electronics USB 3.0 Host Controller Driver.
- Page 9 It will take a while to install the Driver. Notice: The Software Installation may pop-up during installation. Please click Continue Anyway to complete the installation. Please click Finish to complete the NEC Electronics USB 3.0 Host Controller Driver. *Actual strings depend on your operation system. These screen shots are from Windows XP and might vary slightly for each operation system.
-
Page 10: Hardware Installation
3. Hardware Installation Please find the ExpressCard slot of your system, and insert the SuperSpeed USB 3.0 ExpressCard into the slot. The SuperSpeed USB 3.0 ExpressCard supports hot-swapping, so you don’t need to turn off your system before the installation. For Window XP When inserting SuperSpeed USB 3.0 ExpressCard into the slot, the following screen will show up. - Page 11 Please choose “Install the software automatically” and click Next. Notice: The sign of Hardware Installation may show up, please click Continue Anyway. Please click Finish to complete the Found New Hardware Wizard. *Actual strings depend on your operation system. These screen shots are from Windows XP and might vary slightly for each operation system.
-
Page 12: Installation Verification
4. Installation Verification After finishing driver installation and plugging this ExpressCard to laptop, the system will detect the device. You can go to Device Manager to verify the entire installation. Window XP... -
Page 13: Window Vista/ Windows 7
Window Vista/ Windows 7... -
Page 14: Specification
5. Specification Description SuperSpeed USB 3.0 ExpressCard Standard USB 3.0, backward compatible with USB 2.0 / 1.x USB Port USB 3.0 SuperSpeed Downstream port x 2 Data transfer rate USB 3.0: up to 5 Gbps USB 2.0: up to 480 Mbps USB 1.x: up to 12 Mbps Bus Interface ExpressCard 1.0...
