Touch T414S Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

T214B
T314B
T414S
OWNER'S MANUAL
T214B T314B T414S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T414S and is the answer not in the manual?

Questions and answers

Related Manuals for Touch T414S

Summary of Contents for Touch T414S

  • Page 1 T214B T314B T414S OWNER’S MANUAL T214B T314B T414S...

  • Page 2: Important Safeguards

    3. Install the brewer in proper location as instructed in this manual. 4. Do not use accessory parts not recommended by Touch Coffee & Beverages, LLC. Using unauthorized accessory parts may result in fire, electrical shock or injury to persons.

  • Page 3: Save These Instructions

    SAVE THESE INSTRUCTIONS Warning to user and parents 1. Brewer injects EXTREMELY HOT WATER! DO NOT let children use the brewer without adult supervision. 2. After brewing cocoa or soluble, IMMEDIATELY RUN an 8 oz. brew cycle without the Pod in the brewer to rinse the brewer. This will avoid clogging up the two Needles in the Red Cup Holder.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Using Touch’s T214B / T314B / T414S Brewing System PART 1. SET-UP Helpful Hints ................................Unpacking Instructions ............................. Product Features ..............................PART 2. BREWING A CUP Setting Up Your Brewer ............................Ready to Brew Your First Cup ..........................

  • Page 5: Part 1. Set-Up

    We recommend you save all packing materials in case future shipping of the product is necessary. WARNING: Keep all plastic bags away from children. Touch Coffee & Beverages is NOT affiliated with Keurig, Inc. Keurig® and K-Cup® are register trademarks of Keurig, Inc.

  • Page 6: Product Features

    PART 1. SET-UP Product Features T214B, T314B, T414S Brewer parts Controls and Indicators T214B Cover Power Button Cover Handle Low Water Indicator Red Cup Holder Brewing Indicating Light Deep Well 6 oz Button T314B Housing 8 oz Button T414S Power Cord...

  • Page 7: Part 2. Brewing A Cup

    PART 2. BREWING A CUP Setting Up Your Brewer IMPORTANT: DO NOT use the brewer until it has been set-up for its first use. NOTE: If the brewer has been exposed to temperatures below freezing, allow the brewer at least two hours to reach room temperature before using it. A frozen or extremely cold brewer may not operate properly.
  • Page 8 PART 2. BREWING A CUP Setting Up Your Brewer (Continued) CAUTION: DO NOT pull the Latch to open the Cover during the brewing period. (Fig. 4) CAUTION: Extremely Hot Water! (Fig. 5) 8. With the cover closed, press the 10 oz Button to start the brewing cycle. (Fig. 5) The brewing indicating light on the upper right corner will stay ON while the brewer is warming up.

  • Page 9: Ready To Brew Your First Cup

    NOTE: If you do not push a cup size button to start brewing within 60 seconds, the brewer will be disabled to prevent accidental activation. Re-activate the Brewer by pulling on the Latch and Closing the Cover again. T214B T314B / T414S Fig.
  • Page 10 PART 2. BREWING A CUP Ready to Brew Your First Cup (Continued) 5. The upper right brewing indicating light will stay ON during warm up, and the light will BLINK during the brewing cycle. (Fig. 10) CAUTION: The brewer will heat the water EXTREMLY HOT during the brewing process. To avoid risk of injury, do not pull on the Latch or open the Cover while brewing.

  • Page 11: Stopping The Brew Process

    PART 2. BREWING A CUP Stopping the Brew Process If you need to stop the brewing process for any reason, then press on the Power Button to turn OFF the brewer. NOTE: If the brewer is turned ON after terminating the previous brewing process, the next brewing cycle may NOT brew a full cup. We recommend performing a brewing cycle without the POD, and then restart the brewing cycle with a POD in the Red Cup Holder.

  • Page 12: Adding Water

    PART 2. BREWING A CUP Adding Water The upper left blue Low Water Light will blink when the water level in the Water Tank is low or if the Water Tank has been removed. (Fig. 13) The brewer will not allow you to brew while the blue Low Water light is blinking. The brewer will shut off automatically if the Water Tank is not refilled within about 2 minutes. The Water Tank can be filled in two ways.

  • Page 13: Part 3. Maintenance

    PART 3. MAINTENANCE Cleaning External Parts We recommend regularly cleaning the brewer’s external components. CAUTION: Only use a moist cloth and if necessary a mild detergent (never use abrasive or aggressive detergents). Do not wash machine parts in the dishwasher. (Fig. 16) 1.

  • Page 14: Cleaning The Red Cup Holder

    PART 3. MAINTENANCE Cleaning the top Needle (Continued) CAUTION: Top Needle is very sharp. To avoid risk of injury, do not directly touch this Needle with your finger. (Fig. 18) Cleaning the Red Cup Holder 1. Open the Cover, and remove the Red Cup Holder from the brewer by pulling on it. (Fig.19) 2.

  • Page 15: Cleaning The Water Tank & Water Tank Lid

    PART 3. MAINTENANCE Cleaning the Water Tank & Water Tank Lid CAUTION: DO NOT use a dishwasher to clean the Water Tank and its Lid. 1. Remove the Water Tank from brewer by tilting and lifting away from the Water Tank away from the brewer. (Fig. 23) 2.

  • Page 16: De-Scaling Your Brewer

    PART 3. MAINTENANCE De-scaling Your Brewer Depending on the quality of your water supply, calcium and scale may build up inside the brewer. Scale is non-toxic but build up of scale can hinder brewer performance. We recommend de-scaling the brewer every 3-6 months depending on the brewer usage. Follow these instructions for de-scaling: ITEMS NEEDED: large ceramic mug (do not use a paper cup), fresh water, 58 oz.
  • Page 17 PART 3. MAINTENANCE De-scaling Your Brewer STEP 2: FRESH WATER RINSE 1. Fill the Water Tank with fresh water but not beyond the MAX Fill Line. (Fig. 29) 2. Place a large mug on the Drip Tray and press the 14 oz button without a Pod. (Fig. 30) Throw away the heated water into the sink. (Fig. 31) 3.

  • Page 18: Part 4. Troubleshooting

    PART 4. TROUBLESHOOTING Brewer does not have power. • Plug the brewer into an independent outlet. • Check to be sure that it is plugged in securely. • Plug into a different outlet. • Reset your home’s circuit breaker, if necessary. •...
  • Page 19 PART 4. TROUBLESHOOTING • On a rare occasion, the brewer may shut OFF while brewing. This may happen if the water in the water tank is too hot. This is done to protect the heating mechanism in the brewer. If this happens, let the brewer cool down and replace the water in the water tank with room temperature water. If the brewer continues to shut OFF while brewing after replacing the water, please contact the customer service.

  • Page 20: Part 5. Warranty

    It is recommended that you fill out and return the warranty card enclosed with the brewer so that the purchase information will be stored in our system. Touch will, at its option, repair or replace a defective brewer without charge upon its receipt of proof of the date of purchase. If a replacement brewer is necessary to service this warranty, the replacement brewer may be new or reconditioned.
  • Page 21 Touch Customer Service to obtain a Return Merchandise Authorization (RMA) number. Touch brewers returned without an RMA number will be returned to the sender without servicing. Touch is committed to your satisfaction. If you have questions, just give us a call to have them answered quickly without leaving the comfort of your home. Touch Coffee & Beverages, LLC 15312 E.
  • Page 22 I would like to receive product news and information and special offer as described in your Privacy Policy at www. touchbeverages.com / privacy-policy. First Name Mail the Warranty and Registration Card to: Last Name Touch Coffee & Beverages, LLC 15312 E. Valley Blvd. City of Industry, CA. 91746 U.S.A...
  • Page 23 MEMO...
  • Page 24 For Household Use Only To learn more about Touch, visit www.touchbeverages.com or Call Toll-Free: 844-20TOUCH (844-208-6824) © 2014 Touch, Incorporated All rights reserved...
