LINE LIGHT 1
Item no. 03.5203
LINE LIGHT 1
216 high bright
1100 lumen
75
o
PLCC SMD LED
24V DC
-10
to +40
C
ø25 X 1600 mm
IP67
o
o
15W
PCB 1425 mm
20W POWER SUPPLY UNIT
230V AC/50Hz
24V DC/20W
IP67
1m H05RN-F, 2x1.0mm
2
4m H03VV-F, 2x0,5mm
2
with standard European plug
Advertisement
Related Manuals for SCANGRIP LINE LIGHT 6
Summary of Contents for SCANGRIP LINE LIGHT 6
- Page 1 LINE LIGHT 1 Item no. 03.5203 LINE LIGHT 1 216 high bright 1100 lumen PLCC SMD LED 24V DC to +40 ø25 X 1600 mm IP67 PCB 1425 mm 20W POWER SUPPLY UNIT 230V AC/50Hz 24V DC/20W IP67 1m H05RN-F, 2x1.0mm...
-
Page 2: Line Light
LINE LIGHT 4 Item no. 03.5201 LINE LIGHT 4 4 X 216 high bright 4 X 1100 lumen PLCC SMD LED 24V DC to +40 4 X ø25 X 1600 mm IP67 4 X 15W PCB 1425 mm 80W POWER SUPPLY UNIT 230V AC/50Hz 24V DC/80W IP67... - Page 3 LINE LIGHT 6 Item no. 03.5200 LINE LIGHT 6 6 X 216 high bright 6 X 1100 lumen PLCC SMD LED 24V DC to +40 6 X ø25 X 1600 mm IP67 6 X 15W PCB 1425 mm 2 X 80W POWER SUPPLY UNIT 230V AC/50Hz 24V DC/80W IP67...
- Page 4 LINE LIGHT 1. Assembly 2 holders IMPORTANT ~ 1m 1 m between the two clips! Place LINE LIGHT unit in clips Distance ø 6mm Backside - star washer...
-
Page 5: Connecting Power Supply
Backside - nut Important Fasten nut Make sure to be free of moving jack! 2. Connecting powersupply Remove end tube... - Page 6 Mount cables and tighten screws Blue -> blue Brown -> brown Tighten carefully by hand to make waterproof...
- Page 7 3. Mount connection between tubes Suitable distance Mount end cover...
- Page 8 LINE LIGHT 4. How to mount LINE LIGHT 4 5. How to mount LINE LIGHT 6...
- Page 9 • Respekter altid den gældende lovgivning for arbejde med elektrisk udstyr for dermed at reducere risikoen for ulykker • Beskyt netledningen mod olie, varme og skarpe kanter Genbrug af lysstofrør: Smid ikke brugte lysstofrør i husholdningsaffaldet. Tag lysstofrøret med til indsamlingsstation for genbrug. •...
- Page 10 • Siempre respetar la ley vigente sobre trabajos con equipos eléctricos para reducir el riesgo de accidentes • Proteger el cable de línea contra aceite, calor y cantos filosos Reciclaje de tubo fluorescente: No mezclar los tubos fluorescentes con los residuos domés - ticos.
- Page 11 LINE LIGHT EU Design Patent 10 years factory guarantee SCANGRIP A/S Rytterhaven 9 DK-5700 Svendborg scangrip@scangrip.com • • •...
