Summary of Contents for FARMA BC25
- Page 1 Energy Cutter BC18 BC25 EN_V1.3-2018W02 Original instruction INSTRUCTION BOOK...
-
Page 2: Table Of Contents
ENERGY CUTTER BC18/BC25 Original instruction ........................... 3 INTRODUCTION ........................4 1. SAFETY REGULATIONS ..........................7 2. SAFETY DEVICES ........................11 3. GENERAL DESCRIPTION ....................... 12 4. TECHNICAL SPECIFICATION ........................13 5. DIMENSIONAL DIAGRAM ..........................16 6. INSTALLATION ........................24 8. SERVICE /MAINTENANCE .................. -
Page 3: Introduction
The FARMA Energy cutter is a combined grapple and felling head that is often used for clearing energy wood. It is simple to i stall, a d epla es the g apple loade ’s egula g apple tool. The FARMA E e g utte is recommended for FARMA cranes from size C 4.6 upwards. -
Page 4: Safety Regulations
Original instruction 1. SAFETY REGULATIONS We understand your desire to get started with your FARMA Energy cutter as quickly as possible. In order to avoid unwanted operational stoppages or, in the worst case scenario, hazardous situations, please acquaint yourself first with the machine's functions and its safety instructions. - Page 5 ENERGY CUTTER BC18/BC25 Original instruction Forbidden to raise or lower the cutter before the log is cut off! It is important that you adjust the speed as you approach the log and will clamp around the tree. Approach always the material to be cut so that the felling head is at 90 degree angle to the log.
- Page 6 ENERGY CUTTER BC18/BC25 Original instruction It is absolutely prohibited to stand under a raised machine! Note: To reduce the risk of injuries, always keep the cutter's grapple arms outside of the blade when the cutter is not in operation. See figure below.
-
Page 7: Safety Devices
ENERGY CUTTER BC18/BC25 Original instruction 2. SAFETY DEVICES 2.1 Position of labels BC18 for cranes position of labels: BC18 for excavators position of labels: AS Fors MW EN_V1.3-2018W02/Instruction book www.forsmw.com... - Page 8 ENERGY CUTTER BC18/BC25 Original instruction BC25 position of labels: AS Fors MW EN_V1.3-2018W02/Instruction book www.forsmw.com...
- Page 9 ENERGY CUTTER BC18/BC25 Original instruction 2.2 Presentation of labels WARNING! Warning triangle and instruction manual label. The cutter is supplied with a warning triangle alongside the instruction manual decal in order to reinforce the requirement for the user to read the entire instruction manual carefully before starting to use the cutter.
- Page 10 ENERGY CUTTER BC18/BC25 Original instruction INFORMATION Lubrication This decal is used to show the importance of regular lubrication of the cutter. INFORMATION Data plate of energy cutter AS Fors MW EN_V1.3-2018W02/Instruction book www.forsmw.com...
-
Page 11: General Description
(diameter 49 or 59 mm) directly on the rotator shaft in the same way as a normal grapple. It is possible to flange the rotator directly onto the BC18, without a flange plate. Tilt cylinder Cutting blade This is illustrative photo to describe cutter components... -
Page 12: Technical Specification
* The maximum cutting diameter ultimately depends on the choice of tree species. ** Can be used at 25 l/min, although operation becomes slow. *** BC18 for cranes **** This model is supplied with a replaceable rotator mount. Bear in mind that there are many aspects that can influence the potential to cut a tree of 18/25 cm, these include the tree species, moisture, and ambient temperature and whether the tree is frozen. -
Page 13: Dimensional Diagram
ENERGY CUTTER BC18/BC25 Original instruction 5. DIMENSIONAL DIAGRAM Dimensionf of BC 18 for cranes: Dimensions of BC18 for excavators: Measure S30/180 340 mm 340 mm 340 mm 185 mm 200 mm 295 mm 660 mm 660 mm 660 mm 985 mm... - Page 14 ENERGY CUTTER BC18/BC25 Original instruction Blank BC25: Dimensions of BC25 for excavators: Measure S30/180 455 mm 455 mm 455 mm 200 mm 293 mm 182 mm 890 mm 890 mm 890 mm 1087 mm 1114 mm 1087 mm 1216 mm...
- Page 15 ENERGY CUTTER BC18/BC25 Original instruction MS03 Measure MM10/MH10 MS08 455 mm 455 mm 455 mm 205 mm 205 mm 295 mm 890 mm 890 mm 890 mm 1087 mm 1087 mm 1110 mm 1216 mm 1216 mm 1239 mm 537 mm...
-
Page 16: Installation
ENERGY CUTTER BC18/BC25 Original instruction 6. INSTALLATION Installing the cutter unit by the loading arms/boom The cutter is installed on the rotator via the journal/shaft. No separate hydraulic hoses or electrical cables are required here for use. The cutter is connected directly in place of the grapple claw. - Page 17 ENERGY CUTTER BC18/BC25 Original instruction Hydraulic scheme BC18 AS Fors MW EN_V1.3-2018W02/Instruction book www.forsmw.com...
- Page 18 ENERGY CUTTER BC18/BC25 Original instruction Main parts of hydraulic scheme BC18 (FMWH00005): Pos. No Description QTY. Valveblock Relief valve A gle ipple 0° T-nipple Straight nipple Rubber seal Hose Hose Hose Hose Hose Cartridge nipple AS Fors MW EN_V1.3-2018W02/Instruction book...
- Page 19 ENERGY CUTTER BC18/BC25 Original instruction Hydraulic scheme BC25 AS Fors MW EN_V1.3-2018W02/Instruction book www.forsmw.com...
- Page 20 ENERGY CUTTER BC18/BC25 Original instruction Main parts of hydraulic scheme BC25 (FMWH00042): Pos. No Description QTY. Bayonet coupling Dust cover Rubber bonded seal T-nipple Hose Hose Hose AS Fors MW EN_V1.3-2018W02/Instruction book www.forsmw.com...
- Page 21 Operating a cutter requires knowledge about the machine you are using. It is important for you to a ui e k o ledge a d to t ai ith ega d to the utte ’s eha iou . FARMA e e g utte s may only be used by individuals who possess knowledge about the product.
- Page 22 ENERGY CUTTER BC18/BC25 Original instruction Working in extreme conditions The recommended ambient working temperature for this machine is -20°C to + 0°C. Note that when working in low or high temperatures, the level of wear and stress on seals and hoses increases.
- Page 23 ENERGY CUTTER BC18/BC25 Original instruction BC18 BC25 AS Fors MW EN_V1.3-2018W02/Instruction book www.forsmw.com...
-
Page 24: Service /Maintenance
ENERGY CUTTER BC18/BC25 Original instruction 8. SERVICE /MAINTENANCE General information Service and maintenance must be carried out regularly in order to guarantee problem-free, economical use. Note: Failu e to o pl ith the Fo s WM i st u tio a ual i alidates all the a hi e’s... -
Page 25: Daily Maintenance
ENERGY CUTTER BC18/BC25 Original instruction Store explosive and flammable liquids at a safe distance from sparks or open flames. Note: When changing oil, collect the oil in a safe manner. Never release oil onto the ground. This is prohibited by law. Oil and grease must by law also be disposed of at an authorised location. - Page 26 ENERGY CUTTER BC18/BC25 Original instruction The law demands that all waste oil be dealt with and disposed of at the correct place during service and maintenance. For recommended lubricating greases, see Requirements and test methods SS 15 54 70 http://www.sp.se/km/grease Surface cleaning Remove accumulated dirt and dust.
- Page 27 ENERGY CUTTER BC18/BC25 Original instruction Fluid for the hydraulic system Mineral-based hydraulic fluid and various environmental oils are recommended when using the cutter. The fluid must not contain water. If the temperature of the hydraulic fluid is high, this causes the machine's seals to become worn earlier than normal.
- Page 28 If you want to use BC18 as a grapple, the tilt has to be locked. This is done in the tilted down position. Begin by closing the grapple so that it tilts down, undo the locking nut (1) and then screw in the adjustment screw (2) 3–4 turns.
- Page 29 ENERGY CUTTER BC18/BC25 Original instruction Lubrication schedule BC18 When the machine is used regularly, although under normal working conditions, all grease nipples must be lubricated every 20 hours of operation. In the case of significant loads, the lubrication interval is reduced.
- Page 30 ENERGY CUTTER BC18/BC25 Original instruction Lubrication schedule BC25 AS Fors MW EN_V1.3-2018W02/Instruction book www.forsmw.com...
-
Page 31: Ec Declaration Of Conformity (Sample)
Type: FC variant: BC18/ BC25 Serial no.: FCBC18xx2xxxxx/FCBC25xx1xxxxx Trade name: FARMA BC18/ BC25 Energy cutter Manufacture year: xxxx is manufactured accordingly to demands in directive 2006/42/EC and therefore can be used mounted together with other equipment to provide a complete machine.
