Body Masters CM 292 Instruction Manual
  1. Manuals
  2. Brands
  3. Body Masters Manuals
  4. Fitness Equipment
  5. CM 292
  6. Instruction manual

Body Masters CM 292 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

W A R N I N G
IT IS THE OWNER/MANAGER'S RESPONSIBILITY TO INSURE THAT ALL USERS OF BODY MASTERS
EQUIPMENT BECOME FAMILIAR WITH THE CONTENTS OF THIS MANUAL, AND TO INSTRUCT USERS ON
THE PROPER OPERATION OF THE EQUIPMENT AND TO WARN THEM OF THE POTENTIAL HAZARDS.

Prior to Exercising:

CONSULT YOUR PHYSICIAN:
The exercise techniques described by Body Masters should not be used without prior consultation and recommendation of a medical
doctor. We do not guarantee or warrant the safety of the techniques described herein! If at any time during exercise user feels faint,
dizzy, or experiences pain, stop and consult your physician.
USE A CERITIFIED TRAINER!
Always consult a Certified Trainer to familiarize you with the exercise machine's performance characteristics and proper use!
Be certain that you are familiar with the specific working functions of the exercise machine!
APPRECIATE THE RISKS!
Read carefully all warnings and instructional material on the exercise equipment! If you have any questions, consult the authorized
personnel before use!
Be certain that weight stack pins are completely inserted!
Inspect machine carefully for any worn, loose, or missing parts! If any defect is suspected, do not use! Report suspected problem to
authorized personnel immediately! Pay close attention to belts, cables, and their connections!
Never use dumbbells or other means to increase the intended weight resistance!
Utilize the selected exercise equipment only for its intended purpose!
Do not wear loose or dangling clothing or jewelry while using equipment. Stay clear of all moving components!
Use a competent spotter whenever exercising on any piece of Free Weight Equipment!
Keep children away from the equipment!
Never pin the weight stack while stack is in an elevated position! Do not use any machine found in this condition!
BE PREPARED TO EXERCISE!
Always warm-up adequately prior to engaging in any weight training exercise!
Know how to properly perform the desired exercise! Be sure that you are familiar with safe exercise technique! When in doubt, con-
sult a Certified Trainer.
Know your limitations! Never exceed your known performance capabilities! When in doubt, consult a Certified Trainer.

EQUIPMENT MAINTENANCE

Follow carefully the maintenance schedule recommended in your maintenance and warranty manual.
Setup and operate equipment on a solid, level surface.
The safety and integrity designed into the equipment can only be maintained when the equipment is regularly examined for damage
and repair! It is the sole responsibility of the owner/user/facility operator to ensure that regular maintenance is performed!
Worn or damaged components shall be replaced immediately or the equipment removed from service until the repair is made. Only
manufacturer supplied components shall be used to maintain/repair the equipment.
FAILURE TO COMPLY WITH THESE GUIDELINES COULD
RESULT IN SERIOUS INJURY OR EVEN DEATH!
For Any Questions Regarding Maintenance, Please Call Our Customer Service Hotline:
1-800-325-8964
