U.S. General 2575 Assembly And Operation Instructions Manual

A-tongue trailer 1,350 lb. maximum capacity payload

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

1,350 LB. MAXIMUM CAPACITY PAYLOAD

AssEMBLY AND OPERATION INsTRUCTIONs

Diagrams within this manual may not be drawn proportionally.

Due to continuing improvements, actual product may differ slightly from the product described herein.

Distributed exclusively by Harbor Freight Tools

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.

sAVE THIs MANUAL.

2003 by Harbor Freight Tools

manual or any artwork contained herein may be reproduced in any shape or form

without the express written consent of Harbor Freight Tools.

For technical questions or replacement parts, please call 1-800-444-3353.

A-TONGUE TRAILER

Model

3491 Mission Oaks Blvd., Camarillo, CA 93011

Manual Revised 04j, 07f, 09b

02575

IMPORTANT INFORMATION

This trailer's Hitch Coupler MUST be

properly secured to the hitch ball of the towing

vehicle. After assembly and attachment, pull

up and down on the Hitch Coupler to make

sure the hitch ball is fitting snugly in the Hitch

Coupler. There must be no play between the

hitch ball and Hitch Coupler. If there is play,

tighten the Adjustment Nut until no play is

present. If the Adjustment Nut is too tight, the

Handle will not lock. Carefully read and follow

the complete instructions in this manual

BEFORE setup or use.

If the Coupler is not secured

properly, the ball could come loose

while the trailer is in motion, possibly

causing property damage, SERIOUS

PERSONAL INJURY, or DEATH.

WARNING!

Table of Contents

Need help?

Do you have a question about the 2575 and is the answer not in the manual?

Questions and answers

Summary of Contents for U.S. General 2575

Page 1 ® A-TONGUE TRAILER 1,350 LB. MAXIMUM CAPACITY PAYLOAD Model 02575 AssEMBLY AND OPERATION INsTRUCTIONs WARNING! IMPORTANT INFORMATION This trailer’s Hitch Coupler MUST be properly secured to the hitch ball of the towing vehicle. After assembly and attachment, pull up and down on the Hitch Coupler to make sure the hitch ball is fitting snugly in the Hitch Coupler.
Page 2: Table Of Contents
CONTENTs sPECIFICATIONs ..................3 GENERAL sAFETY WARNINGs AND PRECAUTIONs ......3 sPECIFIC PRODUCT WARNINGs AND PRECAUTIONs ..... 4 UNPACKING .................... 5 AssEMBLY INsTRUCTIONs ..............6 To Assemble the Tires, Wheels, and Axle:............6 To Assemble the Frame and Tongue: ..............7 To Attach the springs, Tires, Wheels, and Axle to the Frame: ......8 To Attach the Fenders: ..................10 To Attach the side Running Lights: ..............10 To Attach the Tail Light Bracket and License Plate Bracket: ......10...
Page 3: Specifications
sPECIFICATIONs Maximum Payload Capacity 1,350 Lbs. Bed Size 40” x 50” Overall Dimensions 87-1/2” L x 52-3/4” W x 22-3/4” H Tire Size & Type 4.80 x 12”, 4 Ply, Tubeless Tongue Level Height 14” From Ground Ball Coupler Size 1-7/8”...
Page 4: Specific Product Warnings And Precautions
sTAY ALERT. Watch what you are doing at all times. Use common sense. Do not use this product when you are tired or distracted from the job at hand. CHECK FOR DAMAGED PARTs. Before using this product, carefully check that it will operate properly and perform its intended function.
Page 5: Unpacking
ALWAYs CHECK TO MAKE sURE THE PAYLOAD BEING TRANsPORTED Is PROPERLY AND sAFELY sECURED ON THE TRAILER. Load the Trailer evenly from side to side with 60% of the load forward of the Axle (19). MAKE sURE THE TOWING VEHICLE Is CAPABLE OF TOWING THE TRAILER AND ITs PAYLOAD.
Page 6: Assembly Instructions
AssEMBLY INsTRUCTIONs Note: For additional references to the parts listed below, refer to the Assembly Diagrams near the end of this manual. To Assemble the Tires, Wheels, and Axle: Insert one Hub (20) fully onto each end of the Axle (19). BEARING PACKING INsTRUCTIONs: Read the following instructions;...
Page 7: To Assemble The Frame And Tongue
To Assemble the Frame and Tongue: Position the Right Side Rail (1R) and Left Side Rail (1L) parallel and aligned with one another. (see Figure A.) Align the mounting hole located at each end of a Cross Member (2) with the mount- ing hole located in one end of the Right Side Rail (1R) and one end of the Left Side Rail (1L).
Page 8: To Attach The Springs, Tires, Wheels, And Axle To The Frame
Align the mounting hole located at each end of the Rear Cross Member (3) with the mounting hole located in the end of the Right Side Rail (1R) and the end of the Left Side Rail (1L). On each end insert one 3/8” x 7/8” Carriage Bolt (A) upward from the underside of the aligned mounting holes, and secure the Rear Cross Member to the Right Side Rail and Left Side Rail with one Washer (C) and one Nut (B).
Page 9 Align the two mounting holes in a Rear Spring Hanger (15R) with the two mounting holes located in the rear section of the Left Side Rail (1L). Insert two 3/8” x 7/8” Carriage Bolts (A) upward from the underside of the aligned mounting holes, and secure the Rear Spring Hanger to the Left Side Rail with two Washers (C) and two Nuts (B).
Page 10: To Attach The Fenders
To Attach the Fenders: Align the two mounting holes in a Fender (13) with the two mounting holes located in the side, mid-section of the Left Side Rail (1L). Then secure the Fender to the Left Side Rail with two Bolts (A), two Washers (C), and two Nuts (B). Align the two mounting holes in the remaining Fender (13) with the two mounting holes located in the side, mid-section of the Right Side Rail (1R).
Page 11: To Attach The Trailer Beds
FIGURE B BOTTOM VIEW LEFT TAIL LIGHT (25L) LEFT sIDE RAIL (1L) LEFT CONNECTING RAIL (7) WIRING HARNEss RIGHT CONNECTING RAIL (8) UsE HEAVY GAUGE, NYLON, TIE sTRIPs (NOT INCLUDED) TO ATTACH WIRING HARNEss TO UNDERsIDE OF FRAME. RIGHT sIDE RAIL (1R) RIGHT TAIL LIGHT (25R) Use heavy gauge, nylon, tie strips (not included) to attach the wiring harnesses of the Left and Right Tail Lights (25L, 25R) to the underside of the Frame and Tongue...
Page 12: Operating Instructions
“R” PIN (L) TRIGGER COUPLER (12) HANDLE sAFETY PIN (K) ADJUsTMENT NUT 1-7/8” HITCH BALL (NOT INCLUDED) VEHICLE HITCH FIGURE C (NOT INCLUDED) nut in place) needs to be pressed back OPERATING INsTRUCTIONs while the Nut is tightened. After Nut is CAUTION tightened, the retaining plate needs Care must be taken when backing up...
Page 13: Tire Information
TIRE INFORMATION Tire Terminology Glossary • Accessory weight means - the combined weight of automatic transmission, power steering, power brakes, power windows, power seats, radio, and heater, to the extent that these items are available as factory-installed equipment. • Carcass means - the tire structure except for the tread which provides the major portion of the tire’s capability to deflect in response to the vertical loads and tractive forces that the tire transmits from the roadway to the non-pneumatic rim, the wheel center member, or the vehicle and which attaches to the...
Page 14: Tire Markings
Tire Markings Inner diameter Load index and in inches speed rating* European tire section width certificate* in inches U.s. DOT tire identification number Tire ply composition and materials used Maximum permissible inflation pressure Maximum load rating Trailer *Information not required by U.s. DOT tire •...
Page 15: Tire Inflation And Load Limit
• speed Rating- The speed rating denotes the speed at which a tire is designed to be driven for ex- tended periods of time. This does not indicate that the Tire speed Rating Codes vehicle or rims can safely reach or maintain that speed. Code MPH Code MPH Code MPH...
Page 16: Tire Care
TIRE CARE Checking Tire Pressure Note: Underinflated tires can decrease handling, stopping performance, traction, tire life, and load-carrying capability, in addition to causing other negative and hazardous effects, including tire failure. Overinflated tires are at greater risk of an impact break, where the tread and casing break when striking a hard edge, often opening a huge gash across the tread.
Page 17: Tire Size
Check all the tires to make sure they have the same air pressure. If the tires’ pressure was not measured “cold”, then the pressure should be rechecked with the tires cold as soon as possible. Tire size To maintain safety, only purchase new tires of the same size as the original tires. Look at the Tire and Loading Information Placard, the Specifications Chart in this manual, or the sidewall of the tire being replaced.
Page 18: Vehicle Load Limit
VEHICLE LOAD LIMIT steps for Determining Correct Load Limit Locate the statement “The weight of cargo should never exceed XXX kilograms or XXX pounds” on your vehicle’s placard. That figure equals the available amount of cargo and luggage load capacity. Determine the combined weight of luggage and cargo being loaded on the vehicle.
Page 19: Parts List And Diagrams
PLEAsE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
Page 20: Assembly Diagram A
Assembly Diagram A N, B For technical questions, please call 1-800-444-3353. SKU 02575 Page 20...
Page 21: Assembly Diagram B
Assembly Diagram B TRAILER BED (X) BOLT WAsHER (C) NUT (B) For technical questions, please call 1-800-444-3353. SKU 02575 Page 21...
Page 22: Wiring Diagram For Lights
Wiring Diagram for Lights Note: Some trailer tail lights will have two leads instead of three. They connect to the harness leads the same way; brown to brown, color to color. REV 03d, 06e For technical questions, please call 1-800-444-3353. SKU 02575 Page 22...
Page 23: Limited 90 Day Warranty
LIMITED 90 DAY WARRANTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
