- Page 1 HALOGEN LIGHT MODEL NO: CHL100-1000 PART NO: SEE PAGE 2 ASSEMBLY & OPERATING INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0617 - ISSUE 2...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE Halogen Light. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
11. We recommend that a Residual Current Device (RCD) is used in conjunction with your CLARKE Halogen Light. 12. Do not use this unit if it has a broken lens, casing or damaged supply cable. 13. Always ensure that the front and... -
Page 4: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. 230 VOLT MODELS The battery charger for this product is provided with a standard 13 amp, 230 volt (50Hz), BS 1363 plug, for connection to a standard, domestic electrical supply. -
Page 5: Fuse Rating
3. Should you wish to replace a detachable fuse carrier, ensure that the correct replacement is used (as indicated by marking or colour code). 4. Replacement fuse covers can be obtained from your local Clarke dealer or most electrical stockists. - Page 6 ASSEMBLY & MOUNTING INSTRUCTIONS INSTALLING THE BULB AND GRILL The bulb is stored within the lamp housing as illustrated in Fig 1. 1. Remove the wing nut securing the handle where fitted, and then the screw securing the lamp housing cover, arrowed in Fig.1, and install the halogen bulb as follows: 2.
- Page 7 Wiring up these models should be carried out as follows: 1. Remove the cable gland and rubber washer from the cable inlet and retain. Fig. 2 shows the gland and washer removed from model 150D. 2. Remove the Terminal Box cover by unscrewing the four securing screws.
-
Page 8: Other Models
The cover should be firmly secured, but again, do not overtighten the screws. The lamp may be mounted to a convenient surface using the holes provided in the mounting bracket, and then tilted to the desired angle. Tighten the mounting bracket pivot screws (B, Fig.10) to secure. MODELS 100D, 151D &... - Page 9 Fig 7 Fig 8 IMPORTANT: Ensure the legs are spread wide enough so that the centre column is clear of the ground as shown in Fig 7., otherwise the centre column will act as a fourth leg and the stand will therefore be unstable. Fig. 8 illustrates the stand in an unstable condition.
-
Page 10: Troubleshooting
2. Rest the lamp support bar on the bracket on top of the column as shown in Fig.9. 3. With the two lamps being supported (e.g., resting on a workbench or similar, in order to take their weight), thread the securing screw through the hole in the cable junction box fixing bracket, as shown in Fig.9,... -
Page 11: Maintenance
2. When handling the bulb use clean paper or cloth...DO NOT allow your fingers to come into contact with the glass REPLACEMENT BULBS Replacement bulbs can be obtained from your local dealer or Clarke International Spares Department. 230V, 150W Part No. 5460625 230V, 500W Part No.
