Summary of Contents for MWS MulchMaster PM53A
- Page 1 HM46 / HM46A / PM53A Betriebsanleitung Manual de instrucciones Operation Manual Gebruiksaanwijzing Notice d’utilisation Brugsanvisning Istruzioni per l’uso Bruksanvisning...
- Page 2 Funktionen / Functions / Fonctions / Funzioni / Funciones / Functies / Funktioner / Funktioner (10.2) (10.1) (10) (21) (13) (21) (13) HM / PM - 01/08...
- Page 3 Detailansicht / Detailed View / Vue détaillées / Schema dettagliato / Aspecto de los detalles / Gedetailleerde afbeelding / Detailvisning / Detaljbild (21) (13) (( ( (12) (14) (11) (16) (17) (22) (10) (20) (15) (19) (18) HM / PM - 01/08...
-
Page 4: Technical Data
Technical Data Description Description Handle bar Fuel injection primer (PM) Engine brake bar Frame Eccentric lever Starter coil handle Air filter Grip protector Speed lever (PM) Engine cooling intake Oil infill spout/dipstick Shielded exhaust pipe/muffler Mark for maximum oil level, MAX Spark plug cap Mark for minimum oil level, MIN Grass deflector on all wheels... -
Page 5: Table Of Contents
Contents Page Functions ............................II Detailed View ..........................III Technical Data ..........................1 Table of Contents ........................... 2 1 Introduction..........................3 2 Important Information ......................... 3 3 Use..............................3 Designated Use........................3 Improper Use ........................4 4 Icons............................. 4 Examples of Warning Icons....................4 Examples of Extra Icons...................... -
Page 6: Introduction
Proper usage entails the observance of this operation manual, all warning labels on the mower itself and the operation manual from the engine manufacturer. MWS Cutting Tools assumes no liability for damage to persons or property arising from improper or negligent operation. -
Page 7: Improper Use
Use / Icons Improper Use The mower may NOT be used: if safety devices are defective or have been manipulated, if irregularities occur while the engine is running, or you suspect that safety has been compromised, by persons who have not read and understood this operation manual, by children and youth under 16 years of age, by persons under the influence of alcohol or drugs... -
Page 8: Warning Symbols On The Mower
Icons Warning Symbols on the Observe all warning labels on the mower itself. They are found in Mower highly visible locations on the exterior covers. Replace any worn-out labels. Meaning of warning labels: 1. WARNING! Read the operation manual before starting and heed all warnings. -
Page 9: During Start-Up
Icons During Start-up Always wear appropriate shoes/boots with sufficient tread. The cutting tool runs at a high speed and can throw foreign objects such as stones or branches out from the mower. Protect yourself with appropriate work attire. Always begin mowing on an open surface, not in high grass. Start the engine only when the mower is securely stationary and the blade can rotate freely. -
Page 10: Description
Icons / Description Never transport the mower while the engine is running. Remove the cutting tool blocks only when the engine is inactive and the spark plug cap is removed. Park the mower in buildings/enclosed areas only after the engine has cooled. -
Page 11: Adding Oil
Description Adding Oil ATTENTION! Checking the oil level accurately is possible only when the mower is parked on as level a surface as possible. Deviations up to 3% incline are within an acceptable range. Change the oil after very 25 hours of operation in order to avoid engine damage. -
Page 12: Setting Cutting Height
Description Set the cutting height with the adjustment lever (10). Raising cutting height: Pull the locking lever (10.1) on the adjustment lever (10) toward you. Pull the adjustment lever (10) back. Lock the desired cutting height in place. Lowering cutting height: Pull the locking lever (10.1) on the adjustment lever (10) toward you and push it forward. - Page 13 Description Starting Engine NOTE: (see p. II) Starting with the starter coil is possible only when the engine brake bar is retracted; otherwise the engine brake prevents ignition. With the engine brake bar (13), pull the starter coil handle (14) swiftly with equally strong arm movements, and hold onto it even after the engine has started.
-
Page 14: Cutting Method
Description Cutting Method The grass is chopped into very fine pieces by a special blade, breaking up its structure. These clippings are then pressed back down into the surface through the topsoil. The clippings decay in a very short time and thereby supply the ground with nutrients. -
Page 15: Maintenance And Care
Maintenance and Care 6 Maintenance and ATTENTION! Perform all maintenance and care procedures only Care when the engine is shut off and the cutting tool is stationary. Be sure also to heed the instructions from the engine manufacturer when performing maintenance and care procedures. -
Page 16: Maintenance And Care Intervals
Maintenance and Care Maintenance and Care Intervals Interval Procedure Check oil level and add as needed Before every use After the first 2 hours of operation Every 5 engine operating hours Check tightness of all fastened parts. Before every use Change oil After the first 5 hours of operation Every 25 hours of operation... -
Page 17: Sharpening Blade
Maintenance and Care / Resuming Operation Sharpening Blade WARNING! A cutting tool (blade) that produces vibrations must be replaced without fail. Do not attempt to true the blade yourself, as you may get it out of balance. This can cause an accident and create the hazard of further damage to the mower. -
Page 18: Recycling
Recycling / Troubleshooting 8 Recycling Please observe all environmental codes and avail yourself of all opportunities to recycle. Recycle parts according to regulations. Plastic parts: Sorted by recycling process (look for the Green Dot); otherwise dispose of as rubbish Metal parts: Scrap recycling Electrical wires: Electrical appliance scrap or coloured metal scrap Used oil:... -
Page 19: Warranty Terms
„Kool Bore Intek“ series Problems that MWS itself or its contract dealers are notified of after expiration of the warranty period have no basis for a warranty claim. Each warranty claim is subject to a limitation of 6 months after discovery of the problem. -
Page 20: Ec Declaration Of Conformity
EU Konformitetserklæring Dichiarazione di Conformità CE EU Konformietsforklaring Wir We Nous Noi Nosotros Wij Vi Vi MWS Schneidwerkzeuge GmbH & Co. KG An der Asbacher Str. 5, D-98574 Schmalkalden erklären, dass die Maschine declare that the machine déclarons que la machine dichiariamo che la macchina declaramos que la máquina verklaren dat de machine da stroje todistamme, että... - Page 21 (0 36 83) 64 22 02 modifiche senza preavviso Sujeto a modificaciones sin previo aviso Kan zonder kennisgeving wijzigingen ondergaan Ret til ændringer e-Mail: info@mws-sm.com forbeholdes Kan utsättas för modifieringar utan att detta meddelas Web: www.mulchmaster.de © Januar 2008 MWS Schneidwerkzeuge GmbH & Co. KG...
