Summarization of Contents
Introduction and Setup Essentials
Unpacking Instructions
Instructions for safely removing speakers from packaging and retaining materials for future use.
Package Contents
Details the items included in each speaker box: speakers, magnetic grilles, and cutout templates.
Required Tools and Items
Lists the necessary tools and materials for installation, such as saws, wires, and measuring tools.
General Speaker Placement Guidelines
Dispersion and Coverage
Explains the wide 75-degree dispersion and its benefits for room coverage compared to competitors.
Spacing Calculation Formula
Details the formula and chart for calculating in-ceiling speaker spacing based on ceiling height.
Installation Preparation and Placement
Recommended Speaker Wire
Guidance on selecting appropriate wire gauge based on the length of the speaker wire run.
Precautions Before Installation
Check for obstructions and use tools to check for wires, pipes, or studs before cutting.
In Wall Placement Guidelines
Optimal sound achieved at or slightly above ear level, with listening distance consideration.
Stereo Audio Applications
Position speakers at thirds of longest dimension, or adjacent to TV for TV audio.
Multi-channel Audio Applications
5.1 and 7.1 Surround Setups
Diagrams and descriptions for 5.1 and 7.1 surround speaker placement.
Phase Linearity and Blending
Highlights phase linearity and seamless integration with other Totem speaker lines.
Angled In-Ceiling Speaker Positioning
Direct drivers towards the listening area for the most direct signal and best performance.
Installing Your Speakers
Step 1: Trace Location
Use the provided template to trace the speaker cutout location.
Step 2: Cut Speaker Cavity
Carefully cut out the speaker cavity with a drywall saw.
Step 3: Fish Cable & Connect Terminals
Route speaker cable, strip ends, and connect to terminals, observing polarity.
Step 4: Secure Speaker & Tighten
Insert speaker and gradually tighten screws using appropriate torque for a secure fit.
Step 5: Place Grille
Place the grille onto the speaker to complete the installation.
Painting and Optional Accessories
Painting the Grilles
Instructions for painting stainless steel grilles while preserving scrim-cloth adhesion.
Optional Accessories Details
Information on pre-construction kits (PCK) and square grille kits (SGK).
Totem Limited Warranty
Warranty Terms and Conditions
Covers 5-year warranty, purchase requirements, and conditions that void the warranty.
Warning: Overpowering and Clipping
Explains risks of overpowering/clipping, identifying them, and preventing speaker damage.
Speaker Break-in Period
Recommends 75-100 hours of playing time for optimal speaker performance.
