Summarization of Contents
2. GENERAL
2.1. PARAMETERS
Configuration settings for general module behavior, including alive beacon and button functions.
2.2. OBJECTS
Defines communication objects related to general module status and control.
3. LOGIC GATE
3.1. PARAMETERS
Parameters for configuring logic gate type, inputs, feedback, and delays for AND, OR, XOR operations.
3.2. OBJECTS
Communication objects used for inputting values and reading logic gate outputs.
4. CONVERTER
4.1. PARAMETERS
Parameters for setting up converter gates, input/output data types, and value conversion.
4.2. OBJECTS
Communication objects for sending values to converter inputs and reading converter outputs.
5. FUNCTIONS
5.1. LIGHTING
Functionality for controlling lighting circuits, including time delays, staircase functions, and scenes.
5.2. HEATING
Configuration options for controlling heating systems, including valve operation, modes, and forced positions.
5.3. SHUTTER/BLIND
Control features for shutters and blinds, including movement, slat positioning, alarms, and locking.
5.4. SHUTTER/BLIND 24V
Specific application description for 24V shutter/blind control, highlighting output differences.
5.5. FAN COILS
Control functions for fan coil units, covering fan operation, delays, modes, and disabling.
