Summary of Contents for SunStar 30T

  • Page 1 Rev. 1513150616 Part No. 161500-15-019 Copyright 2014 Winnebago Industries, Inc. All rights reserved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 - INTRODUCTION About this Manual ..........................1-1 Safety Messages Used in this Manual ....................1-1 Pre-Delivery Inspection ........................1-2 Before Driving ..........................1-2 Front Axle Tire Alignment ....................... 1-2 Service and Assistance ........................1-2 Reporting Safety Defects ........................1-2 Occupant and Cargo Carrying Capacity Label .................
  • Page 4 Table Of Contents Rearview Monitor System ........................ 3-6 Mirrors – Power Electric ........................3-6 Brake-Shift Interlock ........................3-7 Park Brake – Foot Pedal ........................3-7 Tow/Haul Transmission Mode ......................3-8 Map Light Switch ..........................3-8 Hazard Warning Flashers ........................3-8 Battery Boost Switch ........................
  • Page 5 Table Of Contents 5 - PROPANE GAS Propane Gas Supply .......................... 5-1 Propane Accessory Connection ......................5-2 Safe Use of the Propane Gas System ....................5-3 Propane Gas Warnings and Precautions ................... 5-4 Propane Gas Pressure Regulator ....................... 5-4 Propane Vaporization in Cold Weather .................... 5-5 6 - ELECTRICAL Electrical Cautions ..........................
  • Page 6 Table Of Contents DVD Player ............................8-1 CD/DVD Player ..........................8-2 Flip-Down Screen Video Players ..................... 8-3 Audio/Video System Cables ......................8-5 TV (Dining Buffet) - Power Lift ....................... 8-5 TV – Bedroom (Flip Down) ......................8-6 Bedroom DVD/Satellite Receiver Connection ................. 8-6 TV Antenna –...
  • Page 7 Table Of Contents Roof ..............................11-1 Undercarriage ..........................11-1 Exterior Automotive Paint Finish ....................11-2 Exterior Graphic Care ........................11-4 Plastic Parts – Cleaning ........................11-4 Exterior Lights ..........................11-5 Interior Soft Goods ......................... 11-5 Ceiling Fabric Care ......................... 11-7 Cabinetry –...

  • Page 9: Introduction

    SECTION 1 - INTRODUCTION Congratulations! We welcome you to the design without notice, and without exciting world of motorhome travel and incurring obligation to install the same camping. You will find it convenient and on products previously manufactured. enjoyable to have all the comforts of home and The materials in your InfoCase contain still enjoy the great outdoors wherever you warranty information and operating and...

  • Page 10: Pre-Delivery Inspection

    SECTION 1 - INTRODUCTION BEFORE DRIVING WARNING Familiarize yourself with State/Province and local regulations before traveling. There are many local rules that may impact your RV WARNING indicates a hazardous travels. situation which, if not avoided, could result in death or serious personal injury. FRONT AXLE TIRE ALIGNMENT CAUTION...

  • Page 11: Occupant And Cargo Carrying Capacity Label

    SECTION 1 - INTRODUCTION a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or ® Winnebago Industries To contact NHTSA, you may either call the Vehicle Safety Hotline toll-free at: 1-888-327-4236; (TTY: 1-800-424-9153) or go to their website at http://www.safercar.gov or write to: Administrator, NHTSA...

  • Page 12: Vehicle Certification Label

    SECTION 1 - INTRODUCTION VEHICLE CERTIFICATION LABEL This label is affixed to the lower driver side armrest panel, driver door, or the driver side door jamb, depending on model. It contains vehicle identification numbers and other important reference information. EXPLANATION OF DATA 1.

  • Page 13: Specifications And Capacities

    SECTION 1 - INTRODUCTION SPECIFICATIONS AND CAPACITIES ® ® ® ® ® Ford Ford Ford Ford Ford 18,000 lb. 18,000 lb. 22,000 lb. 22,000 lb. 22,000 lb. Chassis with Chassis with Chassis with Chassis with Chassis with 19.5" Tires 19.5" Tires 22.5"...

  • Page 14: Owner And Vehicle Information

    SECTION 1 - INTRODUCTION OWNER AND VEHICLE INFORMATION OWNER INFO Owner’s Name(s) __________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ VEHICLE INFORMATION Motorhome Model Number __________________________________________________________ Motorhome Serial Number ___________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ®...

  • Page 15: Safety And Precautions

    SECTION 2 - SAFETY AND PRECAUTIONS GENERAL WARNINGS DRIVING SAFETY • Only seats equipped with seat belts are to be occupied while the vehicle is moving. WA RNING • Make sure all passengers have seat belts fastened. Lap belts should fit low on the hips and upper thighs.

  • Page 16: Fuel And Propane Gas

    SECTION 2 - SAFETY AND PRECAUTIONS • Do not operate the cruise control on icy or extremely wet roads, winding roads, in heavy WA RNING traffic, or in any other traffic situation where a constant speed cannot be maintained. • Use care when accelerating or decelerating on Propane gas containers, gasoline, or a slippery surface.

  • Page 17: Propane Gas Leaks

    SECTION 2 - SAFETY AND PRECAUTIONS DA NG E R DA NG E R Do not use gas cooking appliances for IF YOU SMELL PROPANE comfort heating. Can lead to carbon 1. Extinguish any open flames and all monoxide poisoning, which can lead to smoking materials.

  • Page 18: Carbon Monoxide Warning

    SECTION 2 - SAFETY AND PRECAUTIONS CARBON MONOXIDE WA RNING WARNING EXPLOSION HAZARD: DO NOT use an WA RNING open flame to test for gas leaks. When testing for gas line leaks with a soapy water solution, DO NOT use a detergent Avoid inhaling exhaust gases, as they containing ammonia or chlorine.

  • Page 19: Smoke Alarm

    SECTION 2 - SAFETY AND PRECAUTIONS source such as the furnace, gas range/oven, water SMOKE ALARM heater, refrigerator, chassis engine, and electric generator engine. Your coach is equipped with a Smoke Alarm (located on the ceiling in the lounge area.) The Press button to test Smoke Alarm is powered by a 9-volt battery and has a sensor that is designed to detect smoke.

  • Page 20: Fire Extinguisher

    SECTION 2 - SAFETY AND PRECAUTIONS FIRE EXTINGUISHER ELECTRICAL A dry chemical Fire Extinguisher is located • Careless handling of electrical components near the main entrance door. can be fatal. Never touch or use electrical components or appliances while feet are bare, while hands are wet, or while standing in water or on wet ground.

  • Page 21: Maintenance

    SECTION 2 - SAFETY AND PRECAUTIONS MAINTENANCE • Do not remove the radiator cap while engine and radiator are still hot. Always check coolant level visually at the see-through coolant reservoir. • Never get beneath a vehicle that is held up by a jack only.

  • Page 22: Slideout Rooms

    SECTION 2 - SAFETY AND PRECAUTIONS WA RNING Keep all persons clear of the slideout room and moving parts while extending or retracting. Do not occupy the slideout room while it is being extended or retracted. Failure to observe can result in death or serious injury.

  • Page 23: Formaldehyde Information

    SECTION 2 - SAFETY AND PRECAUTIONS during each use. High indoor temperatures and humidity may raise formaldehyde levels. When a WA RNING recreational vehicle is in areas subject to high temperatures, an air conditioning system can be used to control indoor temperature levels. If you Do not exceed 225-lb.

  • Page 24: Roadside Emergency

    SECTION 2 - SAFETY AND PRECAUTIONS as possible. Vacuum the carpet. Clean food spills If Winnebago Industries determines that mold thoroughly and quickly. Avoid grease buildup is present due to conditions it determines is not a near the stove or sink. Clean the exhaust fan result of a manufacturing defect found within the above the stove often.

  • Page 25: Jump Starting

    SECTION 2 - SAFETY AND PRECAUTIONS tire or wheel rim by driving on it. A tire or JUMP STARTING wheel replacement is cheaper than damaging the vehicle or injuring yourself. If your coach will not start from the chassis battery, try using the Battery Boost switch to •...

  • Page 27: Driving Your Motorhome

    SECTION 3 - DRIVING YOUR MOTORHOME The information in this section refers only to features installed or adapted to the dash and Lift to Recline Power Seat driver compartment area by Winnebago Controls ® Industries . It also includes passenger seating in the living area of the coach.

  • Page 28: Co-Pilot Footrest

    SECTION 3 - DRIVING YOUR MOTORHOME Armrest Adjustment –If Equipped The armrests may be swung upward out of the way for easy exit or access to the front seats. A roller on the underside of the front of the armrest also lets you adjust the resting angle for personal comfort, whether the seat is upright or reclined.

  • Page 29: Seat Belts

    SECTION 3 - DRIVING YOUR MOTORHOME Adjustment To lengthen belt, swivel the tab end at a right angle to belt and pull strap to desired length. To shorten, pull loose end of belt. To Fasten Be sure belt is not twisted. Grasp each part of the belt assembly and push tongue into buckle.

  • Page 30: Seat Belt Care And Cleaning

    SECTION 3 - DRIVING YOUR MOTORHOME 2. Make sure that it will attach to your vehicle and restrain your child securely and WARNING conveniently so that you are able to install it correctly each time it is used. 3. Be certain that it is appropriate for the child's Never wear the shoulder belt in any height, weight, and development.

  • Page 31: Keys

    SECTION 3 - DRIVING YOUR MOTORHOME KEYS Your motorhome is supplied with several keys. In addition to the chassis manufacturer’s ignition key, you receive keys for the entrance door and exterior compartment doors. Keys have an identification number, either a small metal tag or stamped into the key head.

  • Page 32: Rearview Monitor System

    SECTION 3 - DRIVING YOUR MOTORHOME • Reverse step to store passenger workstation. MIRRORS – POWER ELECTRIC REARVIEW MONITOR SYSTEM –If Equipped Always adjust mirrors for maximum rear –If Equipped visibility before driving off. Make sure the seat is Your coach may be equipped with a Rearview adjusted for proper vehicle control and that you Monitor System, which lets you see what is are sitting back squarely into the seat.

  • Page 33: Brake-Shift Interlock

    SECTION 3 - DRIVING YOUR MOTORHOME camera view on the monitor until the turn is completed or the signal lever is canceled manually. Mirror Heat Switch (Located on driver side trim panel) -Typical View Mirror Arm/Head Adjustment If you cannot adjust a mirror properly using the control switch, the mirror may need a coarse adjustment by rotating the mirror head.

  • Page 34: Tow/Haul Transmission Mode

    SECTION 3 - DRIVING YOUR MOTORHOME TOW/HAUL TRANSMISSION MODE ® Ford Chassis only This mode locks out Overdrive and helps reduce gear “hunting” by the automatic transmission while towing. It also improves power delivery and uses engine braking to help control vehicle speed when descending hills.

  • Page 35: Radio In-Dash/Rearview Monitor System

    SECTION 3 - DRIVING YOUR MOTORHOME Press and Hold the Battery Boost switch in the reads “Battery”. This will need to be ON (up) position while turning ignition key for reset every time the power is emergency starting power. disconnected from the radio. NOTE: The House/Coach Battery Disconnect switch near the entrance door must be ON and house batteries must be...

  • Page 36: Radio Remote Control

    SECTION 3 - DRIVING YOUR MOTORHOME USB Cable by house batteries. If the House/Coach Battery Disconnect switch is OFF, the –If Equipped speakers will not emit sound. Your coach may be equipped with a cable to connect your USB to play through your radio. The USB cable is located on the dash beverage tray.
  • Page 37 SECTION 3 - DRIVING YOUR MOTORHOME See the receiver manufacturer’s information in your InfoCase for programming and operating instructions. USB Cable –If Equipped Your coach may be equipped with a cable to connect your USB to play through your radio. The USB cable is located on the dash beverage tray.

  • Page 38: Air Conditioner/Heater - Automotive (Dash)

    SECTION 3 - DRIVING YOUR MOTORHOME NOTE:The House/Coach Battery Disconnect NOTE: The dash air conditioner/heater is not switch must be ON while listening to the designed to heat and cool the entire dash radio, as the audio relay is powered interior of the coach, but is intended only by house batteries.

  • Page 39: Cb Radio Power Wiring

    SECTION 3 - DRIVING YOUR MOTORHOME NOTE: The House/Coach Battery Disconnect switch must be ON while listening to the dash radio because the audio relay is powered by house batteries. If the House/ Coach Battery Disconnect switch is off, the speakers will not emit sound. CB Power Wires (Located behind fuse and breaker panel) -Typical View...

  • Page 40: Engine Access - Interior

    SECTION 3 - DRIVING YOUR MOTORHOME • Insert hex wrench into the hole located on the top center of the engine cover (as shown) or the front edge of engine cover (depending on model) to unlock. To Close Hood -Typical installation shown •...

  • Page 41: Engine Cooling System

    SECTION 3 - DRIVING YOUR MOTORHOME Further Information NOTE: If your coach is featured with a beverage tray, it may need to be removed to Refer to the chassis manual in your InfoCase provide additional clearance before for information and precautions on filling, removing the engine cover.

  • Page 42: Suspension Alignment And Tire Balance

    SECTION 3 - DRIVING YOUR MOTORHOME Further Information SUSPENSION ALIGNMENT Refer to the chassis manual in your InfoCase AND TIRE BALANCE for further information. The front suspension and steering system of CIRCUIT BREAKERS AND this vehicle was factory aligned using highly accurate equipment prior to delivery to the FUSES –...
  • Page 43 SECTION 3 - DRIVING YOUR MOTORHOME Further Information Refer to the chassis manual provided in your InfoCase for additional information about chassis-supplied fuses and circuit breakers. 3-17...

  • Page 45: Appliances And Systems

    SECTION 4 - APPLIANCES AND SYSTEMS The appliances installed in your motorhome are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. See Section 2 - Safety and Precautions of this manual for any safety and precautions you need to take regarding the operation of your appliances.
  • Page 46 SECTION 4 - APPLIANCES AND SYSTEMS To be able to use both types of energy, the refrigerator does not have a compressor like household refrigerators. Instead, it uses an ammonia-water solution for cooling. Basically, ammonia vapor is distilled from the solution by heat produced from either propane gas flame or electrical heat element.

  • Page 47: Refrigerator - Residential

    SECTION 4 - APPLIANCES AND SYSTEMS • Press the TEMP SET button to change temperature setting from 1 to 9 on display. NOTICE Start at the ‘coldest’ setting to ensure coldest temperature in the freezer compartment, then adjust warmer as necessary after cold food has To prevent permanent damage to the been added.

  • Page 48: Ice Maker

    SECTION 4 - APPLIANCES AND SYSTEMS Travel Latch See the manufacturer’s user guide provided in your InfoCase for information on adjusting To remove the Travel Latch, turn counter- refrigerator/freezer temperatures to best suit your clockwise. To reinstall the travel latch, insert into needs.

  • Page 49: Refrigerator Service Access Compartment

    SECTION 4 - APPLIANCES AND SYSTEMS REFRIGERATOR SERVICE REFRIGERATOR SERVICE ACCESS COMPARTMENT ACCESS COMPARTMENT – RESIDENTIAL (Exterior) (Exterior) The exterior refrigerator service compartment allows access to the rear of the refrigerator for The exterior residential refrigerator service inspection, maintenance, and service. compartment allows access to the rear of the refrigerator for inspection, maintenance, and To Open...

  • Page 50: Avoiding Asphyxiation

    SECTION 4 - APPLIANCES AND SYSTEMS DA NG E R Do not use gas cooking appliances for comfort heating. Can lead to carbon monoxide poisoning, which can lead to death or serious injury. WARNING -Typical View Gas cooking appliances need fresh air for To Light Range Top Burners safe operation.

  • Page 51: Microwave Oven

    SECTION 4 - APPLIANCES AND SYSTEMS Further Information MICROWAVE OVEN See the manufacturer’s user guide provided –If Equipped inside the appliance for complete operating Refer to the manufacturer’s user guide located instructions and replacement of vent hood light inside the appliance for complete operating bulbs and replacement or cleaning of grease filter instructions.

  • Page 52: Washer/Dryer - Prep Package

    SECTION 4 - APPLIANCES AND SYSTEMS WASHER/DRYER – PREP PACKAGE If your coach is not equipped with a Washer/ Dryer, plumbing may be present for installation. Typically, the plumbing lines are located inside the wardrobe or storage cabinet depending on model. We recommend obtaining parts and service for the Washer/Dryer installation from your ®...
  • Page 53 SECTION 4 - APPLIANCES AND SYSTEMS Model 35B (Equipped with Black and Gray Waste Level Selector Switches) Press either the Black or Gray Waste Level Selector switch to select the desired tank level to be displayed on the monitor panel. The approximate fluid levels are measured by electronic sensors on the sides of the tanks.

  • Page 54: Power Control System (Pcs)

    SECTION 4 - APPLIANCES AND SYSTEMS Battery Charge Meter POWER CONTROL SYSTEM Press and Hold the “Levels Test” switch to (PCS) check the level of charge (voltage) in the 12-volt house battery. –If Equipped The colored segments (red, yellow, and green) The Power Control System (PCS) monitors will light from the bottom up to the amount of the electrical usage of the appliances and...

  • Page 55: Motoraid Water Heater

    SECTION 4 - APPLIANCES AND SYSTEMS Be sure the water heater is filled with water before starting either electric or propane gas operation. To fill the water heater, turn the Water Pump switch on and open a hot water faucet anywhere in the coach. When water begins to flow steadily from the faucet, the water heater is full.

  • Page 56: Pressure-Temperature Relief Valve

    SECTION 4 - APPLIANCES AND SYSTEMS CAUTION NOTICE Any leak in the heat exchanger or its Hot water can escape from tank causing supply or return lines could cause loss of injury. Operate this valve only when the coolant and subsequent engine failure. tank water is cold.

  • Page 57: To Shut Down

    SECTION 4 - APPLIANCES AND SYSTEMS To Shut Down FURNACE – PROPANE GAS 1. Slide Thermostat switch to the Off position. To Start Up 2. Close propane tank valve if coach will be stored for a period of time. 1. Open the Propane Gas Tank valve by turning fully “counter-clockwise”.

  • Page 58: Ducted Roof Air Conditioning System

    SECTION 4 - APPLIANCES AND SYSTEMS is set to automatically start the propane furnace to All cooling functions controlling to setpoint assist the Heat Pump if room temperature cools to have a short cycle protection time delay of three five degrees or more below the thermostat set minutes.

  • Page 59: Propane Gas

    SECTION 5 - PROPANE GAS PROPANE GAS SUPPLY Tank Gauge & Tank Fill Overflow Sender The propane gas system supplies fuel for the Valve Valve gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel.

  • Page 60: Propane Accessory Connection

    SECTION 5 - PROPANE GAS propane gas outlets in the United States do not offer any other type of liquefied petroleum gas WARNING than propane to the general public.) Check local phone directory yellow pages for locations of local propane gas refilling stations or bulk Do not fill propane container(s) to more dealerships.

  • Page 61: Safe Use Of The Propane Gas System

    SECTION 5 - PROPANE GAS “clockwise” to turn gas supply OFF. Rotate the SAFE USE OF THE PROPANE shut-off valve “counter-clockwise” to turn gas GAS SYSTEM supply ON. See Section 2 - Safety and Precautions in this The propane system is designed and built with manual for other safety and precautions you need strict adherence to national, state, and to be aware of related to propane.

  • Page 62: Propane Gas Warnings And Precautions

    SECTION 5 - PROPANE GAS • Never attach a lock or any device requiring a • Never smoke while refilling vehicle fuel tank key to the propane compartment door. or propane gas container. According to standards set for recreation • Avoid inhaling exhaust gases produced by vehicles, the propane supply valve must be burned gasoline, diesel fuel, or propane gas in...

  • Page 63: Propane Vaporization In Cold Weather

    SECTION 5 - PROPANE GAS Propane regulators must always be installed with the regulator vents facing downward. Regulators that are not in compartments have been equipped with a protective cover. Make sure that the regulator vent faces downward and that the cover is kept in place to minimize vent blockage that could result in excessive propane pressure causing fire or explosion.
  • Page 64 SECTION 5 - PROPANE GAS This means that in extremely cold weather when a large volume of gas is being used by the furnace for heating, it is possible to experience a loss of gas pressure. At first, this problem may appear to be caused by an empty tank or a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed by the furnace.

  • Page 65: Electrical

    SECTION 6 - ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motorhome that is • 12-volt DC system (battery current);...
  • Page 66 SECTION 6 - ELECTRICAL be used is designed to mate with the prongs of the power cord plug, the electrical connection can be expected to carry rated load. Connecting the Power Cord To connect to an external source, remove the cord from the utility compartment and plug it into a suitable power outlet to provide external power to the coach and converter/charger system.

  • Page 67: Inverter Unit - 1000W

    SECTION 6 - ELECTRICAL power fails, contact the park attendants and have them check the fuse or breaker for your supply receptacle. INVERTER UNIT – 1000W –If Equipped The inverter changes 12-volt DC battery power into 120-volt AC power for use by 120- volt AC equipment inside the coach.

  • Page 68: Inverter/Charger Unit - 2000W

    SECTION 6 - ELECTRICAL Inverter Control Panel The inverter can also be used while driving the motorhome because the –If Equipped engine alternator will charge the The inverter has a wall-mounted monitor/ batteries while driving. control panel. It will also display warnings for overload conditions or other operating failure The inverter/charger unit is located in the conditions.

  • Page 69: Power Center

    When the inverter is not being used, it should Power Center be shut off at the control panel. The inverter (Models 27N and 30T) could drain the house batteries if the shoreline is -Typical View not connected to external power and the House/ Coach Battery Disconnect switch is on.

  • Page 70: Circuit Breakers - House 120-Volt Ac

    SECTION 6 - ELECTRICAL Charging Section The converter charges house batteries while 120-volt external power is connected. The converter will automatically “sense” the condition of the battery. If it is below “full charge”, the Charging Section will start charging the batteries. If the house batteries have been extremely discharged, they will accept charge at a relatively high amperage rate.

  • Page 71: Electrical Outlets - House 120-Volt Ac

    SECTION 6 - ELECTRICAL component itself. When an overload or short GROUND FAULT CIRCUIT develops, the breaker will open preventing INTERRUPTER damage to the system. Shut off the equipment (example: roof air Bath, galley, and exterior outlets are conditioner) and allow a brief cooling period. connected to a GFCI (Ground Fault Circuit Then reset the breaker by moving the switch to Interrupter), which is an extremely sensitive...

  • Page 72: Automatic Power Transfer Switch

    SECTION 6 - ELECTRICAL Automatic Power Transfer Switch ELECTRICAL GENERATOR – (available with 50-amp service only) 120-VOLT –If Equipped –If Equipped Whenever the generator is needed, an automatic power transfer system automatically switches the household electrical system to the WARNING generator 30 seconds after the generator is started.
  • Page 73 SECTION 6 - ELECTRICAL Automatic Generator Start (AGS) –If Equipped The Automatic Generator Start feature monitors house battery voltage and coach interior temperature, and has the ability to automatically start the Generator to help maintain full air conditioning function and house battery charge. The AGS control pad is also equipped with an hourmeter feature, which registers the total number of hours that the generator has been...

  • Page 74: Chassis Battery

    SECTION 6 - ELECTRICAL Operation Warnings and Cautions Chassis Battery The chassis battery is used to operate the engine starter and automotive accessories and WARNING controls found on the instrument panel. The slideout room systems and the electric step are also connected to the chassis battery.

  • Page 75: Battery Access

    SECTION 6 - ELECTRICAL NOTE: Some electronic displays and memory functions may need to be reset after power has been reconnected. See also “Battery Care” elsewhere in this section. House Chassis Batteries Battery -Typical View House/Coach Battery Disconnect Switch CAUTION (Located near entrance door) -Typical View Step cover must be closed and latched.
  • Page 76 SECTION 6 - ELECTRICAL The two best defenses against sulfating Further precautions are: and insufficient charge are to: • Check the state of charge periodically to avoid discharge or sulfating. 1. Turn off the House/Coach Battery Disconnect switch to avoid parasitic discharge (the trickle To ensure that the battery will always accept discharge caused by directly connected and hold a charge, follow these simple...

  • Page 77: Circuit Breakers And Fuses - House 12-Volt Dc

    House 12-Volt Fuses Turn the Chassis Battery Disconnect switch (Models 27N and 30T) (located near the entrance door) to the OFF A label on the panel states the amperage rating position to disconnect batteries.
  • Page 78 (Located on the right-hand side (Located inside passenger compartment) of the Power Converter) -Typical View (Models 27N and 30T) -Typical View The fuse panel accepts only blade type plug-in fuses. Always replace fuses with those of the same amperage rating.

  • Page 79: Plumbing

    SECTION 7 - PLUMBING FRESH WATER SYSTEM The Fresh Water System provides water to the galley sink, shower, bathroom lavatory, toilet, and water heater. Water may be supplied by either of two sources: • A fresh water tank and water pump located within the motorhome, or •...
  • Page 80 SECTION 7 - PLUMBING Fresh Water Valve Fresh Water Valve (Located in water service center) (Located in water service center) -Typical View -Typical View 4. Turn city water supply ON. Using City Water 5. Use the level display on the monitor panel to When connected to an outside source of water, oversee filling of the tank, or when the tank is the water bypasses the water pump and storage...

  • Page 81: Water Pump

    SECTION 7 - PLUMBING Using Tank Water (Gravity Fill) NOTE: Ensure the Fresh Water valve is in NORMAL position to use the water • Turn Water Pump switch ON. While the pump. If the valve is in Tank Fill position, switch is on, the water pump will the pump will run continuously without automatically supply tank water as needed.
  • Page 82 While the switch is “ON”, the pump will -Typical installation shown automatically supply water as it is needed. • Models 27N and 30T - Located in passenger We recommend that you turn the Water Pump side compartment behind rear axle.

  • Page 83: Ice Maker Water Filter

    SECTION 7 - PLUMBING NOTE: When removing the coach from storage, ICE MAKER WATER FILTER always disinfect and flush the water system thoroughly before installing a –If Equipped new filter. If the refrigerator in your coach is equipped with an ice maker, an ice maker filter is provided, DISINFECTING YOUR FRESH which removes chlorine and odors for clean, WATER SYSTEM...
  • Page 84 SECTION 7 - PLUMBING 4. Let the system stand at least 4 hours when disinfecting with 50 ppm residual chlorine. (If a shorter time period is desired, then a 100 WARNING ppm chlorine concentration should be allowed to stand in the system for at least 1 Chlorine is poisonous.

  • Page 85: Shower Hose Vacuum Breaker

    SECTION 7 - PLUMBING detected in the water discharged. Do not and allows water remaining in the hose to drain forget the hot water faucets. down. This is a normal function of the shower (You may need to leave a hot water faucet valve assembly and is not a leak or defect.

  • Page 86: Dumping Holding Tanks

    SECTION 7 - PLUMBING site. This means you can use the toilet(s), sinks, and shower even in areas where utility hookups are not available. The black water holding tank(s) contains the sewage from the toilet(s) and may include bathroom lavatory on some models. The gray water holding tank contains the waste water from the galley sink and shower, and may include Important “Don’ts”...
  • Page 87 SECTION 7 - PLUMBING NOTE: Model 35B is equipped with two sets of 7. Rinse sewage drain hose thoroughly with Black and Gray Waste Tank Drain water before stowing. Valves - one set is in the driver side NOTE: We recommend that you dump all compartment ahead of rear axle, and holding tanks before traveling to avoid the other set is in the driver side...

  • Page 88: Waste Water System (Waste Pump)

    SECTION 7 - PLUMBING Using On-Site Sewer Hook-Ups The two black water holding tanks contain the sewage from the toilets. The gray water holding The sewage drain hose may remain attached to tank typically contains the waste water from the the sewage drain outlet and be routed out the galley sink, shower, and bathroom lavatories.
  • Page 89 SECTION 7 - PLUMBING Sewage Drain Hose -Typical View 2. Remove dust cap from sewage drain outlet and connect sewage drain hose. Be sure it is firmly attached. Black Waste Tank Drain Valve #1 (Front) (Located in passenger side compartment ahead of rear axle) -Typical View 5.
  • Page 90 SECTION 7 - PLUMBING 8. Open the Gray Waste Tank Drain Valve (located in the water service center). Be sure there are no sags in the hose to ensure complete drainage. Close Gray Waste Tank Drain Valve as soon as tank is empty. Waste Pump Switch (Located in water service center) -Typical View...

  • Page 91: Waterline & Tank Drain Valves

    SECTION 7 - PLUMBING opened. If the valves are left open, the liquids will drain off, leaving solids in the tank. Should D R A I N D R A I N this accidentally happen, disconnect the sewage C L O S E drain hose, fill the tank about half full with water, C L O S E and drive a few miles to dislodge the solids.

  • Page 92: Winterizing Procedure

    SECTION 7 - PLUMBING your finger into the city water inlet and gently press the backflow valve “button” in the center of the inlet to drain any water trapped in the inlet line. Normal By-Pass Flow Mode CAUTION Leave bypass valve handle in NORMAL FLOW position if draining water and Using exterior shower to drain waterline blowing out waterlines.
  • Page 93 SECTION 7 - PLUMBING 5. Open Faucets. Turn on the water pump and open all sink faucets and shower head knobs. Leave open after water stops flowing. 6. Drain Toilet. Press the toilet flush pedal and hold until water stops flowing in the toilet. Then turn Water Pump switch off.
  • Page 94 SECTION 7 - PLUMBING Method 2 – Antifreeze Fill 12. Turn air pressure off. Disconnect water purge adapters. Recap the city water inlet to Procedure avoid contamination by dirt or insects. (Fill plumbing lines with RV water system antifreeze) After Disconnecting Air Pressure 13.
  • Page 95 SECTION 7 - PLUMBING Antifreeze Siphon Tube • Insert into container of RV water system antifreeze Winterization Valve • Point toward antifreeze siphon tube to Ice Maker Water Filter Assembly winterize (Located below galley sink) • Twist the filter cartridge “counter-clockwise” about a quarter-turn and pull it down and out RV Antifreeze Siphon Tube and Winterization Valve...
  • Page 96 SECTION 7 - PLUMBING 10. Turn the Winterization valve so it points toward the waterline to the water pump. This will stop the flow from the antifreeze siphon tube and revert the tank line flow to the water pump. 11. Replace the protective cap onto the end of the antifreeze siphon tube to keep out insects and debris when not in use.

  • Page 97: Winterizing Optional Appliances

    SECTION 7 - PLUMBING To Winterize the Waste Pump 5. Ice Maker is now winterized. (Model 35F with forward bathroom toilet) To use Ice Maker again after seasonal storage: • Ensure that black and gray holding tanks are 1. Flush antifreeze from the waterlines (if completely empty.
  • Page 98 SECTION 7 - PLUMBING Winterizing Washer/Dryer –If Equipped Method 1 – Drain Water If you have decided to completely drain the coach waterlines, follow these steps to winterize your Washer/Dryer: 1. With the Washer/Dryer power OFF, pour 1/2 quart of RV-type antifreeze into the Washer drum.
  • Page 99 SECTION 7 - PLUMBING 2. Press ON/OFF button, set water temperature to WARM, then press START. Let machine fill until the drum turns (this could take up to 1 to 2 minutes). 3. Press ON/OFF button to turn power OFF. 4.

  • Page 100: Water System Drain Valve Locations

    SECTION 7 - PLUMBING WATER SYSTEM DRAIN VALVE LOCATIONS Model System Drain Valve Locations Model 27N Waterlines • Open exterior shower faucet and lay shower head on ground. Also, place the tip of your finger inside the city water connection and gently press the backflow valve (small “button”...
  • Page 101 SECTION 7 - PLUMBING Model 35F Waterlines • Open exterior shower faucet and lay shower head on ground. Also, place the tip of your finger inside the city water connection and gently press the backflow valve (small “button” in center of connector) to drain any water left in the city waterline.
  • Page 102 SECTION 7 - PLUMBING Model 36Y Waterlines • Open exterior shower faucet and lay shower head on ground. Also, place the tip of your finger inside the city water connection and gently press the backflow valve (small “button” in center of connector) to drain any water left in the city waterline.

  • Page 103: Entertainment

    SECTION 8 - ENTERTAINMENT FRONT TV IGNITION SWITCH INTERLOCK –If Equipped If your coach is equipped with a front overhead TV, it is plugged into a special electrical outlet with a built-in ignition switch interlock. The device allows the front overhead TV to operate only when the ignition key is in the Off or Accessory positions.

  • Page 104: Cd/Dvd Player

    SECTION 8 - ENTERTAINMENT Set TV Sound Output Further Information For further information and operating • Use the TV Menu button to set TV audio instructions, see the manufacturer’s information output to Variable Audio Output. (See TV included in your InfoCase. owner’s manual for instructions.) This will connect TV stereo sound output to the deluxe CD/DVD PLAYER...

  • Page 105: Flip-Down Screen Video Players

    SECTION 8 - ENTERTAINMENT • When the main menu screen appears, use the FLIP-DOWN SCREEN VIDEO arrow buttons on the DVD remote to select the PLAYERS desired entry or press the ENTER or PLAY buttons on the remote (or “Play” button on (Rear Bunk models only) DVD player) to begin playing the feature.

  • Page 106: Reading Lights

    SECTION 8 - ENTERTAINMENT 12-Volt Master Power • Insert the CD label side down (facing you) into the slot on the side of the player. The • The Video Players operate on player will automatically switch to proper 12-volt DC current. Turn on the mode to play audio or video CD.

  • Page 107: Audio/Video System Cables

    SECTION 8 - ENTERTAINMENT AUDIO/VIDEO SYSTEM CABLES A set of color-coded Audio/Video System Cables are provided in the front overhead entertainment center cabinet for connection of your choice of DVD player, home theater system, or satellite receiver. Buffet TV Power Lift/Lower Control Switch These cables are connected to the lounge TV (Located on face of buffet cabinet) and exterior entertainment center TV (if...

  • Page 108: Tv - Bedroom (Flip Down)

    SECTION 8 - ENTERTAINMENT Further Information 3. To lower the TV back into stored position, press the control switch DOWN. The power See the television manufacturer’s user guide lift/lower mechanism will stop automatically provided in your InfoCase for complete operating when the TV is all the way seated into stored instructions.

  • Page 109: Tv Signal Amplifier

    SECTION 8 - ENTERTAINMENT Operating the Digital Antenna 5. Rotate Attenuator Dial COUNTER- CLOCKWISE until the last illuminated LED 1. Turn the Digital Antenna Power Switch ON. light flickers. 6. Rotate antenna to illuminate the last flickering LED light. 7. Repeat Steps 5 and 6 to pinpoint signal reception.

  • Page 110: Satellite Dish And Cable Tv Connections

    SECTION 8 - ENTERTAINMENT A second connection may be included in an EXTERIOR ENTERTAINMENT overhead cabinet in the bedroom for the rear TV CENTER (if equipped). ® See your authorized Winnebago Industries –If Equipped dealer for proper installation and sealing of roof The exterior entertainment center contains a mounted components.

  • Page 111: Exterior Entertainment Center (Flip-Up)

    SECTION 8 - ENTERTAINMENT To Flip-up TV Exterior Entertainment Center -Typical View -Typical View Further Information 1. To extend the TV, release the TV lock mechanism by pulling to the left. Please read the manufacturer’s user guide in your InfoCase for complete operating instructions.
  • Page 112 SECTION 8 - ENTERTAINMENT To store TV 1. Pull the TV all the way out and push straight down. 2. Push TV into the compartment. You will hear a “click” when the TV is secured into locked position. Further Information Please read the manufacturer’s user guide in your InfoCase for complete operating instructions.

  • Page 113: Furniture And Softgoods

    SECTION 9 - FURNITURE AND SOFTGOODS LOUNGE CHAIR – SWIVEL –If Equipped (Typical View – Your coach may differ in appearance) This chair is not equipped with a seat belt and is not intended for seating while the vehicle is in motion.
  • Page 114 SECTION 9 - FURNITURE AND SOFTGOODS 3. Latch strap and tighten as necessary for security. WARNING Properly secure all free-standing chairs, furniture, and loose items prior to driving. Moving items can cause driver distraction, possibly resulting in an accident that can result in death or serious injury.

  • Page 115: Sleeping Facilities

    SECTION 9 - FURNITURE AND SOFTGOODS Dinette to Bed 3. Push edge of buffet table in to adjoin with the table extension. 1. Remove both dinette back cushions and set aside. 2. Lift both dinette seat cushions upward. 4. Reverse steps to store buffet table extension. SLEEPING FACILITIES WARNING Sleeping facilities are not intended for use...

  • Page 116: Dinette/Bed Conversion - Dream Dinette

    SECTION 9 - FURNITURE AND SOFTGOODS 4. Release the catch on the table leg brace and fold the leg up against the bottom of the table. Table Leg Catch Bed to Dinette 5. Remove the table from the wall support Reverse steps to convert back into dinette bracket by lifting the end of the table.
  • Page 117 SECTION 9 - FURNITURE AND SOFTGOODS Dinette to Bed 4. Push table straight down. Lower dinette seat cushions. 1. Remove both dinette back cushions and set aside. 5. Rotate lock rod up to secure table in the lowered position. 2. Lift both dinette seat cushions upward. Lock Rod 6.

  • Page 118: Dinette Conversion

    SECTION 9 - FURNITURE AND SOFTGOODS WARNING Failure to engage the lock rod when the table is raised may result in injury. DINETTE CONVERSION –If Equipped (Typical view – your coach may be featured with two dinette tables and pedestal legs, depending on model) Dinette Table Setup -Typical View 1.
  • Page 119 SECTION 9 - FURNITURE AND SOFTGOODS Footrest Lever • To retract footrest, push downward with your 3. For additional sleeping space, lift the front legs and the footrest will close. edge of the recliner seat upward and pull outward from the wall while gently pushing downward until the cushions lie flat.

  • Page 120: Sofa/Bed Conversion

    SECTION 9 - FURNITURE AND SOFTGOODS SOFA/BED CONVERSION –If Equipped Sofa to Bed • Pull OUT on security latch (located on front of sofa) to release sofa seat. Security Latch Handle accessible through front sofa opening Security Latch (Located on front of sofa) - Pull OUT to release •...

  • Page 121: Sofa/Bed Removable Armrests

    SECTION 9 - FURNITURE AND SOFTGOODS SOFA/BED REMOVABLE COMFORT SOFA SLEEPER ARMRESTS –If Equipped (Typical View – Your coach may differ in –If Equipped appearance) Some models may be equipped with Your coach may be equipped with a Comfort removable sofa armrests that must be removed Sofa Sleeper, which is featured with an air bed before converting the sofa into additional that can be adjusted to the firmness of your...
  • Page 122 SECTION 9 - FURNITURE AND SOFTGOODS 3. Rotate the lever lock (located on the bottom NOTE: The air mattress is plugged into an AC right-hand side of the sofa bed) “clockwise” to power outlet behind the sofa. release the bottom section of the sofa bed. It may be necessary to press the “Reset”...
  • Page 123 SECTION 9 - FURNITURE AND SOFTGOODS NOTE: Pump will automatically turn off and the Inflate/Deflate switch will automatically return to the OFF position upon complete deflation. Silent Night Comfort Adjust If your air bed pressure drops below the predetermined pressure level, the Silent Night Comfort Adjust Pump will automatically turn on 3.

  • Page 124: Extendable Sectional Sofa

    SECTION 9 - FURNITURE AND SOFTGOODS Further Information See the air bed manufacturer’s user guide provided in your InfoCase for complete operating instructions, safety precautions, and repair information. EXTENDABLE SECTIONAL SOFA –If Equipped (Typical View – Your coach may differ in appearance) Your coach may be equipped with an Extendable Sectional Sofa, which converts easily...

  • Page 125: Bunk - Front Pull Down

    SECTION 9 - FURNITURE AND SOFTGOODS Reverse steps to store the sectional extension. 3. Grasp the pull strap (located on the front side of the sectional extension seat cushion) and BUNK – FRONT PULL DOWN pull UP and OUT. –If Equipped (Typical View –...

  • Page 126: Power Loft Bed

    SECTION 9 - FURNITURE AND SOFTGOODS POWER LOFT BED –If Equipped (Typical View – Your coach may differ in appearance) NOTE: The Power Loft Bed is not intended for storage. The Loft Bed is stowed near the cab ceiling as shown in the following photo.
  • Page 127 SECTION 9 - FURNITURE AND SOFTGOODS 3. Push the DOWN arrow to lower the Loft Bed. • Attach straps to the brackets located on the cabinet face. WARNING Keep people away from operating mechanism and pinch hazard areas during use. Failure to do so could cause injury.
  • Page 128 SECTION 9 - FURNITURE AND SOFTGOODS 4. Insert manual retractor into loft bed motor (as shown) and turn clockwise to raise the loft bed into stored position. 3. Fasten the safety belt. 5. Turn the key (located on the right sidewall behind the passenger seat) to the “OFF”...
  • Page 129 SECTION 9 - FURNITURE AND SOFTGOODS • Do not overload. Ladder is intended for one person. • Make sure you are physically capable to safely use the ladder. Strength, flexibility and stability are required. • Grasp the side rails firmly and always use both hands as you climb the ladder.

  • Page 130: Roller Shades (Manual) - Solar/Blackout

    SECTION 9 - FURNITURE AND SOFTGOODS You can pre-set the auto-stop positioning of your shade, which allows your shade to retract to a cushioned stop, at the positioning of your choice. NOTE: Ensure top of ladder is properly engaged onto retainer brackets and ladder is resting firmly on floor before using.
  • Page 131 SECTION 9 - FURNITURE AND SOFTGOODS brown lines, wavy or curly graining, bird's eye dots and mineral streaks. These traits are natural and serve to enhance maple's natural beauty. • Cherry is characterized by its red undertones, but may vary in color from white to a deep, rich brown.

  • Page 133: Slideout Rooms And Leveling

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING SLIDEOUT ROOM LOCK SLIDEOUT ROOM OPERATION SYSTEM – ELECTRIC –If Equipped If your vehicle is not equipped with a slideout WARNING room keylock, then the ignition key must be placed in the on or run position to operate the slideout room(s).

  • Page 134: To Retract Slideout Room

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING Extend Procedure: See “Before Extending!” before proceeding. CAUTION • Engage the parking brake. • Start the engine so the alternator can provide Never drive the vehicle with a slideout maximum power for proper operation of room extended! slideout mechanisms.

  • Page 135: Slideout Room - Extreme Weather Precaution

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING NOTICE Because the slideout roof is drawn into the interior of the coach when retracted, be sure there is no debris, such as excessive dirt, tree seeds, twigs, leaves, etc. on the roof before retracting. Slideout Cover-Awning Retract Procedure: -Typical View...

  • Page 136: Manual Override

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING • (9) - HALL POWER SHORT TO • Status • Motor • Mode GROUND. Power to encoder has been LED’s Direction Button shorted to ground. This is usually a wiring problem. NOTE: When an error code is present, the slideout control panel needs to be reset.
  • Page 137 SECTION 10 - SLIDEOUT ROOMS AND LEVELING NOTE: Use caution when removing components on painted units. Push-In Procedure 1. Using a razor blade, remove sealant from the top of screw cover. 4. Gently pull aluminum trim away from sidewall with hand to disengage screw from motor.

  • Page 138: General Slideout Care

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING 7. When the slideout room is fully retracted, secure the room with a support item (e.g. 2x4 wood board) above the interior slideout room to secure room during travel. NOTE: For larger slideout rooms, place a travel support item on each end of the interior slideout room.

  • Page 139: Leveling System

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING Slideout Room Seal Care and while in PARK, raising either one or both of the rear wheels off the ground could Maintenance allow the vehicle to roll off the jacks. While most household cleaners work well for cleaning slideout room seals, certain chemical agents may cause the seals to degrade.

  • Page 140: Checking Hydraulic Oil Level

    SECTION 10 - SLIDEOUT ROOMS AND LEVELING briefly and a chime will sound when the ignition 2. Turn the Leveling System Power switch ON, key is turned to the On or Run positions if the use the arrow “Down” button and select “Auto jacks are down.
  • Page 141 SECTION 10 - SLIDEOUT ROOMS AND LEVELING of debris and contamination of hydraulic oil in the reservoir, which could lead to pump failure or other problems. Breather/Fill Cap Hydraulic Oil Reservoir (Located behind driver side front tire) -Typical View NOTE: Only fill the hydraulic reservoir with the jacks in the retracted (UP) position.

  • Page 143: Maintenance And Storage

    SECTION 11 - MAINTENANCE AND STORAGE SEALANTS – INSPECTION AND GENERAL INFORMATION NOTICE Water is a recreational vehicle’s worst enemy when it is allowed to enter where it is not Sealants must be inspected every 6 intended. Sealants perform a very important months and replaced if necessary.

  • Page 144: Exterior Automotive Paint Finish

    SECTION 11 - MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the • Do not scrape ice or snow from the painted amount of cargo you can carry and remain within surface. Brush off gently with a soft-bristled GVWR and GAWR limits.
  • Page 145 SECTION 11 - MAINTENANCE AND STORAGE Washing NOTE:Avoid aiming water flow from a hose or spray from high-pressure washing • Commercial vehicle wash facilities should be equipment into any appliance intake, as strictly avoided! They will scratch your RV! damage or difficulty in operating Truck-style wash centers have high- appliances may occur.

  • Page 146: Exterior Graphic Care

    SECTION 11 - MAINTENANCE AND STORAGE Further Information • Avoid paste waxes. They sometimes have fillers and additives that give a very short term See the manufacturer’s information provided result. Stay away from silicones in polishes in your InfoCase for complete care and and soaps.

  • Page 147: Exterior Lights

    SECTION 11 - MAINTENANCE AND STORAGE EXTERIOR LIGHTS NOTICE ® Most Winnebago Industries vehicles have polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical Do not use citrus-based cleaners on solvents and cleaners. polycarbonate finishes. Citric compounds Use only soap and water to clean exterior will damage the high-gloss surface, lamp lenses, especially headlights.
  • Page 148 SECTION 11 - MAINTENANCE AND STORAGE Care Instructions shades should be closed when the motorhome is parked for an extended • Spot clean with mild soap and water. period of time. • Air dry or, if desired, dry quickly using a hair dryer on warm setting - not hot.

  • Page 149: Ceiling Fabric Care

    SECTION 11 - MAINTENANCE AND STORAGE Most commercially available carpet and CEILING FABRIC CARE upholstery cleaners will do an excellent job removing stains. From time to time, additional –If Equipped cleaning methods may need to be used to remove While using your coach, your ceiling fabric stubborn or difficult stains.

  • Page 150: Cabinetry - Cleaning

    SECTION 11 - MAINTENANCE AND STORAGE You may have to repeat this procedure more spray cleaner. You can also use liquid or gel-type than once to achieve desired results. Finish up cleaners containing bleach. Because the material with clean water, using the same method, and is nonporous, stains cannot penetrate below the blot dry.

  • Page 151: Stainless Steel Appliances

    SECTION 11 - MAINTENANCE AND STORAGE Stubborn Dirt and Burnt Grease Avoid paint remover or oven cleaner. The solid surface material is also resistant to most Use a multipurpose cream detergent and a soft chemical substances but exposure to some harsh cloth.

  • Page 152: Range And Refrigerator

    SECTION 11 - MAINTENANCE AND STORAGE • For stubborn stains, use a mild abrasive NOTE: Floor cleaners containing waxes, ® ® cleanser like Soft Scrub , Comet , etc. Work brighteners, or gloss agents are not in the direction of the “grain” of the brushed recommended.

  • Page 153: Bathroom

    SECTION 11 - MAINTENANCE AND STORAGE Asphalt, candle grease, chewing gum, fat, oil, DOORS AND WINDOWS tar, and shoe polish: • Gently remove with a blunt instrument and Windows may be periodically cleaned with a treat with a soft nylon pad and non-abrasive good quality glass cleaner or mild soap solution floor cleaner.

  • Page 154: Vehicle Storage - Removal

    SECTION 11 - MAINTENANCE AND STORAGE NOTE: We do not recommend leaving the 5. Close all faucets and drain valves that are shoreline plugged in continuously during open. storage. 6. Add a few gallons of water to the fresh water tank and turn on the water pump to check for 6.

  • Page 155: Chassis Service And Maintenance

    SECTION 11 - MAINTENANCE AND STORAGE Re-sealing is quite simple and the material is quickly and easily applied. Appropriate compounds are available from your dealer. See “Sealants – Recommended Application” page in the Supplement Manual provided in your InfoCase. Also inspect weather seals around doors, etc., and if necessary, have a dealer replace immediately.

  • Page 156: Coach Maintenance Chart

    SECTION 11 - MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System ...
  • Page 157 SECTION 11 - MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: ...
  • Page 158 SECTION 11 - MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants ...

  • Page 159: Miscellaneous

    SECTION 12 - MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motorhome’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available WARNING space when loading your motorhome.
  • Page 160 SECTION 12 - MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motorhome is to weigh each “corner”...

  • Page 161: Car Or Trailer Towing

    SECTION 12 - MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual listed Gross Weight Ratings. See “Vehicle set (left rear duals or right rear duals) should not Certification Label” in the Introduction section exceed 6,000 lbs. for information on gross weight ratings.

  • Page 162: Trailer Wiring Connector

    SECTION 12 - MISCELLANEOUS located outside our recommended limits) places The following diagram shows proper excessive stress on the hitch. This abuse of the connection of trailer or tow vehicle wiring to the ball mount and the hitch may cause premature coach light system.

  • Page 163: Fireplace

    SECTION 12 - MISCELLANEOUS transmission, drive line, drive axle, and others. equipped with a Class IV hitch have a The tow vehicle brakes may be rated for label limiting vertical tongue load to 500 operation at GVWR, not GCWR. lbs. On a 228" wheelbase, a 500-lb. load on a hitch 11' from the rear axle will NOTE: State or provincial laws/regulations may apply about 800 lbs.

  • Page 164: Control Panel

    SECTION 12 - MISCELLANEOUS Remote Operation Control Panel • Flame • Heater • Power • Power • Flame • Timer • Heater • Backlight • Timer • Backlight NOTE: Holding the POWER button on the control panel for ten seconds will disable Fireplace Remote Control the heater function.

  • Page 165: Windows

    SECTION 12 - MISCELLANEOUS Stationary Extended Mode - Step Switch OFF (Step Remains Extended) With the Step power switch in the OFF position, the step will extend when the screen door is opened and will stay extended whether the door is opened or closed. NOTE: The step switch is “locked”...

  • Page 166: Power Roof Ventilator

    SECTION 12 - MISCELLANEOUS Vertical Slider Windows Vertical windows have spring-loaded catches on both sides of the window that pop out to hold the window in its fully raised position. Press both catches inward while opening and closing the window. -Typical View •...

  • Page 167: Entrance Door Prop Rod

    SECTION 12 - MISCELLANEOUS Further Information Manual Dome Fuse Fan Speed See the power ventilator manufacturer’s Crank Knob Selector operating instructions supplied in your InfoCase for further instructions, care, and cleaning information. ENTRANCE DOOR PROP ROD –If Equipped (Typical view – your coach may differ in appearance depending on model.) The main entrance door may feature a rod designed to prop the entrance door open when the...

  • Page 168: Awning - Power

    SECTION 12 - MISCELLANEOUS Further Information AWNING – POWER For complete operating instructions, features, –If Equipped safety precautions, and maintenance care, refer to The Power Awning switch is located on the the Awning manufacturer’s user guide provided control panel just inside the entrance door. in your InfoCase.

  • Page 169: Humidity And Condensation

    SECTION 12 - MISCELLANEOUS The ladder on your vehicle is provided for EFFECTS OF PROLONGED limited access to the roof. OCCUPANCY Walking or working on the roof should be left to qualified service personnel using proper safety Your motorhome was designed primarily for equipment in a safe environment.
  • Page 171 INDEX About this Manual ..........................1-1 Air Conditioner Filter ........................... 4-14 Air Conditioner/Heater – Automotive (Dash) ..................3-12 Audio/Video System Basic Operation ....................8-1 Audio/Video System Cables ........................8-5 Awning – Power ..........................12-10 Bathroom ............................11-11 Battery Access ............................6-11 Battery Boost Switch ..........................
  • Page 172 Index Doors and Windows ..........................11-11 Drainage System (P-Traps) ........................7-8 Driving Safety ............................2-1 Ducted Roof Air Conditioning System ....................4-14 DVD Player ............................. 8-1 Effects of Prolonged Occupancy ......................12-11 Electrical ..............................2-6 Electrical Cautions ..........................6-1 Electrical Generator – 120-Volt ......................6-8 Electrical Outlets –...
  • Page 173 Index Ice Maker ..............................4-4 Ice Maker Water Filter ..........................7-5 Interior Soft Goods ..........................11-5 Inverter Unit – 1000W ..........................6-3 Inverter/Charger Unit – 2000W ......................6-4 Jump Starting ............................2-11 Keys ................................ 3-5 Leveling System ........................... 10-7 Lights ..............................3-16 Loading ..............................
  • Page 174 Index Range and Refrigerator ........................11-10 Range Hood ............................4-7 Rearview Monitor System ........................3-6 Refrigerator – Residential ........................4-3 Refrigerator ............................. 4-1 Refrigerator ............................. 4-2 Refrigerator Service Access Compartment – Residential ............... 4-5 Refrigerator Service Access Compartment ..................... 4-5 Reporting Safety Defects ........................
  • Page 175 Index Tires ..............................3-15 Toilet ............................... 7-7 Tool and Ladder Storage ........................12-10 Tow/Haul Transmission Mode ....................... 3-8 Towing Guidelines ..........................12-4 Trailer Wiring Connector ........................12-4 TV – Bedroom (Flip Down) ........................8-6 TV (Dining Buffet) - Power Lift ......................8-5 TV Antenna –...

Table of Contents
