PROPANE CONVECTION CONSTRUCTION HEATER
IMPORTANT: Read and understand this manual before
assembling, starting, or servicing heater. Improper use
of heater can cause serious injury. Keep this manual for
future reference.
GENERAL HAZARD WARNING:
Failure to comply with the precautions and instructions pro-
vided with this heater, can result in death, serious bodily injury
and property loss or damage from hazards of fire, explosion,
burn, asphyxiation, and/or carbon monoxide poisoning.
Only persons who can understand and follow the instruc-
tions should use or service this heater.
If you need assistance or heater information such as an in-
structions manual, labels, etc. contact the manufacturer.
Safety Information ............................................... 2
Product Identification ........................................... 3
Unpacking ........................................................... 3
Theory of Operation ............................................ 3
Ventilation ............................................................ 3
Propane Supply ................................................... 4
Installation ........................................................... 4
Operation ............................................................. 4
Storage ................................................................ 5
OWNER'S MANUAL
TABLE OF CONTENTS
Save this manual for future reference.
For more information, visit www.desatech.com
Variable 15,000/25,000
Btu/Hr Models
Maintenance ........................................................ 5
Inspecting Burner ................................................ 5
Specifications ...................................................... 6
Technical Service ................................................ 6
Troubleshooting ................................................... 6
Illustrated Parts Breakdown and Parts List ......... 7
Replacement Parts .............................................. 7
Warranty and Repair Service .............................. 8
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Desa Btu
Summary of Contents for Desa Btu
- Page 1 TABLE OF CONTENTS Maintenance ... 5 Inspecting Burner ... 5 Specifications ... 6 Technical Service ... 6 Troubleshooting ... 6 Illustrated Parts Breakdown and Parts List ... 7 Replacement Parts ... 7 Warranty and Repair Service ... 8 Variable 15,000/25,000 Btu/Hr Models...
-
Page 2: Safety Information
SAFETY INFORMATION WARNING: This product con- tains and/or generates chemicals known to the State of California to cause cancer or birth defects, or other reproductive harm. WARNING: Fire, burn, inha- lation, and explosion hazard. Keep solid combustibles, such as building materials, paper or cardboard, a safe distance away from the heater as recommended by the instructions. -
Page 3: Product Identification
SAFETY INFORMATION Continued 112396-01B IDENTIFICATION Shell Base Piezo Ignitor Button Figure 1 - Product Identification www.desatech.com PRODUCT Gas Inlet Connector Automatic Control Valve Button... - Page 4 Propane Supply Valve Propane Tank Figure 2 - Connecting Heater to Propane www.desatech.com Hose Regulator Fitting Tank 112396-01B...
- Page 5 112396-01B www.desatech.com...
-
Page 6: Technical Service
SPECIFICATIONS • Rating: High - 25,000 Btu/Hr (26.375 Kj/Hr) Low - 15,000 Btu/Hr (15.826 Kj/Hr) • Fuel: Propane Vapor Only • Fuel Consumption/Hour: Minimum - 0.17 gal (0.64 liter), Maximum 0.27 gal (1.02 liter) Minimum - 0.70 lb (0.32 kg), Maximum 1.16 lb (0.53 kg) -
Page 7: Illustrated Parts Breakdown And Parts List
PARTS UNDER WARRANTY Contact authorized dealers of this product. If they canʼt supply original replacement part(s), either contact your nearest Parts Central or call DESA Heating Products (US) at 1-866-672-6040 or DESA Industries (CAN) at 1-905-826-8010. 112396-01B This list contains replaceable parts used in your heater. -
Page 8: Warranty And Repair Service
Date of Purchase LIMITED WARRANTIES FOR NEW AND FACTORY DESA Heating Products warrants this heater and any parts thereof, to be free of defects in materials New Products: and workmanship for one (1) year from the date of first purchase, when operated and maintained in accordance with the manufacturer's instructions. -
Page 9: Table Of Contents
Inspección Del Quemador ... 5 Especificaciones ... 6 Servicio técnico ... 6 Solución de problemas ... 6 Clasificación ilustrada de piezas y lista de piezas ...7 Piezas de repuesto ... 7 Garantía y servicio de reparación ... 8 Modelos de 15,000/25,000 BTU/h variables... -
Page 10: Información De Seguridad
INFORMACIÓN DE SEGURIDAD ADVERTENCIA: Este producto contiene y/o genera químicos que el Estado de California reconoce que causan cáncer, defectos de nacimiento u otros daños relacio- nados con la reproducción. ADVERTENCIA: Peligro de incendio, quemaduras, inhala- ción y explosión. Mantenga los combustibles sólidos, como ma- teriales de construcción, papel o cartón a una distancia segura del... -
Page 11: Identificación Del Producto
INFORMACIÓN DE IDENTIFICACIÓN DEL SEGURIDAD PRODUCTO Continuación 112396-01B www.desatech.com... - Page 12 www.desatech.com 112396-01B...
- Page 13 112396-01B www.desatech.com...
-
Page 14: Especificaciones
ESPECIFICACIONES • Clasificación: Alta - 25,000 BTU/h (26.375 kJ/h), Baja - 15,000 BTU/h (15.826 kJ/h) • Combustible - Sólo vapor de propano • Consumo de combustible/hora: mín. 0.64 litros (0.17 gal.), máx. 1.02 litros (0.27 gal.), mín. 0.32 kg (0.70 lb), máx. 0.53 kg (1.16) lb •... -
Page 15: Piezas De Repuesto
Comuníquese con los distribuidores autorizados de este producto. Si no pueden suministrar piezas de repuesto originales, comuníquese con la central de piezas más cercana o llame a DESA Heating Products (EE.UU.) al 1-866-672-6040 o DESA 112396-01B Esta lista contiene las partes reemplazables utilizadas en el calentador. -
Page 16: Garantía Y Servicio De Reparación
Si su calentador requiere servicio, regréselo al centro de servicio autorizado más cercano. Se debe presentar una prueba de compra con el calentador. El calentador será inspeccionado. Un defecto puede ser ocasionado por materiales o mano de obra defectuosos. Si es así, DESA Heating Products reparará o reemplazará el calentador sin ningún cargo. SERVICIO DE REPARACIÓN Regrese su calentador al centro de servicio autorizado más cercano. - Page 17 Inspection du brûleur ... 5 Caractéristiques ... 6 Service Technique ... 6 Dépannage ... 6 Vue détaillée et liste des pièces ... 7 Piéces Détachées ... 7 Service de garantie et de réparation ... Dos Variable 15 000/25 000 Btu/heure Modéles...
-
Page 18: Information Relativeà La Sécurité
INFORMATION RELATIVE À LA SÉCURITÉ AVERTISSEMENT : Ce produit contient ou génère des substan- ces chimiques que l’état de Cali- fornie reconnaît comme pouvant entraîner le cancer, des anomalies congénitales ou d’autres troubles de reproduction. AVERTISSEMENT : Risques d’incendie, de brûlures et d’ex- plosion. -
Page 19: Identification Du Produit
INFORMATION RELATIVE IDENTIFICATION DU À LA SÉCURITÉ PRODUIT Suite 112396-01B www.desatech.com... - Page 20 www.desatech.com 112396-01B...
- Page 21 112396-01B www.desatech.com...
-
Page 22: Alimentation En Propane
CARACTÉRISTIQUES • Rendement: Élevé - 26.375 Kj/Hr (25.000 Btu/hr), Bas - 15.826 Kj/Hr (15.000 Btu/hr) • Combustible - Vapeur de propane seulement • Consommation en combustible/heure: Faible 0,64 litres (0,17 gal), Fort 1,02 litres (0,27 gal): Faible 0,32 kg (0,70 livres), Fort 0,53 kg (1,16 livres) •... -
Page 23: Vue Détaillée Et Liste Des Pièces
PIÈCES SOUS GARANTIE Contacter les concessionnaires agréés de ce produit. Si les pièces de rechange dʼorigine ne sont pas disponibles chez les concessionnaires agréés, appeler DESA Heating Products (US) au 112396-01B N° N° DE RÉF DESCRIPTION 1 101880-01 Assemblage de l’habillage 1 2 101864-01 Prêt-à-monter de l’as-... -
Page 24: Service De Garantie Et De Réparation
GARANTIES LIMITÉES POUR LES PRODUITS NEUFS ET LES PRODUITS REMIS EN ÉTAT DESA Heating Products garantit que cet appareil de chauffage et ses pièces sont exempts de défauts Produits neufs : de matériaux et de fabrication et cela pour une durée d'un (1) an à partir de la date du premier achat, lorsque l'appareil de chauffage est utilisé...
