  • Page 1 400.2D 400.4D 800.4D 400.4S 800.4S...
  • Page 2 1 EVO Amplifier 1 Owner’s Manual 1 Allen wrench 2.5mm* 2 Cables for High Input 1 Promotional Sticker *Only in "S" version...

  • Page 3: Important Info

    Dear Customer, IMPORTANT INFO Congratulations on acquiring a product with the highest We recommend the use of SounDigital original accessories quality and technology! for a better performance. The crossovers and voltmeters The SounDigital products are developed to assure offered by SounDigital follow the same quality standards as maximum efficiency and reability to your sound system.
  • Page 4 When passing cables through metallic walls, use rubber O- Connect the power cables in to the amplifier, observing the Ø Ø rings to avoid cable cutting and short circuits. polarity. Connect all the positive cables from the fuse holder or circuit breaker to the positive conector of the amplifier and all Make sure the place chosen for the installation of the the negative power cables from the bussbar or from the...

  • Page 5: Panels Description

    PANELS DESCRIPTION 400.2D EVO 400.4D EVO BRIDGE BRIDGE +12V FUSE GAIN GAIN X-OVER X-OVER FULL FULL CONTROLS CONTROLS Protection Fuse 30A; Protection Fuse 30A; Positive power supply connector (+12V); Positive power supply connector (+12V); Negative power supply connector (GND); Negative power supply connector (GND);...
  • Page 6 PANELS DESCRIPTIONS 400.4S EVO BRIDGE BRIDGE +12V FUSE 45Hz 850Hz 45Hz 850Hz Protection fuse 30A; Variable crossover control CH3 and CH4; Positive power supply connector +12V; Selector switch of crossover CH3 and CH4; Negative power supply connector (GND); Gain Control CH3 and CH4; Remote power supply connector (REM);...
  • Page 7 PANELS DESCRIPTIONS 800.4D EVO GAIN GAIN X-OVER X-OVER FULL FULL CONTROLS CONTROLS Negative speaker connector (-) CH1; Positive speaker connector (+) CH4; Positive speaker connector (+) CH1; Negative speaker connector (-) CH4; Selector switch of crossover CH1 and CH2; Positive speaker connector (+) CH3; Gain control CH1 and CH2;...
  • Page 8 PANELS DESCRIPTIONS 800.4S EVO 45Hz 850Hz 45Hz 850Hz Positive Speaker connector (+) CH1; High level audio input CH3 and CH4; Negative Speaker connector (-) CH1; Variable crossover control CH3 and CH4; Positive speaker connector (+) CH2; Selector switch of crossover CH3 and CH4; Negative Speaker connector (-) CH2;...
  • Page 9 The versatility of the SounDigital multi-channel amplifiers, allows the installation in 1 or 2 channel mode. Bellow is the schematic for the 2-channel mode: Min. Impedance MODEL Bridge per Channel 400.2D EVO 4 Ω 4 Ω 2 Ω 400.2D EVO 2 Ω 2 Ω 1 Ω...
  • Page 10 400.4D EVO / 400.4S EVO INSTALLATION ATTENTION: Before proceeding with the installation of your SounDigital amplifier, unplug the negative (-) terminal of the battery. The versatility of the SounDigital multi-channel amplifiers, allows the installation in 4, 3 or 2 channel mode. Below is the schematic for the 4-channel mode: Min.
  • Page 11 800.4D EVO / 800.4S EVO INSTALLATION ATTENTION: Before proceeding with the installation of your SounDigital amplifier, unplug the negative (-) terminal of the battery. The versatility of the SounDigital multi-channel amplifiers, allows the installation in 4, 3 or 2 channel mode. Below is the schematic for the 3-channel mode: Min.

  • Page 12: Input Connections

    INPUT CONNECTIONS Switch Key at position "F" (Full Range): All the frequencies Ø are reproduced. RCA Inputs +12V -12dB Switch key at "HP" - Set in the variable control between Ø 45Hz and 850Hz ("A") where you want to perform the high pass cut filter;...

  • Page 13: Crossover Set Up

    4Ω / 400W 20.0 V 40.0 V CROSSOVER SET UP Set up procedure 400.2D EVO, 400.4D EVO and 800.4D EVO This procedure is the same for both gain controls; Ø Turn the gain control all the way down. Ø Disconnect the output cables from the amplifier outputs;...

  • Page 14: Technical Specs

    35 Ah *Power at 12.6V @ 60Hz following the ANSI / CTA-2006B standard with a maximum THD of 1% DIMENSIONS 5" (128mm) 4.2" (106mm) 400.2D EVO / 400.4D EVO / 400.4S EVO 5.6" (143mm) Weight: 400.2D EVO :1.5lbs(0.7kg) 400.4D EVO :1.5lbs(0.7kg)
  • Page 15 60 Ah 60 Ah *Power at 12.6V @ 60Hz following the ANSI / CTA-2006B standard with a maximum THD of 1% DIMENSIONS 8.4" (213mm) 400.2D EVO / 400.4D EVO / 400.4S EVO 6.9" (176mm) 7.8" (198mm) Weight 800.4D EVO :2.5lbs (1.1kg)
  • Page 16 TECHNICAL SPECS PARAMETER 400.4S EVO 800.4S EVO 2Ω 800.4S EVO 4Ω Bridge RMS Power @ 8Ω* 2 x 110W 2 x 120W 2 x 220W Bridge RMS Power @ 4Ω* 2 x 200W 2 x 220W 2 x 400W Bridge RMS Power @ 2Ω* 2 x 400W RMS Power per channel @ 4Ω* 4 x 55W...

  • Page 17: Limited Warranty

    LIMITED WARRANTY SounDigital warrants the original purchaser that this product shall be free of defects in materials an workmanship for a period of twelve (12) months from the original date of purchase. Some countries have extended warranty in case the product is installed by an authorized dealer.
