Rockville RXM-S30 Manual

Download this manual

65-C1294-MA 210*140mm 105g铜版纸 CE6767 CE6768 CE6775 CE6776

Need help?

Do you have a question about the RXM-S30 and is the answer not in the manual?

Page 1 65-C1294-MA 210*140mm 105g铜版纸 CE6767 CE6768 CE6775 CE6776...
Page 6 The RXM-S20 and RXM-S30 feature a marine pubic address system with microphone. Simply plug the microphone in to the 3.2mm jack and you are ready to to. The amplifier features talk-over functionality. When microphone is keyed music will fade to the background. When microphone is unkeyed, music slowly fades back in.
Page 7 4 CHANNEL AMP WITH 2 CHANNEL INPUT If your head unit has one pair of Left and Right RCA out put jacks, plug them in to RCA input Jacks 1 and 2 of the amplifier and set the input model switch to the 2CH position.
Page 8 4 CHANNEL AMP WITH 2 CHANNEL INPUT If your head unit has 2 pairs of RCA ouput jacks, input Front Left and Front Right in to Channels 1 and 2. Then attach radio output Rear Left and Rear Right to Channels 3 and 4.
Page 10 RXD-F20 RXD-F30 • RMS Power Ratings: • RMS Power Ratings: 600 Watts(4 x 150 Watts RMS) @ 2 Ohms 800 Watts(4 x 200 Watts RMS) @ 2 Ohms 800 Watts(2 x 400 Watts RMS) @ 4 Ohms Bridged 1200 Watts(2 x 600 Watts RMS) @ 4 Ohms Bridged...
Page 11 RXM-S20 RXM-S30 • RMS Power Ratings: • RMS Power Ratings: 600 Watts(4 x 150 Watts RMS) @ 2 Ohms 800 Watts(4 x 200 Watts RMS) @ 2 Ohms 800 Watts(2 x 400 Watts RMS) @ 4 Ohms Bridged 1200 Watts(2 x 600 Watts RMS) @ 4 Ohms Bridged 800 Watts(4 x 200 Watts RMS) @ 4 Ohms 1200 Watts(4 x 300 Watts RMS) @ 4 Ohms •...
Page 12 65-C1297-MA...
