- Page 1 STREAMIT INTERNET RADIO Streamit Internet Radio SIR series of devices User’s manual ENGLISH User’s manual May 2008 Version 1.0...
- Page 2 Streamit Internet Radio SIR series of devices User’s manual ENGLISH Version: 1.0 Date: May 2008...
- Page 4 Copyright ©2008 Streamit All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the written permission of Streamit. No patent liability is assumed, with respect to the use of the information contained herein. Disclaimer This manual has been validated and reviewed for accuracy.
-
Page 5: Table Of Contents
STREAMIT INTERNET RADIO Contents GETTING STARTED ......................4 …....................4 IRST AND FOREMOST .......................4 SUPPORT .......................4 EFERENCES ....................5 NPACKING YOUR DEVICE ........................5 ACK VIEW ........................5 RONT ......................6 OTTOM INSTALLATION........................7 .......................7 ACK MOUNT 2.1.1 Mounting a single SIR in a 19 inch rack ..............7 2.1.2... -
Page 6: Getting Started
1 Getting Started 1.1 First and foremost… thank you for purchasing the Streamit Internet Radio (SIR). We greet you as a new user of the Streamit products and hope that your new Internet Radio Device will give you many years of pleasure. -
Page 7: Unpacking Your Device
1 x 12V-500mA power supply with screw-on connector 1 x USB-AB cable 1 x User manual (this one) 1.5 Back view Figure 1.1: Streamit Internet Radio back view A – External Protective Earth connector E – Left RCA audio (cinch) connector B – RJ45 Ethernet connector F –... -
Page 8: Bottom View
Q – Streamit logo M – 2x16 characters LCD display R – Source control button 1.7 Bottom View Figure 1.3: Streamit Internet Radio bottom view S – Product sticker U – 4 x chassis mount openings T – 4 x rubber feet User’s manual... -
Page 9: Installation
19 inch racks. For rack mounting, the SIR Rack- mounting Kit is required. This kit can be ordered from Streamit or official Streamit dealers and contains 5 mounting plates in total as shown below in Figure 2.1. Using combination of these plates, it is possible to mount either one or two SIR radios in a 19”... -
Page 10: Mounting Two Sirs In A 19 Inch Rack
STREAMIT INTERNET RADIO 2.1.2 Mounting two SIRs in a 19 inch rack Mounting two SIR devices in a 19’’ rack requires using the two SIR-SIR mounting plates and the two small side mounting plates. Mounting the side plates is done in the same way as when mounting a single SIR (please see §... -
Page 11: Connecting Your Sir
STREAMIT INTERNET RADIO 2.2 Table Mount When used in an office environment the SIR could be placed on your office desk, next to your PC, while in a professional environment your SIR would typically be mounted in a rack. 2.3 Connecting your SIR Despite where you use your SIR and how it is mounted, it is important that you connect it properly. -
Page 12: Connecting The Ethernet Cable
USB cable is plugged in the device, while the A-connector is intended for connecting to your Windows PC. Before making this connection we recommend that the Streamit Terminal Program is first installed. For more information on STP, including installation and user manual, please see [1]. -
Page 13: The Configuration Wizard
STREAMIT INTERNET RADIO 2.4.1 The Configuration Wizard Step 1: Language setting As default the wizard will start with [English]. Press OK to confirm the language preference (in this case [English]). You could also choose between [Dutch] and [German] by using the menu up/down buttons. -
Page 14: Playing From A Stream
The first update check is performed on the software; should a newer version be available from Streamit’s update server, the SIR will update to this version. You do not need to do anything in the meanwhile, but wait for the update to finish. -
Page 15: The Mmc/Sd/Sdhc Card
Ethernet connection or with the stream that is being played, the SIR will automatically switch to the card and starts playing from there. Streamit is currently looking at the possibility to expand the card functionalities even further. For more up-to-date information on this topic, please visit our website. -
Page 16: Choosing To Turn The Keylock On From The Configuration Wizard
STREAMIT INTERNET RADIO Step 2.4: Network Mask setting Enter the net-mask you would like to assign your SIR radio. We recommend that the default (255.255.255.255) is used. Use the Menu-Left/Menu-Right to move the cursor and the Menu-Up/Menu-Down to respectively increase or decrease the values. - Page 17 STREAMIT INTERNET RADIO Step 6.2: Enter new PIN To lock your device’s keypad a four digits PIN has to be entered. Every digit will have the value 1-5 because the preset buttons are used to enter the pin. After entering you PIN code, press OK button to confirm.
-
Page 18: Sir Configuration - Setup Menu
STREAMIT INTERNET RADIO SIR Configuration – Setup menu It is possible to use your SIR’s setup menu to manually change configurations of your device. The menu of your SIR is accessed by pressing the OK and Escape buttons together while the device is in powered off state. -
Page 19: Changing Volume Setting
STREAMIT INTERNET RADIO 3.3 Changing volume setting The output volume level of your SIR radio is represented in numerical format as 0-32. The numerical value 0 corresponds to the minimum volume level, while 31 to the maximum. You can change the volume level from the [Volume] menu. -
Page 20: Changing Bass Setting
STREAMIT INTERNET RADIO 3.4 Changing bass setting The output bass level of your SIR radio is numerically represented from values 0-16 with 0 as the minimum and 16 as maximum bass. You can change the bass level from the [Bass] menu. -
Page 21: Turning Keylock On
STREAMIT INTERNET RADIO 3.6.1 Turning Keylock ON You can turn the Keylock ON from the [Keylock] menu as follows: Enter the [Setup] and browse until you find the [Keylock] option. Press OK to access this menu which allows you to choose between the two available options;... -
Page 22: Forcing Keylock Off
3.6.3 Forcing Keylock OFF Should it happen that you forget your PIN code it is not possible to recover it. In case such a scenario applies the Streamit Terminal Program must be used to force the Keylock OFF. See [1] for more information. -
Page 23: Service Menu
Your SIR also shows you the version it is running; in this example version 00.03.04. It is sometimes important for the technical support people at Streamit to know this information, in order to help you properly in case help is required. - Page 24 STREAMIT INTERNET RADIO OK for reset to start. On the LCD the text “Resetting…” is show. The device will then enter the wizard mode. User’s manual May 2008 Version 1.0...
