  • Page 1 Read Instructions Before Using Your New E-bike DO NOT RETURN STORE. For questions regarding assembly and use, call Customer Service: 877-441-6999.
  • Page 2 Never carry passengers on your E-bike. Check your state and local laws governing the use of motorized vehicles in your area. Yukon Trail, Inc. is not responsible for your Failure to comply with state and local ordinances Relating to the use of the E-bike.
  • Page 3 Congratulations on your new purchase! Our service department is dedicated to your satisfaction with 877.441.6999. For questions regarding performance, assembly, operation, parts or return, contact the Manufacturer directly by calling toll free DO NOT RETURN TO STORE 877.441.6999. DO NOT RETURN STORE. For questions regarding assembly and use, call Customer Service: 877-441-6999.
  • Page 4 Before You Ride About this Manual It is important for you to understand your new bicycle. By reading this manual before you go out on your first ride, you will know how to get better performance, comfort, and enjoyment from your new bicycle. It is also important that your first ride on your new bicycle is taken in a controlled environment, away from cars, obstacles, and other cyclists.
  • Page 5 Safety Checklist Before you ride, it is important to carry out the following safety checks: 1. Brakes Ensure front and rear brakes work properly Ensure brake shoe pads are not over worn and are correctly position in relation o the rims. Ensure brake control cables are lubricated, correctly adjusted and display no obvious wear.
  • Page 6 4. Chain Ensure chain is oiled, clean and runs smoothly. Extra care is required in wet or dusty conditions. 5. Bearing Ensure pedals are securely tightened to the cranks. Check headset, wheel bearings, pedals bearing and bottom bracket bearings. 6. Cranks and Pedals Ensure pedals are securely tightened to the cranks Ensure cranks are secure to axle and are not bent.
  • Page 7 9. Accessories Ensure that all reflectors are properly fitted and not obscured. Ensure all other fittings on the bike are properly and securely fastened, and functioning. Ensure the rider is wearing a helmet. 10. Motor Drive Assembly and Throttle Ensure all motor drive components are correctly mounted and functioning properly.
  • Page 8 Helmets It is strongly advised that a properly fitting, ANSL or SNELL approved, bicycle safety helmet be worn at all times when riding your bicycle. In addition, if you are carrying a passenger on a child safety seat, they must also be wearing a helmet.
  • Page 9 Component List DO NOT RETURN STORE. For questions regarding assembly and use, call Customer Service: 877-441-6999.
  • Page 10 DO NOT RETURN STORE. For questions regarding assembly and use, call Customer Service: 877-441-6999.
  • Page 11 DO NOT RETURN STORE. For questions regarding assembly and use, call Customer Service: 877-441-6999.
  • Page 12 Battery Gauge When the throttle or sensor is engaged (Powering the motor) and the bicycle is in motion, the LED’s on the battery gauge (on the throttle or separate unit) indicate instantaneous line voltage as measured at the battery terminals- and not the available energy in the battery pack.
  • Page 13 Throttles Throttle, are equipped on some models of electric bicycles. Throttles operate be rotating the throttle much like a motorcycle. They generally are the inner half of the right side handlebar grip and may also contain a battery gauge. The more you twist the throttle, the faster the motor system will propel bicycle.

  • Page 14: First Use

    Taking Care of Your Batteries Proper maintenance of the batteries will maximize their lifespan and available ride time. · W e use SLA (Sealed Lead Acid) or Li-Ion (Lithium Ion) batteries in all of our electric bicycles. These are very user friendly types of batteries when cared for properly.
  • Page 15 · The Li-Ion battery rear lights power is directly on the rear of battery . · The Battery power switch is the Red Button under the rear battery (beneath LED Light). · The Li-Ion battery charger connector is covered by a rubber cover when you lift the battery handle.
  • Page 16 SLA Battery Packs (Sealed Lead Acid battery) SLA battery packs: 24V 10Ah Sealed Lead Acid Battery, First time charging time: 8 hours, Recharging time: 6~8 hours, Do not charge longer than 24 hours! Last about 350 recharge cycles. . Turn the key to unlock the battery box. 2.
  • Page 17 Li-Ion Battery Packs (Lithium-ion battery) Li-ion battery packs: 36V 10Ah Lithium Battery, First time charging time: 6 hours, Recharging time: 4~6 hours, Do not charge longer than 24 hours! Last over 1000 recharge cycles. 1. Turn the key to unlock the battery box. 2.
  • Page 18 Charger The electric bike comes with its own “Smart Charger” that connects with an easy-access charger port for recharging the batteries. This charger has lights which show the battery charge status. Batteries work best when they have a full charge, so always be sure to recharge them fully after each ride.
  • Page 19 Charge, for the full time. If the battery still has not charged, you may need to replace it. Use only Yukon Trail Authorized SLA battery chargers with bicycles equipped with SLA batteries. Using any other charger will damage the batteries and void your warranty.
  • Page 20 Charge for the full time. If the battery still has not charged, you may need to replace it. Use only Yukon Trail Authorized Li-Ion chargers with bicycles equipped with Li-Ion batteries. Using any other charger will damage the batteries and void your warranty.
  • Page 21 Battery Care Battery Storage How to store your battery for a extended time? Charge the battery every 3 months to avoid capacity loss. Batteries slowly self-discharge when left unused for a long time; if battery cells are allowed to reach a critically low voltage, their lifespan and capacity will be permanently reduced.

  • Page 22: Battery Disposal

    Only use YUKON TRAIL supply chargers. Q; Is it normal that the batteries get warm when recharging? A: Yes, it is normal that the batteries will become warm to the touch during the recharging process.
  • Page 23 When recycling lead batteries do not mix them with non-lead batteries. Non-lead batteries pose a fire/explosion hazard if brought to a lead battery recycling facility. Lead batteries (example: sealed lead acid batteries, etc.) and non-lead batteries (example: lithium ion, nickel metal hydride, etc.) are recycled at different facilities.
  • Page 24 Quick release to adjust the height of the seat which is comfortable for you.(Xplorer & Outback Models). The Navigator & Dirt Hawk seat, you can lift the seat and take out of the battery to recharge separately. DO NOT RETURN STORE. For questions regarding assembly and use, call Customer Service: 877-441-6999.
  • Page 25 Braking Adjustment V-Brake 1. If fitted with V-brakes, insert the brake body into the center spring hole in the frame mounting boss, and then secure the brake body to the frame with the link fixing bolt. 2. While holding the shoe against the rim, adjust the amount of shoe protrusion by interchanging the position of the B washers (i.e 6mm and 3mm) so that dimension A is kept at 39mm or more.
  • Page 26 3. While holding the shoe against the rim, tighten the shoe fixing nut. 4. Pass the inner cable through the inner cable lead. Set the cable with a clearance of 1mm between each brake pad and the rim, tighten the cable fixing bolt.
  • Page 27 6. Depress the brake lever about 10 times as far as the grip to check that everything is operating correctly and that the shoe clearance is corrected before riding the bike. Chain Adjustment Inspection The chain must be kept clean, rust free and frequently lubricated in order to extend its life as long as possible.
  • Page 28 Adjustment and Replacement On derailleur geared bicycles the rear derailleur automatically tensions the chain. To adjust the chain on single speed freewheel, coaster hub braked or 3 speed hub geared bicycles: 1. Loosen the rear axle nuts ( and coaster brake arm clip ) and move the wheel forward to loosen , or backward to tighten, in the frame.
  • Page 29 Fuse All Yukon Trail electric bicycles are equipped with fuse. The fuse may be located, depending on the model of the bike, in the following locations: SLA fuse (40A glass type fuse) on the battery pack, externally accessible. li-Ion, 30A blade type fuse & 5A blade type fuse- inside the bottom end of the down tube, remove down tube cap to access.
  • Page 30 Tools Bag 1. 2pcs Open ended wrench: 8mm/10mm, 13mm/15mm 2. 2pcs Allen key wrenches: 2.5mm/3.5mm/4mm, 5mm/6mm/8mm 3. 1pc Standard flat head screwdriver DO NOT RETURN STORE. For questions regarding assembly and use, call Customer Service: 877-441-6999.

  • Page 31: Wiring Diagram

    Troubleshooting Failure symptoms Cause of Problem Solution Battery voltage is too low Immediately charge Battery is not providing The battery Replace the battery indicator light on proper power the meter is off, The battery lock does not and the motor does Replace of the battery not work work, preventing battery...
  • Page 32 (Diagram is for representational purpose only. Your bicycles’ wiring system may differ) WARRANTY REGISTRATION DO NOT RETURN STORE. For questions regarding assembly and use, call Customer Service: 877-441-6999.

  • Page 33: Limited Warranty

    Store Address: ________________________________________________________ Receipt or Transaction #: ________________________________________________ The registration must be returned to Yukon Trail, Inc. within 10days of purchase. It is the only information Yukon Trail will have for notification to you of any information regarding this product.
