Martin Audio MA2.0 Fixed Installations

MA2.0
Lightweight, High Performance Amplifier

features

Advanced Class D Output Stage
Switch-mode power supply
Low inrush current
Built-in clip limiters
Variable speed cooling fan
Comprehensive front panel indicators
Fully protected circuitry
Compact, lightweight

applications

Live sound reinforcement
Fixed installations
Adding to the range of MA Series amplifiers is the new MA2.0.
At 1U and 7.3kg (16lbs) this amplifier offers unparalleled
performance in a compact, light weight, cost effective
package. Delivering up to 1000 watts per channel (4 ohm) this
amplifier provides the power and quality that will more than
meet the requirements of small to medium sized applications
such as stage monitors, installed and portable sound
reinforcement. With Clip Limiting, DC, VHF, Thermal and AC
protection built in as standard, this new additions to the MA
range of amplifiers will continue to supply peak performance
and power over many years of service.

overall dimensions

440.0mm [17.32"]
482.0mm [18.98"]
CLIP
-6dB
-18dB
SIGNAL
- dB +32 - dB +32
READY TEMP
REAR RACK SUPPORT
FIXINGS
MA2.0
MA2.0
All information is Copyright © 2010 Martin Audio Ltd.

technical specifications

MAX OUTPUT POWER

EIA AT 1KHz AND 1% THD
8 PER CHANNEL
W
4 PER CHANNEL
W
2 PER CHANNEL
W
8 BRIDGED
W
4 BRIDGED
W

DISTORTION

THD FROM 0.1W TO FULL POWER
INTERMODULATION SMPTE
INTERMODULATION DIM 100
S/N RATIO
DAMPING FACTOR (8 )
W
SLEW RATE (8 )
W
GAIN

FRONT PANEL

LED INDICATORS

REAR PANEL

INPUT CONNECTORS
OUTPUT CONNECTORS
LINK SWITCH

POWER

OPERATION VOLTAGE
(internal selection)

DIMENSIONS

WIDTH
HEIGHT
DEPTH
WEIGHT
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: info@martin-audio.com
All information is Copyright © 2010 Martin Audio Ltd.
www.martin-audio.com
600W
1000W
1800W (10ms peak power)
2000W
3600W (10ms peak power)
< 0.1% (Typically)
< 0.1% (Typically)
< 0.01% (Typically)
> 105dBA (20Hz to 20kHz)
> 100 @ 100Hz
20 V/ s
µ
32dB
Signal
Clip
Protect
Thermal Forecast
2 x XLR (Female) Input
2 x XLR (Male) Link
2 x Neutrik Speakon
Channel A-B Link
AC: 115V or 230V (+15% - 25%)
50/60Hz
483mm (19ins)
44mm (1.75ins) 1U
358mm (14ins)
7.3kg (16lbs)
