Summarization of Contents
Air Filters / Front Panel
Remove the air filters
Procedure for removing air filters, noting interchangeability and reassembly guides.
Remove the front panel
Steps to remove the front panel, including opening it fully and releasing shafts.
Horizontal Blades / Vertical Blade ASSYS
Remove the horizontal blades
Detailed steps to remove horizontal blades, including shaft manipulation and reassembly guidance.
Remove the vertical blade ASSYS
Procedure for removing vertical blade assemblies, noting fin count and interchangeability.
Electrical Box / PCBs / Swing Motor
Remove the electrical box
Steps for removing the electrical box, including screws, wires, and fixtures.
Remove the PCBs
Procedure to remove PCBs, involving shield plates, hooks, and electrical box covers.
Remove the swing motor
Steps to detach and remove the swing motor, including screw and connector disconnection.
