Summarization of Contents
Hook-Up Guide
Direct By-Pass
Routes instrument directly to the output jack when the unit is off.
Input Connection
Set input switch to match instrument pickup for optimal level and impedance.
Instrument Output
Connects to amplifier's input jack for normal volume and tone.
D.I. Output
Provides balanced D.I. output for connecting to mic inputs.
External Power Option
Accepts wide range of AC/DC power supplies via standard jack.
Phantom Power
Supplies reliable power when 48V phantom power is applied to D.I.
9V Battery Power
Unit can be powered by a 9V battery for portable use.
Controls Overview
Big Bottom Effect
Dynamically enhances low end for bass instruments or adds warmth to acoustic instruments.
Aural Exciter Effect
Adds definition, air, and clarity by recreating harmonic details.
Key Controls Explained
Describes Hi Tune, Hi Blend, Foot Switch, and LED indicator functions.
Tune-Up Procedures
Optimal Placement and Rules
Guidance on pedal placement relative to other effects and amplifiers.
Setting Up Big Bottom
Adjusting Lo Tune and Lo Blend for desired bass enhancement.
Setting Up Aural Exciter
Adjusting Hi Tune and Hi Blend for desired treble enhancement.
Technical Theory
History of Aural Exciter
Traces the development and impact of the original Aural Exciter.
Understanding Aural Exciter
Explains how the exciter recreates lost harmonics and enhances sound realism.
Understanding Big Bottom
Explains how Big Bottom enhances low frequencies and improves tone.
