Summarization of Contents
Safety Instructions
Intended Use
Details the product's intended application and mounting requirements.
Device Variants
a. Audio Module
Core element for functioning combinations, includes terminals and storey call button.
b. Standard Push-button Module
Used for operation or adding buttons; inscription field is not illuminated.
c. Universal Push-button Module
For audio/video systems, extra buttons; inscription field is illuminated.
d. Video Module
Displays camera images from the connected door station.
Functioning Combinations
Explains how modules a-d can be combined into functional devices.
Accessories
Connection Cable 700 mm
Optional cable for positioning modules up to 500 mm apart.
Individual Inscription Covers
Covers for design F50 push-button modules for custom inscription.
Dismounting Protection
Accessory to secure modules, requiring a tool for detachment.
Product Characteristics: Modules
Standard Push-button Module
Features include LEDs, inscription field, and audio cable.
Universal Push-button Module
Features include illuminated inscription field and connection options for supply/modules.
Video Module 2.2"
Specifies TFT monitor, resolution, brightness, and colour settings.
Audio Module
Can be used as a signal unit; features 2-wire installation and polarity reversal protection.
Audio Module and Indoor Station Features
Audio Module Features
Details parallel switching, sound quality, microphone, connections, and volume adjustments.
Audio Indoor Station
Covers functions like speech, door release, call silencing, and configurable buttons.
Audio and Video Indoor Station Functions
Audio Indoor Station Functions
Details intercom functions, group formation, and status indications.
Video Indoor Station
Lists TFT monitor, resolution, brightness/colour settings, and functions like speech/vision.
Video Indoor Station Functions and Capabilities
Video Indoor Station Functions
Describes switching functions, privacy, parallel switching, and intercom capabilities.
Operation
Accepting Door Calls
Procedure for answering a visitor's call using the speech button.
Actuating the Door Release
How to operate the door release mechanism after a call.
Switching Off the Ring Tone
Method to mute or silence the ring tone using the mute button.
Switching On the Light
How to activate the lighting function via the light button.
Dialling the Door Station
Making a speech connection to the door station.
Voice Volume
Adjusting the voice volume using the mute and light buttons.
Switching Over the Speech Direction
Manually switching speech direction if automatic function fails.
Inscription Field Illumination
Turning the inscription field illumination on or off with the light button.
Configuration
Ring Tone Volume
Steps to set the ring tone volume in 5 different steps.
Ring Tone Melody
Instructions for choosing between 11 available ring tone melodies.
Button Assignment
Explains how buttons can be assigned for internal calls or control functions.
Video Functions Configuration
Switching On the Monitor
How to display the camera picture from the door station.
Setting the Brightness
Adjusting video image brightness to 7 different levels.
Setting the Colour
Adjusting video image colour to 7 different levels.
Setting the Microphone Sensitivity
Adjusting microphone sensitivity for clear speech transmission.
Mounting
Recommended Mounting Height
Specifies the recommended installation height for the indoor station.
Module Installation
Describes mounting modules in flush-mounting junction boxes using supporting frames.
Rear View and Mounting Options
Mounting Combinations
Details mounting in combination or individually, horizontally or vertically.
Cable Connection Points
Illustrates interconnection of modules and connection to the In-Home bus.
Connecting the Cables
Cable Type and Connection
Specifies telecom cable type J-Y (St) Y and connection procedure.
Terminal Assignment: Audio Module
Details terminal labels (TaM/TbM, ERT/Etb) for the audio module.
Terminal Assignment: Universal Push-button Module
Details terminal labels (M+/M-) for supplementary supply on the universal module.
