Xtant A1544A - TECHNICAL DATA REPORT Technical Data page 2

A1544A Technical Data Report
Xtant A Series 15" dual 4 Ohm Subwoofer
SEALED ENCLOSURE
Enclosure Volume 1.50 Ft³ (42.5 l)
F3
45 Hz
Ripple 3.04dB
Qtc 1.59
Net Volume
1.40 Ft³ (39.6 l)
Driver Volume
.10 Ft³ (2.9 l)
Excursion Limited SPL 118dB
Excursion Limited Power
300 Watts
VENTED ENCLOSURE
Enclosure Volume
2.75 Ft³ (77.9 l)
Vent Dimensions
(2)4"x16"
F3 42 Hz
Tuning Frequency
37 Hz
Ripple
4.89dB
Net Volume
2.40 Ft³ (67.9 l)
Driver Volume
.10 Ft³ (2.9 l)
Vent Volume
.25 Ft³ (7.1 l)
Excursion Limited SPL 120dB
Excursion Limited Power
300 Watts
BANDPASS ENCLOSURE (S - 0.4)
Enclosure Volume
2.69 Ft³ (76.2 l)
Bandpass 53 - 124
Bandpass Gain 7.8dB
Vent Dimensions
(4)4"x6"
Tuning Frequency 81 Hz
Ripple 2.48dB
Sealed Volume
.70 Ft³ (19.8 l)
Vented Volume
1.71 Ft³ (48.6 l)
Driver Volume .10 Ft³ (2.9 l)
Vent Volume
.17 Ft³ (4.9 l)
Excursion Limited SPL 122dB
Excursion Limited Power 300 Watts
BANDPASS ENCLOSURE (S - 0.5)
Enclosure Volume
3.70 Ft³ (104.8 l)
Bandpass 52 - 107
Bandpass Gain 9.8dB
Vent Dimensions
(4)4"x3"
Tuning Frequency 75 Hz
Ripple 1.37dB
Sealed Volume
.85 Ft³ (24.1 l)
Vented Volume
2.68 Ft³ (75.9 l)
Driver Volume .10 Ft³ (2.9 l)
Vent Volume
.07 Ft³ (2.1 l)
Excursion Limited SPL 123dB
Excursion Limited Power 300 Watts
XTANT A Series Woofers purchased in the United States from an authorized XTANT dealer are guaranteed against defects in material and workmanship for a period of ONE YEAR, if consumer installed, from the date purchased by the end user, and limited to the original retail purchaser of the product. Product
found to be defective during that period will be repaired or replaced by XTANT at no charge. This warranty is void if it is determined that unauthorized parties have attempted repairs or alterations of any nature. Warranty does not extend to cosmetics or finish. Before presuming a defect is present in the product,
be certain that all related equipment and wiring is functioning properly. XTANT disclaims any liability for other incurred damages resulting from product defects. Any expenses incurred in the removal and reinstallation of products are not covered by this warranty. XTANT's total liability will not exceed the purchase
price of the product. If a defect is present, your authorized XTANT dealer may be able to effect repairs. Proof of purchase is required when requesting service, so please retain your sales receipt and take a moment to register your warranty on line @ xtant.com.
Sealed and Vented Frequency Response
100
97
3 FT³ Vented
94
91
2 FT³ Sealed
88
85
82
79
76
73
70
10 20
1.75 Ft³ (49.6 l) 2.00 Ft³ (56.6 l) 2.25 Ft³
42 Hz 41 Hz
3.02dB 2.96dB
1.49 1.42
1.65 Ft³ (46.7 l) 1.90 Ft³ (53.8 l)
.10 Ft³ (2.9 l) .10 Ft³ (2.9 l)
118dB 117dB
300 Watts 300 Watts
3.00 Ft³ (85.0 l) 3.25 Ft³ (92.0 l) 3.50 Ft³
(2)4"x15.5" (2)4"x14.75"
38 Hz 38 Hz
36 Hz 35 Hz
4.96dB 5.02dB
2.66 Ft³ (75.2 l) 2.92 Ft³ (82.7 l)
.10 Ft³ (2.9 l) .10 Ft³ (2.9 l)
.24 Ft³ (6.9 l) .23 Ft³ (6.5 l)
120dB 120dB
300 Watts 300 Watts
2.86 Ft³ (81.0 l) 3.09 Ft³ (87.5 l) 3.39 Ft³
47 - 119 42 - 114
6.7dB 5.5dB
(4)4"x7.75" (4)4"x9.75"
76 Hz 71 Hz
2.58dB 2.68dB
.82 Ft³ (23.2 l) .97 Ft³ (27.6 l)
1.71 Ft³ (48.6 l) 1.71 Ft³ (48.6 l)
.10 Ft³ (2.9 l) .10 Ft³ (2.9 l)
.23 Ft³ (6.5 l) .30 Ft³ (8.4 l)
121dB 120dB
300 Watts 300 Watts
3.90 Ft³ (110.4 l) 4.16 Ft³ (117.8 l) 4.53 Ft³
46 - 103 43 - 98
8.7dB 7.5dB
(4)4"x4.25" (4)4"x6"
70 Hz 65 Hz
1.44dB 1.50dB
1.00 Ft³ (28.4 l) 1.21 Ft³ (34.2 l)
2.68 Ft³ (75.9 l) 2.68 Ft³ (75.9 l) 2.68 Ft³
.10 Ft³ (2.9 l) .10 Ft³ (2.9 l)
.11 Ft³ (3.3 l) .17 Ft³ (4.9 l)
122dB 121dB
300 Watts 300 Watts
30 40 50 60 70 80 90
Frequency (Hz)
(63.7 l) 2.50 Ft³ (70.8 l) Volumen del gabinete - Volume de l'enceinte - Gehäusevolumen
39 Hz 36 Hz F3
2.87dB 2.79dB
Ondulación - Ondulation - Welligkeit
1.36 1.31 Qtc
2.15 Ft³ (60.9 l) 2.40 Ft³ (67.9 l) Volumen neto - Volume net - Nettovolumen
.10 Ft³ (2.9 l) .10 Ft³ (2.9 l) Volumen del altavoz - Volume de l'étage d'attaque - Subwoofervolumen
117dB 117dB Nivel de presión sonora de excursión limitada - Niveau de pression acoustique limitée par la course - Auslenkungsbegrenzter Schallpegel
300 Watts 300 Watts Potencia de excursión limitada - Puissance limitée par la course - Auslenkungsbegrenzte Leistung
(99.1 l) 3.75 Ft³ (106.2 l) Volumen del gabinete - Volume de l'enceinte - Gehäusevolumen
(2)4"x14.25" (2)4"x13.75" Dimensiones de las aberturas de ventilación - Dimensions de l'enceinte - Entlüftungsabmessungen
36 Hz 33 Hz
F3
34 Hz 33 Hz Frecuencia de sintonización - Fréquence d'accord - Resonanzfrequenz
5.03dB 5.03dB Ondulación - Ondulation - Welligkeit
3.18 Ft³ (90.0 l) 3.44 Ft³ (97.3 l) Volumen neto - Volume net - Nettovolumen
.10 Ft³ (2.9 l) .10 Ft³ (2.9 l) Volumen del altavoz - Volume de l'étage d'attaque - Subwoofervolumen
.22 Ft³ (6.3 l) .21 Ft³ (6.0 l) Volumen de las aberturas de ventilación - Volume d'aération - Entlüftungsvolumen
120dB 120dB
Nivel de presión sonora de excursión limitada - Niveau de pression acoustique limitée par la course - Auslenkungsbegrenzter Schallpegel
300 Watts 300 Watts Potencia de excursión limitada - Puissance limitée par la course - Auslenkungsbegrenzte Leistung
(96.0 l) 3.59 Ft³ (101.7 l) Volumen del gabinete - Volume de l'enceinte - Gehäusevolumen
37 - 110 32 - 105
Paso de banda - Bande passante - Bandpass
4.2dB 2.7dB Amplificación del paso de banda - Gain de bande passante - Bandpassverstärkung
(4)4"x12.5" (3)4"x11.5" Dimensiones de las aberturas de ventilación - Dimensions de l'enceinte - Entlüftungsabmessungen
65 Hz 60 Hz
Frecuencia de sintonización - Fréquence d'accord - Resonanzfrequenz
2.78dB 2.88dB Ondulación - Ondulation - Welligkeit
1.19 Ft³ (33.8 l) 1.51 Ft³ (42.8 l) Volumen sellado - Volume hermétique - Geschlossenes Volumen
1.71 Ft³ (48.6 l) 1.71 Ft³ (48.6 l) Volumen ventilado - Volume aéré - Ventiliertes Volumen
.10 Ft³ (2.9 l) .10 Ft³ (2.9 l) Volumen del altavoz - Volume de l'étage d'attaque - Subwoofervolumen
.39 Ft³ (10.9 l) .26 Ft³ (7.5 l) Volumen de las aberturas de ventilación - Volume d'aération - Entlüftungsvolumen
119dB 118dB
Nivel de presión sonora de excursión limitada - Niveau de pression acoustique limitée par la course - Auslenkungsbegrenzter Schallpegel
300 Watts 300 Watts Potencia de excursión limitada - Puissance limitée par la course - Auslenkungsbegrenzte Leistung
(128.3 l) 5.07 Ft³ (143.6 l) Volumen del gabinete - Volume de l'enceinte - Gehäusevolumen
38 - 93 32 - 88
Paso de banda - Bande passante - Bandpass
6.2dB 4.6dB Amplificación del paso de banda - Gain de bande passante - Bandpassverstärkung
(4)4"x8.25" (4)4"x11" Dimensiones de las aberturas de ventilación - Dimensions de l'enceinte - Entlüftungsabmessungen
60 Hz 54 Hz
Frecuencia de sintonización - Fréquence d'accord - Resonanzfrequenz
1.58dB 1.66dB Ondulación - Ondulation - Welligkeit
1.50 Ft³ (42.5 l) 1.95 Ft³ (55.3 l) Volumen sellado - Volume hermétique - Geschlossenes Volumen
(75.9 l) 2.68 Ft³ (75.9 l) Volumen ventilado - Volume aéré - Ventiliertes Volumen
.10 Ft³ (2.9 l) .10 Ft³ (2.9 l) Volumen del altavoz - Volume de l'étage d'attaque - Subwoofervolumen
.25 Ft³ (7.0 l) .34 Ft³ (9.5 l) Volumen de las aberturas de ventilación - Volume d'aération - Entlüftungsvolumen
120dB 118dB
Nivel de presión sonora de excursión limitada - Niveau de pression acoustique limitée par la course - Auslenkungsbegrenzter Schallpegel
300 Watts 300 Watts Potencia de excursión limitada - Puissance limitée par la course - Auslenkungsbegrenzte Leistung
One Year Limited Warranty
Bandpass Frequency Response
100
97
94 3.9 FT³ Bandpass
91
3.09 FT³ Bandpass
88
85
82
79
76
73
70
10 20
100
30 40 50 60 70 80 90 100
Frequency (Hz)
