  • Page 2 IF YOU ARE THE FIRST REGISTERED RETAIL OWNER OF YOUR VEHICLE, YOU MAY OBTAIN A COMPLIMENTARY PRINTED COPY OF THE OWNER’S MANUAL, NAVIGATION/ UCONNECT MANUALS OR WARRANTY BOOKLETS BY CALLING 1 866 726-4636 (U.S.) OR 1 800 387-1143 (CANADA) OR BY CONTACTING YOUR DEALER. IMPORTANT This User Guide is intended to familiarize you with the important features of your vehicle.

  • Page 3: Table Of Contents

    ELECTRONIC RANGE SELECT (ERS) . . 82 TOW/HAUL MODE ... . 214 AIR SUSPENSION SYSTEM (1500 MODELS) INTEGRATED TRAILER BRAKE — IF EQUIPPED ....83 MODULE .
  • Page 4 FLUID CAPACITIES — TRANSMISSION ONLY) ..238 1500 3.0L DIESEL ... . 303 ENGINE MOUNTED FUEL FILTER/WATER FLUIDS, LUBRICANTS, AND GENUINE SEPARATOR ....239 PARTS —...

  • Page 5: Introduction/Welcome

    I N T R O D U C T I O N / W E L C O M E WELCOME FROM FCA US LLC Congratulations on selecting your new FCA US LLC (“FCA US”) vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. Your new FCA US vehicle has characteristics to enhance the driver's control under some driving conditions.
  • Page 6 I N T R O D U C T I O N / W E L C O M E WARNING! • Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury. •...
  • Page 7 I N T R O D U C T I O N / W E L C O M E USE OF AFTERMARKET PRODUCTS (ELECTRONICS) The use of aftermarket devices including cell phones, MP3 players, GPS systems, or chargers may affect the performance of on-board wireless features including Keyless Enter-N-Go and Remote Start range.

  • Page 8: Controls At A Glance

    C O N T R O L S A T A G L A N C E DRIVER COCKPIT 1. Headlight Switch pg. 76 2. Instrument Cluster Display Controls pg. 187 3. Turn Signal/Wiper/Washer/High Beams Lever pg. 75 4. Instrument Cluster pg. 8 5.
  • Page 9 C O N T R O L S A T A G L A N C E 11. Switch Panel 12. Power Inverter Outlet pg. 194 13. Glove Compartment 14. Power Outlet 15. Gear Selector 16. Hood Release (below steering wheel at base of instrument panel) pg. 287 17.

  • Page 10: Instrument Cluster

    C O N T R O L S A T A G L A N C E INSTRUMENT CLUSTER 1. Temperature Gauge 2. Tachometer 3. Voltmeter (See page 252 for Instrument Cluster Warning Lights.)
  • Page 11 C O N T R O L S A T A G L A N C E 4. Instrument Cluster Display 5. Oil Pressure Gauge 6. Speedometer 7. Fuel Gauge (See page 258 for Instrument Cluster Indicator Lights.)

  • Page 12: Getting Started

    G E T T I N G S T A R T E D KEY FOB This feature allows the driver to operate the ignition switch with the push of a button, as long as the Remote Keyless Entry (RKE) key fob is in the passenger compartment.

  • Page 13: Panic Alarm

    G E T T I N G S T A R T E D Locking And Unlocking The Doors Push and release the unlock button on the key fob once to unlock the driver’s door. Push and release the unlock button twice within five seconds to unlock all doors, the tailgate, and the RamBox (if equipped).

  • Page 14: Keyless Enter-N-Go - Passive Entry

    G E T T I N G S T A R T E D Emergency Key Should the battery in the vehicle or the key fob go dead, there is an emergency key located in the key fob that can be used for locking and unlocking the doors. •...
  • Page 15 G E T T I N G S T A R T E D To Lock The Vehicle’s Doors: With a valid Keyless Enter-N-Go key fob within 5 ft (1.5 m) of the driver or passenger front door handles, push door handle lock button to lock all doors. Do NOT grab the door handle, when pushing the door handle lock button.

  • Page 16: Keyless Enter-N-Go - Ignition

    G E T T I N G S T A R T E D KEYLESS ENTER-N-GO — IGNITION Starting With a valid Keyless Enter-N-Go key fob inside the vehicle: 1. Shift the transmission into PARK (P). 2. While pressing the brake pedal, push the ENGINE START/STOP button once.

  • Page 17: Remote Start

    G E T T I N G S T A R T E D REMOTE START • Push remote start button on the key fob twice within five seconds. Pushing the remote start button a third time shuts the engine off. •...

  • Page 18: Occupant Restraint Systems

    G E T T I N G S T A R T E D To Disarm The System Push the key fob unlock button or cycle the ignition to the ON/RUN position. The vehicle security alarm is designed to protect your vehicle. However, you can create conditions where the vehicle security alarm will give you a false alarm.

  • Page 19: Seat Belt Systems

    G E T T I N G S T A R T E D 5. You should read the instructions provided with your child restraint to make sure that you are using it properly. 6. All occupants should always wear their lap and shoulder belts properly. 7.
  • Page 20 G E T T I N G S T A R T E D when the ignition switch is first in the START or ON/RUN position the Seat Belt Reminder Light will turn on and remain on until both outboard front seat belts are buckled.
  • Page 21 G E T T I N G S T A R T E D WARNING! • Relying on the air bags alone could lead to more severe injuries in a collision. The air bags work with your seat belt to restrain you properly. In some collisions, the air bags won’t deploy at all.
  • Page 22 G E T T I N G S T A R T E D WARNING! • A lap belt worn too high can increase the risk of injury in a collision. The seat belt forces won’t be at the strong hip and pelvic bones, but across your abdomen. Always wear the lap part of your seat belt as low as possible and keep it snug.
  • Page 23 G E T T I N G S T A R T E D Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is above the back of the front seat, and next to your arm in the rear seat (for vehicles equipped with a rear seat).
  • Page 24 G E T T I N G S T A R T E D 4. Position the lap belt so that it is snug and lies low across your hips, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt.
  • Page 25 G E T T I N G S T A R T E D Adjustable Upper Shoulder Belt Anchorage In the driver and front passenger seats, the top of the shoulder belt can be adjusted upward or downward to position the seat belt away from your neck. Push or squeeze the anchorage button to release the anchorage, and move it up or down to the position that serves you best.
  • Page 26 G E T T I N G S T A R T E D First Row Center Seat Belt Operating Instructions (Regular Cab Only) The first row center seat belt (Regular Cab only) features a seat belt with a mini-latch plate and buckle, which allows the seat belt to detach from the lower anchor when the seat is folded.
  • Page 27 G E T T I N G S T A R T E D 10. To disengage the mini-latch plate from the mini-buckle for storage, insert the regular latch plate into the center red slot on the mini-buckle. The seat belt will automatically retract to its stowed position.
  • Page 28 G E T T I N G S T A R T E D Seat Belt Extender If a seat belt is not long enough to fit properly, even when the webbing is fully extended and the adjustable upper shoulder belt anchorage (if equipped) is in its lowest position, your authorized dealer can provide you with a Seat Belt Extender.
  • Page 29 G E T T I N G S T A R T E D NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt still must be worn snugly and positioned properly. The pretensioners are triggered by the Occupant Restraint Controller (ORC).
  • Page 30 G E T T I N G S T A R T E D WARNING! • Never place a rear-facing child restraint in front of an air bag. A deploying passenger front air bag can cause death or serious injury to a child 12 years or younger, including a child in a rear-facing child restraint.
  • Page 31 G E T T I N G S T A R T E D Air Bag System Components • Occupant Restraint Controller (ORC) • Air Bag Warning Light • Steering Wheel and Column • Instrument Panel • Knee Impact Bolsters •...
  • Page 32 G E T T I N G S T A R T E D WARNING! Ignoring the Air Bag Warning Light in your instrument panel could mean you won’t have the air bag system to protect you in a collision. If the light does not come on as a bulb check when the ignition is first turned on, stays on after you start the vehicle, or if it comes on as you drive, have an authorized dealer service the air bag system immediately.
  • Page 33 G E T T I N G S T A R T E D Driver And Passenger Front Air Bag Features The Advanced Front Air Bag system has multistage driver and front passenger air bags. This system provides output appropriate to the severity and type of collision as determined by the Occupant Restraint Controller (ORC), which may receive informa- tion from the front impact sensors (if equipped) or other system components.
  • Page 34 G E T T I N G S T A R T E D The steering wheel hub trim cover and the upper right side of the instrument panel separate and fold out of the way as the air bags inflate to their full size. The front air bags fully inflate in less time than it takes to blink your eyes.
  • Page 35 G E T T I N G S T A R T E D 2. Supplemental Side Air Bag Inflatable Curtains (SABICs): Located above the side windows. The trim covering the SABICs is labeled “SRS AIRBAG” or “AIRBAG.” SABICs may help reduce the risk of head or other injuries to front and rear seat outboard occupants in certain side impacts and/or vehicle rollover...
  • Page 36 G E T T I N G S T A R T E D WARNING! • Occupants, including children, who are up against or very close to Side Air Bags can be seriously injured or killed. Occupants, including children, should never lean on or sleep against the door, side windows, or area where the side air bags inflate, even if they are in an infant or child restraint.
  • Page 37 G E T T I N G S T A R T E D The Side Air Bags will not deploy in all rollover events. The rollover sensing-system determines if a rollover event may be in progress and whether deployment is appropriate.
  • Page 38 G E T T I N G S T A R T E D • As the air bags deflate, you may see some smoke-like particles. The particles are a normal by-product of the process that generates the non-toxic gas used for air bag inflation.
  • Page 39 G E T T I N G S T A R T E D Maintaining Your Air Bag System WARNING! • Modifications to any part of the air bag system could cause it to fail when you need it. You could be injured if the air bag system is not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.

  • Page 40: Child Restraints

    G E T T I N G S T A R T E D NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded.
  • Page 41 G E T T I N G S T A R T E D Summary Of Recommendations For Restraining Children In Vehicles Recommended Type Of Child Re- Child Size, Height, Weight Or Age straint Children who are two years old Either an Infant Carrier or a Infants and or younger and who have not...
  • Page 42 G E T T I N G S T A R T E D WARNING! Do not install a rear-facing car seat using a rear support leg in this vehicle. The floor of this vehicle is not designed to manage the crash forces of this type of car seat.
  • Page 43 G E T T I N G S T A R T E D WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the child restraint manufacturer’s directions exactly when installing an infant or child restraint.
  • Page 44 G E T T I N G S T A R T E D Recommendations For Attaching Child Restraints Restraint Combined Use Any Attachment Method Shown With An “X” Below Type Weight of the LATCH – Seat Belt LATCH – Seat Belt + Child + Child Lower An-...
  • Page 45 G E T T I N G S T A R T E D LATCH Positions For Installing Child Restraints In This Vehicle Regular Cab LATCH Positions Top Tether Anchorage Symbol Crew/Mega Cabs 60/40 Split Bench LATCH Positions Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol...
  • Page 46 G E T T I N G S T A R T E D Quad Cab 60/40 Split Bench LATCH Positions Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol Quad/Crew Cabs Full Bench LATCH Positions Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol...
  • Page 47 G E T T I N G S T A R T E D Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the combined What is the weight limit weight of the child and the (child’s weight + weight of child restraint is 65 lbs the child restraint) for us-...
  • Page 48 G E T T I N G S T A R T E D Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint.
  • Page 49 G E T T I N G S T A R T E D Locating The Upper Tether Anchorages Regular Cab models have tether strap anchorages behind the front center and right seats. Quad Cab, Mega Cab and Crew Cab models have tether strap anchorages located behind each of the rear seats.
  • Page 50 G E T T I N G S T A R T E D Center Seat LATCH Quad Cab Or Crew Cab Full Bench Rear Seat: No Lower Center LATCH Anchorages Available WARNING! • Do not install a child restraint in the center position using the LATCH system. This position is not approved for installing child seats using the LATCH attachments.
  • Page 51 G E T T I N G S T A R T E D 3. Attach the lower hooks or connectors of the child restraint to the lower anchorages in the selected seating position. 4. If the child restraint has a tether strap, connect it to the top tether anchorage. See the section “Installing Child Restraints Using The Top Tether Anchorage”...
  • Page 52 G E T T I N G S T A R T E D Installing Child Restraints Using The Vehicle Seat Belt Child restraint systems are designed to be secured in vehicle seats by lap belts or the lap belt portion of a lap/shoulder belt. WARNING! •...
  • Page 53 G E T T I N G S T A R T E D Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Regular Cab Automatic Locking Retractor (ALR) Locations ALR = Switchable Automatic Locking Retractor Top Tether Anchorage Symbol Quad Cab/Mega Cab/Crew Cab Automatic Locking Retractor (ALR) Locations Cinch = Cinching Latch Plate...
  • Page 54 G E T T I N G S T A R T E D Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit Always use the tether an- (child’s weight + weight of chor when using the seat the child restraint) for us- Weight limit of the Child belt to install a forward...
  • Page 55 G E T T I N G S T A R T E D 2. Pull enough of the seat belt webbing from the retractor to pass it through the belt path of the child restraint. Do not twist the belt webbing in the belt path. 3.
  • Page 56 G E T T I N G S T A R T E D 4. Finally, pull up on any excess webbing to tighten the lap portion around the child restraint while you push the child restraint rearward and downward into the vehicle seat.
  • Page 57 G E T T I N G S T A R T E D Regular And Mega Cab Trucks: In the regular cab truck, the top tether anchorages are located behind the center and right passenger seats. In the mega cab truck, the top tether anchorages are located behind each rear seating position.
  • Page 58 G E T T I N G S T A R T E D WARNING! Never place a rear-facing child restraint in front of an air bag. A deploying Passenger Advanced Front Air Bag can cause death or serious injury to a child 12 years or younger, including a child in a rear-facing child restraint.
  • Page 59 G E T T I N G S T A R T E D 2. Place a child restraint on the seat and adjust the tether strap so that it will reach over the seat back, under the head restraint, through the tether strap loop behind the seat and over to the tether strap loop behind the center seat.
  • Page 60 G E T T I N G S T A R T E D 3. Pass the tether strap hook under the head restraint behind the child seat, though the tether strap loop behind the seat and over to the right or left outboard tether strap loop.

  • Page 61: Transporting Pets

    G E T T I N G S T A R T E D Installing Three Child Restraints: 1. Place a child restraint on each outboard rear seat. Route the tether straps following the directions for right and left seating positions, above. 2.

  • Page 62: Head Restraints

    G E T T I N G S T A R T E D HEAD RESTRAINTS Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact. Head restraints should be adjusted so that the top of the head restraint is located above the top of your ear.

  • Page 63: Rear Head Restraints

    G E T T I N G S T A R T E D WARNING! • A loose head restraint thrown forward in a collision or hard stop could cause serious injury or death to occupants of the vehicle. Always securely stow removed head restraints in a location outside the occupant compartment.

  • Page 64: Front Seats

    G E T T I N G S T A R T E D FRONT SEATS Driver's Power Seat — If Equipped Some models may be equipped with an eight-way power driver's seat. The power seat switches are located on the outboard side of the driver's seat cushion. There are two power seat switches that are used to control the movement of the seat cushion and the seatback.
  • Page 65 G E T T I N G S T A R T E D WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.
  • Page 66 G E T T I N G S T A R T E D NOTE: Your vehicle is equipped with two key fobs, one key fob can be linked to memory position 1 and the other key fob can be linked to memory position 2. The memory seat buttons are located on the outboard side of the driver’s seat cushion.
  • Page 67 G E T T I N G S T A R T E D To program your key fobs, perform the following: 1. Cycle the vehicle’s ignition to the OFF position. 2. Select desired memory profile (1) or (2). NOTE: If a memory profile has not already been set, refer to "Programming The Memory Feature"...
  • Page 68 G E T T I N G S T A R T E D Easy Entry/Exit Seat This feature provides automatic driver’s seat positioning to enhance driver mobility when entering and exiting the vehicle. The distance the driver’s seat moves depends on where you have the driver’s seat positioned when you remove the key fob from the ignition (or change the ignition to OFF, for vehicles equipped with Keyless Enter-N-Go).
  • Page 69 G E T T I N G S T A R T E D Manual Seat Adjuster — If Equipped Both front seats are adjustable forward or rearward. The manual seat adjustment handle is located under the seat cushion at the front edge of each seat. While sitting in the seat, pull up on the handle and slide the seat forward or rear- ward.

  • Page 70: Heated/Ventilated Seats

    G E T T I N G S T A R T E D HEATED/VENTILATED SEATS Front Heated Seats The front heated seats control buttons are located on the center instrument panel below the climate controls. If your vehicle is equipped with a touchscreen, the front heated seats control buttons are also located within the climate or controls screen of the touchscreen.
  • Page 71 G E T T I N G S T A R T E D switch to LO-level after a maximum of 60 minutes of continuous operation. At that time, the number of illuminated LEDs changes from two to one, indicating the change.

  • Page 72: Heated Steering Wheel

    G E T T I N G S T A R T E D If your vehicle is not equipped with a touchscreen, this feature can be programmed through the instrument cluster display. Refer to “Instrument Cluster Display” in “Understanding Your Instrument Panel”...

  • Page 73: Tilt Steering Column

    G E T T I N G S T A R T E D WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion, or other physical conditions must exercise care when using the steering wheel heater.
  • Page 74 G E T T I N G S T A R T E D DRIVER ADJUSTABLE PEDALS — IF EQUIPPED The adjustable pedals system is designed to allow a greater range of driver comfort for steering wheel tilt and seat position. This feature allows the brake, accelerator, and clutch pedals (if equipped) to move toward or away from the driver to provide improved position with the steering wheel.

  • Page 75: Power Folding Outside Mirrors For Standard And Trailer Tow

    G E T T I N G S T A R T E D POWER FOLDING OUTSIDE MIRRORS FOR STANDARD AND TRAILER TOW If equipped with power folding mirrors, they can be electrically folded rearward and unfolded into the drive position. The switch for the power folding mirrors is located between the power mirror switches L (left) and R (right).

  • Page 76: Operating Your Vehicle

    O P E R A T I N G Y O U R V E H I C L E ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km).

  • Page 77: Turn Signals/Wiper/Washer/High Beams Lever

    O P E R A T I N G Y O U R V E H I C L E TURN SIGNALS/WIPER/WASHER/HIGH BEAMS LEVER Turn Signal/Wiper/Washer/High Beam Lever Turn Signals/Lane Change Assist Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off.

  • Page 78: Headlight Switch

    O P E R A T I N G Y O U R V E H I C L E High Beams Push the lever away from you to activate the high beams. A high beam symbol will illuminate in the cluster to indicate the high beams are on. NOTE: For safe driving, turn off the high beams when oncoming traffic is present to prevent headlight glare and as a courtesy to other motorists.

  • Page 79: Instrument Panel Dimmer

    O P E R A T I N G Y O U R V E H I C L E Instrument Panel Dimmer • Rotate the dimmer control to the extreme left position to fully dim the instrument panel lights and prevent the interior lights from illuminating when a door is opened.

  • Page 80: Speed Control

    O P E R A T I N G Y O U R V E H I C L E SPEED CONTROL When engaged, the Speed Control takes over accelerator operations at speeds greater than 25 mph (40 km/h). The Speed Control buttons are located on the right side of the steering wheel. NOTE: In order to ensure proper operation, the Speed Control System has been designed...
  • Page 81 O P E R A T I N G Y O U R V E H I C L E To Deactivate A soft tap on the brake pedal, pushing the CANC button or normal brake pressure while slowing the vehicle will deactivate the Speed Control without erasing the set speed from memory.

  • Page 82: To Accelerate For Passing

    O P E R A T I N G Y O U R V E H I C L E To Decrease Speed When the Speed Control is set, you can decrease speed by pushing the SET (-) button. The drivers preferred units can be selected through the instrument panel settings if equipped.

  • Page 83: Eight-Speed Automatic Transmission - If Equipped

    O P E R A T I N G Y O U R V E H I C L E EIGHT-SPEED AUTOMATIC TRANSMISSION — IF EQUIPPED Your vehicle may be equipped with a fuel efficient eight-speed transmission. The electronic transmission gear selector is located on the instrument panel. The transmission gear (PRND) is displayed both above the rotary gear selector control and in the instrument cluster.

  • Page 84: Electronic Range Select (Ers)

    O P E R A T I N G Y O U R V E H I C L E ELECTRONIC RANGE SELECT (ERS) Electronic Range Select (ERS) allows you to limit the highest available transmission gear, and can be activated during any driving condition. When towing a trailer or operating the vehicle in off-road conditions, using ERS shift control will help you maximize both performance and engine braking.

  • Page 85: Air Suspension System (1500 Models) - If Equipped

    ERS Control AIR SUSPENSION SYSTEM (1500 MODELS) — IF EQUIPPED Description The air suspension system provides full time load leveling capability along with the benefit of being able to adjust vehicle height by the push of a button.
  • Page 86 O P E R A T I N G Y O U R V E H I C L E • Off-Road 1 (OR1) (Raises the vehicle approximately 1 in (26 mm) - This position should be the primary position for all off-road driving until Off Road 2 (OR2) is needed.
  • Page 87 O P E R A T I N G Y O U R V E H I C L E to “Instrument Cluster Display” in “Understanding Your Instrument Panel” in the Owner’s Manual www.ramtrucks.com/en/owners/manuals further information. Air Suspension Modes The Air Suspension system has multiple modes to protect the system in unique situations: AERO Mode To improve aerodynamics, the air suspension system has a feature which will put the...

  • Page 88: Air Suspension System (Rebel Models Only) - If Equipped

    O P E R A T I N G Y O U R V E H I C L E Protection Strategy In order to “protect” the air suspension system, the vehicle will disable load leveling as required (suspension overloaded, battery charge low, etc.). Load leveling will automatically resume as soon as system operation requirements are met.
  • Page 89 O P E R A T I N G Y O U R V E H I C L E • Aero Mode (Lowers the vehicle approximately .6 in [15 mm]) – This position provides improved aerodynamics by lowering the vehicle. The vehicle will automatically enter Aero Mode when the vehicle speed remains between 62 mph (100 km/h) and 66 mph (106 km/h) for greater than 20 seconds or if the vehicle speed exceeds 66 mph (106 km/h).
  • Page 90 O P E R A T I N G Y O U R V E H I C L E NOTE: This mode is intended to be enabled with engine running. Tire/Jack Mode To assist with changing a tire, the air suspension system has a feature which allows the automatic leveling to be disabled.

  • Page 91: Air Suspension System (2500/3500 Models) - If Equipped

    O P E R A T I N G Y O U R V E H I C L E AIR SUSPENSION SYSTEM (2500/3500 MODELS) — IF EQUIPPED Description This air suspension system is a rear leveling ride height system. The main purpose of this system is to maintain the truck’s rear ride height level.
  • Page 92 O P E R A T I N G Y O U R V E H I C L E WARNING! The air suspension system uses a high pressure volume of air to operate the system. To avoid personal injury or damage to the system, see your authorized dealer for service.

  • Page 93: Manual Climate Controls Without Touchscreen

    O P E R A T I N G Y O U R V E H I C L E Protection Strategy In order to “protect” the air suspension system, the vehicle will disable load leveling as required (suspension overloaded, battery charge low, etc.). Load leveling will automatically resume as soon as system operation requirements are met.

  • Page 94: Manual Climate Controls With Touchscreen

    O P E R A T I N G Y O U R V E H I C L E MANUAL CLIMATE CONTROLS WITH TOUCHSCREEN Uconnect 8.4 Manual Climate Controls 1 — Max A/C Button 6 — Blower Speed Up Button 2 —...

  • Page 95: Air Recirculation

    O P E R A T I N G Y O U R V E H I C L E Climate Control Knobs 1 — A/C Button 5 — Rotate Blower Control 2 — Temperature Control Buttons 6 — OFF Button 3 —...

  • Page 96: Automatic Climate Controls With Touchscreen

    O P E R A T I N G Y O U R V E H I C L E AUTOMATIC CLIMATE CONTROLS WITH TOUCHSCREEN Uconnect 8.4 Automatic Climate Controls 1 — MAX A/C Button 8 — Passenger Temperature Down 2 —...
  • Page 97 O P E R A T I N G Y O U R V E H I C L E Climate Control Knobs 1 — A/C Button 7 — Rear Defroster Button 2 — Driver Temperature Up 8 — Passenger Temperature Down 3 —...

  • Page 98: Parksense Front And Rear Park Assist - If Equipped

    O P E R A T I N G Y O U R V E H I C L E Air Recirculation • Use Air Recirculation for maximum A/C operation. • For window defogging, turn the Recirculation button off. • If the Air Recirculation button is pushed while in the AUTO mode, the indicator light may flash three times to indicate the cabin air is being controlled automatically.

  • Page 99: Parkview Rear Back Up Camera - If Equipped

    O P E R A T I N G Y O U R V E H I C L E PARKVIEW REAR BACK UP CAMERA — IF EQUIPPED Your vehicle may be equipped with the ParkView Rear Back Up Camera that allows you to see a image of the rear surroundings of your vehicle whenever the gear selector is put into REVERSE or whenever it is initiated through "Backup Camera"...
  • Page 100 O P E R A T I N G Y O U R V E H I C L E WARNING! Drivers must be careful when backing up even when using the ParkView Rear Back Up Camera. Always check carefully behind your vehicle, and be sure to check for pedestrians, animals, other vehicles, obstructions, or blind spots before backing up.

  • Page 101: Power Sliding Rear Window

    O P E R A T I N G Y O U R V E H I C L E POWER SLIDING REAR WINDOW The switch for the power sliding rear window is located on the overhead console. Push the switch right to open the glass and pull the switch left to close the glass.
  • Page 102 O P E R A T I N G Y O U R V E H I C L E Closing Sunroof Express Closing Push the switch forward and release it within one-half second. The sunroof will fully close automatically from any position. Manual Closing Push and hold the switch forward to close the sunroof.

  • Page 103: Wind Buffeting

    O P E R A T I N G Y O U R V E H I C L E WIND BUFFETING Wind buffeting can be described as a helicopter-type percussion sound. If buffeting occurs with the rear windows open, adjust the front and rear windows together. If buffeting occurs with the sunroof open, adjust the sunroof opening, or adjust any window.

  • Page 104: Electronics

    E L E C T R O N I C S YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect Voice Command Button pg. 158 2. Uconnect Phone Button pg. 158 3. Steering Wheel Audio Controls (Left — Behind Steering Wheel) pg. 187 4.
  • Page 105 E L E C T R O N I C S 7. Back Button 8. Tune/Scroll Knob — Browse/Enter Button 9. Uconnect 8.4 Radio pg. 146 10. Power Inverter (If Equipped) pg. 194 11. USB Port pg. 135 12. Aux Jack pg. 135 13.

  • Page 106: Cybersecurity

    E L E C T R O N I C S CYBERSECURITY Your vehicle may be a connected vehicle and may be equipped with both wired and wireless networks. These networks allow your vehicle to send and receive informa- tion. This information allows systems and features in your vehicle to function properly.

  • Page 107: Identifying Your Radio

    E L E C T R O N I C S IDENTIFYING YOUR RADIO Radio 3.0 • Two buttons on the faceplate on either side of the display Radio 3.0 Uconnect 3.0 • Two buttons on the faceplate on either side of the display •...
  • Page 108 E L E C T R O N I C S Uconnect 8.4 • 8.4” Touchscreen • HD Button will NOT be visible on right side of screen when viewing AM or FM • SiriusXM Travel Link feature NOT listed within Apps Uconnect 8.4 Uconnect 8.4 NAV •...

  • Page 109: Uconnect Access

    E L E C T R O N I C S UCONNECT ACCESS Uconnect Access — If Equipped (Available On Uconnect 8.4/8.4 NAV — U.S. Residents Only) WARNING! ALWAYS drive safely with your hands on the wheel. You have full responsibility and assume all risks related to the use of the Uconnect features and applications in this vehicle.
  • Page 110 E L E C T R O N I C S Before you drive, familiarize yourself with the easy-to-use Uconnect Access services. 1. The ASSIST and 9-1-1 buttons are located on your rearview mirror. The ASSIST button is used for contacting Roadside Assistance, Vehicle Care and Uconnect Access Care.
  • Page 111 E L E C T R O N I C S Uconnect Access Registration (Uconnect 8.4/8.4 NAV, U.S. 48 Contiguous States, Alaska And Hawaii) To unlock the full potential of Uconnect Access in your vehicle, you first need to register with Uconnect Access. 1.
  • Page 112 E L E C T R O N I C S Download The Uconnect Access App You’re only a few steps away from using remote commands and sending a destination from your phone to your vehicle. To use the Uconnect Access Mobile App: •...
  • Page 113 E L E C T R O N I C S Vehicle Finder The Vehicle Finder feature of the Uconnect Access Mobile App allows you to find the location of your vehicle when you have lost it. You can also sound the alarm and flash the lights to make finding your vehicle even easier.
  • Page 114 E L E C T R O N I C S Send ‘N Go The Send ‘n Go feature of the Uconnect Access Mobile App allows you to search for a destination on your mobile device and then send the route to your vehicle’s native navigation system.
  • Page 115 E L E C T R O N I C S Renewing Subscriptions And Purchasing 3G Wi-Fi Hotspot (Uconnect 8.4/8.4 NAV, U.S. 48 Contiguous States, Alaska And Hawaii) Subscriptions, and 3G Wi-Fi Hotspot, can be purchased from the Uconnect Store within your vehicle, and online at your Owner Site.
  • Page 116 E L E C T R O N I C S Apps Main Menu Press the “Apps ” button on the touchscreen to open the Apps main menu, in this screen you will be able to access all of your available Apps. To access an App directly, press the corresponding button on the touchscreen and you will be directed to that App.
  • Page 117 E L E C T R O N I C S Maintaining Your Uconnect Access Account Selling Your Vehicle When you sell your vehicle, we recommend that you remove your Uconnect Access Account information from the vehicle. You can do this on your Owner’s site website at mopar.com.
  • Page 118 E L E C T R O N I C S WARNING! • ALWAYS obey traffic laws and pay attention to the road. Some Uconnect Access services, including 9-1-1 and Assist, will NOT work without an operable 1X (voice/data) or 3G (data) network connection. •...
  • Page 119 E L E C T R O N I C S NOTE: Your vehicle may be transmitting data as authorized by the subscriber. 1. Assist Call (8.4/8.4 NAV) — The rearview mirror contains an ASSIST push button, and the touchscreen contains a Uconnect Access App, which will automatically connect the vehicle occupants to one of these predefined destinations for immediate support: •...
  • Page 120 E L E C T R O N I C S to you, we may record and monitor your conversations with Roadside Assistance, Uconnect Care or Vehicle Care, whether such conversations are initiated through the Uconnect Services in your vehicle, your device or via a landline device, and may share information obtained through such recording and monitoring in accordance with regulatory requirements.
  • Page 121 E L E C T R O N I C S WARNING! NEVER use the 3G Wi-Fi Hotspot when you are driving the vehicle. As the driver, you should only use the 3G Wi-Fi Hotspot when the vehicle is parked in a safe location.
  • Page 122 E L E C T R O N I C S Remote Door Lock/Unlock — This feature provides the ability to lock or unlock the door on your vehicle, without the keys and from virtually any distance. You can send a request to your vehicle in one of three ways: 1.
  • Page 123 E L E C T R O N I C S To Send A Text Message: 1. Push the Uconnect Phone Button on the steering wheel. 2. Wait for the beep. 3. Say “Text.” 4. Uconnect will prompt you “Say the phone number, or full name and phone type of the contact you want to send a message to.”...

  • Page 124: Radio 3.0

    E L E C T R O N I C S RADIO 3.0 Radio 3.0 1 — RADIO Button 8 — Play/Pause — 2 — INFO Button MUTE Button 3 — A-B-C Button 9 — MENU Button 4 — Preset Buttons 10 —...
  • Page 125 E L E C T R O N I C S Audio Setting • Push the AUDIO button on the radio faceplate. • The Audio Menu shows the following options for you to customize your audio settings. Treble, Mid, Bass, Fade, Balance, Speed Adjusted Volume, Loudness and AUX Offset •...
  • Page 126 E L E C T R O N I C S USB/Audio Jack (AUX) Manual Operation To select a specific audio source, push the MEDIA button on the faceplate and select from the following modes: USB/iPod • USB/iPod Mode is entered by either inserting a USB Jump Drive or iPod cable into the USB port or by pushing the MEDIA button located left of the display.

  • Page 127: Uconnect 3.0

    E L E C T R O N I C S UCONNECT 3.0 Uconnect 3.0 Radio 1 — RADIO Button 8 — BACK Button 2 — PHONE Pick-Up Button 9 — MENU Button 3 — Phone Hang-Up Button 10 — INFO Button 4 —...
  • Page 128 E L E C T R O N I C S Audio Setting • Push the AUDIO button on the radio faceplate. • The Audio Menu shows the following options for you to customize your audio settings. Treble, Mid, Bass, Fade, Balance, Speed Adjusted Volume, Loudness and AUX Offset •...

  • Page 129: Uconnect 3.0 Voice Recognition Quick Tips

    E L E C T R O N I C S USB/Audio Jack (AUX) Manual Operation To select a specific audio source, push the MEDIA button on the faceplate and select from the following modes: USB/iPod • USB/iPod Mode is entered by either inserting a USB Jump Drive or iPod cable into the USB port or by pushing the MEDIA button located left of the display.
  • Page 130 E L E C T R O N I C S Get Started 1. U.S. residents can visit UconnectPhone.com to check device and feature compat- ibility and to find device pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition.
  • Page 131 E L E C T R O N I C S Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button .
  • Page 132 E L E C T R O N I C S Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit UconnectPhone.com to check device and feature compat- ibility and to find device pairing instructions.
  • Page 133 E L E C T R O N I C S Additional Information © 2016 FCA US LLC. All rights reserved. Mopar, Mopar Owner Connect and Uconnect are registered trademarks of FCA US LLC. Android is a trademark of Google Inc.

  • Page 134: Uconnect 5.0

    E L E C T R O N I C S UCONNECT 5.0 Uconnect 5.0 Radio 1 — RADIO Button 6 — BACK Button 2 — COMPASS Button 7 — SCREEN OFF Button 3 — SETTINGS Button 8 — Mute Button — VOLUME 4 —...

  • Page 135: Clock Setting

    E L E C T R O N I C S Clock Setting To start the clock setting procedure, perform the following: 1. Push the SETTINGS button on the faceplate on the right side of the display, then press the “Clock & Date” button on the touchscreen. 2.
  • Page 136 E L E C T R O N I C S Radio Operation Uconnect 5.0 Radio Screen 1 — Radio Station Presets 5 — Station Info 2 — Show All Presets 6 — Direct Tune 3 — Seek Up 7 — Radio Band 4 —...
  • Page 137 E L E C T R O N I C S SiriusXM Premier Over 160 Channels Get every channel available on your satellite radio, and enjoy all you want, all in one place. Hear commercial-free music plus sports, news, talk and entertainment. Get all the premium programming, including Howard Stern, every NFL game, Oprah Radio, every MLB and NHL game, every NASCAR race, Martha Stewart and more.

  • Page 138: Uconnect 5.0 Voice Recognition Quick Tips

    E L E C T R O N I C S Audio Jack (AUX) • The AUX allows a device, such as an MP3 player or an iPod, to be plugged into the radio and utilize the vehicle’s audio system, using a 3.5 mm audio cable, to amplify the source and play through the vehicle speakers.
  • Page 139 E L E C T R O N I C S Get Started 1. U.S. residents can visit UconnectPhone.com to check device and feature compat- ibility and to find device pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition.
  • Page 140 E L E C T R O N I C S Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect system. Push the VR button . After the beep, say: • Cancel to stop a current voice session •...
  • Page 141 E L E C T R O N I C S Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button .
  • Page 142 E L E C T R O N I C S Media Uconnect offers connections via USB, Bluetooth and auxiliary ports (If Equipped). Voice operation is only available for connected USB and iPod devices. (Remote CD player optional and not available on all vehicles.) Push the VR button .
  • Page 143 E L E C T R O N I C S Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit UconnectPhone.com to check device and feature compat- ibility and to find device pairing instructions.
  • Page 144 E L E C T R O N I C S Voice Text Reply Uconnect will announce incoming text messages. Push the Phone button say Listen. (Must have compatible device paired to Uconnect system.) 1. Once an incoming text message is read to you, push the Phone button .

  • Page 145: Uconnect 8.4/8.4 Nav

    E L E C T R O N I C S UCONNECT 8.4/8.4 NAV Uconnect 8.4/8.4 NAV At A Glance Uconnect 8.4 NAV Radio Screen WARNING! ALWAYS drive safely with your hands on the wheel. You have full responsibility and assume all risks related to the use of the Uconnect features and applications in this vehicle.
  • Page 146 E L E C T R O N I C S • If the time is not displayed at the top of the screen, press the “Settings” button on the touchscreen. In the Settings screen, press the “Clock” button on the touchscreen, then check or uncheck this option.
  • Page 147 E L E C T R O N I C S Personalized Menu Bar The Uconnect features and services in the main menu bar are easily changed for your convenience. Simply follow these steps: Uconnect 8.4/8.4 NAV Main Menu 1. Press the “Apps ”...
  • Page 148 E L E C T R O N I C S Radio Uconnect 8.4 NAV Radio 1 — Radio Station Presets 7 — Audio Settings 2 — Toggle Between Presets 8 — Seek Up 3 — Status Bar 9 — Direct Tune To A Radio Station 4 —...
  • Page 149 E L E C T R O N I C S Seek Up/Seek Down • Press the Seek up or down arrow buttons on the touchscreen for less than two seconds to seek through radio stations. • Press and hold either arrow button on the touchscreen for more than two seconds to bypass stations without stopping.
  • Page 150 E L E C T R O N I C S SiriusXM Premier Over 160 Channels Get every channel available on your satellite radio, and enjoy all you want, all in one place. Hear commercial-free music plus sports, news, talk and entertainment. Get all the premium programming, including Howard Stern, every NFL game, Oprah Radio, every MLB and NHL game, every NASCAR race, Martha Stewart and more.
  • Page 151 E L E C T R O N I C S SiriusXM Parental Controls • You can skip or hide certain channels from view if you do not want access to them. Press the “Apps” button on the touchscreen, then the “Settings” button on the touchscreen, next press the “Sirius Setup”...
  • Page 152 E L E C T R O N I C S • SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase. If you decide to continue your service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 for U.S.
  • Page 153 E L E C T R O N I C S Media Hub — USB/Audio Jack (AUX) — If Equipped There are many ways to play music from MP3 players or USB devices through your vehicle's sound system. Press your Media button on the touchscreen to begin.
  • Page 154 E L E C T R O N I C S Bluetooth Streaming Audio • If equipped with Uconnect Voice Command, your Bluetooth-equipped device may also be able to stream music to your vehicle's sound system. Your connected device must be Bluetooth-compatible and paired with your system (see Uconnect Phone for pairing instructions).
  • Page 155 E L E C T R O N I C S Navigation • The information in the section below is only applicable if you have the 8.4 NAV system or the Navigation has been activated on your 8.4 system. • If you have a Uconnect 8.4 system your radio is “Navigation-Ready,” and can be equipped with Navigation at an extra cost.
  • Page 156 E L E C T R O N I C S Finding Points Of Interest • From the main Navigation menu, press the “Where To?” button on the touch- screen, then press the “Points of Interest” button on the touchscreen. •...
  • Page 157 E L E C T R O N I C S Go Home • A Home location must be saved in the system. From the Main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Go Home” button on the touchscreen.
  • Page 158 E L E C T R O N I C S Taking A Detour • To take a detour you must be navigating a route. • Press the “Detour” button on the touchscreen. NOTE: If the route you are currently taking is the only reasonable option, the device may not calculate a detour.

  • Page 159: Uconnect 8.4/8.4 Nav Voice Recognition Quick Tips

    E L E C T R O N I C S NOTE: SiriusXM Travel Link requires a subscription, sold separately after the five (5) year trial subscription included with your vehicle purchase. SiriusXM Travel Link is only available in the United States. UCONNECT 8.4/8.4 NAV VOICE RECOGNITION QUICK TIPS Introducing Uconnect Start using Uconnect Voice Recognition with these helpful quick tips.
  • Page 160 E L E C T R O N I C S Get Started 1. Visit UconnectPhone.com to check device and feature compatibility and to find device pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition. 3.
  • Page 161 E L E C T R O N I C S 2. Uconnect Phone Button , Push to initiate, answer, or end a phone call, send or receive a text. Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect system.
  • Page 162 E L E C T R O N I C S Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button .
  • Page 163 E L E C T R O N I C S Siri Eyes Free — If Equipped Siri lets you use your voice to send text messages, select media, place phone calls and much more. Siri uses your natural language to understand what you mean and will respond back to confirm your requests.
  • Page 164 E L E C T R O N I C S Getting Started Ensure Siri is enabled on your iPhone. Enable Siri 1 — Select Settings On Your iPhone 3 — Select Siri 2 — Select General 4 — Enable Siri...
  • Page 165 E L E C T R O N I C S 1. Pair your Siri enabled device to the vehicles sound system. Refer to “Uconnect Phone” in “Electronics” for a detailed pairing procedure. Pair Your iPhone 2. Push and Hold, then release the Uconnect Voice Recognition (VR) button on the steering wheel.
  • Page 166 E L E C T R O N I C S 3. After the double beep, begin speaking to Siri. Examples of Siri commands and questions: • "Play Rolling Stones" • "Send text message to John" • "Read text message from Sarah" •...
  • Page 167 E L E C T R O N I C S Media Uconnect offers connections via USB, Bluetooth, and auxiliary ports (If Equipped). Voice operation is only available for connected USB and iPod devices. Push the VR button . After the beep, say one of the following commands and follow the prompts to switch your media source or choose an artist.
  • Page 168 E L E C T R O N I C S Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit: • UconnectPhone.com for device compatibility and pairing instructions. Canadian residents can visit: •...
  • Page 169 E L E C T R O N I C S Voice Text Reply Uconnect will announce incoming text messages. Push the Phone button say Listen. (Must have compatible device paired to Uconnect system.) 1. Once an incoming text message is read to you, push the Phone button .
  • Page 170 E L E C T R O N I C S Climate (8.4/8.4 NAV) Too hot? Too cold? Adjust vehicle temperatures hands-free and keep everyone comfortable while you keep moving ahead. (If vehicle is equipped with climate control.) Push the VR button .
  • Page 171 E L E C T R O N I C S Navigation (8.4/8.4 NAV) The Uconnect navigation feature helps you save time and become more productive when you know exactly how to get to where you want to go. (Navigation is optional on the Uconnect 8.4 system.
  • Page 172 E L E C T R O N I C S Uconnect Access — If Equipped (8.4/8.4 NAV) WARNING! ALWAYS obey traffic laws and pay attention to the road. Some Uconnect Access services, including 9-1-1 and Assist, will NOT work without an operable 1X(voice/ data) or 3G(data) network connection.
  • Page 173 E L E C T R O N I C S Register (8.4/8.4 NAV) To unlock the full potential of Uconnect Access in your vehicle, you first need to register with Uconnect Access. 1. Push the ASSIST button on your rearview mirror. 2.
  • Page 174 E L E C T R O N I C S Voice Texting (8.4/8.4 NAV) You must be registered with Uconnect Access and have a compatible MAP – enabled device to use your voice to send a personalized text message. (Not compatible with iPhone.) 1.
  • Page 175 E L E C T R O N I C S Yelp (8.4/8.4 NAV) Once registered with Uconnect Access, you can use your voice to search for the most popular places or things around you. 1. Push the VR button .
  • Page 176 E L E C T R O N I C S SiriusXM Travel Link (8.4/8.4 NAV — US Market Only) Need to find a gas station, view local movie listings, check a sports score or the five - day weather forecast? SiriusXM Travel Link is a suite of services that brings a wealth of information right to your Uconnect 8.4 NAV system.
  • Page 177 E L E C T R O N I C S Additional Information © 2016 FCA US LLC. All rights reserved. Mopar, Mopar Owner Connect and Uconnect are registered trademarks of FCA US LLC. Android is a trademark of Google Inc.

  • Page 178: Uconnect Phone

    E L E C T R O N I C S UCONNECT PHONE Uconnect Phone (Bluetooth Hands Free Calling) Uconnect 5.0 Phone Menu 1 — Call/Redial/Hold 7 — Uconnect Phone Settings Menu 2 — Mobile Phone Signal Strength 8 — Text Messaging 3 —...
  • Page 179 E L E C T R O N I C S Uconnect 8.4/8.4 NAV Phone Menu 1 — Favorite Contacts 12 — Browse Phone Book Entries (Con- 2 — Mobile Phone Battery Life tains 9-1-1) 3 — Currently Paired Mobile Phone 13 —...
  • Page 180 E L E C T R O N I C S NOTE: • The Uconnect Phone requires a mobile phone equipped with the Bluetooth Hands-Free Profile, Version 1.0 or higher. • Most mobile phones/devices are compatible with the Uconnect system, however some mobile phones/devices may not be equipped with all of the required features to utilize all of the Uconnect system features.
  • Page 181 E L E C T R O N I C S Uconnect 8.4, 8.4 NAV: 1. Place the ignition in the ACC or ON position. 2. Press the “Phone” button in the Menu Bar on the touchscreen. 3. Select “Settings.” 4.
  • Page 182 E L E C T R O N I C S Select The iPhone's Priority Level When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite mobile phone. Selecting “Yes” will make this mobile phone the highest priority.
  • Page 183 E L E C T R O N I C S Select The Android Mobile Phone's Priority Level When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite mobile phone. Selecting “Yes” will make this mobile phone the highest priority.
  • Page 184 E L E C T R O N I C S Voice Command Tips • Speaking complete names (i.e; Call John Doe vs. Call John) will result in greater system accuracy. • You can “link” commands together for faster results. Say “Call John Doe, mobile,” for example.
  • Page 185 E L E C T R O N I C S Incoming Text Messages After pairing your Uconnect system with a Bluetooth enabled mobile device with the Message Access Profile (MAP), the Uconnect system can announce a new incoming text message and read it to you over the vehicle’s audio system. NOTE: Only incoming text messages received during the current ignition cycle can be viewed/read.
  • Page 186 E L E C T R O N I C S Android Devices 1. Push the Menu button on the mobile phone. 2. Select Settings. 3. Select Connections. 4. Turn “Show Notifications” to on. • A pop up will appear asking you to accept a request for permission to connect to your messages.
  • Page 187 E L E C T R O N I C S Here’s How: 1. Push the Uconnect Phone button and wait for the beep, then say “reply.” Uconnect will give the following prompt: “Please say the message you would like to send.”...
  • Page 188 E L E C T R O N I C S Mobile Phone won’t pair to system: • Perform a hard reset in the mobile phone by removing the battery (if removable — see your mobile phone’s owner manual). • Delete pairing history in mobile phone and Uconnect system, usually found in phone’s Bluetooth connection settings.

  • Page 189: Steering Wheel Audio Controls

    E L E C T R O N I C S STEERING WHEEL AUDIO CONTROLS The steering wheel audio controls are located on the rear surface of the steering wheel. Right Switch • Push the switch up or down to in- crease or decrease the volume.

  • Page 190: Programmable Features

    E L E C T R O N I C S Compass Calibration This compass is self-calibrating, which eliminates the need to set the compass manually. When the vehicle is new, the compass may appear erratic, and the instrument cluster display will display “CAL” until the compass is calibrated. You may also calibrate the compass by completing one or more 360 degree turns (in an area free from large metal or metallic objects) until the “CAL”...
  • Page 191 E L E C T R O N I C S Uconnect Customer Programmable Features The Uconnect system allows you to access Customer Programmable feature settings such as Display, Voice, Clock, Safety & Driving Assistance, Lights, Doors & Locks, Auto-On Comfort, Engine Off Options, Compass Settings (Uconnect 5.0,) Trailer Brake, Suspension, Audio, Phone/Bluetooth, SiriusXM Setup, Restore Settings, Clear Personal Data, and System Information through buttons on the touchscreen.
  • Page 192 E L E C T R O N I C S Instrument Cluster Reconfigurable Screen Setup The following settings allow you to change what information is displayed in the instrument cluster as well as the location that information is displayed. Digital Speedometer •...

  • Page 193: Universal Garage Door Opener (Homelink)

    E L E C T R O N I C S Trailer Tow • Push the up or down arrow button until the Trailer Tow icon is highlighted in the instrument cluster display. The screen will display the following information: •...
  • Page 194 E L E C T R O N I C S NOTE: Erasing all channels should only be performed when programming HomeLink for the first time. Do not erase channels when programming additional buttons. If you have any problems, or require assistance, please call toll-free 1-800-355-3515 or, on the Internet at HomeLink.com for information or assistance.

  • Page 195: Using Homelink

    E L E C T R O N I C S NOTE: You have 30 seconds in which to initiate the next step after the LEARN button has been pushed. 6. Return to the vehicle and push the programmed HomeLink button twice (holding the button for two seconds each time).

  • Page 196: Power Inverter

    E L E C T R O N I C S WARNING! • Your motorized door or gate will open and close while you are programming the universal transceiver. Do not program the transceiver if people or pets are in the path of the door or gate.

  • Page 197: Power Outlets

    E L E C T R O N I C S POWER OUTLETS The auxiliary 12 Volt (13 Amp) power outlets can provide power for in-cab accesso- ries designed for use with the standard “cigar lighter” plug. The 12 Volt power outlets have a cap attached to the outlet indicating “12V DC”, together with either a key symbol or a battery symbol.
  • Page 198 E L E C T R O N I C S • Inside the upper lid of the center storage compartment. NOTE: • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded, the fuse protecting the sys- tem will need to be replaced.

  • Page 199: Auxiliary Switches - If Equipped

    E L E C T R O N I C S AUXILIARY SWITCHES — IF EQUIPPED There can be up to five auxiliary switches located in the lower switch bank of the instrument panel which can be used to power various electronic devices and PTO (Power Take Off) –...

  • Page 200: Off-Road Capabilities

    O F F - R O A D C A P A B I L I T I E S FOUR-WHEEL DRIVE OPERATION — IF EQUIPPED • Four-wheel drive trucks are equipped with either a manually shifted transfer case or an electronically shifted transfer case. Refer to the operating instructions for electronic transfer case, located in this section for further information.
  • Page 201 O F F - R O A D C A P A B I L I T I E S NEUTRAL (N) Neutral — This range disengages both the front and rear driveshafts from the powertrain. To be used for flat towing behind another vehicle. Refer to “Recreational Towing”...
  • Page 202 O F F - R O A D C A P A B I L I T I E S Electronically Shifted Transfer Case (Five-Position Switch) — If Equipped This is an electronic shift transfer case and is operated by the 4WD Control Switch (Transfer Case Switch), which is located on the instrument panel.
  • Page 203 O F F - R O A D C A P A B I L I T I E S NEUTRAL (N) Neutral — This range disengages both the front and rear driveshafts from the powertrain. To be used for flat towing behind another vehicle. Refer to “Recreational Towing”...
  • Page 204 O F F - R O A D C A P A B I L I T I E S Four-Position Electronically Shifted Transfer Case (Eight Speed Transmission Only) — If Equipped This is an electronic shift transfer case and is operated by the 4WD Control Switch (Transfer Case Switch), which is located on the instrument panel.
  • Page 205 O F F - R O A D C A P A B I L I T I E S This electronically shifted transfer case is designed to be driven in the two–wheel drive position (2WD) for normal street and highway conditions on dry hard surfaced roads).
  • Page 206 O F F - R O A D C A P A B I L I T I E S Five-Position Electronically Shifted Transfer Case (Eight Speed Transmission Only) — If Equipped This is an electronic shift transfer case and is operated by the 4WD Control Switch (Transfer Case Switch), which is located on the instrument panel.
  • Page 207 O F F - R O A D C A P A B I L I T I E S NEUTRAL (N) Neutral — This range disengages both the front and rear driveshafts from the powertrain. To be used for flat towing behind another vehicle. Refer to “Recreational Towing”...

  • Page 208: Utility

    U T I L I T Y TONNEAU COVER The Tonneau Cover can be removed and reinstalled by using the locking clamps located underneath the Tonneau Cover. NOTE: Be sure that the Tonneau Cover is secured before driving. EASY-OFF TAILGATE To simplify mounting of a camper unit with an overhang, the tailgate can be removed.

  • Page 209: Pickup Box

    U T I L I T Y PICKUP BOX The pickup box has many features designed for utility and convenience. NOTE: If you are installing a Toolbox, Ladder Rack or Headache Rack at the front of the Pickup Box, you must use Mopar Box Reinforcement Brackets that are available from your authorized dealer.
  • Page 210 U T I L I T Y A touchscreen button "X" to disable display of the camera image is made available when the vehicle is not in REVERSE gear. A display timer is initiated when the Cargo Camera image is displayed. The image will continue to be displayed until the display timer exceeds 10 seconds and the vehicle speed is above 8 mph (13 km/h) or the touchscreen button "X"...

  • Page 211: Rambox

    U T I L I T Y RAMBOX RamBox Features 1 — Bed Extender 2 — Bed Rail Tie-Down System Adjustable Cleats 3 — Storage Bin 4 — Push The Button To Open The RamBox system is an integrated pickup box storage and cargo management system consisting of three features: •...

  • Page 212: Bed Extender

    U T I L I T Y RamBox Integrated Box Side Storage Bins The cargo storage bins provide watertight, lockable, illuminated storage for up to 150 lbs (68 kg) of evenly distributed cargo. • To open a storage bin, push and release the button located on the lid. •...
  • Page 213 U T I L I T Y 4. Rotate the center handle horizontally to secure the side gates in the closed position. 5. Lock the center handle using the vehicle key to secure the panel into place and assist against theft. Divider Position There are 11 divider slots along the bed inner panels which allow for various positions to assist in managing your cargo.
  • Page 214 U T I L I T Y Bed Rail Tie-Down System There are two adjustable cleats on each side of the bed that can be used to assist in securing cargo. Each cleat must be located and tightened down in one of the detents, along either rail, in order to keep cargo properly secure.

  • Page 215: Towing & Payload

    U T I L I T Y CAUTION! Failure to follow the following items could cause damage to the vehicle: • Assure that all cargo inside the storage bins is properly secured. • Do not exceed cargo weight rating of 150 lb (68 kg) per bin. •...

  • Page 216: Tow/Haul Mode

    U T I L I T Y TOW/HAUL MODE When driving in hilly areas, towing a trailer, carrying a heavy load, etc., and frequent transmission shifting occurs, push the TOW/HAUL switch to select TOW/HAUL mode. This will improve performance and reduce the potential for transmission overheating or failure due to excessive shifting.
  • Page 217 U T I L I T Y Setting With The Uconnect Touchscreen Radio To make the proper selection in the Uconnect touchscreen radio, push the More button on the faceplate (Uconnect 5.0) or press the “Apps” button on the touch- screen (Uconnect 8.4), then press the “Settings”...

  • Page 218: Recreational Towing (Behind Motorhome, Etc.)

    U T I L I T Y RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF Two-Wheel Four-Wheel Drive Models The Ground Drive Models See Instructions • Automatic transmission in PARK NOT AL- • Manual transmission in gear (NOT Flat Tow NONE LOWED...
  • Page 219 U T I L I T Y Recreational Towing — Two-Wheel Drive Models DO NOT flat tow this vehicle. Damage to the drivetrain will result. Recreational towing (for two-wheel drive models) is allowed ONLY if the rear wheels are OFF the ground. This may be accomplished using a tow dolly or vehicle trailer. If using a tow dolly, follow this procedure: NOTE: If vehicle is equipped with air suspension, ensure the vehicle is set to Normal Ride...
  • Page 220 U T I L I T Y CAUTION! • DO NOT dolly tow any 4WD vehicle. Towing with only one set of wheels on the ground (front or rear) will cause severe transmission and/or transfer case damage. Tow with all four wheels either ON the ground, or OFF the ground (using a vehicle trailer).
  • Page 221 U T I L I T Y NOTE: If vehicle is equipped with air suspension, ensure the vehicle is set to Normal Ride Height. 3. Press and hold the brake pedal. 4. Depress the clutch pedal on a manual transmission. 5.
  • Page 222 U T I L I T Y • The ignition must be in the ON/RUN mode for a shift to take place and for the position indicator lights to be operable. If the ignition is not in the ON/RUN mode, the shift will not take place and no position indicator lights will be on or flashing.
  • Page 223 U T I L I T Y NOTE: When shifting out of transfer case NEUTRAL (N), turning the engine OFF is not required, but may be helpful to avoid gear clash. With the 8-speed automatic transmission, the engine must remain running, since turning the engine OFF will shift the transmission to PARK (and the transmission must be in NEUTRAL for the transfer case to shift out of NEUTRAL).

  • Page 224: 1500 3.0L Diesel

    1 5 0 0 3 . 0 L D I E S E L DIESEL ENGINE BREAK-IN RECOMMENDATIONS The 3.0 turbocharged diesel engine does not require a break-in period due to its construction. Normal operation is allowed, providing the following recommendations are followed: •...

  • Page 225: Diesel Engine Starting Procedures

    1 5 0 0 3 . 0 L D I E S E L DIESEL ENGINE STARTING PROCEDURES Normal Starting Procedure 1. Apply the parking brake. 2. Ensure the gear selector is in the PARK position. 3. Press and hold the brake pedal while pushing the ENGINE START/STOP button once and the system will engage the starter to crank the engine.

  • Page 226: Diesel Fuel Filter/Water Separator

    1 5 0 0 3 . 0 L D I E S E L Winter Front Usage A winter front or cold weather cover is to be used in ambient temperatures below 32°F (0°C), especially during extended idle conditions. This cover is equipped with four flaps for managing total grille opening in varying ambient tempera- tures.

  • Page 227: Fuel Filter Replacement

    1 5 0 0 3 . 0 L D I E S E L Fuel Filter Replacement 1. Ensure engine is turned off. 2. Place drain pan under the fuel filter assembly. 3. Open the water drain valve, and let any accumulated water drain. 4.

  • Page 228: Exhaust Regeneration

    1 5 0 0 3 . 0 L D I E S E L EXHAUST REGENERATION This engine meets all required EPA diesel engine emissions standards. To achieve these emissions standards, your vehicle is equipped with a state-of-the-art engine and exhaust system. These systems are seamlessly integrated into your vehicle and managed by the Powertrain Control Module (PCM).

  • Page 229: Cool-Down Idle Chart

    1 5 0 0 3 . 0 L D I E S E L CAUTION! See your authorized dealer, as damage to the exhaust system could occur soon with continued operation. • Exhaust Filter Full — Power Reduced See Dealer — This message indicates the PCM has derated the engine to limit the likelihood of permanent damage to the after-treatment system.

  • Page 230: Adding Fuel - Diesel Engine Only

    1 5 0 0 3 . 0 L D I E S E L ADDING FUEL — DIESEL ENGINE ONLY Your vehicle is equipped with a cap-less fuel system. Most fuel cans will not open the flapper door. A funnel is provided to open the flapper door to allow emergency refueling with a fuel can.

  • Page 231: Diesel Exhaust Fluid

    1 5 0 0 3 . 0 L D I E S E L 4. Pour fuel into funnel opening. 5. Remove the funnel from filler pipe, clean off prior to putting back in the jack storage area under the passenger seat.

  • Page 232: System Overview

    1 5 0 0 3 . 0 L D I E S E L System Overview This vehicle is equipped with a Diesel Exhaust Fluid (DEF) injection system and a Selective Catalytic Reduction (SCR) catalyst to meet the emission requirements. The DEF injection system consists of the following components: •...
  • Page 233 1 5 0 0 3 . 0 L D I E S E L DEF Fill Procedure 1. Remove cap from DEF tank (located behind the fuel door on driver’s side of the vehicle). 2. Insert DEF container or fill nozzle into DEF fill location and fill DEF tank.
  • Page 234 1 5 0 0 3 . 0 L D I E S E L CAUTION! • To avoid DEF spillage, and possible damage to the DEF tank from overfilling, do not “top off” the DEF tank after filling. • DO NOT OVERFILL. DEF will freeze below 12ºF (-11ºC). The DEF system is designed to work in temperatures below the DEF freezing point, however, if the tank is overfilled and freezes, the system could be damaged.
  • Page 235 1 5 0 0 3 . 0 L D I E S E L Diesel Exhaust Fluid (DEF) Fault Warning Messages There are different messages which are displayed if the vehicle detects that the DEF system has been filled with a fluid other than DEF, has experienced component failures, or when tampering has been detected.

  • Page 236: 6 . 7 L C U M M I N S D I E S E L

    6 . 7 L C U M M I N S D I E S E L DIESEL ENGINE BREAK-IN RECOMMENDATIONS The Cummins turbocharged diesel engine does not require a break-in period due to its construction. Normal operation is allowed, providing the following recommenda- tions are followed: •...
  • Page 237 6 . 7 L C U M M I N S D I E S E L NOTE: • Normal starting of either a cold or a warm engine is obtained without pumping or pressing the accelerator pedal. • Under cold weather conditions, the engine may not immediately crank if the "Wait To Start"...

  • Page 238: Engine Block Heater

    6 . 7 L C U M M I N S D I E S E L Engine Block Heater For ambient temperatures below 0°F (-18°C), engine block heater usage is recom- mended. For ambient temperatures below –20°F (-29°C), engine block heater usage is required.

  • Page 239: Diesel Exhaust Brake (Engine Braking)

    6 . 7 L C U M M I N S D I E S E L position to allow air flow to the charge air cooler and automatic transmission oil cooler. When ambient temperatures drop below 0°F (-17°C) the four flaps need to be closed.

  • Page 240: Idle-Up Feature (Automatic Transmission Only)

    The engine RPM will go up to 1100 RPM. To increase the RPM, push and hold the RESUME/ACCEL switch and the idle speed will increase to approximately 1500 RPM. To decrease the RPM, push and hold the SET/DECEL switch and the idle speed will decrease to approximately 1100 RPM.

  • Page 241: Engine Mounted Fuel Filter/Water Separator

    6 . 7 L C U M M I N S D I E S E L ENGINE MOUNTED FUEL FILTER/WATER SEPARATOR Draining Fuel/Water Separator If the “Water in Fuel” indicator light is illuminated and an audible chime is heard five times, you should stop the engine and drain the water from the separator. The drain is located on the bottom of the Fuel Filter and Water Separator assembly which is located on the driver's side of the engine.

  • Page 242: Underbody Mounted Fuel Filter/Water Separator

    6 . 7 L C U M M I N S D I E S E L CAUTION! • Diesel fuel will damage blacktop paving surfaces. Drain the filter into an appropriate container. • Do not prefill the fuel filter when installing a new fuel filter. There is a possibility debris could be introduced into the fuel filter during this action.

  • Page 243: Exhaust Regeneration

    6 . 7 L C U M M I N S D I E S E L The underbody mounted filter housing will cause the engine not to run if: • No filter is installed. NOTE: • Using a fuel filter that does not meet the manufacturer's filtration and water separating requirements can severely impact fuel system life and reliability.
  • Page 244 6 . 7 L C U M M I N S D I E S E L WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your exhaust system. Do not park or operate your vehicle in areas where your exhaust system can contact anything that can burn.

  • Page 245: Cool-Down Idle Chart

    6 . 7 L C U M M I N S D I E S E L CAUTION! See your authorized dealer, as damage to the exhaust system could occur soon with continued operation. • Exhaust Filter Full — Power Reduced See Dealer — This message indicates the PCM has derated the engine to limit the likelihood of permanent damage to the after-treatment system.

  • Page 246: Adding Fuel - Diesel Engine Only

    6 . 7 L C U M M I N S D I E S E L ADDING FUEL — DIESEL ENGINE ONLY Your vehicle is equipped with a cap-less fuel system. Most fuel cans will not open the flapper door. A funnel is provided to open the flapper door to allow emergency refueling with a fuel can.

  • Page 247: Diesel Exhaust Fluid

    6 . 7 L C U M M I N S D I E S E L 4. Pour fuel into funnel opening. 5. Remove the funnel from filler pipe, clean off prior to putting back in the jack storage area under the passenger seat.

  • Page 248: Diesel Exhaust Fluid Storage

    6 . 7 L C U M M I N S D I E S E L • DEF control module • NOx sensors • NH3 sensor • Temperature sensors • SCR catalyst The DEF injection system and SCR catalyst enable the achievement of diesel emissions requirements;...
  • Page 249 6 . 7 L C U M M I N S D I E S E L NOTE: • Driving conditions (altitude, vehicle speed, load, etc.) will effect the amount of DEF that is used in your vehicle. • Another factor is that outside temperature can affect DEF consumption. In cold conditions –...
  • Page 250 6 . 7 L C U M M I N S D I E S E L DEF Fill Procedure 1. Remove cap from DEF tank (located behind the fuel door on driver’s side of the vehicle). 2. Insert DEF container or fill nozzle into DEF fill location and fill DEF tank.
  • Page 251 6 . 7 L C U M M I N S D I E S E L Diesel Exhaust Fluid (DEF) Warning Messages There are four different messages which are displayed if the vehicle detects that the DEF system has been filled with a fluid other than DEF, has experienced component failures, or when tampering has been detected.
  • Page 252 6 . 7 L C U M M I N S D I E S E L Diesel Exhaust Fluid (DEF) Fault Warning Messages There are five different messages which are displayed if the vehicle detects that the DEF system has been filled with a fluid other than DEF, has experienced component failures, or when tampering has been detected.
  • Page 253 6 . 7 L C U M M I N S D I E S E L NOTE: When this message is displayed, the engine can still be started. However, the ve- hicle will only operate at a maximum speed of 5 MPH. •...

  • Page 254: What To Do In Emergencies

    W H A T T O D O I N E M E R G E N C I E S ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling.
  • Page 255 W H A T T O D O I N E M E R G E N C I E S WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. —...
  • Page 256 W H A T T O D O I N E M E R G E N C I E S WARNING! Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have a collision. Have the vehicle checked immediately.
  • Page 257 W H A T T O D O I N E M E R G E N C I E S We recommend you do not operate the vehicle or engine damage will occur. Have the vehicle serviced immediately. — Anti-Lock Brake (ABS) Light This light monitors the Anti-Lock Brake System (ABS).
  • Page 258 W H A T T O D O I N E M E R G E N C I E S — Transmission Temperature Warning Light This light indicates that there is excessive transmission fluid temperature that might occur with severe usage such as trailer towing. If this light turns on, stop the vehicle and run the engine at idle, with the transmission in NEUTRAL, until the light turns off.
  • Page 259 W H A T T O D O I N E M E R G E N C I E S as soon as possible, and inflate them to the proper pressure. Driving on a significantly under-inflated tire causes the tire to overheat and can lead to tire failure. Under- inflation also reduces fuel efficiency and tire tread life, and may affect the vehicle’s handling and stopping ability.

  • Page 260: Instrument Cluster Indicator Lights

    W H A T T O D O I N E M E R G E N C I E S CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle.

  • Page 261: If Your Engine Overheats

    W H A T T O D O I N E M E R G E N C I E S — Cargo Light Indicates that the rear cargo light is on. — Door Ajar Indicates that one of the vehicle’s doors is open. —...

  • Page 262: Jacking And Tire Changing

    W H A T T O D O I N E M E R G E N C I E S CAUTION! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads HOT (H), pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range.
  • Page 263 W H A T T O D O I N E M E R G E N C I E S 1500 Series Trucks • Remove the jack and tool bag by removing the wing bolt and sliding the jack and tool bag from under the seat.

  • Page 264: Removing The Spare Tire

    W H A T T O D O I N E M E R G E N C I E S Removing The Spare Tire 1. Remove the spare tire before attempting to jack up the truck. 2. Attach the wheel wrench to the jack extension tube. 3.
  • Page 265 W H A T T O D O I N E M E R G E N C I E S Preparations 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. 2. Turn on the Hazard Warning flasher. 3.
  • Page 266 W H A T T O D O I N E M E R G E N C I E S 1500 Series Trucks • For 4x2 and 4x4 trucks, when changing a front wheel, place the scissors jack under the rear portion of the lower control arm as shown below.
  • Page 267 W H A T T O D O I N E M E R G E N C I E S • Operate the jack using the jack drive tube and the wheel wrench. The tube extension may be used but is not required. •...
  • Page 268 W H A T T O D O I N E M E R G E N C I E S 2500/3500 Series Trucks • Operate the jack using the jack drive tube and the wheel wrench. The tube extension, may be used, but is not required. •...
  • Page 269 W H A T T O D O I N E M E R G E N C I E S Front 4x4 Jacking Location...
  • Page 270 W H A T T O D O I N E M E R G E N C I E S For 4x2 and 4x4 trucks, when changing a rear wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the axle between the spring and the shock absorber with the drive tubes extending to the rear.
  • Page 271 • Using the lug wrench, finish tightening the wheel nuts using a crisscross pattern. The correct wheel nut tightness is 130 ft lbs (176 N·m) torque (1500 Series), 135 ft lbs (183 N·m) torque for 2500/3500 single-rear wheel (SRW) models, and 140 ft lbs (190 N·m) for 3500 dual rear-wheel models.
  • Page 272 W H A T T O D O I N E M E R G E N C I E S Reinstalling The Jack And Tools 1500 Series Trucks 1. Tighten the jack all the way down by turning the jack turn-screw clockwise until the jack is snug.
  • Page 273 W H A T T O D O I N E M E R G E N C I E S 5. Turn the wing bolt clockwise to secure to the floor pan. Reinstall the plastic cover. Wing Bolt Location 2500/3500 Series Trucks 1.

  • Page 274: Wheel Nuts

    W H A T T O D O I N E M E R G E N C I E S Hub Caps/Wheel Covers • The hub caps must be removed before raising the vehicle off the ground. • For single rear-wheel (SRW) models, use the blade on the end of the lug wrench to pry the hub cap off.
  • Page 275 W H A T T O D O I N E M E R G E N C I E S 8-Stud — Dual Rear Wheels • Dual wheels are flat-mounted and center-piloted. The lug nuts are a two-piece assembly. When the tires are being rotated or replaced, clean these lug nuts and add two drops of oil at the interface between the hex and the washer.
  • Page 276 To Stow The Flat Or Spare NOTE: RAM 1500 vehicles equipped with aluminum wheels cannot be stored under the vehicle because the wheel retainer will not fit through the wheel pilot hole. Secure the flat tire in the bed of the truck. Have the flat tire repaired or replaced immediately.
  • Page 277 W H A T T O D O I N E M E R G E N C I E S WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.

  • Page 278: Jump-Starting Procedures

    W H A T T O D O I N E M E R G E N C I E S CAUTION! • Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. •...
  • Page 279 W H A T T O D O I N E M E R G E N C I E S Preparations For Jump-Start The battery in your vehicle is located in the front of the engine compartment, behind the left headlight assembly. NOTE: The positive battery post may be covered with a protective cap if equipped.
  • Page 280 W H A T T O D O I N E M E R G E N C I E S Jump-Starting Procedure WARNING! Failure to follow this jump-starting procedure could result in personal injury or property damage due to battery explosion. CAUTION! Failure to follow these procedures could result in damage to the charging system of the booster vehicle or the discharged vehicle.

  • Page 281: Emergency Tow Hooks

    W H A T T O D O I N E M E R G E N C I E S 6. Once the engine is started, remove the jumper cables in the reverse sequence: Disconnecting The Jumper Cables 1. Disconnect the negative (-) end of the jumper cable from the engine ground of the vehicle with the discharged battery.

  • Page 282: Gear Selector Override - 6-Speed Transmission

    W H A T T O D O I N E M E R G E N C I E S GEAR SELECTOR OVERRIDE — 6-SPEED TRANSMISSION If a malfunction occurs and the gear selector cannot be moved out of the PARK position, you can use one of the following procedures to temporarily move the gear selector: Column Shifter —...
  • Page 283 W H A T T O D O I N E M E R G E N C I E S Center Console Shifter — If Equipped 1. Turn the engine off. 2. Firmly apply the parking brake. 3. Using a small screwdriver or similar tool, remove the gear selector override access cover (located to the right of the gear selector).

  • Page 284: Manual Park Release - 8 Speed Transmission

    W H A T T O D O I N E M E R G E N C I E S MANUAL PARK RELEASE — 8 SPEED TRANSMISSION WARNING! Always secure your vehicle by fully applying the parking brake, before activating the Manual Park Release.
  • Page 285 W H A T T O D O I N E M E R G E N C I E S 3. Using the screwdriver or similar tool, push the Manual Park Release lever locking tab (just below the middle of the lever) to the right. 4.

  • Page 286: Towing A Disabled Vehicle

    W H A T T O D O I N E M E R G E N C I E S...

  • Page 287: Freeing A Stuck Vehicle

    W H A T T O D O I N E M E R G E N C I E S FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand, or snow, it can often be moved using a rocking motion.

  • Page 288: Enhanced Accident Response System (Ears)

    W H A T T O D O I N E M E R G E N C I E S CAUTION! • When “rocking” a stuck vehicle by shifting between DRIVE/SECOND GEAR and REVERSE, do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result.

  • Page 289: Maintaining Your Vehicle

    M A I N T A I N I N G Y O U R V E H I C L E TO OPEN AND CLOSE THE HOOD To open the hood, two latches must be released. 1. Pull the hood release lever located below the steering wheel at the base of the instrument panel.

  • Page 290: Engine Compartment - 3.6L

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — 3.6L 1. Air Cleaner Filter 2. Engine Oil Fill (Under Cover) 3. Brake Fluid Reservoir 4.
  • Page 291 M A I N T A I N I N G Y O U R V E H I C L E 6. Washer Fluid Reservoir 7. Engine Coolant Reservoir 8. Engine Coolant Pressure Cap 9. Engine Oil Dipstick...

  • Page 292: Engine Compartment - 5.7L

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — 5.7L 1. Air Cleaner Filter 2. Transmission Fluid Dipstick 3. Engine Oil Fill 4. Brake Fluid Reservoir 5.
  • Page 293 M A I N T A I N I N G Y O U R V E H I C L E 6. Engine Oil Dipstick 7. Power Distribution Center (Fuses) 8. Washer Fluid Reservoir 9. Engine Coolant Reservoir 10. Engine Coolant Pressure Cap...

  • Page 294: Engine Compartment - 6.4L

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — 6.4L 1. Engine Coolant Reservoir 2. Transmission Fluid Dipstick 3. Engine Oil Fill 4. Brake Fluid Reservoir 5.
  • Page 295 M A I N T A I N I N G Y O U R V E H I C L E 7. Power Distribution Center (Fuses) 8. Washer Fluid Reservoir 9. Power Steering Reservoir 10. Engine Oil Dipstick 11. Air Cleaner Filter...

  • Page 296: Engine Compartment - 3.0L Diesel

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — 3.0L DIESEL 1. Air Cleaner Filter 2. Engine Oil Fill 3. Brake Fluid Reservoir 4. Aux Power Distribution Center (Fuses) 5.
  • Page 297 M A I N T A I N I N G Y O U R V E H I C L E 6. Power Distribution Center (Fuses) 7. Washer Fluid Reservoir 8. Engine Coolant Reservoir 9. Engine Oil Dipstick...

  • Page 298: Engine Compartment - 6.7L Diesel With 68Rfe Transmission

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — 6.7L DIESEL WITH 68RFE TRANSMISSION 1. Batteries 2. Engine Coolant Reservoir 3. Transmission Fluid Dipstick 4.
  • Page 299 M A I N T A I N I N G Y O U R V E H I C L E 7. Power Steering Fluid Reservoir 8. Power Distribution Center (Fuses) 9. Engine Oil Dipstick 10. Engine Oil Fill 11.

  • Page 300: Engine Compartment - 6.7L Diesel With As69Rc Transmission

    M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT — 6.7L DIESEL WITH AS69RC TRANSMISSION 1. Batteries 2. Engine Coolant Reservoir 3. Transmission Fluid Dipstick 4.
  • Page 301 M A I N T A I N I N G Y O U R V E H I C L E 7. Washer Fluid Reservoir 8. Power Steering Fluid Reservoir 9. Engine Oil Dipstick 10. Engine Oil Fill 11. Air Cleaner Filter...

  • Page 302: Fluid Capacities - Gas Engine

    Antifreeze/Coolant 10 Year/150,000 Mile Formula 13.7 Quarts 13 Liters that meets the requirements of FCA Material Stan- dard MS.90032.) 5.7L Engine – 1500 Models (We recommend you use Mopar Antifreeze/Coolant 10 Year/ 18.3 Quarts 17.3 Liters 150,000 Mile Formula that meets the require- ments of FCA Material Standard MS.90032.)

  • Page 303: Fluids, Lubricants, And Genuine Parts - Gas Engine

    M A I N T A I N I N G Y O U R V E H I C L E FLUIDS, LUBRICANTS, AND GENUINE PARTS — GAS ENGINE Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use Mopar Antifreeze/ Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Technology).
  • Page 304 M A I N T A I N I N G Y O U R V E H I C L E CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.

  • Page 305: Fluid Capacities - 1500 3.0L Diesel

    M A I N T A I N I N G Y O U R V E H I C L E Component Fluid, Lubricant, or Genuine Part Front Axle – 1500 Four-Wheel Drive Mod- We recommend you use Mopar GL-5 Syn- thetic Axle Lubricant SAE 75W-85.

  • Page 306: Fluids, Lubricants, And Genuine Parts - 1500 3.0L Diesel

    M A I N T A I N I N G Y O U R V E H I C L E FLUIDS, LUBRICANTS, AND GENUINE PARTS — 1500 3.0L DIESEL Engine Component Fluid, Lubricant, or Genuine Part Engine We recommend you use Mopar Antifreeze/Coolant 10 Year/ Coolant 150,000 Mile Formula OAT (Organic Additive Technology).
  • Page 307 Transfer Case We recommend you use Mopar BW44– 44 Transfer Case Fluid. Front Axle – 1500 Four-Wheel Drive We recommend you use Mopar GL-5 Syn- Models thetic Axle Lubricant SAE 75W-85. Rear Axle We recommend you use Mopar Synthetic Gear Lubricant SAE 75W-140 (MS-8985).

  • Page 308: Fluid Capacities - 6.7L Cummins Diesel Engine

    M A I N T A I N I N G Y O U R V E H I C L E FLUID CAPACITIES — 6.7L CUMMINS DIESEL ENGINE U.S. Metric Fuel (Approximate) 2500/3500 Standard Cab 28 Gallons 106 Liters Longbed Models 2500/3500 Crew/Mega 31 Gallons...

  • Page 309: Fluids, Lubricants, And Genuine Parts - 6.7L Cummins Diesel Engine

    M A I N T A I N I N G Y O U R V E H I C L E FLUIDS, LUBRICANTS, AND GENUINE PARTS — 6.7L CUMMINS DIESEL ENGINE Engine Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Engine Coolant Formula OAT (Organic Additive Technology).
  • Page 310 M A I N T A I N I N G Y O U R V E H I C L E CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.

  • Page 311: Maintenance Procedures

    “Instrument Cluster Warning Lights” in “What To Do In Emergen- cies” in this guide or “Instrument Cluster Display” in “Understanding Your Instru- ment Panel” in your Owner’s Manual at www.ramtrucks.com/en/owners/manuals. 1500 Models Only NOTE: Under no circumstances should oil change intervals exceed 10,000 miles (16,000 km), twelve months or 350 hours of engine run time, whichever comes first.
  • Page 312 M A I N T A I N I N G Y O U R V E H I C L E Severe Duty All Models NOTE: Change Engine Oil at 4,000 miles (6,500 km) if the vehicle is operated in a dusty and off road environment or is operated predominantly at idle, or only very low engine RPM’s.
  • Page 313 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 314 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 315 M A I N T A I N I N G Y O U R V E H I C L E...

  • Page 316: Maintenance Schedule - 1500 3.0L Diesel Engine

    M A I N T A I N I N G Y O U R V E H I C L E MAINTENANCE SCHEDULE — 1500 3.0L DIESEL ENGINE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
  • Page 317 M A I N T A I N I N G Y O U R V E H I C L E Maintenance Chart — Diesel Fuel Up To B5 Biodiesel (1500 Diesel) Required Maintenance Refer to the Maintenance Schedules on the following pages for required mainte- nance.
  • Page 318 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 319 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 320 M A I N T A I N I N G Y O U R V E H I C L E...

  • Page 321: Maintenance Schedule - 6.7L Cummins Diesel Engine

    M A I N T A I N I N G Y O U R V E H I C L E MAINTENANCE SCHEDULE — 6.7L CUMMINS DIESEL ENGINE CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle.
  • Page 322 M A I N T A I N I N G Y O U R V E H I C L E Replace the engine oil and oil filter every 15,000 miles (24,000 km) or six months, or sooner if prompted by the oil change indicator system. Under no circumstances should oil change intervals exceed 15,000 miles (24,000 km) or six months, whichever comes first.
  • Page 323 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 324 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 325 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 326 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 327 M A I N T A I N I N G Y O U R V E H I C L E...
  • Page 328 M A I N T A I N I N G Y O U R V E H I C L E...

  • Page 329: Fuses

    Rad Fan – If Equipped 40 Amp Green – Compressor for Air Suspension – If Equipped 40 Amp Green – Antilock Brakes/Electronic Stability Control Pump 40 Amp Green – Starter Solenoid 20 Amp Blue – Emissions Diesel – If Equipped (1500 LD/Cum- mins Diesel)
  • Page 330 – Body Controller #4 / Interior Light- 30 Amp Pink – Smart Bar – If Equipped 20 Amp Blue – SCR – If Equipped (1500 LD Diesel) 30 Amp Pink (Cummins Diesel) 30 Amp Pink – Passenger Door Module 30 Amp Pink –...
  • Page 331 10 Amp Red SCR Relay – If Equipped – 15 Amp Blue Underhood Lamp – 10 Amp Red PM Sensor – If Equipped (1500 LD Diesel & Cummins Die- sel) – 10 Amp Red Air Conditioning Clutch – 20 Amp Yellow...
  • Page 332 Fuel Transfer Pump (HD Only) – If Equipped – 20 Amp Yellow Brake Vacuum Pump Gas/Diesel – (Gas Engine & If Equipped 1500 LD Diesel) – 10 Amp Red Coolant Temperature Valve Actuator – 10 Amp Red Antilock Brakes / Electronic Stabil- ity Control –...

  • Page 333: Tire Safety Information

    M A I N T A I N I N G Y O U R V E H I C L E CAUTION! • When installing the power distribution center cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the power distribution center and possibly result in an electrical system failure.
  • Page 334 M A I N T A I N I N G Y O U R V E H I C L E Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/ 80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S.
  • Page 335 M A I N T A I N I N G Y O U R V E H I C L E Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side.
  • Page 336 M A I N T A I N I N G Y O U R V E H I C L E Tire Loading And Tire Pressure Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver's side door.
  • Page 337 M A I N T A I N I N G Y O U R V E H I C L E WARNING! • Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recom- mended load capacity for your vehicle.
  • Page 338 M A I N T A I N I N G Y O U R V E H I C L E Steps For Determining Correct Load Limit— (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.” on your vehicle's placard. (2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.
  • Page 339 M A I N T A I N I N G Y O U R V E H I C L E Metric Example For Load Limit For example, if “XXX” amount equals 635 kg, and there will be five 68 kg passengers in your vehicle, the amount of available cargo and luggage load capacity is 295 kg (635-340 (5x68) = 295 kg) as shown in step 4.

  • Page 340: Tires - General Information

    M A I N T A I N I N G Y O U R V E H I C L E TIRES — GENERAL INFORMATION Spare Tires — If Equipped NOTE: For vehicles equipped with Tire Service Kit instead of a spare tire, please refer to the “Tire Service Kit”...
  • Page 341 M A I N T A I N I N G Y O U R V E H I C L E Full Size Spare — If Equipped The full size spare is for temporary emergency use only. This tire may look like the originally equipped tire on the front or rear axle of your vehicle, but it is not.
  • Page 342 M A I N T A I N I N G Y O U R V E H I C L E CAUTION! Avoid products or automatic car washes that use acidic solutions or strong alkaline additives or harsh brushes. These products and automatic car washes may damage the wheel's protective finish.

  • Page 343: Department Of Transportation Uniform Tire Quality Grades

    M A I N T A I N I N G Y O U R V E H I C L E DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating as- signed by the tire's manufacturer in each category is shown on the sidewall of the tires on your vehicle.
  • Page 344 M A I N T A I N I N G Y O U R V E H I C L E Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire's resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.

  • Page 345: Replacement Bulbs

    M A I N T A I N I N G Y O U R V E H I C L E REPLACEMENT BULBS All of the inside bulbs are brass or glass-wedge base. Aluminum base bulbs are not approved. Interior Bulbs Bulb Number Overhead Console Lamps...

  • Page 346: Consumer Assistance

    C O N S U M E R A S S I S T A N C E CONSUMER ASSISTANCE FCA US LLC CUSTOMER CENTER P.O. Box 21–8004 Auburn Hills, MI 48321–8004 Phone: 1-866-726-4636 FCA CANADA INC. CUSTOMER CENTER P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1-800-465-2001 (English) Phone: 1-800-387-9983 (French) ASSISTANCE FOR THE HEARING IMPAIRED To assist customers who have hearing difficulties, the manufacturer has installed...

  • Page 347: Reporting Safety Defects In The United States

    C O N S U M E R A S S I S T A N C E NOTE: • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep ® , Ram Truck, Dodge and SRT websites. •...

  • Page 348: Mopar® Accessories

    M O P A R ® A C C E S S O R I E S MOPAR® ACCESSORIES AUTHENTIC ACCESSORIES BY MOPAR • In choosing Authentic Accessories you gain far more than expressive style, premium protection, or extreme entertainment, you also benefit from enhancing your vehicle with accessories that have been thoroughly tested and factory- approved.

  • Page 349: Faq's

    F A Q ’ s FAQ’s FREQUENTLY ASKED QUESTIONS GETTING STARTED How do I install my LATCH Equipped Child Seat? pg. 48 How do I program my Front Seat Memory? pg. 63 OPERATING YOUR VEHICLE How does the Electronic Range Select (ERS) operate? pg. 82 ELECTRONICS Which radio is in my vehicle? •...
  • Page 350 Where is my Fuse Block located? pg. 327 What type of oil do I use? pg. 300 How often should I change my engine’s oil? • Gasoline Engine pg. 309 • Cummins Diesel Engine pg. 319 • 1500 Diesel Engine pg. 314...

  • Page 351: Index

    I N D E X Access Automatic Temperature Control Uconnect ..107, 109, 115 (ATC) ....94 Adding Engine Coolant Automatic Transmission (Antifreeze).
  • Page 352 I N D E X Infants And Child Restraints . . .39 Diesel Engine Maintenance . .224, 239 Locating The LATCH Diesel Exhaust Fluid (DEF) . .229, 245 Anchorages ... . .46 Diesel Fuel Water Separator.
  • Page 353 I N D E X Exhaust Brake... . .237 High Beam/Low Beam Select Exhaust Regeneration ..226 (Dimmer) Switch ..76 Exhaust System .
  • Page 354 I N D E X Service ....343 Overheating, Engine ..259 Turn Signal ... . .75 Loading Vehicle Paint Care .
  • Page 355 I N D E X Radio (Sound Systems) ..132, 139 Seats....62 Rain Sensitive Wiper System ..75 Adjustment .
  • Page 356 I N D E X Suspension, Air ..83, 86 Turbo Cool Down ..227, 243 Turn Signals ...75, 258 Tailgate .
  • Page 357 I N D E X Washer Wheel And Wheel Trim Care. .309, 339 Adding Fluid ...309 Wheel Cover ....272 Washers, Windshield .
  • Page 358 N O T E S...
  • Page 359 N O T E S...
  • Page 360 N O T E S...
  • Page 361 N O T E S...
  • Page 362 N O T E S...

  • Page 363: Driving And Alcohol

    This guide has been prepared to help you get quickly acquainted with your new Ram brand vehicle and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/Uconnect Manuals and other Warning Labels in your vehicle.
  • Page 364 Download a FREE electronic copy of the Owner’s Manual and Warranty Booklet by visiting: WWW.RAMTRUCKS.COM/EN/OWNERS/MANUALS OR WWW.RAMTRUCKS.COM/EN/WARRANTY (U.S.); WWW.OWNERS.MOPAR.CA/EN (CANADA). © 2016 FCA US LLC. ALL RIGHTS RESERVED. RAM IS A REGISTERED TRADEMARK OF FCA US LLC. 17D241-926-AA RAM TRUCKS 1500/2500/3500 Third EDITION USER GUIDE...

Table of Contents
