PrODuCT SHeeT: ASCOM openACCeSS
EMC (industrial usage)
Emissions
EN55022 B
EN61000-4-2, EN61000-4-3, EN61000-4-4,
Immunity
EN61000-4-5, EN61000-4-6
Mechanical
485x163x325mm
Size (WxHxD)/mm:
445x163x300mm (4U)
inside 19" rack
Weight
11,6 kg
Filtered airflow from
Cooling
right side to left side /
front
Power
230 V AC
Input voltage
Optionally: 48 V DC
Power consumption
max 350W
Available interfaces
Main Unit
Management LAN
10/100/1000Mbit/s Ethernet with autocross
1 x 10/100/1000Mbit/s Ethernet with
LAN
autocross
Serial port
4 x RS-232
Although the information in this publication is represented in good faith and believed to be correct, Ascom makes no representations or warranties
as to the completeness or accuracy of the information. In no event will be Ascom responsible for damages of any nature whatsover resulting from the
use of or reliance upon the information contained in this document. Such information is subject to change without notice. Ascom gives no warranty
and makes no representation that any of its products contained in this document are designed for any particular use or purpose. The graphics and
content of this document are the copyrighted work of Ascom and contain proprietary trademarks and tradenames of Ascom.
Ascom (Switzerland) Ltd.
Belpstrasse 37
CH-3000 Berne 14
T + 41 31 999 13 65
F + 41 31 999 16 82
securitycommunication@ascom.com
www.ascom.com
®
NODe G
Main Unit
Telephony MUX Unit
393x45x294mm
445x45x294mm
(1U) inside 19" rack
3,9 kg
Filtered airflow from
right side to left side
Main Unit
Telephony MUX Unit
230 V AC or 48 V DC
(selectable by
switch)
max 75W
Ascom (Austria) Ges.m.b.H
Lemböckgasse 49
1230 Wien
T +43 1 811 77 0
F +43 1 811 77 10
info@ascom.at
www.ascom.at
Expansion units (Inside main unit)
Number of PCI
6 (Relay card doesn't occupy a slot)
expansion slots
8 x E1 ports per unit for data (G.703/G.704) and
8 x E1 PCI
voice (EuroISDN)
SHDSL/E1 PCI
2 x G.SHDSL ports and 2 x E1 ports per unit
Eurocom PCI
4 x Eurocom A ports (8 pin) per unit
4 x FastEthernet PCI
4 x 10/100Mbit/s Ethernet ports per unit
4 x SFP module slots (for optical ethernet) and 4
Gigabit switch PCI
x 10/100/1000Mnit/s ethernet ports per unit
6 x Relay in, 2 x Relay out and reset button per
Relay extension
unit (possibility to double in/out ports in single
extension)
Telephony expansion units (Inside telephony MUX unit)
Number of expansion
8
slots
4xa/b FXS
4xa/b FXS per unit
4xa/b FXO
4xa/b FXO per unit
