UNIVERSAL - QUICK/DISCONNECT
COMPRESSION GAUGE SET
Visit our Web site at: http://www.harborfreight.com
©
Copyright
2006 by Harbor Freight Tools
herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools.
For technical questions, please call 1-800-444-3353.
Pressure Gauge
Pressure Gauge
Scale
Pressure Gauge
Hose
Hose Adapters
Net Weight
You will need this instruction sheet for the safety warnings and precautions, assembly, operat-
ing, parts list and assembly diagram. Keep your invoice with this instruction sheet. Write the
invoice number on the front cover. Keep this instruction sheet and invoice in a safe and dry
place for future reference.
When unpacking, check to make sure all the parts shown on the Assembly Diagram are
included. If any parts are missing or broken, please call Harbor Freight Tools at the number
shown on the front cover of this instruction sheet as soon as possible.
SAFETY WARNINGS AND PRECAUTIONS
Use the Compression Kit only in well ventilated areas. A running engine
1.
produces carbon monoxide. Carbon monoxide is a colorless, odorless
gas that, when inhaled, can cause serious injury or death.
Model 95187
3491 Mission Oaks Blvd., Camarillo, CA 93011
TO PREVENT SERIOUS INJURY, READ
AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
®
. All rights reserved. No portion of this instruction sheet or any artwork contained
SPECIFICATIONS
3" Diameter x 1-1/8" Deep with Push Button Air Release Valve
0<->300 PSI (In 10 PSI Increments)
0<->2000 kPa (In 100 kPa Increments)
26" L x 3/16" I.D. x 15/32" O.D.
Maximum working pressure 500 PSI
Long Reach: 10-1/2" Long x M12 x 1.25 / 500 PSI Working Pressure
Standard Reach: 10-1/2" Long x M14 x 1.25 / 500 PSI Working Pressure
Standard Reach: 10-1/2" Long x M10 x 1.00 / 500 PSI Working Pressure
2.8 Pounds
SAVE THIS INSTRUCTION SHEET
UNPACKING
®
®
Rev 11/06
