Summary of Contents for Creda HB37766E
-
Page 2: Table Of Contents
Contents Safety Advice Electrical Requirements Features - get to know the main parts of your Dryer Where to put your Dryer How to use your Dryer The Controls 10-11 Sorting your laundry 12-13 Items requiring special attention Easy Care Programme Guide to Drying Times Caring for your Dryer If something goes wrong... -
Page 3: Safety Advice
For your safety IMPORTANT Using your Tumble Dryer is easy. Nevertheless, for your own safety and to get the best results it is important to know your Dryer by reading right through this handbook before using your dryer for the first time. NEVER Allow children to play with or otherwise interfere with the dryer. - Page 4 For your safety ALWAYS When the dryer is not in use, switch off at the wall, remove plug and close the door. ALWAYS Comply with the specified electrical requirements. ALWAYS Ensure that the mains cable and plug is completely withdrawn from its storage place in the rear exhaust duct.
-
Page 5: Electrical Requirements
Electrical Requirements WARNING: This appliance must be earthed! Supply REFER TO THE RATING PLATE FOR VOLTAGE AND CURRENT REQUIREMENTS (see diagram for location.) The flexible mains lead is supplied fitted with a BS1363 plug and with a 13 amp BS1362 fuse. The plug should be connected to the mains supply via a suitable switched socket which is accessible after installing your dryer. -
Page 6: Features - Get To Know The Main Parts Of Your Dryer
Features - Get to know the main parts of your dryer Model and serial numbers NOTE: if your FLUFF FILTER dryer is new Clean after each use wipe out the inside of the drum before you first use it to remove any dust which may have accumulated... -
Page 7: Where To Put Your Dryer
Where to put and vent your dryer Your Tumble Dryer should NOT be located adjacent to a gas hob cooker, heater, or eye level grill as flames from the burners could cause damage to your machine. When the dryer is fitted under a work surface allow space for air to enter the rear grille, 10mm above the dryer minimum. - Page 8 Where to put and vent your dryer Permanent In conjunction with the vent hose we recommend the use of a Venting Wall/Window Vent Kit. These are available from your retailer or nearest Spares Centre. Wall/Window Fitting instructions are supplied with the kits, which can be mounted Venting through a wall or window.
-
Page 9: How To Use Your Dryer
How to use your dryer 1. Plug in, switch 2. Sort your laundry on electricity. (see section “Sorting WARNING: WHEN Your Laundry”) SWITCHING ON OR OFF, PLEASE ENSURE THAT YOUR HANDS ARE DRY 4. Always check 3. Open the door FLUFF FILTER is the following: by pressing the... -
Page 10: The Controls
The Controls Heat Switch (OUT low heat, IN high heat) Audio Switch Start button Door Release button Filter Care Light (selected models) Mains On light Indicator Setting the timer Turn the timer clockwise to select the required drying time. The drying time for both heat settings is controlled by the timer. All you have to do is turn the timer control clockwise until the required time appears in line with the indicator. - Page 11 The Controls Selecting the To select high heat (Cottons and synthetics), the heat selection required Heat switch must be In. Switch Setting To select Low heat (Acrylics), the heat selection switch must be Out, a blue indicator will be visible on the top of the switch. See section “Guide to Drying Times”.
-
Page 12: Sorting Your Laundry
Sorting your laundry 1. Always separate laundry into the correct fabric groups before washing and drying. 2. See that all zips are closed, hooks and eyes are fastened and belt, strings etc. are tied loosely in bows, you will normally have done this for each item before the washing stage. - Page 13 Wash Care Labels Most of today’s fabrics can be tumble dried in your Dryer with no trouble at all, but there are certain fabric finishes which should be dried away from direct heat. The majority of garments now have wash-care labels on them, giving full washing and drying instructions.
-
Page 14: Items Requiring Special Attention
Items requiring special attention The drying requirements of blankets and bedspreads will, of course, Blankets and Bedspreads vary tremendously according to size and weight. Some, however are simply too big. if you have difficulty getting them into the Dryer, the machine will have difficulty drying them properly. -
Page 15: Easy Care Programme
Easy Care Programme Creda ‘Easy Care’ provides a short programme consisting of approximately 7.5 minutes of heat with an approximately 2.5 minutes cool tumble period. It is a short conditioning programme that softens the fibres allowing them to relax making handling and ironing easier and less time consuming. -
Page 16: Guide To Drying Times
Guide to drying times Please note that the drying times stated below and on appliance control panel; are a GUIDE only and drying times are affected by:- The amount of Items such as towelling retain a lot of water after spinning, also the water remaining suggested wash programme for small items such as T-Shirts may in the clothes... -
Page 17: Caring For Your Dryer
Caring for your Dryer Your Tumble Dryer needs very little attention. The following simple steps will keep it performing well. When finished Switch off electricity and remove plug. Ensure hands are dry. After each load Always clean the filter, by rinsing under the tap or using a vacuum cleaner. - Page 18 Spare parts Please remember your new appliance is a complex piece of equipment. ‘DIY” repairs or unqualified and untrained service people may put you in danger, could damage the appliance, and might mean you lose cover under the Parts Guarantee. If you do experience a problem with the appliance don’t take risks, call in our Service Engineer.
-
Page 19: If Something Goes Wrong
If something goes wrong First, don’t panic! There may be nothing wrong at all. Look for your problem below, then check the things we suggest. More often than not, this will give you the answer to your problem, and you’ll be able to carry on without having to telephone your Service Office. - Page 20 08701 54 64 74 For further product information All Creda Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.
