ViewSonic VA1930WM - 19" LCD Monitor Specification page 2

VA1930wm
19" WIDESCREEN HEIGHT ADJUST LCD WITH CLEARMOTIV
360º SWIVEL
HEIGHT ADJUST
TILT
ViewSonic Corporation's QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Customer Service and Technical Support: (800) 688-6688 • Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
*Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details.
Windows Vista and the Windows Vista logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Corporate names, trademarks stated herein are the property of their
respective companies. Copyright © 2007 ViewSonic Corporation. All rights reserved. [13368-00B-01/07] VA1930wm-1
For more product information, visit us on the web at ViewSonic.com
LCD Type
Display Area
Optimum Resolution
Contrast Ratio
Viewing Angles
Response Time
Light Source
Brightness
Panel Surface
VIDEO INPUT Analog/Digital
Frequency
Sync
COMPATIBILITY PC
Mac ® *
CONNECTOR Analog/Digital
Audio In
Power
POWER Voltage
Consumption
AUDIO Speakers
Amplifier
CONTROLS Basic
OnView ®
ERGONOMICS
OPERATING Temperature
CONDITIONS Humidity
DIMENSIONS Physical with stand
(W x H x D) Physical without stand 18.1" x 13.9" x 2.4" (460mm x 352mm x 61mm)
WEIGHT Net with stand
Net without stand
Gross with stand
REGULATIONS
RECYCLE/DISPOSAL
POWER MANAGEMENT
PACKAGE CONTENTS
WARRANTY
® 5MS VIDEO RESPONSE
19" color TFT active matrix SXGA+ LCD
16.1" horizontal x 10.1" vertical; 19" diagonal
1440x900
700:1 (typ)
160° horizontal, 160° vertical @ contrast ratio > 10:1
5ms (typ)
Long life, 50,000 hrs. (typ)
300 cd/m2 (typ)
Anti-glare
RGB analog (75 ohms, 0.7 Vp-p)/DVI-D
F h : 24~82kHz, F v : 50~75Hz
H/V separated (TTL)
VGA up to 1440x900 non-interlaced
Power Mac ™ G3/G4/G5 up to 1440x900
15-pin mini D-sub/DVI-D
Stereo mini audio line in
3-pin AC plug
AC 100–240V (universal)
35W (typ)
2x1.5-watt
1.5-watt @ THD < 8%
Power, 1, down, up, 2, mute, volume +/ –
Auto image adjust, brightness, contrast, input selection,
ViewMatch color adjust (sRGB, 9300K, 6800K, 6500K),
®
information (mode, model number, serial number), audio
(volume, mute), manual image adjust (H. position, V. position,
fine tune, sharpness), setup menu (language, resolution
notice, OSD position, OSD timeout, OSD background),
memory recall
Height adjustment range 3.2", tilt, swivel range 360º
41–95°F (3–35°C)
20–80% (non-condensing)
18.1" x 17.1" x 9.1" (460mm x 434mm x 230mm)
11.9 lb. (5.4 kg)
9.6 lb. (4.4 kg)
15.2 lb. (6.9 kg)
UL, cUL, FCC-B, ICES-003, CB, CE, ENERGY STAR
TUV/GS, Argentina TUV-S, TUV/ERGO (covers ISO13406-2 &
MPR II), TCO'03, GOST-R, SASO, PCBC, VCCI, BSMI, CCC,
MIC, PSB, C-TICK, RoHS
The lamp in this product contains mercury. Please dispose of
in accordance with local, state and federal laws.
Meets TCO'03 and ENERGY STAR ®
LCD display, VGA cable, power cable, audio cable,
Quick Start Guide, ViewSonic Wizard CD
Three-year limited warranty
® , NOM,
standards
