12 VOLT MagneTic
LeD TOwing LighT kiT
SeT up anD OperaTing inSTrucTiOnS
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
read this material before using this product.
Failure to do so can result in serious injury.
SaVe ThiS ManuaL.
Copyright
this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
Distributed exclusively by harbor Freight Tools
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
©
2008 by Harbor Freight Tools
66186
®
. All rights reserved. No portion of
®
.
Advertisement
Table of Contents
Related Manuals for HAUL MASTER 66186
Summary of Contents for HAUL MASTER 66186
- Page 1 12 VOLT MagneTic LeD TOwing LighT kiT Model 66186 SeT up anD OperaTing inSTrucTiOnS Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. ® Distributed exclusively by harbor Freight Tools 3491 Mission Oaks Blvd., Camarillo, CA 93011...
- Page 2 Obey D.O.T. (Department of Transportation) and all other applicable regulations regarding installation and use. Attach lights to vehicle before moving. Loose lights are a traffic hazard. Thoroughly test vehicle lights and tow lights for attachment and operation before use. For technical questions, please call 1-800-444-3353. SKU 66186 Page 2...
- Page 3 When unpacking, check to make sure that the item is intact and undamaged. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. For technical questions, please call 1-800-444-3353. SKU 66186 Page 3...
- Page 4 Make sure both wires stay properly in place while the cover is closed until it snaps together. Verify that all wires are held se- B) place splice around curely. vehicle wire For technical questions, please call 1-800-444-3353. SKU 66186 Page 4...
- Page 5 After towing, disconnect “Trailer” Connector, remove tow lights from towed ve- hicle, clean with a moist cloth, and store in dry location out of reach of children. For technical questions, please call 1-800-444-3353. SKU 66186 Page 5...
- Page 6 Threaded Shaft Left-Right Cord Shell Bulb Wire Spring Washer Wires Splices Flat Washer Wiring Pigtail Ground Terminal “Trunk” 4-Way Flat Connector Protective Label Screw Screw (M3 x 16) Cover Nut (M3) For technical questions, please call 1-800-444-3353. SKU 66186 Page 6...
- Page 7 HER INSTALLATION OF REPLACEMENT PARTS THERETO. record product’s Serial number here: note: If product has no serial number, record month and year of purchase instead. note: No replacement parts are available for this product. For technical questions, please call 1-800-444-3353. SKU 66186 Page 7...
