Xtant A1244A - TECHNICAL DATA REPORT Technical Data page 2

A1244A Technical Data Report
Xtant A Series 12" dual 4 Ohm Subwoofer
SEALED ENCLOSURE
Enclosure Volume 1.00 Ft³ (28.3 l)
F3
43 Hz
Ripple 4.16dB
Qtc 1.75
Net Volume
.92 Ft³ (26.0 l)
Driver Volume
.08 Ft³ (2.3 l)
Excursion Limited SPL 116dB
Excursion Limited Power
250 Watts
VENTED ENCLOSURE
Enclosure Volume
2.00 Ft³ (56.6 l)
Vent Dimensions
4"x13.75"
F3 35 Hz
Tuning Frequency
33 Hz
Ripple
5.97dB
Net Volume
1.81 Ft³ (51.3 l)
Driver Volume
.08 Ft³ (2.3 l)
Vent Volume
.11 Ft³ (3.0 l)
Excursion Limited SPL 117dB
Excursion Limited Power
250 Watts
BANDPASS ENCLOSURE (S - 0.5)
Enclosure Volume
2.83 Ft³ (80.1 l)
Bandpass 50 - 99
Bandpass Gain 11.5dB
Vent Dimensions
(2)4"x1.75"
Tuning Frequency 72 Hz
Ripple 1.33dB
Sealed Volume
.55 Ft³ (15.6 l)
Vented Volume
2.18 Ft³ (61.8 l)
Driver Volume .08 Ft³ (2.3 l)
Vent Volume
.02 Ft³ (.5 l)
Excursion Limited SPL 121dB
Excursion Limited Power 250 Watts
BANDPASS ENCLOSURE (S - 0.6)
Enclosure Volume
3.90 Ft³ (110.4 l)
Bandpass 49 - 89
Bandpass Gain 12.9dB
Vent Dimensions
(3)4"x2"
Tuning Frequency 67 Hz
Ripple .63dB
Sealed Volume
.64 Ft³ (18.3 l)
Vented Volume
3.14 Ft³ (89.0 l)
Driver Volume .08 Ft³ (2.3 l)
Vent Volume
.03 Ft³ (.9 l)
Excursion Limited SPL 122dB
Excursion Limited Power 250 Watts
XTANT A Series Woofers purchased in the United States from an authorized XTANT dealer are guaranteed against defects in material and workmanship for a period of ONE YEAR, if consumer installed, from the date purchased by the end user, and limited to the original retail purchaser of the product. Product
found to be defective during that period will be repaired or replaced by XTANT at no charge. This warranty is void if it is determined that unauthorized parties have attempted repairs or alterations of any nature. Warranty does not extend to cosmetics or finish. Before presuming a defect is present in the product,
be certain that all related equipment and wiring is functioning properly. XTANT disclaims any liability for other incurred damages resulting from product defects. Any expenses incurred in the removal and reinstallation of products are not covered by this warranty. XTANT's total liability will not exceed the purchase
price of the product. If a defect is present, your authorized XTANT dealer may be able to effect repairs. Proof of purchase is required when requesting service, so please retain your sales receipt and take a moment to register your warranty on line @ xtant.com.
