ASCOM TACTICAL OPENACCESS NODE R - DATASHEET 1 Datasheet page 2

product sheet: tActIcAL opeNAccess Node r
Technical Specification
Networking
Network topology Support for meshed network topologies.
Dynamic routing adaptation in response to network
Topology changes
topology changes.
Routing Supports both unicast as well as multicast routing.
Best path selection across different network domains
Routing path selection
(i.e. tactical radio network, LAN, military backbone).
Data Features
IP IPv4
Built-in Domain Name Server for IP-address-to-name
DNS
and name-to-IP-address translation.
Built-in Dynamic Host Configuration Protocol server for
DHCP
IP address assignment.
Radio Features
Optimised network topology management for tactical
Tactical radio network
radio networks. No limitation on the type of radio
topology
network topology.
4x VHF / HF tactical radio (e.g. PR4G transparent data
Radio Connection
interface and remote control interface supported)
ARQ Per-link ARQ across radio networks
Management Features
Remote configuration and monitoring based on SNMP
Management
and Network Management Application (NMA).
Storage of multiple configuration profiles. Configura-
Configuration storage tion changes are possible without reset or reboot.
Configurations can be backed up locally or remotely.
Update management Supports remote software updates.
Environmental Conditions
Operation: -20..+55°C, MIL-STD-810F, 502.4, procedure
II, MIL-STD-810F, 501.4, procedure II
Temperature
Storage: -30..+60°C, MIL-STD-810F, 502.4, procedure I,
MIL-STD-810F, 501.4, procedure I
Cooling possible without external air exchange
Cooling If required, an internal fan activates the airflow and
optimises the cooling.
MIL-STD-810F, 507.3, proc. I, cycle 3 (95%RH) with
Humidity
closed connector shields.
MIL-STD-810F, 506.3, proc. II (dripping-water) with
Waterproof
closed connector shields.
MIL-STD-810F, method 514.4-4 AIII modified (depend-
ing on axis: 1...6.5g RMS, random on random 5 - 500Hz,
Vibrations
8Min/phase, total 40Min/axis, mounted in swing
frame)
MIL-STD-810F, method 516.5, procedure I, 30g 11 ms
Shock
sawtooth, mounted in swing frame
EMC
MIL-STD-461E (CE102, 10kHz – 10MHz, figure CE102-1
Emissions on 24 VDC; RE102, 10 kHz – 1GHz, figure RE102-4 /
army)
MIL-STD-461E (CS114: figure CS114-1 on all cables,
10kHz-1MHz curve #3, 1MHz-30MHz curve #4, 30MHz-
200MHz curve #4; RS103: 30MHz – 1GHz 20V/m,
30MHz–18GHz 50 V/m).
ESD air discharge with 8kV, contact discharge with 4kV
according to IEC 61000-4-2.
Immunity Burst 1 kV according to IEC 61000-4-4 coupling gripper
on the cable.Burst 1 kV according to IEC 61000-4-4
direct coupling on 24V line.
Surge on 24VDC: according to EN 61000-6-2 (Immunity,
Industry, Table 3 dc power port); line-to-earth +/- 0.5kV
1.2 / 50 us (8/20), 12 Ohm; line-to-line: +/- 0.5kV 1.2 /
50 us (8/20), 2 Ohm.
Mechanical
Size (LxHxD)/mm 279x105x215 (without connectors)
Weight 6kg
Circular interface and power supply plugs, mounted on
Connectors
front side
Power
Input voltage 24VDC (18-33VDC)
Power consumption 20W nominal, 30W maximal
An internal lithium-polymer storage battery 24V /
Power autonomy
1.5Ah provides power for 5 minutes.
Available Interfaces
Remote relay Relay I/O control over IP
6 x asynchronous port 16C550 compatible
Serial lines
4 x synchronous port
Switched Ethernet 2 x 10Base-T / 100Base-TX
Service interface 1xUSB 2.0, 1xRS-232
User Interfaces
Display 2-digit process display
Status PC (HD and LAN activity)
radio control, supply power, fans, temperature, storage
Operational displays
battery
Switches / keys On/Off Reset Test
