Summarization of Contents
About This Manual
Product Support
Information on how to contact Fike for assistance with the Cheetah Xi system.
Safety Information
Details important warnings and cautions for safe operation and equipment protection.
Related Documentation
Lists other Fike documents providing comprehensive system understanding.
Revision History
Tracks changes and updates made to the programming manual across revisions.
C-Linx Programming Options
Understanding Cheetah Xi
Provides an overview of the Cheetah Xi system's configuration capabilities and software.
Software Programming Features
Details configurable features available through the C-Linx programming software.
Getting Started
User Interface
Explains the Cheetah Xi control panel keypad, display, and navigation keys.
Password Protection
Describes the password system for accessing and controlling panel features.
Configuring the System
Outlines the two primary methods for system configuration: Autoprogram and Engineered Configure.
Addressing Devices
Details various methods for assigning unique addresses to field devices.
Configuration Menu
Configuration Menu 1
Accesses device, NAC, SLC, and Learn functions for system configuration.
Configure Field Device
Modifies operational parameters for addressable devices connected to SLCs.
Modify Panel NAC Circuits
Programs the panel's on-board notification appliance circuits (NAC #1 and NAC #2).
Change SLC Supervision
Adjusts supervision options for available signaling line circuits.
Execute Learn Function
Identifies and adds installed addressable devices to the panel's supervision list.
Configuration Menu 2
Accesses settings for system time, silence, power, and sensitivity.
Daytime Sensitivity Settings
Configures separate alarm thresholds for daytime and non-operational hours.
Configuration Menu 3
Accesses settings for peripheral devices, walktest, ground fault, and abort types.
Peripheral Device Parameters
Modifies operating parameters for the panel's peripheral devices.
Ground Fault Detection
Controls the panel's detection of ground faults at two levels.
Configuration Menu 4
Accesses settings for AC trouble delay, VESDA, auxiliary power, relays, and power cutoff.
Configure VESDA Detectors
Changes operating parameters for connected air sampling detectors.
Configure Auxiliary Power Circuits as Aux/NACs
Configures auxiliary power circuits to function as notification appliance circuits.
Configure Panel Relays and Optional Modules
Changes programming for on-board relays and optional modules.
Configuration Menu 5
Accesses settings for panel logo, auto addressing, dialer tests, and network configuration.
Auto Address Devices
Assigns addresses to new, unprogrammed addressable devices on the SLC.
Configure Panel Network
Provides configuration options for the Cheetah Xi's network module.
Configuration Menu 6
Accesses settings for IP addresses, network supervision, IP time, and panel operations.
Set Panel IP Addresses
Sets IP address configuration parameters for the panel's Ethernet module.
Configure Panel for Network Supervision
Configures the panel to supervise other fire panels on the same Ethernet network.
Configuration Menu 7
Accesses settings for AHU key requirement feature.
Enable AHU Key Requirement Feature
Sets parameters to require an AHU FIRE KEY input for fan restart initiation.
Appendix A
Cheetah Xi Menu Structure (V6.40)
Provides a detailed hierarchical overview of the Cheetah Xi system's menu structure.
