Soehnle 63340 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

WEB CONNECT ANAL YSIS
Instruction Manual
BMI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 63340 and is the answer not in the manual?

Questions and answers

Related Manuals for Soehnle 63340

Summary of Contents for Soehnle 63340

  • Page 1 WEB CONNECT ANAL YSIS Instruction Manual...

  • Page 2: Table Of Contents

    Content Introduction Proper use Safety information Why is body analysis sensible? Bio Impedanz Analysis (BIA) The body mass index (BMI) Rules for weighing Start-up operation Description of the device System requirements Installation Insert or replace batteries Activate connection between web box and scale Messages Setting up the user account Entering personal data I unit of measurement (kg - lb -st) I Target weight.

  • Page 3: Introduction

    1. Introduction 1.1 Proper use With professional Bio Impedance Multi-Frequency Measurement, ”Web Connect Analysis” always delivers precise data regarding body weight, muscle mass, fat and water content. Therefore, the body analysis scale ensures the anyone wanting to stay active and healthy.

  • Page 4: Safety Information

    1.2 Safety information Danger Improper use may result in hazards that may lead to death or severe injury. Warning Improper use may, in certain circumstances, cause injuries and pose risks to your health. Attention Improper use may result in injury or property damage. Notes Important information Danger...
  • Page 5 Attention • Batteries contain chemicals. A leakage of these chemicals could result in damages to objects or bodily injuries. If battery acid comes into contact with the eye, immediately rinse the eye with plenty of water and contact a physician. •...

  • Page 6: Why Is Body Analysis Sensible

    A balanced and controlled diet and exercise are the true “secrets” for great health, moderate body weight, and general wellbeing. For this, a Soehnle body analysis scale will enable you to determine the body values that are relevant for your health.

  • Page 7: The Body Mass Index (Bmi)

    1.5 The body mass index (BMI) The foundation of this calculation is the body mass index - an index number that can be used to interpret body weight in terms of the risk it poses to your health. The index number is calculated based on the body weight in kilogram, divided by the body height squared 75 kg (example: BMI = = 24,5)

  • Page 8: Rules For Weighing

    1.6 Rules for weighing The weight of an adult can change by approx. 2-3 kg during one day. For a reliable weight control it is therefore important to maintain constant weighing conditions. That’s why it’s best to weigh oneself • sober •...
  • Page 9 water content due to the consumption of foods and liquids, menstruation, illness, exercise, and bathing. Implausible results may occur among • persons with fever, edema, or osteoporosis • persons in dialysis treatment • persons taking cardiovascular medicines • pregnant women •...

  • Page 10: Start-Up Operation

    2. Start-up operation 2.1 Description of the device Scale Web Box 1. Display 14. Power supply socket 2. Weighing platform 15. Reset key 16. Broadband interface 3. Activation key 17. Internet connection indicator 4. Battery cover 18. Network connection indicator 5.

  • Page 11: System Requirements

    2.2 System requirements 1. Broadband router with one free LAN port (10 Mbit/s) and internet access 2. Internet-capable device (e.g. smartphone, tablet or PC/MAC) with web browser of the newest generation. No software or app installation required. 3. Valid email address for registration on the portal. 2.3 Installation 1.

  • Page 12: Activate Connection Between Web Box And Scale

    2.5 Activate connection between web box and scale The distance between the web box and the scale should not exceed 20 cm during activation. Push the button on the back of the scale to start activation. Activation was successful if [ ] is displayed. However, if the scale displays E8, activation failed.
  • Page 13 manually. This might be the case if the DHCP* function is deactivated on the router. If this is the case, please continue as follows: 1. The web box must be switched on (both LEDs are 2. Push the reset key and hold it for approx. 5 seconds. Both LEDs will light up simultaneously.

  • Page 14: Setting Up The User Account

    (WAN and LAN LED light up). Start synchronization. bare feet and if possible undressed, and stand still until the display goes out. 9. If your weight is being displayed in ”My Soehnle”, 10. Personal data will be entered next (chapter 2.8.1)

  • Page 15: Entering Personal Data I Unit Of Measurement (Kg - Lb -St) I Target Weight

    2.9 Entering personal data This data is absolutely necessary for interpretation of the measurement data. 1. Select language 2. Enter gender 3. Enter the name with which you would like to be addressed 4. Set up birthdate 5. Enter body height 6.

  • Page 16: Body Analysis

    3. Body analysis A body analysis is only possible with bare feet. Personal data must have been entered beforehand. For concise results, please step onto the platform without any clothing and under the same conditions (time, food consumption, etc.). Note: an internet connection must be available if the data is to be transmitted to your personal account. Only the weight will be displayed if no internet connection is available.

  • Page 17: The Personal Account

    4. The personal account 4.1 The main menu 1. Go to my.soehnle.com, enter your user name and your password and tap on ”Login”. 2. You will be in the main menu. The values that were determined last and the difference to your desired weight will be displayed.

  • Page 18: Tabular Display

    4.3 Tabular display Go to ”Table”. Select the period for review (week, month, 6 months, year, or customized via ”Filter data”) for which the values are to be displayed. If you tap on next to an individual value, you can edit this data or add a comment.

  • Page 19: Messages

    7. Messages Problem Cause Solution No batteries or batteries are Insert or replace batteries empty No display Batteries inserted incorrectly Insert batteries correctly 1. Radio communication is interrupted Activate the product again with a 2. Distance between scale and distance of 20 cm between scale web box is too great during and web box.
  • Page 20 Web Box - Radio frequency: 434 MHz - Power supply unit: Model: BLJ5W050100P-V Input: 100-240V~50/60Hz, 150mA Output: 5V 1000mA Scale - Load capacity x graduation = max 150 kg x 100 g / max 330 lb / 0.2 lb - Display precision: Body fat content: 0.1% Body water content: 0.1% Muscle mass: 0.1%...

  • Page 21: Declaration Of Conformity

    9. Declaration of conformity Soehnle herewith declares that this device is in compliance with the basic requirements and all other applicable Although the appliance has been tested and its emissions do not exceed the permitted radio frequency emission levels as laid down in the above directives, there is no guarantee that interference will not occur in certain situations.

  • Page 22: Service And Support

    International Ph.: +49 - 26 04 - 97 70 If you‘d like to contact us in writing, please use the contact form at the SOEHNLE homepage www.soehnle.com. For contact information of SOEHNLE representative in your country, visit www.soehnle.com. 12. Guarantee repair or replacement, for 3 years as of the date of purchase.
  • Page 23 Quality & Design by Leifheit AG Leifheitstraße 1 56377 Nassau / Germany Telefon +49 2604 977-0 +49 2604 977-300 www.soehnle.com...
