O
– HOLE PUNCH TO ATTACH
DOCUMENT TO DRIVETRAIN
READ THIS BEFORE UNPACKING YOUR PRODUCT!
COMPONENT VERIFICATION CHECKLIST
AND ASSEMBLY INSTRUCTIONS
Part No 60121511 Rev D
1
Instructions, Racer Customer Assembly

Advertisement

loading
Need help?

Need help?

Do you have a question about the NRG and is the answer not in the manual?

Questions and answers

Summary of Contents for Eliminator NRG

  • Page 1 – HOLE PUNCH TO ATTACH DOCUMENT TO DRIVETRAIN READ THIS BEFORE UNPACKING YOUR PRODUCT! COMPONENT VERIFICATION CHECKLIST AND ASSEMBLY INSTRUCTIONS Part No 60121511 Rev D Instructions, Racer Customer Assembly...
  • Page 2 ELIMINATOR OSR AND NRG ASSEMBLY To Get Started: 1) Remove packing material to reveal entire frame assembly and other NOTE: SOME IMAGES USED ARE FOR REFERENCE ONLY. components. 2) Remove several pieces of the packaging foam and place them on top of a large surface/table (at least 6’...
  • Page 3: Preparing For Assembly

    Small Components and Verification 1) For the “Small Component Bag” (3), remove the verification sheet and lay out on a flat and level surface. 2) Remove small components from bag and place them on the verification sheet in their outlined areas. a.
  • Page 4 2. Assemble Steering and Braking onto Frame. Are you ready? Cool… Let’s do this. Depending on whether a carbon fiber fork or an aluminum fork was ordered, the assembly steps are different. Instructions for each 1. Install rear wheels to frame. configuration are on the next pages in sections 3 and 4 With the frame resting on the convoluted foam, remove the packaging materials protecting the camber bushing, fenders and rear cross...
  • Page 5 Install the steering handle over the fork steer tube on top of the dust Aluminum Fork Assembly Instructions cap. You may need to unscrew the screws and pry the clamp open (skip if you have a carbon fiber fork) using a flathead screwdriver for it to fit over the fork. Install the top cap and screw from [SHEET #3] onto the fork stem using Remove the packing material from the fork, track control, compensator the 5mm Allen key from [SHEET #1] (recommended torque: 7-9 N.m.)
  • Page 6 The expansion plug assembly is made of two parts: 4. Carbon Fork Assembly Instructions The expansion plug (consists of 4 parts) does as its name (skip if you have an aluminum fork) describes – it expands Remove the packing material from the fork, track control, compensator The top cap also does as its name describes –...
  • Page 7 NOTE: In some cases, with custom mounting positions the Carbon Fork Assembly Instructions brake cable may have to cross over the frame. In these- (continued…) situations, ensure that the brake cable does not get tangled or twisted when moving the steering handle to either side. Insert the expansion plug into the fork steer tube so that the threads protrude 1/4”...
  • Page 8 6. Install Compensator Next, attach the compensator to the fork. The hardware and assembly instructions will vary depending on whether your Racing Chair has Bottom Mount or Top Mount track control. See below for instructions that correlate to your Racing Chairs configuration Bottom Track Control Install the compensator using an 1/8”...
  • Page 9 7. Install front wheel Install the front wheel located in a wheel box using both M6 x 20mm Screws [SHEET #2]. NOTE: The wheel and tire can be mounted in either direction. Once the mounting holes and hub aligned, finger tighten each screw Using the 5mm Allen key from [SHEET #1], tighten them down to secure the wheel (recommended torque: 8-9 N.m.) 8.
  • Page 10 9. Inflation of Tires Ensure knurled nut identified on the valve stem is tightened against the Remove valve stem cap Loosen up needle to outward position Thread on valve stem adapter Inflate tires using a traditional Schrader air nozzle (do not exceed recommendations embossed on tire).
