XDMA6630
During installation, the Bluetooth microphone input must be connected in order for
Bluetooth operation to be fully functional.
Connect the Bluetooth microphone to the Bluetooth microphone input (as shown above)
during installation of the head unit. Bluetooth phone calls will not function correctly unless the
microphone is plugged in.
BLUETOOTH MICROPHONE INSTALLATION
Important
RCA Preamp Output
Connections
REAR/SUB
(selectable)
FRONT
FRONT
R/SUB
REMOTE IN
Steering Wheel Interface Input
(PAC SWI-PS required)
BLACK
Bluetooth Microphone Input
Connect the included
Bluetooth microphone.
L-CH
R-CH
Antenna
Connector
Bluetooth Microphone
(must be connected for Bluetooth functionality)
