ESET PERSONAL FIREWALL User Manual page 11

Item
Name
Direction
Action
Protocol
Log
Notify user
Local port
Application
Remote port
Remote address
NOTE: The rule order is not important. Only rules related to a given communication are applied to it. If no such rule
exists, communication is blocked. More specific rules have priority over less specific (compare "deny communication
for FTP client" and "allow FTP communication").
The following table shows a list of typical rules. Most of these can be applied if Policy-based filtering mode is
activated:
Meaning/defines
name of rule
direction of communication (In, Out, Both)
action to be executed (deny, allow, ask)
protocol
select this option to log the activity connected with the rule (see the chapter on
logging)
displays a message when the rule is applied
source communication port (or group of ports)
the name of the application/process to which the rule applies
target communication port (or group of ports)
target IP address (or IP address range, or subnet)
11
