e_kl577_17.fm Page -1 Friday, June 27, 2008 3:37 PM
smc PENTAX-DA
INTERCHANGEABLE LENS
OPERATING MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA 300mm f/4ED [IF] SDM and is the answer not in the manual?

Questions and answers

Related Manuals for Pentax DA 300mm f/4ED [IF] SDM

Summary of Contents for Pentax DA 300mm f/4ED [IF] SDM

  • Page 1 Page -1 Friday, June 27, 2008 3:37 PM smc PENTAX-DA INTERCHANGEABLE LENS OPERATING MANUAL...
  • Page 2 Please read this operating manual carefully before using the lens to ensure that it is used properly. In addition, also refer to your camera operating manual. smc PENTAX-DA lens can be used exclusively with PENTAX digital SLR cameras. This lens is not compatible with film SLR cameras.

  • Page 3: Using Your Lens Safely

    e_kl577_17.fm Page 1 Friday, June 27, 2008 3:37 PM USING YOUR LENS SAFELY Although we have carefully designed these lenses for safe operation, please pay special attention to items marked with the following symbols when using this product. WARNING This symbol indicates precautions that if not followed, could result in serious injuries to the user.

  • Page 4: Precautions And Lens Maintenance

    e_kl577_17.fm Page 2 Friday, June 27, 2008 3:37 PM PRECAUTIONS AND LENS MAINTENANCE 1. Storage and mildew prevention. • Take the lens out of the protective case or camera bag, and store it in a dry, well-ventilated place. • Avoid storing the lens in a poorly ventilated location such as a closet, wardrobe, drawer, vehicle, or where insect repellent or medicine is kept.

  • Page 5: Table Of Contents

    FOREWORD USING YOUR LENS SAFELY ................. 1 PRECAUTIONS AND LENS MAINTENANCE ............2 FEATURES OF THE smc PENTAX-DA LENS ............6 smc PENTAX-DA LENS ..................7 About the DA lens mount ..................8 About lenses with a supersonic motor ..............9 Precautions for using lenses equipped with a supersonic motor on ......................
  • Page 6 e_kl577_17.fm Page 4 Friday, June 27, 2008 3:37 PM Precautions on close-distance scale ..............21 ZOOM LENS ......................22 About the zoom ring ..................23 About the zoom lock switch ................24 MACRO LENS ....................... 25 Magnification Scale ................... 25 ATTACHING THE LENS HOOD ................
  • Page 7 Page 5 Friday, June 27, 2008 3:37 PM Compatibility table for PENTAX circular polarizing filters ........36 PRECAUTIONS WHEN USING THE LENS WITH A FLASH ....... 40 Built-in Flash ...................... 40 External Flash ....................40 Compatibility of DA Lenses with the Built-in Flash ..........42 TRIPOD MOUNT ....................

  • Page 8: Features Of The Smc Pentax-Da Lens

    Page 6 Friday, June 27, 2008 3:37 PM FEATURES OF THE smc PENTAX-DA LENS • The smc PENTAX-DA lens is an interchangeable lens specifically designed for digital cameras. Its image circle is specialized for the image sensor (23.5 x 15.7mm) and its optical system is optimized for the characteristics of digital images.

  • Page 9: Smc Pentax-Da Lens

    Page 7 Friday, June 27, 2008 3:37 PM smc PENTAX-DA LENS Focusing ring Lens hood attaching index Distance scale Distance scale window Depth-of-field scale Depth-of-field scale Distance index Mounting index Note: • The DA lens does not have an aperture ring. Aperture settings are controlled automatically as if set to the auto “A”...

  • Page 10: About The Da Lens Mount

    Page 8 Friday, June 27, 2008 3:37 PM About the DA lens mount The DA lens is an interchangeable lens specifically designed for the PENTAX digital SLR cameras. There are three mounts for the DA lens, the K and K...

  • Page 11: About Lenses With A Supersonic Motor

    e_kl577_17.fm Page 9 Friday, June 27, 2008 3:37 PM About lenses with a supersonic motor The lenses in the table below are equipped with internal supersonic motors. When mounted on a camera body that supports supersonic motors, the autofocus (AF) is quiet and smooth. •...

  • Page 12: Precautions For Using Lenses Equipped With A Supersonic Motor On The

    • How to Check and Update the Firmware Holding-down the MENU button while turning ON the will display the firmware version in the center of the display. Download and install the firmware update for the using the link below. • Firmware Download Page: http://www.pentax.jp/english/support/download_digital.html...

  • Page 13: Mounting And Removing The Lens

    e_kl577_17.fm Page 11 Friday, June 27, 2008 3:37 PM MOUNTING AND REMOVING THE LENS To mount the lens on the camera body Attach the lens while aligning the red dots on the lens and body, then turn the lens clockwise until it clicks in place.

  • Page 14: Lens Cap

    e_kl577_17.fm Page 12 Friday, June 27, 2008 3:37 PM LENS CAP Take off the lens cap by pressing the two tabs inward. Memo: • When not using the lens, be sure to attach the lens cap. • Attach the dedicated lens cap over the lens hood on the DA 21mm f/3.2 AL Limited, DA 35mm f/2.8 Macro Limited, DA FISH-EYE 10-17mm f/3.5-4.5ED [IF], and DA 70mm f/2.4 Limited.

  • Page 15: Attaching The Dedicated Lens Cap To Da 40Mm F/2.8 Limited

    e_kl577_17.fm Page 13 Friday, June 27, 2008 3:37 PM Attaching the dedicated lens cap to DA 40mm f/2.8 Limited First screw the dedicated hood onto the front of the lens, then screw the lens cap onto the lens hood.

  • Page 16: Focusing

    e_kl577_17.fm Page 14 Friday, June 27, 2008 3:37 PM FOCUSING Changing the Focus Mode Use the camera’s focus mode switch to change between the autofocus mode and manual focus mode. For details, refer to your camera operating manual. For the DA lens The focus mode switch on the DA lens is used to change between the autofocus and manual focus modes (the focus mode...

  • Page 17: Using Autofocus

    e_kl577_17.fm Page 15 Friday, June 27, 2008 3:37 PM Using Autofocus Set the focus mode to autofocus. Press the shutter release button halfway to autofocus. With the camera, you can also press the AF button to autofocus. See page 14 for information about changing the focus mode. Focusing with the OK Button With the camera set as explained below, autofocusing by pressing the shutter release button halfway...
  • Page 18 e_kl577_17.fm Page 16 Friday, June 27, 2008 3:37 PM CAUTION During autofocusing, the focusing ring of the following lenses will rotate. • To prevent malfunction, do not touch the focusing ring during autofocusing. Particularly be careful when the Focus Mode is set to AF.C (AF-continuous). The camera continues adjusting the focus while the AF button is pressed or the shutter release button is pressed halfway.

  • Page 19: Using Manual Focus

    e_kl577_17.fm Page 17 Friday, June 27, 2008 3:37 PM Using Manual Focus Set the focus mode to MF, and turn the focusing ring to focus manually. See page 14 for information about changing the focus mode. Using the Quick-Shift Focus System If the focus mode is set to autofocus, you can focus manually after autofocus is achieved.

  • Page 20: How To Use The Quick-Shift Focus System

    e_kl577_17.fm Page 18 Friday, June 27, 2008 3:37 PM How to use the Quick-Shift Focus System Using Autofocus Set the focus mode switch to autofocus, then press the shutter release button halfway to autofocus. With the camera, you can also press the AF button to focus. With the camera set as explained in “Focusing with the OK Button”...
  • Page 21 e_kl577_17.fm Page 19 Friday, June 27, 2008 3:37 PM CAUTION • When using the Quick-Shift Focus System, keep pressing the shutter release button (or AF button) after you achieve focus and before taking a picture. If you let go of the shutter release button before taking the picture, autofocus will operate all over again when you press the shutter release button again.

  • Page 22: Da 200Mm F/2.8Ed [If] Sdm, Da 300Mm F/4Ed [If] Sdm Focusing

    e_kl577_17.fm Page 20 Friday, June 27, 2008 3:37 PM DA 200mm f/2.8ED [IF] SDM, DA 300mm f/4ED [IF] SDM focusing • The mechanism does not allow the angle of rotation of the focusing ring and the distance scale to align while focusing.

  • Page 23: Precautions On Close-Distance Scale

    e_kl577_17.fm Page 21 Friday, June 27, 2008 3:37 PM Close-distance scale Precautions on close-distance scale (For DA 16-45mm f/4ED AL, DA 18-55mm f/3.5-5.6 AL II, DA18-55mm f/3.5-5.6 AL) In the close-distance scale range (the orange area on the distance scale), when shooting at the maximum aperture, image quality deterioration in the picture corners may result because of the optical characteristics of the lens.

  • Page 24: Zoom Lens

    e_kl577_17.fm Page 22 Friday, June 27, 2008 3:37 PM ZOOM LENS Focusing index Lens hood attaching index Focusing ring Distance scale Zoom ring Focal length scale Zoom index Mounting index...

  • Page 25: About The Zoom Ring

    e_kl577_17.fm Page 23 Friday, June 27, 2008 3:37 PM The zoom lens has a focusing ring on the front side and a zoom ring on the rear side. Turn the zoom ring to set the desired angle of view (lens focal length). Memo: •...

  • Page 26: About The Zoom Lock Switch

    e_kl577_17.fm Page 24 Friday, June 27, 2008 3:37 PM Red line LOCK LOCK About the zoom lock switch The DA 18-250mm f/3.5-6.3ED AL [IF] is equipped with a zoom ring lock. This prevents the lens from extending under its own weight while you are carrying the camera. Set the zoom ring to the widest angle (18mm).

  • Page 27: Macro Lens

    e_kl577_17.fm Page 25 Friday, June 27, 2008 3:37 PM MACRO LENS DA 35mm f/2.8 Macro Limited lens adjust focus from infinity to life-size [1x]. Magnification Scale The magnification is indicated by denominators on the distance scale. “5” indicates “1/5x”. When determining the magnification first, set the magnification in the manual focus mode and adjust focus by moving the camera closer or further from the subject.

  • Page 28: Attaching The Lens Hood

    Screw the hood on to the front of the lens to attach it. The hood is telescopic. Extend it fully to use it. Memo: The lens hood cannot be mounted on some circular polarizing filters that are not produced by PENTAX, depending on the type.

  • Page 29: Screw-On Type (Da 40Mm F/2.8 Limited Dedicated Lens Hood)

    e_kl577_17.fm Page 27 Friday, June 27, 2008 3:37 PM Lens hood attaching index Screw-on Type (DA 40mm f/2.8 Limited dedicated lens hood) Screw the hood on to the front of the lens to attach it. Bayonet Type When attaching the lens hood, align the index on the lens hood with the attaching index on the lens, and push both parts straight toward each other.

  • Page 30: Bayonet Type (Da 21Mm F/3.2 Al Limited Dedicated Lens Hood)

    e_kl577_17.fm Page 28 Friday, June 27, 2008 3:37 PM Lens hood attaching index Bayonet Type (DA 21mm f/3.2 AL Limited dedicated lens hood) When attaching the lens hood, align the index on the lens hood with the attaching index on the lens, and push both parts straight toward each other.

  • Page 31: About The Pl Filter Window

    e_kl577_17.fm Page 29 Friday, June 27, 2008 3:37 PM About the PL filter window If a circular polarizing filter is attached to the DA lens, you can easily turn the filter via the PL filter window on the bayonet-type hood. Lens with hood with a PL filter window - DA 14mm f/2.8ED [IF] - DA 50-135mm f/2.8ED [IF] SDM...
  • Page 32 e_kl577_17.fm Page 30 Friday, June 27, 2008 3:37 PM How to use the lens hood with polarizing filter window Remove the PL filter window cap by sliding it in the direction as shown above. Turn the outer rim of the circular polarizing filter from the PL filter window as shown above. Attach the PL filter window cap.

  • Page 33: Built-In Lens Hood

    e_kl577_17.fm Page 31 Friday, June 27, 2008 3:37 PM Built-in lens hood The following lenses have a lens hood built into the lens body. The hood cannot be removed from the lens. • DA FISH-EYE 10-17mm f/3.5-4.5ED [IF] • DA35mm f/2.8 Macro Limited (*) Lenses marked with an * have built-in sliding hoods which should be extended.

  • Page 34: Filters

    e_kl577_17.fm Page 32 Friday, June 27, 2008 3:37 PM FILTERS Make sure the filter size matches the lens, then screw the filter onto the front of the lens. Memo: • The compatible filter size for each lens is listed on pages 46-51. •...

  • Page 35: Attaching A Filter And The Dedicated Lens Hood To The Da 21Mm F/3.2 Al Limited Lens

    e_kl577_17.fm Page 33 Friday, June 27, 2008 3:37 PM Attaching a filter and the dedicated lens hood to the DA 21mm f/3.2 AL Limited lens It is possible to attach a 49mm diameter filter to the front of the DA 21mm f/3.2 AL Limited lens, but not when the dedicated lens hood is attached.

  • Page 36: Attaching A Filter And The Dedicated Lens Hood To The Da 70Mm F/2.4 Limited Lens

    With the DA 70mm f/2.4 Limited lens, attach the 49mm diameter filter to the front of the lens. To use it together with the dedicated lens hood, screw it on over the filter that is attached. Memo: • The lens hood cannot be mounted on some circular polarizing filters that are not produced by PENTAX, depending on the type.

  • Page 37: Circular Polarizing Filters And Vignetting

    PENTAX circular polarizing filters (currently not available) with various lenses. There are two types of PENTAX circular polarizing filters. The A type (on the left in the diagram below) and the B type (on the right in the diagram below). The B type filter is thinner than the A type filter.

  • Page 38: Compatibility Table For Pentax Circular Polarizing Filters

    Compatibility table for PENTAX circular polarizing filters * PENTAX circular polarizing filters are not currently available. * PENTAX does not produce a circular polarizing filter with a 62mm diameter that can be used with the DA 18-250mm f/3.5-6.3ED AL [IF].
  • Page 39 e_kl577_17.fm Page 37 Friday, June 27, 2008 3:37 PM Circular polarizing filter Circular polarizing filter (A type) (B type) Lens Compatibility Notes Compatibility Notes *Can be mounted and used. However, when the A type DA 200mm f/2.8ED [IF] SDM of circular polarizing filter is mounted, the mount of the *YES dedicated bayonet hood...
  • Page 40 DA 55-300mm f/4-5.8ED mounted on that. *1 The lens hood cannot be mounted on some circular polarizing filters that are not produced by PENTAX, depending on the type. *2 Vignetting occurs at focal lengths below 15mm with other PENTAX filters (such as the Skylight) besides circular polarizing filters.
  • Page 41 e_kl577_17.fm Page 39 Friday, June 27, 2008 3:37 PM Memo: • Filters, including circular polarizing filters, cannot be mounted on the DA FISH-EYE 10-17mm f/3.5-4.5ED [IF] lens.

  • Page 42: Precautions When Using The Lens With A Flash

    e_kl577_17.fm Page 40 Friday, June 27, 2008 3:37 PM PRECAUTIONS WHEN USING THE LENS WITH A FLASH Built-in Flash The built-in flash can not be used when the distance is less than 0.7m. When the flash is used within 0.7m, it causes incorrect exposure control and vignetting in the picture corners. •...
  • Page 43 Page 41 Friday, June 27, 2008 3:37 PM DA 12-24mm f/4ED AL [IF] PENTAX external flash units which cover a 24mm lens on a 35mm SLR, or 16mm lens on a digital SLR, can be used when the lens is set from 16mm to 24mm.

  • Page 44: Compatibility Of Da Lenses With The Built-In Flash

    e_kl577_17.fm Page 42 Friday, June 27, 2008 3:37 PM Compatibility of DA Lenses with the Built-in Flash Compatibility Lens DA 14mm f/2.8ED [IF] DA 21mm f/3.2 AL Limited DA 35mm f/2.8 Macro Limited DA 40mm f/2.8 Limited DA 70mm f/2.4 Limited DA 200mm f/2.8ED [IF] SDM DA 300mm f/4ED [IF] SDM DA FISH-EYE 10-17mm...
  • Page 45 e_kl577_17.fm Page 43 Friday, June 27, 2008 3:37 PM Except for the DA 35mm f/2.8 Macro Limited, DA 70mm f/2.4 Limited, DA 40mm f/2.8 Limited and DA 21mm f/3.2 AL Limited, do not use the lens hood when using the built-in flash. This is to prevent obstruction of the flash coverage by the lens hood.

  • Page 46: Tripod Mount

    e_kl577_17.fm Page 44 Friday, June 27, 2008 3:37 PM TRIPOD MOUNT 300mm f/4ED [IF] SDM is equipped with the tripod mount. To position the camera vertically or horizontally, loosen the camera position shift lock screw, turn the camera 90° to the right or left as desired, and tighten the lock screw firmly.

  • Page 47: Removing The Tripod Mount

    e_kl577_17.fm Page 45 Friday, June 27, 2008 3:37 PM Removing the Tripod Mount To remove the mount, use a coin to loosen the screw by turning it to the left. Be careful not to loosen the screw too much or else it may fall out. Insert a coin into the slot on the screw and turn to the left.

  • Page 48: Main Specifications

    Page 46 Friday, June 27, 2008 3:37 PM MAIN SPECIFICATIONS * For use with any PENTAX digital SLR camera. * AL = Uses an aspheric lens, ED = lens made with extra-low dispersion glass, IF = inner focus-type lens,...
  • Page 49 e_kl577_17.fm Page 47 Friday, June 27, 2008 3:37 PM Lens DA 40mm f/2.8 Limited DA 70mm f/2.4 Limited DA 200mm f/2.8ED [IF] SDM 40mm (equivalent to approx. 70mm (equivalent to approx. 200mm (equivalent to approx. Focal length 61mm in 35mm format) 107mm in 35mm format) 307mm in 35mm format) Elements in groups 5-4...
  • Page 50 e_kl577_17.fm Page 48 Friday, June 27, 2008 3:37 PM DA FISH-EYE 10-17mm f/3.5- Lens DA 300mm f/4ED [IF] SDM DA 12-24mm f/4ED AL [IF] 4.5ED [IF] 12-24mm (equivalent to 300mm (equivalent to approx. 10-17mm (35mm conversion Focal length approx. 18.5-37mm in 35mm 460mm in 35mm format) not possible) format)
  • Page 51 e_kl577_17.fm Page 49 Friday, June 27, 2008 3:37 PM DA 16-50mm f/2.8ED AL [IF] Lens DA 16-45mm f/4ED AL DA 17-70mm f/4 AL [IF] SDM 16-45mm (equivalent to 16-50mm (equivalent to 17-70mm (equivalent to Focal length approx. 24.5-69mm in 35mm approx.
  • Page 52 e_kl577_17.fm Page 50 Friday, June 27, 2008 3:37 PM DA 18-250mm f/3.5-6.3ED AL DA 18-55mm f/3.5-5.6 AL ΙΙ Lens DA18-55mm f/3.5-5.6 AL [IF] 18-55mm (equivalent to 18-55mm (equivalent to 18-250mm (equivalent to Focal length approx. 27.5-84mm in 35mm approx. 27.5-84mm in 35mm approx.
  • Page 53 e_kl577_17.fm Page 51 Friday, June 27, 2008 3:37 PM DA 50-135mm f/2.8ED [IF] Lens DA 50-200mm f/4-5.6ED DA 55-300mm f/4-5.8ED 50-135mm (equivalent to 50-200mm (equivalent to 55-300mm (equivalent to Focal length approx. 76.5-207mm in 35mm approx. 76.5-306mm in 35mm approx. 84.5-460mm in 35mm format) format) format)
  • Page 54 e_kl577_17.fm Page 52 Friday, June 27, 2008 3:37 PM Memo...
  • Page 55 e_kl577_17.fm Page 53 Friday, June 27, 2008 3:37 PM Memo...
