GE PVB98DTBB Dimensions And Installation Information

PVB98DT
GE Profile 36" Telescopic Downdraft System
™
Dimensions and Installation Information (in inches)
For answers to your Monogram, GE Profile
®
GE appliance questions, visit our website at
®
geappliances.com or call GE Answer Center
service, 800.626.2000.
Venting Options (in inches)
Through the Floor
In Cabinet Discharge (Right)
or
™
®
In Cabinet Discharge (Down) Note: Telescopic downdraft vents are not
recommended to be installed with cooktops that are
flush mounted.
Approved for use with the following GE Profile
GE cooktops–36" electric models, 36" gas sealed
burner models and 36" induction models.
Not Approved for use with standard burner gas
cooktops.
Note: The cooktop must be at least 26" deep with a
flat surface area of 23-1/2" or more, front to back. In
addition, other clearances to the front edge of the
In Cabinet Discharge (Left)
countertop must be considered.
Note: Dimensions shown are for reference only. Before
cutting out countertop, refer to instructions packed with
downdraft and cooktop.
Note: Installation on cabinets/countertops against
the wall will not be possible in most applications.
Against the wall installations are limited to
dimension requirements. Refer to installation
instructions packed with product for further details.
JXRB67 Indoor Remote Accessory. Optional
accessory may be ordered for installation of motor
and blower assembly in an indoor remote location.
*
Specification Revised 12/11
, and
™
Listed by
Underwriters
Laboratories
220983
