INSTALLATION INSTRUCTIONS,

USE AND MAINTENANCE MANUAL
STOVE INSTALLATION AND COMMISSIONING MUST BE
BEFORE USING THE STOVE, IS MANDATORY' THAT
UNDERSTAND THE CONSTRUCTOR MANUAL IN ALL
Rev.14.01 EN
CARRIED OUT BY MANUFACTURER OR DEALER
QUALIFIED TECHNICIAN
AUTHORIZED OPERATORS TO READ AND TO
ITS PARTS.
La stufa
INTEL
LIGEN
TE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Compact and is the answer not in the manual?

Questions and answers

Related Manuals for STOVEitaly Compact

Summary of Contents for STOVEitaly Compact

  • Page 1: Installation Instructions

    La stufa INTEL LIGEN INSTALLATION INSTRUCTIONS, USE AND MAINTENANCE MANUAL STOVE INSTALLATION AND COMMISSIONING MUST BE CARRIED OUT BY MANUFACTURER OR DEALER QUALIFIED TECHNICIAN BEFORE USING THE STOVE, IS MANDATORY’ THAT AUTHORIZED OPERATORS TO READ AND TO UNDERSTAND THE CONSTRUCTOR MANUAL IN ALL ITS PARTS.
  • Page 2 PRESENTATION ECOLOGIC PELLETS STOVES “STOVE ITALY” Dear Customer, first of all we would like to thank you for having bought your new ECOLOGIC PELLETS STOVE “STOVE ITALY” The stoves “STOVE ITALY” are the results of successful researches, innovation and quality together with refined style.

  • Page 3: Declaration Of Performance

    Magis:165,1 mg/m3 - Alare, Greco, Focus, Favilla, Berija, Dama, Dalmata: 126 mg/m3 - Piano, Quadra Coke: 304 mg/m3 - Compact: 249 mg/m3 – Gaio: 423,5 mg/m3 - GaioC: 453,2 mg/m3 - CO [ % ] Reduced heat output: Primavera Luna, Luna Ceramica, Chiaroscuro, Tosca, Mozaik, Mont Blanc: 571 mg/m3 - Alare, Greco, Focus, Favilla, Berija, Dama, Dalmata: 576 mg/m3 - Piano, Quadra Coke: 273 mg/m3 - Compact: 661 mg/m3 - Gaio: 272.3 mg/m3 - GaioC: 272.3 mg/m3 - Surface temperature: Pass- Electrical safety: Pass - Cleanability:...

  • Page 4: Warranty Certificate

    PRESENTATION ECOLOGIC PELLETS STOVES “STOVE ITALY” WARRANTY CERTIFICATE In accordance with the warranty conditions described in par.2.5, the buyer must fill in this warranty certificate in each part, and send a copy within 8 days from the date of installation and starting to the MANUFACTURER (TECNO COVER SRL –...

  • Page 5: Test Certificate

    PRESENTATION ECOLOGIC PELLETS STOVES “STOVE ITALY” TEST CERTIFICATE DATE This test certificate confirms the correct installation and starting , the correct stove functioning and lack of any obvious defect. This test document must be filled in completely and signed by the authorized reseller and sent to the MANUFACTURER (TECNO COVER SRL –...

  • Page 6: Table Of Contents

    INDEX ECOLOGIC PELLETS STOVES “STOVE ITALY” P P P P RESENTATION RESENTATION RESENTATION RESENTATION ................page 2 Declaration of performance ..................page. 3 Warranty certificate ...................... page. 4 Test certificate......................page. 5 INDE INDEX X X X INDE INDE ..................... page.
  • Page 7 INDEX ECOLOGIC PELLETS STOVES “STOVE ITALY” 7.2– Command and control panel ................page 38 7.2.1- Infrared remote control ................page 40 7.3- Inspections before turning on ................page 41 7.4- Pellets load ing.......................page 41 7.5- First turning on ......................page 42 7.6- Manual turning on ....................page 42 7.6.1- Air fan speed regulation ................page 43 7.6.2- Manual turning off ..................page 43 7.7- Automatic turning on_off ..................page 43...

  • Page 8: Declaration And Ce Mark

    Description Pellet stove Trademark STOVE ITALY Model Luna, Luna Ceramica, Chiaroscuro, Primavera, Tosca Alare, Greco, Focus, Berija, Dama, Favilla, Dalmata, Pia- no, Quadra, Mozaik, Compact, Mont Blanc, Coke, Tondo, Magis, Gaio, Gaio C is in accordance with the following Directives: 2004/108/EC (Directive EMC) •...

  • Page 9: Ce Mark

    • TENSION AND FREQUENCY OF ELECTRIC FEEDING (V / Hz) • CURRENT INTENSITY (A) • ELECTRICAL POWER (kW) • CE MARK STOVEitaly Tecno COVER Srl. Registred office: via Palladio, 68 ; 36010 ZANE’ (VI) ITALY Factory: via Balestri 15; 36010 CARRE’ (VI) ITALY Mod: xxx (year 20xx)
  • Page 10 2- GENERALIT ECOLOGIC PELLETS STOVES “STOVE ITALY” 2.1- - - - IMPORTANCE OF THE MANUAL IMPORTANCE OF THE MANUAL IMPORTANCE OF THE MANUAL IMPORTANCE OF THE MANUAL BEFORE USING THE STOVE, IT IS MANDATORY FOR THE AUTHORIZED OPERATORS TO READ AND UNDERSTAND THIS MANUAL IN ALL PARTS. This technical manual “Instructions for the installation, use and maintenance”...

  • Page 11: Consultation Notes

    GENERALIT -2 ECOLOGIC PELLETS STOVES “STOVE ITALY” 2.2- - - - CONSULTATION NOTES CONSULTATION NOTES CONSULTATION NOTES CONSULTATION NOTES THE SIGN OF GENERAL DANGER AND THE TEXT IN THE SQUARE WRITTEN IN CAPITAL LETTERS, DRAW THE ATTENTION OF THE OPERATOR TO THE WARNINGS DESCRIBED IN THE PRESENT MANUAL Please note: capital letters in the square Bold: highlights important sentences in the text.

  • Page 12: Abbreviations

    2- GENERALIT ECOLOGIC PELLETS STOVES “STOVE ITALY” THE COMPANY SAFETY RESPONSIBLE THE COMPANY SAFETY RESPONSIBLE THE COMPANY SAFETY RESPONSIBLE THE COMPANY SAFETY RESPONSIBLE (In case the stove is used in a company). It is a qualified technician appointed by the customer, having the technical and professional qualifications required by the rules in force for what concerns the safety and the health of the workers at the work station.

  • Page 13: Warranty

    GENERALIT -2 ECOLOGIC PELLETS STOVES “STOVE ITALY” 2.5- - - - WARRANTY WARRANTY WARRANTY WARRANTY 1) DECLARATION OF WARRANTY (As per the community rule 1999/44/CE) The manufacturer guarantees to replace the stove or repair if the stove shows defects which com- promise the correct use and functioning, if these defects are traced to the real responsibility of the manufacturer.

  • Page 14: Stove Name

    In this manual it’s named stove. 3.2- - - - NAME OF THE MODELS NAME OF THE MODELS NAME OF THE MODELS NAME OF THE MODELS The models are named as follows: MODEL MATERIAL LUNA Steel or Ceram PRIMAVERA Steel/Marble CHIAROSCURO Marmo/Steel fireplace insert Steel...

  • Page 15: Components And Dimension Names

    TECHNICAL - 3 ECOLOGIC PELLETS STOVES “STOVE ITALY” 3.3- - - - NAME OF THE COMPONENTS AND DIMENSION NAME OF THE COMPONENTS AND DIMENSION NAME OF THE COMPONENTS AND DIMENSION NAME OF THE COMPONENTS AND DIMENSION In the FIG.2-3-4 are represented and named the main stove components and the dimensions: Width (L), High (H), Depth (P).
  • Page 16 939 mm 910 mm 932 mm FIG.2 (Name of the components and dimensions - MOD. LUNA / PRIMAVERA / CHIAROSCURO) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè (VI) Italia Rev. 14.01 EN...
  • Page 17 TECHNICAL - 3 ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. COMPACT (Measurements in millimiters) 1.050 FIG.3 ( Name of the components and dimensions - MOD. COMPACT) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè (VI) Italia Rev.
  • Page 18 3 - TECHNICAL ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. MONT BLANC (Measurements in millimeters FIG.4 (Name of the components and dimensions - MOD. MONT BLANC) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè (VI) Italia Rev.
  • Page 19 TECHNICAL - 3 ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. COKE (Measurements in millimeters) FIG.5 (Name of the components and dimensions - MOD. COKE) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè (VI) Italia Rev.
  • Page 20 3 - TECHNICAL ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. BERIJA E DAMA (Measurements in millimeters) MOD. BERIJA DAMA 611 mm 615 mm 590 mm 623 mm 803 mm 828 mm FIG.6 (Name of the components and dimensions - MOD. BERIJA - DAMA) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè...
  • Page 21 TECHNICAL - 3 ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. TOSCA - MOZAIK (Measurements in millimeters) MOD. TOSCA 1118 MOZAIK 1146 FIG.7 (Name of the components and dimensions - MOD. TOSCA - MOZAIK ) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè...
  • Page 22 3- TECHNICAL ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. FAVILLA / DALMATA (Measurements in millimeters) MOD. FAVILLA DALMATA 655 mm 615 mm 610 mm 620 mm 1090 mm 1180 mm FIG.8 (Name of the components and dimensions - MOD. FAVILLA / DALMATA) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè...
  • Page 23 TECHNICAL -3 ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. ALARE GRECO FOCUS (fireplace insert) (Measurements in millimeters) WITH BACK EVACUATION WITH SIDE EVACUATION MOD. ALARE GRECO FOCUS FIG.9 (Name of the components and dimensions - MOD. ALARE, GRECO E FOCUS - fireplaces insert) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè...
  • Page 24 3 - TECHNICAL ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. PIANO GAIO GAIO C (fireplaces insert) (Measurements in millimeters) MOD. PIANO GAIO – GAIO C 693 mm 736 mm 573 mm 497 mm 495 mm 598 mm FIG.10 (Name of the components and dimensions - MOD. PIANO FIREPLACES INSERT) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè...
  • Page 25 TECHNICAL - 3 ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. QUADRA (Measurements in millimeters) 1.220 FIG.11 (Name of the components and dimensions - MOD. QUADRA) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè (VI) Italia Rev.
  • Page 26 3 - TECHNICAL ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. TONDO (Measurements in millimeters) FIG.12 (Name of the components and dimensions - MOD. TONDO) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè (VI) Italia Rev.
  • Page 27 TECHNICAL - 3 ECOLOGIC PELLETS STOVES “STOVE ITALY” MOD. MAGIS (Measurements in millimeters) FIG.13 (Name of the components and dimensions - MOD. MAGIS) TECNO COVER SRL Instructions for the installation, use and maintenance Via Palladio, 68 - 36010 Zanè (VI) Italia Rev.

  • Page 28: Technical Data

    3 - TECHNICAL ECOLOGIC PELLETS STOVES “STOVE ITALY” TECHNICAL DATA TECHNICAL DATA TECHNICAL DATA TECHNICAL DATA 3.4- - - - The most significant technical data regarding the various stove models are shown on TAB.4. Some of them are changing accordingly to the different features of the installation place . MODELS Material BEIGE...

  • Page 29: Usage Purpose

    TECHNICAL - 3 ECOLOGIC PELLETS STOVES “STOVE ITALY” 3.5- - - - USAGE PURPOSE USAGE PURPOSE USAGE PURPOSE USAGE PURPOSE :The stove is planned and realized for the following usages Public and private buildings USAGE Covered, lightened and closed room, ventilated enough to enable a tural heat transmission,Once the above is a public place it must full fill the local laws,.regarding safe and health in the working places Do not install the stove in bedrooms neither bathrooms.

  • Page 30: Used Products

    3- TECHNICAL ECOLOGIC PELLETS STOVES “STOVE ITALY” 3.7- - - - USED PRODUCTS USED PRODUCTS USED PRODUCTS USED PRODUCTS CARE OF CUSTOMER PELLETS See chap.3.6. TAB.7 (Used products) IT IS STRICTLY FORBIDDEN TO USE PELLETS CONTAINING GLUES, PAINTS, AND CHEMICAL PRODUCTS LIKE FORMADEHYDE. BURNING SMOKE IS VERY DANGEROUS FOR HUMANS AND ENVIRONMENT.

  • Page 31: Packaging

    The side panels (made of marble or ceramics) of the models DALMATA and DAMA are furthermore sheltered by polystyrene inserts.The adjustable feet are already mounted (with the exeption LUNA- PRIMAVERA) and instructions handbook is located inside the fire box.
  • Page 32 Take the panel temporarily out of the stove and unscrew totally the 2 screws (PIC.14-Ref.2) fixing the stove to the pallet 4) Mount the 4 adjustable feet (PIC.14-Ref.3) (for models LUNA, PRIMAVERA only); 5) The 4 members of the crew put themselves each at any side of the stove and lift it up bringing the stove away from the wooden pallet (FIG.14-Rif.4);...

  • Page 33: Positioning

    INSTALLATION -5 ECOLOGIC PELLETS STOVES “STOVE ITALY” 5.1- - - - POSITIONING POSITIONING POSITIONING POSITIONING Positioning at the working place must be arranged as per the rules specified at par.3.5. It is also mandatory to respect the minimal distances as explained on PIC.15. 5.2- - - - CONNECTING THE AIR INTAKE TUBE AND FLUE CONNECTING THE AIR INTAKE TUBE AND FLUE CONNECTING THE AIR INTAKE TUBE AND FLUE...
  • Page 34 5 - INSTALLATION ECOLOGIC PELLETS STOVES “STOVE ITALY” 5.3– – – – INSERTS INSTALLA INSERTS INSTALLA INSERTS INSTALLATION INSERTS INSTALLA TION TION INSTRUCTION TION INSTRUCTION INSTRUCTION INSTRUCTION INSTALLATION MUST BE DONE CONSIDERING THE MINIMUM DISTANCES(SIX INCHES TO THE SIDE, REAR AND TOP) TO AVOID ANY OTHER POSSIBLE ACCESS BUT FRONT ONLY. STOVE BACK AND TOP NEED OF COOLING.

  • Page 35: Electrical Connection

    INSTALLATION - 5 ECOLOGIC PELLETS STOVES “STOVE ITALY” 5) Installing and fixing the air intake pipe, diameter of 50/70 mm corresponding to the suction pipe of the stove; 6) Grease the burned smokes tube with a proper brush and “copper grease” (or similar grease suitable for high temperatures) P.S: THE FLUE GREASING MAKES EASIER THE STOVE EXTRACTION FROM THE FIREPLACE IN CASE OF MAINTENANCE.

  • Page 36: Canalization Installation

    5.5- - - - INSTALLATION CANALIZATION INSTALLATION CANALIZATION INSTALLATION CANALIZATION INSTALLATION CANALIZATION ( ( ( ( VALID VALID FOR FOR LUNA, LUNA CERAMI- LUNA, LUNA CERAMI- VALID VALID LUNA, LUNA CERAMI- LUNA, LUNA CERAMI- CA, CHIAROSCURO TOSCA, PIANO, QUADRA, COMPACT, MOZAIK, MONT BLANC, , TONDO E...

  • Page 37: Storage

    INSTALLATION -5 ECOLOGIC PELLETS STOVES “STOVE ITALY” 3) - Assass the regulator to a fixed wall (PIC.18) 4)- Connect the cables to the cable regulator predicted 5)- Replace the backside panel PIC.17 (Canalization installation instruction) PIC.18 (Canalization regulator) IT IS COMPULSORY TO FIT PROPERLY REMOVED COMPONENTS 5.6- - - - STORAGE STORAGE STORAGE...

  • Page 38: Safety Systems

    6- SAFETY ECOLOGIC PELLETS STOVES “STOVE ITALY” 6.1- - - - GUIDELINES AND RULES OF REFERENCE GUIDELINES AND RULES OF REFERENCE GUIDELINES AND RULES OF REFERENCE GUIDELINES AND RULES OF REFERENCE The stove has been manufactured considering the evaluations emerged by an accurate analysis of the risks and reaching the aims set by the essential safety and health requirements of the European rules.

  • Page 39: Remaining Risks

    SAFETY - 6 ECOLOGIC PELLETS STOVES “STOVE ITALY” 6.3- - - - REMAINING REMAINING REMAINING RISKS REMAINING RISKS RISKS RISKS IT IS FORBIDDEN TO TAMPER WITH, EXCLUDE, REMOVE, AND/OR REPLACE ANY SAFETY DE- VICE IN THE STOVE. IT IS MANDATORY TO REPLACE AT PROPER TIME FAULTY OR DAMAGED SAFETY DEVICES ONLY WITH ORIGINAL SPARE PARTS.
  • Page 40 7- USE AND OPERATION ECOLOGIC PELLETS STOVES “STOVE ITALY” 7.1- - - - AUTHORIZED OPERATORS WORKING SPACES AUTHORIZED OPERATORS WORKING SPACES AUTHORIZED OPERATORS WORKING SPACES AUTHORIZED OPERATORS WORKING SPACES The authorized operators must occupy exclusively the spaces shown in PIC 17,depending on the kind of intervention.

  • Page 41: Infrared Remote Control

    USE AND OPERATION - 7 ECOLOGIC PELLETS STOVES “STOVE ITALY” 7.2- - - - CONTROL PANEL CONTROL PANEL CONTROL PANEL CONTROL PANEL The PIC.18 shows the control panel installed on the models. STOVE Italy REF. DENOMINATION FUNCTION Pressed, it truns on or off the stove (must not be pressed at the same “ON-OFF”...
  • Page 42 7- USE AND OPERATION ECOLOGIC PELLETS STOVES “STOVE ITALY” 7.2.1 7.2.1 7.2.1 7.2.1- - - - INFRARED REMOTE CONTROL (IR) INFRARED REMOTE CONTROL (IR) INFRARED REMOTE CONTROL (IR) INFRARED REMOTE CONTROL (IR) The PIC 21 shows the remote control supplied with the stove WARNINGS KEEP THE REMOTE CONTROL IN A SAFE PLACE, AWAY FROM CHILDREN...

  • Page 43: Pellets Load Ing

    USE AND OPERATION -7 ECOLOGIC PELLETS STOVES “STOVE ITALY” 7.3- - - - INSPECTION BEFORE LIGHTING INSPECTION BEFORE LIGHTING INSPECTION BEFORE LIGHTING INSPECTION BEFORE LIGHTING BEFORE TURNING ON THE STOVE, AUTHORIZED OPERATORS ARE OBLIGED TO PERFORM THE CHECKS ON TAB.12. IT IS ABSOLUTELY FORBIDDEN TO TURN ON THE STOVE IF THE OPERATOR FINDS DAMAGES AND/OR ANOMALIES.
  • Page 44 7- USE AND OPERATION ECOLOGIC PELLETS STOVES “STOVE ITALY” IT IS STRICTLY FORBIDDEN TO PUT ANY ALIEN DEVICE INSIDE THE PELLETS CONTAINER, TO AVOID A POSSIBLE COMPROMISING STOVE FUNCTIONING. IT 'IS ABSOLUTELY FORBIDDEN TO PUT ANYTHING IN THE STOVE COMBUSTION CHAMBER OR TRYING TO TURNING ON THE STOVE OUTSIDE OF THESE MANUAL INSTRUCTIONS IT IS MANDATORY TO WEAR PROTECTION THERMAL SYSTEMS IN CASE OF TOUCHING HOT PARTS OR POTENTIALLY HOT APPLIANCES...

  • Page 45: Air Fan Speed Regulation

    USE AND OPERATION -7 ECOLOGIC PELLETS STOVES “STOVE ITALY” FROM POSITION A (C FOR TONDO AND MAGIS MODELS) (SEE. PAR.7.1) 1) Connect the electrical plug to the electric grid; (PIC. from 2 to 13 -Ref.14 ) 2) By the infrared remote control (PIC.21), set up the heating, by buttons “+”and “-”. Upon selection, after a few seconds will appear in the LCD display the ambient temperature;...
  • Page 46 MODELS MODELS:: :: :: :: MODELS LUNA, LUNA CERAMICA, CHIAROSCURO, TOSCA, PIANO, QUADRA, MOZAIK, MONT BLANC, LUNA, LUNA CERAMICA, CHIAROSCURO, TOSCA, PIANO, QUADRA, MOZAIK, MONT BLANC, LUNA, LUNA CERAMICA, CHIAROSCURO, TOSCA, PIANO, QUADRA, MOZAIK, MONT BLANC, LUNA, LUNA CERAMICA, CHIAROSCURO, TOSCA, PIANO, QUADRA, MOZAIK, MONT BLANC,...
  • Page 47 USE AND OPERATION ECOLOGIC PELLETS STOVES “STOVE ITALY” FOR MODELS : LUNA, LUNA CERAMICA, CHIAROSCURO, TOSCA, MOZAIK E MONT BLANC FOR MODELS : LUNA, LUNA CERAMICA, CHIAROSCURO, TOSCA, MOZAIK E MONT BLANC FOR MODELS : LUNA, LUNA CERAMICA, CHIAROSCURO, TOSCA, MOZAIK E MONT BLANC...

  • Page 48: Display Settings

    7- USE AND OPERATION ECOLOGIC PELLETS STOVES “STOVE ITALY” 7.9- - - - “DARWIN”SYSTEM MENU FUNCTIONS “DARWIN”SYSTEM MENU FUNCTIONS “DARWIN”SYSTEM MENU FUNCTIONS “DARWIN”SYSTEM MENU FUNCTIONS 7.9.1 7.9.1 7.9.1 7.9.1- - - - DISPLAY SETTINGS DISPLAY SETTINGS DISPLAY SETTINGS DISPLAY SETTINGS THE OPERATORS AUTHORIZED TO THE USE AND MAINTENANCE CAN LIGHTEN THE STOVE ONLY AFTER THE CHECKS AND VERFICATIONS DESCRIBED AT PAR.7.3 WHEN YOU SELECT THE SCREEN MENU, THE SYSTEM WILL AUTOMATICALLY GET OUT IF...
  • Page 49 USE AND OPERATION -7 ECOLOGIC PELLETS STOVES “STOVE ITALY” 7.9.3 7.9.3 7.9.3 7.9.3 - - - - SETTINGS SETTINGS SETTINGS SETTINGS AND AND AUTO POWER OFF AUTO POWER OFF AUTO POWER OFF AUTO POWER OFF WHEN YOU SELECT THE SCREEN MENU, THE SYSTEM WILL AUTOMATICALLY GET OUT IF YOU DO NOT EXECUTE COMMANDS WITHIN FIVE SECONDS The stove temperature control, (for small environments or particularly thermally insulated places), could be improved by setting the "AUTO OFF"...
  • Page 50 7- USE AND OPERATION ECOLOGIC PELLETS STOVES “STOVE ITALY” 7.9.4 7.9.4 7.9.4 7.9.4 - - - - SETTINGS RESETTINGS FLOW SETTINGS RESETTINGS FLOW SETTINGS RESETTINGS FLOW SETTINGS RESETTINGS FLOW WHEN YOU SELECT THE SCREEN MENU, THE SYSTEM WILL AUTOMATICALLY GET OUT IF YOU DO NOT EXECUTE COMMANDS WITHIN FIVE SECONDS THE OPERATORS AUTHORIZED TO THE USE AND MAINTENANCE CAN LIGHTEN THE STOVE ONLY AFTER THE CHECKS AND VERFICATIONS DESCRIBED AT PAR.7.6.
  • Page 51 ECOLOGIC PELLETS STOVES “STOVE ITALY” ANOMALIES CAUSES REMEDIES 8.1- - - - ERROR SIGNALES ( ERROR SIGNALES (ANOMALIE ERROR SIGNALES ( ERROR SIGNALES ( ANOMALIE ANOMALIE S S S S - - - - CAUSE ANOMALIE CAUSE CAUSE CAUSE S S S S - - - - RIMEDIES RIMEDIES RIMEDIES RIMEDIES) ) ) )
  • Page 52 9- MAINTENANCE ECOLOGIC PELLETS STOVES “STOVE ITALY” 9.1- - - - ORDINAR ORDINARY Y Y Y MAINTENANCE MAINTENANCE ORDINAR ORDINAR MAINTENANCE MAINTENANCE It is the series of interventions necessary to maintain the stove usage and functioning conditions, by different kind of interventions (regulations, visual checks, cleaning, etc,..) done by the operator (user) with the frequency indicated TAB.14.
  • Page 53 MAINTENANCE -9 ECOLOGIC PELLETS STOVES “STOVE ITALY” 9.2- - - - EXTRAORDINARY MAINTENANCE EXTRAORDINARY MAINTENANCE EXTRAORDINARY MAINTENANCE EXTRAORDINARY MAINTENANCE It is the series of interventions necessary to maintain the stove use and functioning conditions (cleaning, regulations, parts replacements), some of them done by the operator (user) and others done exclusively by the manufacturer or authorized reseller, with the frequency indicated in TAB.18 or in case of failure or wear BEFORE DOING ANY KIND OF MAINTENANCE IT IS MANDATORY TO DISCONNECT THE...
  • Page 54 Piano Quadra and Coke, have 2 central panels. 5) Spray a proper “unblocking” product to the screws, retaining the top and bottom panels (only for models LUNA / PRIMAVERA / CHIAROSCU- RO, MONT BLANC, MOZAIK, TONDO, MAGIS, COMPACT and TO- SCA) in the combustion chamber.
  • Page 55 MAINTENANCE -9 ECOLOGIC PELLETS STOVES “STOVE ITALY” 9.3– – – – PIPES AND CHIMNEY CLEANINGS. PIPES AND CHIMNEY CLEANINGS. PIPES AND CHIMNEY CLEANINGS. PIPES AND CHIMNEY CLEANINGS. .This operation, has to be done at the end of the stove “working” season , in any case after 15 tons pellets combustion, if it is necessary also, when the heater has fumes problems expulsion.

  • Page 56: General Warning S

    10- DISPOSAL ECOLOGIC PELLETS STOVES “STOVE ITALY” 10.1 10.1- - - - GENERAL WARNINGS GENERAL WARNINGS 10.1 10.1 GENERAL WARNINGS GENERAL WARNINGS .For the stove disposal, you must follow the rules in force in the country of use ALL THE STOVE COMPONENTES MUST BE IDENTIFIED ACCORDING TO THE “CER” (REFUSES EUROPEAN CATALOGUE) CODES DEFINITIONS, AND MUST BE DISPOSED OF DELEGATING AUTHORIZED AND SPECIALIZED COMPANIES, IN THE TOTAL RESPECT OF THE RULES IN FORCE IN THE COUNTRY.
  • Page 57 SPARE PARTS ORDER FORM FORM FORM FORM TECNO COVER SRL SEND TO FAX N°: Via Palladio, 68 - 36010 Zanè (VI) Italia Tel. 0039 0445 314528 0039 0445 395548 info@stoveitaly.com - www.stoveitaly.com CUSTOMER DATA Full name Company name Street Postal Town Code. ……………….……………..…..…...

  • Page 58: Parts List

    12- ELECTRICAL PART ECOLOGIC PELLETS STOVES “STOVE ITALY” 12.1 12.1– – – – DIAGRAM DIAGRAM 12.1 12.1 DIAGRAM DIAGRAM +12V RESET TC2+ TC2- TC1+ TC1- NTC1 NTC2 11 12 12.4 12.4 12.4 12.4- - - - PARTS LIST PARTS LIST PARTS LIST PARTS LIST REF.
  • Page 59 5) Unscrew totally the two screw which fix the stove to the pallet. 6) Mount the 4 adjustable feet on the stove base underside (for model LUNA, PRIMAVERA). 7) The four authorized operators, set out along the four stove sides (Fig.
  • Page 60 THIS MANUAL IS AN INTEGRAL STOVE PART (and / or INSERT MODEL) AND MUST BE PRESERVED FOR FUTURE REFERENCE UNTIL APPLIANCE DEMOLITION. USER MANUAL Tecno COVER s.r.l. Via Palladio, 68 - 36010 Zanè (VI) ITALIA Tel ++39 0445 314528 Fax ++39 0445 395548 info@stoveitaly.com - www.stoveitaly.com...

Table of Contents
