HV-FX7800
HV-FX5850
SERVICE MANUAL
STEREO VIDEO CASSETTE RECORDER <7800/5850>
VIDEO CASSETTE RECORDER <1700/1400/1100>
HV-FX7800
HV-FX5850
HV-GX1700
HV-GX1400
HV-GX1100
BASIC VIDEO MECHANISM
S/M Code No. 09-016-357-3N2
HV-GX1700, GX1400, GX1100
: D33Y1-4HF/PAL(6721RF0450A)<7800,5850>
: D33Y1-2HD/PAL(6721RF0405A)<1700,1400,1100>
K
K
K
K
K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HV-FX5850 and is the answer not in the manual?

Questions and answers

Related Manuals for Aiwa HV-FX5850

Summary of Contents for Aiwa HV-FX5850

  • Page 1 HV-FX7800 HV-FX5850 HV-GX1700 HV-GX1400 HV-GX1100 HV-FX7800 HV-FX5850 HV-GX1700, GX1400, GX1100 SERVICE MANUAL BASIC VIDEO MECHANISM STEREO VIDEO CASSETTE RECORDER <7800/5850> : D33Y1-4HF/PAL(6721RF0450A)<7800,5850> VIDEO CASSETTE RECORDER <1700/1400/1100> : D33Y1-2HD/PAL(6721RF0405A)<1700,1400,1100> S/M Code No. 09-016-357-3N2...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS ..............3 9. Head F/E ................86 ACCESSORIES LIST .............. 4 10. Base Assembly A/C Head ..........86 DISASSEMBLY INSTRUCTIONS ..........5 11. Brake Assembly S ............87 SERVICE POSITION ............... 6 12. Brake Assembly T ............87 VCR TEST TAPE INTERCHANGEABILITY TABLE ....

  • Page 3: Specifications

    SPECIFICATIONS <HV-FX7800, FX5850> <HV-GX1700, GX1400, GX1100> Video recording system Rotary 2 head helical scanning system Video recording system Rotary 2 head helical scanning system Video head Double azimuth 4 heads Video head 2 heads Tuner system Frequency synthesized tuner Tuner system Frequency synthesized tuner TV system TV system...

  • Page 4: Accessories List

    ACCESSORIES LIST -1/1 REF. NO PART NO. KANRI DESCRIPTION 1 S8-35R-P00-66V INSTRUCTION ASSY CFA929MI<78> 1 S8-35R-P00-66G INSTRUCTION ASSY CFA911MI<58> 1 S8-35R-P00-66K INSTRUCTION ASSY CCA200TI<11> 1 S8-35R-P00-66D INSTRUCTION ASSY CCA204TI<14> 1 S8-35R-P00-66E INSTRUCTION ASSY CCA209TI<17> 2 S7-11R-KP0-33A REMOTE CONTROLLER ASSY,CFA929M<78> 2 S7-11R-1P0-33A REMOTE CONTROLLER ASSY,FOR NOR<78>...

  • Page 5: Disassembly Instructions

    DISASSEMBLY INSTRUCTIONS -1/1 1. Top Case Removal 4. Mechanism Removal (see Fig. 3) 1) Remove 4 screws holding the top case. 1) Disconnect the drum FF cable from the connector (PMD01) on the Main C.B. 2. Panel Front Removal (see Fig. 1) 2) Disconnect the ACE head FF cable from the connector (P3D02) 1) Release 7 tabs, and then remove the panel front.

  • Page 6: Service Position

    SERVICE POSITION -1/1 To set the mechanism to the service position in active status: Insert a spacer as shown below: The service position can be set in the stable status without any defective contact. MAIN C.B MECHA SPARSER 60mm MAIN C.B D33 MECHANISM REAR PANEL SPARSER...

  • Page 7: Vcr Test Tape Interchangeability Table

    VCR TEST TAPE INTERCHANGEABILITY TABLE There are two types of the new allgnment tape CH-1B (for NTSC) and CH-2 (for PAL). On each tape four signals (1)-(4) are recorded for the times and in the order shown below. (1) : 8min. → (2) : 2min. → (3) : 5min. → (4) : 5min. The TTV-MP1 (for M-PAL), TTV-MS1 (for MESECAM) and TTV-S1 (for SECAM) allgnment tapes have the same contents as the previous tapes.
  • Page 8 ELECTRICAL MAIN PARTS LIST -1/3 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C326 87-015-681-080 CAP,E 10-16V C327 87-015-681-080 CAP,E 10-16V SI-CS2-416-00B IC,CAT24W16P C333 87-015-681-080 CAP,E 10-16V SI-FA8-082-00A IC,FAN8082 8P C337 87-015-698-080 CAP,E 4.7-50V SI-MCR-HI0-08A IC,HD6432197A37FX C339 87-015-698-080 CAP,E 4.7-50V...
  • Page 9 ELECTRICAL MAIN PARTS LIST -2/3 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C902 87-016-577-080 CAP,E 470UF-16V P3D01 S5-612-34W-000 GF120-10S-TS-A LGC 10P MP<78,58> C907 87-015-695-080 CAP,E 1.0-50V<78> P3D01 S5-612-34Z-000 CONN,3P<11,14,17> C912 87-016-577-080 CAP,E 470UF-16V<EXCEPT 11> P3D02 S6-30R-5S0-10A CONN,6P C956...

  • Page 10: Electrical Main Parts List ................................... 8

    ELECTRICAL MAIN PARTS LIST -3/3 REF. NO PART NO. KANRI DESCRIPTION SW902 S5-562-82C-000 SW,SKQNQED ALPS 5MM SW903 S5-562-82C-000 SW,SKQNQED ALPS 5MM SW904 S5-562-82C-000 SW,SKQNQED ALPS 5MM KEY-2 C.B PKM01 S5-618-44D-000 CONN,5P SW905 S5-562-82C-000 SW,SKQNQED ALPS 5MM SW906 S5-562-82C-000 SW,SKQNQED ALPS 5MM TYPE MODEL NAME SUFFIX SW907...

  • Page 11: Transistor Illustration

    TRNSISTOR ILLUSTRATION -1/1 E C B E C B E C B E C B KTC3205 KTA1267 2SA1980 KTC2804 2SC5343 SRA2203 SRC1203 2SC5344 KSR1003 KTA1268 SRC1201 -11-...

  • Page 12: Wire Harness Diagram

    WIRE HARENESS DIAGRAM -1/1 P7M01 PMD01 PDM01 A.MUTE "H" D.CTL TU.A.L M.GND TU.A.R DRUM BBE A.OUT.R MOTOR 12.3VA BBE A.LOUT NICAM/A2 C.B P7M02 <7800,5850> PMC01 PCM01 DATA MOTOR GND I-LIMIT CAPSTAN CAP CTL 13VA MOTOR CAP REV "L" TU.MONO.AUD 5.1V <7800,5850>...

  • Page 13: Block Diagram

    BLOCK DIAGRAM -1/8 (POWER SECTION) -13-...
  • Page 14 BLOCK DIAGRAM -2/8 (AUDIO/VIDEO SECTION) <HV-FX7800/FX5850> MOD.A.OUT POWER/ S2 V.IN "H" BUF.V.IN TUNER TU.V.IN OSD V.OUT SECTION A.MUTE "H" Q901 SYSTEM IIC CLK AUDIO CONTROL/ IIC DATA SERVO/OSD OUT(R) SECTION A.ENV <7800> IC801 LP REC MUTE "H" OUT(L) TDA9605H A.H/SW Hi-Fi AUDIO PROCESS IC9F1 NJM2233S...
  • Page 15 BLOCK DIAGRAM -3/8 (AUDIO/VIDEO SECTION) <HV-GX1700/GX1400/GX1100> <1100> BUF.V.IN TU.V.IN VIDEO OUT 1 POWER/ AUDIO/ TU.A.L AODIO OUT 1 TUNER VIDEO SECTION SECTION AUDIO OUT 2 MOD.A.OUT VIDEO OUT 2 <1700,1400> IC901 JK901(1/2) MM1443XJ INPUT SELECT SW E1.V E2.V IIC CLK 33 SCL SYSTEM CONTROL/...
  • Page 16 BLOCK DIAGRAM -4/8 (VIDEO SECTION) IC301 LA71598M Q304 AUDIO/VIDEO PROCESSOR MAIN C. COMB CONV LP ’A’ PB DELAY Q303 C LPF LP ’B’ PB SP ’B’ PB DE EMP SP ’A’ PB PB FM <7800,5850> IC7V1 LC74793 V. ENV DOUBLE VPS/PDC DECODER PB EQ SERIAL...

  • Page 17: 1700/1400/1100

    BLOCK DIAGRAM -5/8 (NORMAL AUDIO SECTION) <1700,1400,1100> SCART SECTION <7800,5850> IC301 LA71598HM AUDIO/VIDEO Hi-Fi AUDIO/ PROCESS SCART SECTION <1100> FL301,Q311 AUDIO IN 2 BIAS AUTO CONTROL LINE BIAS Q307 MUTE AUDIO IN 1 AUDIO RECPB MONO A.IN HEAD :REC AUDIO SIGNAL PKM01 PMK02 JK902...
  • Page 18 BLOCK DIAGRAM -6/8 (TUNER, NICAM/A2 SECTION) -18-...
  • Page 19 BLOCK DIAGRAM -7/8 (SYSTEM CONTROL/SERVO/OSD SECTION) <HV-FX7800/FX5850> MAIN (SYSTEM CONTORL/SERVO SECTION)C.B <7800,5850> <7800> 9MT168GK OPTB'H' 72,73 Hi-Fi AUDIO/ SCART SECTION LOADING MOTOR UPD16311GC-AB6 VFD DRIVER 83,107 19 OSD V.OUT 41 S2 V.IN"H" <7800> JK903 12.3V AUDIO-G DRUM MOTOR JK902 POWER/ PDM01 AUDIO-D ENTREE(AV 3)
  • Page 20 BLOCK DIAGRAM -8/8 (SYSTEM CONTROL/SERVO/OSD SECTION) <HV-GX1700/GX1400/GX1100> MAIN (SYSTEM CONTORL/SERVO SECTION)C.B <1700,1400,1100> <1700,1400> 72,73 LOADING SCART MOTOR <1700,1400> SECTION 83,107 12.3V JK902 AUDIO DRUM MOTOR POWER/ PDM01 ENTREE(AV 3) JK901 TUNER VIDEO SECTION <1700,1400> 84,108 13VA 12VA(L/D) IC501 HD6432197A37FX SYSCON/SERVO PROCESS 10P:<1700,1400>...

  • Page 21: Schematic Diagram 1. Power/Tuner/Nicam <7800/5850

    SCHEMATIC DIAGRAM - 1/12 (POWER/TUNER/NICAM SECTION) <HV-FX7800/FX5850> MAIN(POWER/TUNER SECTION)C.B <7800,5850> KTC3205 SYSTEM CONTORL/ SERVO/OSD SECTION 22uH (L/D) (DRUM) J146 SRA2203 Hi-Fi AUDIO/ KSR1003 SCART SECTION FILTER SRA2203 22uH SYSTEM CONTORL/ SERVO/OSD SECTION KTA1273 KTA1273 AUDIO/VIDEO SECTION Hi-Fi AUDIO/ HOT CIRCUIT SCART AC INPUT SECTION...

  • Page 22: Power/Tuner <1700/1400/1100

    SCHEMATIC DIAGRAM - 2/12 (POWER/TUNER SECTION) <HV-GX1700/GX1400/GX1100> MAIN(POWER/TUNER SECTION)C.B <1700,1400,1100> SYSTEM 22uH (L/D) CONTORL/ SERVO/OSD (DRUM) SECTION J146 SCART SECTION KSR1003 FILTER SRA2203 22uH SYSTEM CONTORL/ SERVO/OSD SECTION KTA1273 KTA1273 AUDIO/VIDEO SECTION KP1010 SCART SECTION 2SA1980G AC INPUT HOT CIRCUIT <1700,1400>...

  • Page 23: Voltage Chart 1. Power/Nicam Section

    VOLTAGE CHART - 1/4 (POWER/NICAM SECTION) VOLTAGE CHART - 2/4 (AUDIO/VIDEO SECTION) IC301 IC101 TRANSISTOR IC751 REC PIN REC PIN REC PIN Emitter Collector Base 2.44 2.42 2.41 2.52 2.93 2.92 3.43 3.43 5.06 4.86 4.17 2.44 2.42 3.16 3.14 3.31 3.32 0.03 0.04 Q151...

  • Page 24: Waveform Audio/Video Section

    WAVEFORMS-1/2 (AUDIO/VIDEO SECTION) IC301Pin IC301 Pin IC301 Pin IC301 Pin 31, 32, 38 4.2Vp-p 1.4Vp-p 500mVp-p 1Vp-p REC mode PB mode Video in PB/REC modes IC301 Pin IC301 Pin IC301 Pin IC301 Pin 2.2Vp-p 2.1Vp-p 400mVp-p 600mVp-p REC mode PB mode PB mode PB mode IC301 Pin...

  • Page 25: Audio/Video <7800/5850

    SCHEMATIC DIAGRAM - 3/12 (AUDIO/VIDEO SECTION) <HV-FX7800/FX5850> MAIN(AUDIO/VIDEO SECTION)C.B <7800,5850> (3/9) (4/9) (5/9) (6/9) FULL ERASE HEAD C344 0.01u SYSTEM CONTROL/ SERVO/OSD SECTION (2/9) AUDIO/CTR HEADS Hi-Fi AUDIO/ SCART SECTION CYL.HEADS (3/4) 5.1K (1/3) (1/3) (1/3) (1/3) (2/4) (1/3) <7800> (7/9) AUDIO/VIDEO PROCESSOR...

  • Page 26: Audio/Video <1700/1400/1100

    SCHEMATIC DIAGRAM - 4/12 (AUDIO/VIDEO SECTION) <HV-GX1700/GX1400/GX1100> MAIN(AUDIO/VIDEO SECTION)C.B <1700,1400,1100> (3/9) (4/9) (5/9) (6/9) FULL ERASE C344 HEAD 0.01u <1700,1400> <1100> SYSTEM CONTROL/ SERVO/OSD SECTION (2/9) AUDIO/CTR HEADS CYL.HEADS 4.7K (1/3) (1/3) (1/3) (1/3) (2/3) (1/3) <1700> (7/9) AUDIO/VIDEO PROCESSOR SYSTEM CONTROL/ SERVO/OSD...

  • Page 27: Hi-Fi Audio/Scart <7800/5850

    SCHEMATIC DIAGRAM - 5/12 (SCART SECTION) <HV-FX7800/FX5850> MAIN(Hi-Fi AUDIO/SCART SECTION)C.B <7800,5850> POWER/ AUDIO TUNER SECTION W101 OUT(R) SORTIE G OUT(L) SORTIE D AUDIO/ VIDEO SECTION /16V SYSTEM CONTROL/ JK901(1/2) SERVO/OSD SECTION <7800> Hi-Fi AUDIO PROCESSOR POWER/ TUNER SECTION SYSTEM CONTROL/ SERVO/OSD SECTION <7800>...

  • Page 28: Scart <1700/1400

    SCHEMATIC DIAGRAM - 6/12 (SCART SECTION) <HV-GX1700/GX1400> MAIN(SCART SECTION)C.B <1700,1400> POWER/ TUNER SECTION MM1443XJ INPUT SELECT SW JK901(1/2) 1u/50V SYSTEM CONTROL/ SERVO/OSD SECTION 1u/50V C9X1 1000P 1u/50V 22u/16V 1u/50V 1u/50V 1u/50V JK901(2/2) 1u/50V AUDIO/ VIDEO SECTION SYSTEM 1SS133 1SS133 CONTROL/ SERVO/OSD SECTION SRA2203...

  • Page 29: Scart <1100

    SCHEMATIC DIAGRAM - 7/12 (SCART SECTION) <HV-GX1100> MAIN(SCART SECTION)C.B <1100> POWER/ TUNER SECTION JK901 1u/50V C9X1 1000P C9M1 R9M1 0.1u AUDIO OUT 2 R9M2 3.9K AUDIO/ VIDEO SECTION SYSTEM 1SS133 1SS133 CONTROL/ SERVO/OSD SECTION SRA2203 AUDIO/ VIDEO VIDEO OUT 2 SECTION SRC1203 SRC1203...
  • Page 30 VOLTAGE CHART -3/4 (Hi-Fi AUDIO/SCART SECTION) IC801 11.9 12.0 IC801(TDA9605H) IC901 IC901(MM1443) 11.6 11.6 11.7 11.6 11.6 11.7 IC9F1 -30-...

  • Page 31: System Control/Servo/Osd <7800/5850

    SCHEMATIC DIAGRAM - 8/12 (SYSTEM CONTROL/SERVO/OSC SECTION) <HV-FX7800/FX5850> MAIN(SYSTEM CONTROL/SERVO/OSD SECTION)C.B <7800,5850> KEY 1 C.B KEY 2 C.B (2/3) PKM01 PKM02 9MT168GK (2/8) 10P:<7800> 5P:<5850> CAT24W16P EEPROM (2/5) (2/5) LOADING (3/8) MOTOR (4/5) (3/5) AUDIO/VIDEO SECTION (5/5) RESET <7800> DRUM MOTOR PDM01 OPTB 'H' HD6432197A37FX...

  • Page 32: System Control/Servo/Osd <1700/1400/1100

    SCHEMATIC DIAGRAM - 9/12 (SYSTEM CONTROL/SERVO/OSC SECTION) <HV-GX1700/GX1400/GX1100> MAIN(SYSTEM CONTROL/SERVO/OSD SECTION)C.B <1700,1400,1100> (2/3) (2/8) LTG-9935M-1 10P: <1700,1400> 5P: <1100> CAT24W16P EEPROM (4/8) (2/5) (2/5) (5/8) KEY 1 C.B (3/8) PKM02 (4/5) LOADING MOTOR (3/5) AUDIO/VIDEO SECTION (5/5) KEY 2 C.B PKM01 DRUM MOTOR PDM01...

  • Page 33: System Control/Servo/Osd Section

    VOLTAGE CHART -4/4 (SYSTEM CONTROL/SERVO/OSD SECTION) IC501 REC PIN REC PIN REC PIN 2.45 2.47 5.15 PULSE 3.37 3.37 1.44 2.54 2.54 2.42 2.42 PULSE PULSE 5.26 5.26 2.54 5.05 5.05 PULSE PULSE 103 PULSE PULSE 2.54 2.30 PULSE PULSE 2.78 2.79 104 PULSE PULSE 2.54...

  • Page 34: System Control/Servo/Osd Section

    WAVEFORMS -2/2 (SYSTEM CONTROL/SERVO/OSD SECTION) CTL+ CTL– V.H/SW DV-SYNC (IC501 Pin (IC501 Pin (IC501 Pin (IC501 Pin 1V/10mS 1V/10mS 1V/10mS 1V/100µS REC/PB modes QUE/REV modes V-IN (IC501 Pin (IC501 Pin (IC501 Pin (IC501 Pin 1V/1mS 1V/10mS 1V/10mS 500mV/20µS REC/PB mode REC/PB modes C-SYNC V-OUT...

  • Page 35: Fl Display/Led Display

    FL DISPLAY -1/1 <HV-FX7800/FX5850> LED DISPLAY -1/1 <HV-FX4200/GX1400/GX1100> • GRID ASSIGNMENT TIMER DIGIT 1 DIGIT 2 DIGIT 3 DIGIT 4 DIGIT 5 1A 1B 1C 2A 2G 2C 2D 2E 2F 2C 2H 2J 3A 3B 3C 3D 3E 3F 3G 3H 3J 4A 4B 4C 4D 4E 4F 4G 4H UP LP 5A 5B 5C 5D 5E 5F 5G 5H 5J •...

  • Page 36: Main C.b <7800/5850

    WIRING -1/7 (MAIN C.B) <HV-FX7800/FX5850> MAIN C.B <7800,5850> JK901 AC200 ~ 240V JK801 AUDIO 50Hz EURO AV2 P3D02 PMC01 PML01 PMD01 SORTIE DECODER P3D01 EURO AV1 AUDIO/CTR CAPSTAN MOTOR LOADIG MOTOR DRUM MOTOR AUDIO/ PDM01 HEADS PCM01 CYL. HEADS VIDEO <7800>...

  • Page 37: Main C.b <1700/1400

    WIRING -2/7 (MAIN C.B) <HV-GX1700/GX1400> JK901 MAIN C.B <1700,1400> AC200 ~ 240V EURO AV2 50Hz DECODER PMC01 PML01 P3D02 PMD01 P3D01 EURO AV1 CAPSTAN MOTOR LOADIG MOTOR DRUM MOTOR AUDIO/CTR AUDIO/ CYL. HEADS PCM01 HEADS VIDEO PDM01 <1700> TU701 ENTREE ANTENNE JK901(1/2) L702...

  • Page 38: Main C.b <1100

    WIRING -3/7 (MAIN C.B) <HV-GX1100> MAIN C.B <1100> AC200 ~ 240V 50Hz PMC01 PML01 PMD01 P3D02 JK901 P3D01 EURO AV1 CAPSTAN MOTOR LOADIG MOTOR DRUM MOTOR AUDIO/CTR AUDIO/ CYL. HEADS PCM01 HEADS VIDEO PDM01 TU701 ENTREE ANTENNE JK901 L702 AERIAL SORTIE ANTENNE C713...

  • Page 39: Nicam/A2 C.b <7800/5850

    WIRING -4/7 (NICAM/A2 C.B) <HV-FX7800/FX5850> NICAM/A2 C.B E C B E C B MAIN C.B MAIN C.B P7M01 P7M02 -39-...

  • Page 40: 7800/5850

    SCHEMATIC DIAGRAM -10/12 (KEY-1 C.B SECTION) <HV-7800/FX5800> KEY 1 C.B <7800,5850> SW903 SG5311 ONE-TOUCH PLAYBACK ONE-TOUCH PLAYBACK JK903 AUDIO-R JK902 AUDIO-L AV3 IN JK901 SW901 SW902 VIDEO SRC1201 CHAINE <7800> SW904 POWER STANDBY/ON MAIN C.B <5850> SYSTEM <7800> CONTROL/ SERVO/OSD SECTION PMK02 -40-...
  • Page 41 WIRING -5/7 (KEY-1 C.B) <HV-FX7800> KEY 1 C.B MAIN C.B PMK02 SW903,LED902 ONE-TOUCH PLAYBACK SW904 POWER STANDBY/ON E C B SW901 CHAINE SW902 JK903 JK902 JK901 AUDIO-R AUDIO-L VIDEO AV3 IN <HV-FX5850> KEY 1 C.B MAIN C.B PMK02 SW903,LED902 ONE-TOUCH PLAYBACK SW904 E C B...

  • Page 42: C.b <1700/1400/1100

    SCHEMATIC DIAGRAM -11/12 (KEY-1 C.B SECTION) <HV-GX1700/GX1400/GX1100> KEY 1 C.B <1700,1400,1100> SW903 SG5311 ONE-TOUCH PLAYBACK ONE-TOUCH PLAYBACK JK902 AUDIO AV3 IN JK901 SW901 SW902 VIDEO SRC1201 CHAINE <1700,1400> <1100> POWER MAIN C.B STANDBY/ON SYSTEM CONTROL/ SERVO/OSD <1700,1400> SECTION PMK02 -42-...
  • Page 43 WIRING -6/7 (KEY-1 C.B) <HV-GX1700/GX1400/GX1100> KEY 1 C.B MAIN C.B PMK02 5P <1100> 10P <1700,1400> SW903,LED902 ONE-TOUCH PLAYBACK <1700,1400> SW904 POWER STANDBY/ON E C B SW901 <1700,1400> CHAINE SW902 JK902 JK901 AUDIO-L VIDEO AV3 IN -43-...
  • Page 44 SCHEMATIC DIAGRAM -12/12 (KEY-2 C.B SECTION) KEY 2 C.B SW906 SW908 SW910 PAUSE/STILL PLAY STOP SW905 SW907 SW909 SW911 REC/OTR REW / / F.FWD EJECT MAIN C.B SYSTEM CONTROL/ SERVO/OSD SECTION PMK01 -44-...

  • Page 45: Key-2 C.b

    WIRING -7/7 (KEY-2 C.B) <HV-FX7800> <HV-GX1700/GX1400/GX1100> KEY 2 C.B KEY 2 C.B SW907 REW / SW908 PLAY SW908 PLAY SW911 SW909 EJECT / F.FWD SW910 SW911 STOP EJECT SW906 SW905 PAUSE/STILL REC/OTR SW905 SW906 REC/OTR PAUSE/STILL SW909 SW910 / F,FWD SW907 REW / MAIN C.B...

  • Page 46: Adjustment

    ADJUSTMENT Test Equipment 1. Servo Adjustment 1) PG Adjustment • Oscilloscope • Test Tape MODE MEASUREMENT POINT ADJUSTMENT POINT SPECIFICATION • AC Millivolt Meter TTV-P1 PLAY VIDEO OUT 'PLAY' KEY (SET) 6.5H ± 0.5H (TTV-P1) H/SW (W5D2, W5D3) 'O' KEY (REMOCON) Adjustment Location •...

  • Page 47: Ic Block Diagram

    IC BLOCK DIAGRAM -1/1 IC, LC74793 IC, FAN8082 IC, LA71598HM IC,FAN8082 DRIVER OUT PVCC PRE DRIVER VCTL SVCC BIAS VIN1 VIN2 LOGIC SWITCH IC, TDA9605H IC,STR-G6351L IC, MM1443XJ Vcc2 Vcc1 TUN-V V OUT1 E1-V V OUT2 75 Drive E2-V V OUT3 EXT-V 75 Drive TUN-L...

  • Page 48: Ic Description

    IC DESCRIPTION -1/4 (HD6432197A37FX) <HV-FX7800/FX5850> -1/3 Pin No. Pin Name Description SVss – Servo Block GND CTLref CTL amp reference CTL(+) PB CTL in/REC CTL out (+) CTL(–) PB CTL in/REC CTL out (-) CTL BIAS CTL amp bias voltage CTL FB CTL feedback SW control CTL AMP (O)
  • Page 49 IC DESCRIPTION -1/4 (HD6432197A37FX) <HV-FX7800/FX5850> -2/3 Pin No. Pin Name Description R/C IN Remote data input CT DETECT C + detect – Not connected – Not connected REC 'H' High out at REC mode OTPB 'H' OTPB 'H' T/UP REEL Take-up reel pulse in CAP.
  • Page 50 IC DESCRIPTION -1/4 (HD6432197A37FX) <HV-FX7800/FX5850> -3/3 Pin No. Pin Name Description CAP ACCEL Capstan control at slow I-LIMIT Capstan current control S. MONITOR2 – Not connected S. MONITOR1 – Not connected – Not connected – Not connected – Not connected –...
  • Page 51 IC DESCRIPTION -2/4 (HD6432197A37FX) <HV-GX1700/GX1400/GX1100> -1/3 Pin No. Pin Name Description SVss – Servo Block GND CTLref CTL amp. reference CTL (+) PB CTL in/REC CTL out (+) CTL (–) PB CTL in/REC CTL out (-) CTL BIAS CTL amp bias voltage CTL FB CTL feedback SW control CTL AMP (O)
  • Page 52 IC DESCRIPTION -2/4 (HD6432197A37FX) <HV-GX1700/GX1400/GX1100> -2/3 Pin No. Pin Name Description SE/MESECAM 'H' Osd control in secam/mesecam R/C IN Remote data input C + DETECT C + detect – Not connected VCR 'H' – Not connected REC 'H' High out at rec mode OTPB OTPB "H"...
  • Page 53 IC DESCRIPTION -2/4 (HD6432197A37FX) <HV-GX1700/GX1400/GX1100> -3/3 Pin No. Pin Name Description D. ADJ Drum control output during slow CAP ACCEL Capstan control at slow I-LIMIT Capstan current control S. MONITOR2 – Servo monitor 2(Not connected) S. MONITOR1 – Servo monitor 1(Not connected) SEG 1 LED segment "H"...
  • Page 54 IC DESCRIPTION -3/4 (MSP3417D-QG) -1/1 Pin No. Pin Name Description AVSUP – Analog power supply +5 V ANA IN+ IF inputt ANA IN- CTL(+) input/output TESTEN – Test pin (Not used) XTAL IN Crystal oscillator XTAL OUT Crystal oscillator – Test pin (Not used) D CTR OUT1 –...
  • Page 55 IC DESCRIPTION -4/4 (LC74793) -1/1 Pin No. Pin Name Description VSS1 – Connected to ground (ground of digital circuits) XTAL IN For the connection of crystal or capacitors of crystal oscillator, or external clock input XTAL OUT – CTRL1 L: Crystal oscillator; H: External clock input –...

  • Page 56: Electrical Troubleshooting

    ELECTRICAL TROUBLESHOOTING -1/17 1. Power Circuit(SMPS) (1) No 5.3VA. No 5.3VA. Replace the F101 Is the F101 normal? (Use the same Fuse). Is the BD101 normal? Replace the BD101. Is the R101 normal? Replace the R101. Does the oscillation waveform appear at Is Vcc(about 15~19V) permittable at the the IC101 Pin 1? IC101 Pin 4?
  • Page 57 ELECTRICAL TROUBLESHOOTING -2/17 7. Power Circuit(SMPS) (2) No 12VA.(Capstan) No 12VA. Does 5.3VA work normally? Check whether 5.3VA is out of order. Is the D109 normal? Replace the D109. Check 12VA Line of the MAIN C.B short. (3) No 12VT (CANAL, Buffer) No 12VT.
  • Page 58 ELECTRICAL TROUBLESHOOTING -3/17 2. Servo Circuit Unstable Video in PB Mode. Does the on screen noise level change periodically? Do CTL pulses appear at IC501 pin 8? Does the CFG divide Is the height of the CTL waveform appear at IC501 Head adjusted correctly? pin 9? Do the CTL pulses move...
  • Page 59 ELECTRICAL TROUBLESHOOTING -4/17 7. Power Circuit(SMPS) (4) No 5VT(5V) No 5VT(5V)(5VG). Is 5.3VA put into the Q152(Q151) Check whether 5.3VA is out of other. collector? Is the Q163(Q162) Base "H"? Check the µ-com Control. Is about 4.7V put into the Check the Q163(Q162) Q152(Q151) Base? whether it works normally.
  • Page 60 ELECTRICAL TROUBLESHOOTING -5/17 Capstan Motor Stopped. Does 12VA appear at PMD02 Pin 5? Does 2.8V appear at PMD02 Pin 4? Check Power. Check Connector and Capstan Does PWM wave appear at IC501 Motor Ass'y. Pin 108? Check the Components and foil Patterns Does the CFG signal appear at PMD02 Connected between IC501 Pin 108 and Pin 6?
  • Page 61 ELECTRICAL TROUBLESHOOTING -6/17 Drum Motor stopped. Does 12V appear at PMD01 Pin 4? Does 2.8V appear at PMD01 Pin 1? Check Power. Does Drum PWM appear at IC501 Pin Check Connector and Drum Motor Ass'y. 107? Check the Components and foil Pattern between IC501 Pin 107 and PMD01 Do DFG Pulses appear at PMD01 Pin 3? Pin 1 for shorts.
  • Page 62 ELECTRICAL TROUBLESHOOTING -7/17 Cassette tape loading is unstable. Is REG 12V applied to IC502 Pin 7? Is High signal applied to IC501 Pin 30 Check the power. when inserting the CST? Is 5.3V applied to R544? Does Low signal occur form IC501 Pin 72 Check the CST SW and Check the power.
  • Page 63 ELECTRICAL TROUBLESHOOTING -8/17 3. Y/C CIRCUIT (2) When the Y(Luminance) signal doesn't appear on the screen in PB Mode, Is 5V applied to the IC301 Check the line of the 5.2V Line. (Power Circuit) Pins 16, 40, 55, 58, 87? Is the I C Bus siganl applied Refer to 'SYSTEM I...
  • Page 64 ELECTRICAL TROUBLESHOOTING -9/17 3. System & Front Panel Circuit Auto stop. Does SW30 waveform appear at IC501 Pin 105? Do Take-up reel pulses Check the Drum Motor appear at IC501 Pin 49? Signal. Do Take-up reel pulses Change IC501. appear at the base of Q514? Does 5.3V appear at RS501.
  • Page 65 ELECTRICAL TROUBLESHOOTING -10/17 4. Y/C CIRCUIT (1) No Video in EE Mode, No Video in EE Mode Check the Video Input Does the Video signal Jack. appear at the IC301 Pin 38? (Line In Jack) Is 5V applied to the IC301 Check the 5V Line.
  • Page 66 ELECTRICAL TROUBLESHOOTING -11/17 3. Y/C CIRCUIT (3) When the C(Color) signal doesn't appear on the screen in PB Mode, Is 5V applied to the IC301 Check the line of the 5.2V Line. (Power Circuit) Pins 16, 40, 55, 58, 87? Is the Color Rotary signal Check the Color Rotary applied to the IC301...
  • Page 67 ELECTRICAL TROUBLESHOOTING -12/17 3. Y/C CIRCUIT (4) When the Video signal doesn't appear on the screen in REC Mode, Is the EE signal normal? Check EE Mode. Is 5V applied to the IC301 Check the line of the 5.2V Pins 16, 40, 55, 58, 87? Line.(Power Circuit) Does PB Mdoe operate Check PB Mode.
  • Page 68 ELECTRICAL TROUBLESHOOTING -13/17 5. Tuner/IF circuit (1) No picture on the TV screen No picture on the TV screen Does the Video signal at Is +30VT applied to Check 33VT line. the TU701 Pin24? TU701 Pin 16? Is +5VT applied to Check 5VT line.
  • Page 69 ELECTRICAL TROUBLESHOOTING -14/17 (2) No sound (Mono Model Only) No sound Check the Vcc of IC301 Pin 75. Check 5VT power. Check the Tuner Audio signal Chekc the signal flow from TU701 at IC301 Pin 76. Pin21 to IC301 Pin 76. Check the Audio signal at IC301 Pin 96.
  • Page 70 ELECTRICAL TROUBLESHOOTING -15/17 (3) No sound (Hi-Fi Model Only) No sound Check the Vcc of IC751 Pins 1, 19, 33. Check 5V power. Check the Tuner SiF signal at IC751 Pin 2. Check the Tuner Audio of TU701 Pin 22. Check the oscillator of IC751 Pins 5, 6.
  • Page 71 ELECTRICAL TROUBLESHOOTING -16/17 6. Hi-Fi Circuit (Hi-Fi Model Only) Hi-Fi Playback. Check the Vcc of No sound IC801.(Pins 34, 40) Check the Hi-Fi Selection Check power. Switch and the Tape quality. Is the RF Envelope at Is the Head switching signal Check IC501 Pin 106.
  • Page 72 ELECTRICAL TROUBLESHOOTING -17/17 Hi-Fi REC. It is impossible to record and playback Hi-Fi Audio signal. Check Vcc of IC801. (Pins 34,40) Check IC801 Pin 42(Data),Pin 43(CLOCK). Check Power. Do Audio signals appear at IC801 Check ports of µ-COM. Pins 16, 17? Do FM Audio signals appear at IC801 Check Audio input signal of IC801 Pin 36?

  • Page 73: Mechanical Exploded View 1/1

    MECHANICAL EXPLODED VIEW -1/1 JK901 TU701 (FX5850 Model) (FX7800 Model) (GX1700,GX1400,GX1100 Models) -73-...

  • Page 74: Mechanical Main Parts List 1/1

    MECHANICAL MAIN PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION 250 S1-10R-012-8U0 CASE,TOP ———— FRAME,MAIN 275 S9-30R-010-2A0 HOLDER LED ———— PANEL FRONT(929TP:FX7800Z)<78> ———— PANEL FRONT(911TP:FX5850Z)<58> ———— PANEL,FRONT FRONT(CCA200TP)<11> ———— PANEL,FRONT FRONT(CCA204TP)<14> ———— PANEL,FRONT FRONT(CCA209TI)<17> 283 S5-80R-V00-6S0 DOOR CST (CFA929MI)<78> 283 S5-80R-V00-1Q0 DOOR CST (911MI:FX5850K)<58>...
  • Page 75 COLOR NAME TABLE COLOR NAME TABLE Basic color symbol Color Basic color symbol Color Basic color symbol Color Black Cream Orange Green Gray Blue Transparent Blue Gold Pink Silver Titan Silver Brown Violet White Transparent White Yellow Transparent Yellow Metallic Blue Light Blue Transparent Green Dark Blue...

  • Page 76: Mechanism Exploded View 1/3~3/3

    MECHANISM EXPLODED VIEW -1/3 -76-...

  • Page 77: Mechanism Main Parts List 1/3~3/3

    MECHANISM MAIN PARTS LIST -1/3 REF. NO PART NO. KANRI DESCRIPTION 032 S1-41R-000-2C0 CHASSIS ASSY D33Y 100 S3-01R-003-2A0 PLATE ASSY TOP 101 S8-10R-006-8A0 BRACKET SIDE(L) ———— HOLDER SIDE(L) 104 S9-74R-001-9A0 GUIDE CST ———— HOLDER CST ———— HOLDER SIDE(R) ———— LEVER STOPPER(R) ————...
  • Page 78 MECHANISM EXPLODED VIEW -2/3 -78-...
  • Page 79 MECHANISM MAIN PARTS LIST -2/3 REF. NO PART NO. KANRI DESCRIPTION 001 S7-23R-D20-6B0 DRUM(CIRC) ASSY UPPER ASSY PAL<78,58> 001 S7-23R-D10-4B0 DRUM(CIRC) ASSY SUB D33-2CH SP<11,14,17> 002 S6-80R-B00-2A0 MOTOR(MECH) DRUM GVD-D33Y 003 S9-30R-010-8A0 HOLDER FPC(6CH)<78,58> 003 S9-30R-010-6A0 HOLDER FPC(2CH)<11,14,17> 004 S0-06R-002-0A0 CAP,FPC ————...
  • Page 80 MECHANISM EXPLODED VIEW -3/3 -80-...
  • Page 81 MECHANISM MAIN PARTS LIST -3/3 REF. NO PART NO. KANRI DESCRIPTION 032 S1-41R-000-2C0 CHASSIS ASSY D33Y 051 S4-00R-000-5A0 BELT CAPSTAN 052 S6-80R-A00-1A0 MOTOR(MECH) CAPSTAN F2QSB53 053 S9-74R-001-8A0 GUIDE RACK F/L 054 S4-70R-003-7A0 GEAR RACK F/L 055 S4-70R-003-3A0 GEAR DRIVE 056 S4-70R-003-2B0 GEAR,CAM 057 S4-70R-003-6B0 GEAR CONNECT...

  • Page 82: Deck Mechanism Parts Locations

    DECK MECHANISM PARTS LOCATIONS • Top View Pracedure Fig- Part Fixing Type Starting 1 Drum Assembly 3 Screws , Cap FPC A-1 2 Plate Assembly Top Two Hooks 3 Holder Assembly CST Chassis Hole Bracket Side 'L' 5 6 Bracket Assembly Door 4 Guide CST 2 Hooks...

  • Page 83: Deck Mechanism Disassembly

    DECK MECHANISM DISASSEMBLY (S2) Stator (S2) (S3) Drum Motor (S3) Rotor Drum Sub Assembly (Fig. A-1-1) Drum FPC (S1) (For Jog Shuttle Models) (S1) (S1) Optional Parts Holder FPC or Holder FPC or Holder FPC (only for 2HD Models) (only for 4HD-Mono Models) (only for 4HD-Hi-Fi Models) Cap FPC (Fig.
  • Page 84 DECK MECHANISM DISASSEMBLY Plate Assembly Top (Fig. A-2-1) Holder Assembly CST Lever Stopper(R) (Fig. A-2-2) Arm Assembly F/L (Fig. A-2-6) Arm F/L Lever Assembly S/W (Fig. A-2-7) (S4) (H5) Bracket Side (L) (S4) (Fig. A-2-4) Groove Gear Rack F/L Groove Bracket (For Jog Shuttle Models) Assembly Door...

  • Page 85: Plate Assembly Top

    DECK MECHANISM DISASSEMBLY 2. Plate Assembly Top (Fig. A-2-1) 1) Unhook the (H1) and separate the Left Side. 2) Unhook the (H2) and lift up the Plate Assembly Top. NOTE (1) When reassembling, confirm (A),(B) Part of the Plate (H4) Assembly Top is inserted to the (L),(R) Grooves of the (H3) Bracket Side(L) and Bracket Assembly Door.

  • Page 86: Arm Assembly Cleaner

    DECK MECHANISM DISASSEMBLY Arm Assembly Cleaner (Fig. A-3-1) (S5) Base Assembly A/C Head ( H1) (Fig. A-3-3) (Fig. A-3-2) Head F/E Fig. A-3 (For Jog Shuttle Models) NOTE (1) Place the Spring Lever S/W of the above (No.1) as 8. Arm Assembly Cleaner(Fig. A-3-1) original position.

  • Page 87: Brake Assembly S

    DECK MECHANISM DISASSEMBLY Spring S Brake Brake Assembly S (Fig. A-4-1) Arm Assembly Tension Reel T Spring Tension (Fig. A-4-5) Band Assembly Spring T Brake (Fig. A-4-3) Tension Reel S Brake Assembly T (Fig. A-4-2) (Fig. A-4-4) (For Jog Shuttle Models) Fig.

  • Page 88: Support Cst

    DECK MECHANISM DISASSEMBLY Opener Lid (Fig. A-5-3) Arm Assembly T/up (Fig. A-5-4) Assembly Pinch Base Assembly P4 (Fig. A-5-5) Support CST (Fig. A-5-1) (Fig. A-5-2) Fig. A-5 15. Support CST (Fig. A-5-1) NOTE 1) Break away the (A) part shown above Fig. A-5-1 from (1) When reassembling, confirm the opener lid is placed on the Embossing of the Chassis in the clockwise direction, the Hook(H1) of the Arm Assembly T/UP as below figure.

  • Page 89: Belt Capstan/Motor Capstan

    DECK MECHANISM DISASSEMBLY Belt Capstan (Fig. A-6-1) Motor Capstan Washer(W1) Clutch Assembly D33-K (Fig. A-6-3) (Fig. A-6-2) Washer(W2 ) Optional Parts Gear H-Up/D-K Gear Up/D-K Lever F/R (For Hi-Rewind Models) (For Normal Models) (Fig. A-6-4) Hook(H1) Spring Up/D Brake Assembly Capstan (For 4HD Models) (Fig.

  • Page 90: Bracket Assembly Jog

    DECK MECHANISM DISASSEMBLY Brake Assembly Capstan Hole (A)+(B) Barke Assembly Capstan Gear Cam (H2) (For 4HD Models) Spring Capstan (Fig. A-7-4) Hole (A) Guide Rack F/L (H1) (S4) Barke Assembly Jog (S4) (For Jog Shuttle Models) (Fig. A-7-2) Gear Rack F/L (Fig.

  • Page 91: Gear Drive/Gear Cam/Gear Connector

    DECK MECHANISM DISASSEMBLY Washer (W1) Gear Drive (Fig. A-8-1) Gear Cam Hole (B) (Fig. A-8-2) Brake Assembly Capstan (For 4HD Models) Gear Connector Hole (A) (Fig. A-8-3) Gear Connector Hole (A')+(A) Hole (B') Hole (A') Chassis Bracket Assembly L/D Motor Hole (B')+(B) (Fig.

  • Page 92: Gear Sector

    DECK MECHANISM DISASSEMBLY Washer (W1) Gear Sector (Fig. A-9-1) (S4) Base Tension Plate Slider (Fig. A-9-2) (Fig. A-9-3) Lever Tension (Fig. A-9-4) (For Jog Shuttle Models) Fig. A-9 29. Gear Sector (Fig. A-9-1) NOTE 1) Remove the Washer(W1) and lift up the Gear Sector. 30.

  • Page 93: Gear Assembly P3/Gear Assembly P2

    DECK MECHANISM DISASSEMBLY (Fig. A-10-1) Gear Assembly P3 Gear Assembly P3 Gear Assembly P2 (Fig. A-10-2) Gear Assembly P2 Chassis Optional Parts Base Assembly P2 Arm Assembly Idler Arm Assembly Idler Jog (Fig. A-10-4) (For Normal Models) For Jog Shuttle Models (Fig.

  • Page 94: Tools And Fixtures For Service

    DECK MECHANISM DISASSEMBLY • Tools and Fixfures for Service 1. Cassette Torque meter 2. Alignment tape 3. Torque gauge SRK-VHT-303(Not SVC part) (See figure below) 600g.Cm ATG 4. Torque gauge adaptor 5. Post height adjusting driver 6. + Type driver (∅ 5) Parts No: SV-TGO-030-000 (SMALL) SV-TGO-020-000 (LARGE)

  • Page 95: Deck Mechanism Adjustment

    DECK MECHANISM ADJUSTMENT 1.Mechanism Alignment Position Check Purpose:To determine if the Mechanism is in the correct position, when a Tape is ejected. Test Conditions (Mechanism Test Equipment/ Fixture Check Point Condition) • Mechanism and Mode Switch Position • Blank tape •...

  • Page 96: Preparation For Adjustment

    DECK MECHANISM ADJUSTMENT 2. Preparation for Adjustment (To set the Loading the Cassette without Tape. Cover the Holes of the End Sensors at the both sides of Deck Mechanism to the Loading state the Bracket Side(L) and Bracket Assembly Door to without inserting a Cassette Tape).

  • Page 97: Guide Roller Height Adjustment

    DECK MECHANISM ADJUSTMENT 4.Guide Roller Height Adjustment Purpose: To regulate the Height of the Tape so that the Bottom of the Tape runs along the Tape Guide Line on the Lower Drum. 4-1. Preliminary Adjustment Test Equipment/ Fixture Test Conditions (Mechanism Condition) Adjustment Point •...

  • Page 98: Audio/Control (A/C) Head Adjustment

    DECK MECHANISM ADJUSTMENT 5. Audio/Control (A/C) Head Adjustment Purpose: To insure that the Tape passes accurately over the Audio and Control Tracks in exact Alignment in both the Record and Playback Modes. 5-1. Preliminary Adjustment (Height and Tilt Adjustment) Perform the Preliminary Adjustment, when there is no Audio Output Signal with the Alignment Tape. Test Equipment/ Fixture Test Conditions (Mechanism Condition) Adjustment Point...

  • Page 99: Confirm That The Tape Passes Smoothly Between The Take-Up Guide And Pinch Roller

    DECK MECHANISM ADJUSTMENT 5-2. Confirm that the Tape passes smoothly then slowly turn the Tilt Adjustment Screw(C) in the Counterclockwise direction. between the Take-up Guide and Pinch Roller(using a Mirror or the naked eye). After completing Step 5-1.(Preliminary Adjustment), NOTE: check that the Tape passes around the Take-up Guide and Pinch Roller without Folding or Curling at the Top Check the RF Envelope after adjusting the A/C Head, if...

  • Page 100: Adjustment After Replacing Drum Assembly (Video Heads)

    DECK MECHANISM ADJUSTMENT 7. Adjustment after Replacing Drum Assembly (Video Heads) Purpose: To correct for shift in the Roller Guide and X value after replacing the Drum. Test Conditions Test Equipment/ Fixture Connection Point Adjustment Points (Mechanism Condition) • CH-1: PB RF Envelope •...

  • Page 101: Maintenance/Inspection Procedure

    MAINTENANCE/INSPECTION PROCEDURE 1 Check before starting repairs The following faults can be remedied by cleaning and oiling. Check the needed lubrication and the conditions of cleanliness in the unit. Check with the customer to find out how often the unit is used, and then determine that the unit is ready for inspection and maintenance.

  • Page 102: Required Maintenance

    MAINTENANCE/INSPECTION PROCEDURE 4. Supplies Required for Inspection and 2. Required Maintenance Maintence The recording density of a VCR(VCP) is much higher than that of an audio tape recorder. VCR(VCP) components must (1) Grease : Kanto G-311G (Blue) or equivalent be very precise, at tolerances of 1/1000mm, to ensure (2) Isopropyl Alcohol or equivalent compatiblity with other VCRs.

  • Page 103: Greasing

    MAINTENANCE/INSPECTION PROCEDURE (2) Periodic greasing 5-2) Greasing Grease specified locations every 5,000 hours. (1) Greasing guidelines Apply grease, with a cleaning patch. Do not use excess 1) Loading Path Inside & Top side 5) Lever Tension Groove grease. It may come into contact with the tape transport 2) Shaft 6) Clutch Assembly D33 Shaft or drive system.

  • Page 104: Mechanism Troubleshooting Guide

    MECHANISM TROUBLESHOOTING GUIDE 1.Deck Mechanism Auto REW doesn't work. Is the output of END sensor of supply side "H"? "H": more than 3.5V "L": less than 0.7V~1V Is the Vcc. voltage of End Check the syscon power. sensor 5V? Replace End sensor. Is the voltage across IR LED Replace LED.
  • Page 105 MECHANISM TROUBLESHOOTING GUIDE AUTO STOP. (PLAY/CUE/REV) Check aligment positions (page 95) Check spring Pinch. In Play/Cue/Rev is the pinch roller in contact with the capstan Is the output of DFG, DPG OK? Replace Drum Motor. shaft. Are there T/up and supply reel Check Servo, Syscon.
  • Page 106 MECHANISM TROUBLESHOOTING GUIDE In PB mode Tape Presence not sensed. Is the Pinch Roller attached Check Alignment positions to the Capstan Motor Shaft? (page 95) Does the T/Up Is the Belt ok? Replace the Belt. Reel turn? Check the clutch and the Idler Does the Capstan Motor turn? Assembly.

  • Page 107: Front Loading Mechanism

    MECHANISM TROUBLESHOOTING GUIDE 2. Front Loading Mechanism Cassette cannot be inserted. Is the Lever Switch Spring Replace or add the Does the Lever Switch work? damaged or omitted? Lever Switch Spring. Does the F/L switch work Replace F/L Switch. normally? Is the Vcc of Main P.C.Board Check syscon circuit.
  • Page 108 MECHANISM TROUBLESHOOTING GUIDE Cassette will not load. Does the CST insert? Does the opener Lid work? Replace the Opener Lid. Does the Gear Rack F/L work? Replace the Rear Rack F/L. Does the Opener Door work? Does the Arm Assembly F/L work? Is the opener Door assembled correctly? Does the L/D Motor work? Replace the Arm Assembly F/L.
