BEFORE YOU START Congratulations on your purchase of a RED DSMC ® Digital Still and Motion Camera. Please read the attached safety instructions, and only then unpack the camera body and any accessories. If there is any physical damage or missing components for either your camera body or any accessories, please file a support ticket at www.RED.com/support.
Page 10 shock and serious injury to the user. DO NOT use the camera in the rain or under other conditions with high moisture without appropriate protection, and immediately remove power source if camera or accessories are exposed to moisture. WARNING: To reduce the risk of fire or electric shock, do not expose the camera or accessories to rain or moisture.
Page 11 CAUTION: The power cord plug for the AC Power Adapter is used as the power disconnect. To disconnect all power from the AC Power Adapter, unplug the power cord plug from the wall outlet. During use, the power cord plug should remain easily accessible at all times. R.
Page 12: Theory Of Operation
THEORY OF OPERATION The RED family of Digital Still and Motion Cameras (DSMC) provide high performance digital imaging over a wide range of frame rates and optical formats including Super 35mm / APS-H. The RED DSMC camera is supplied as standard with a PL mount, and may be configured with mounts and 19 mm rods to accommodate most cinematography lenses, matte boxes and follow focus systems.
Page 13: Hdrx
This recording technique permits RGB color processing choices to be deferred to post production or to be adjusted in the field to help a director visualize alternative color treatments, without affecting the recorded RAW data’s image quality or dynamic range. The camera’s monitoring path converts RAW sensor data to a white balanced 12-bit depth 2048 x 1080 pixel RGB 4:4:4 video signal.
Page 14: Magic Motion
• Exporting to EXR file format will give you a multi-view EXR with both exposures (like a stereo EXR). NOTE: If you ignore the X-track data, you will have a standard exposure with up to 13.5 stops of dynamic range just as if you had not enabled HDRx. For this reason, we encourage the A-track exposure to be "normal"...
Page 15: Line Level Analog Inputs
LINE LEVEL ANALOG INPUTS The recording level of a Line input is affected only by the signal provided by the field production sound mixer or other external line level source. The sound mixer operator should choose a mixer output level that aligns a reference tone signal to the 0dBu (-20dBFS) reference mark drawn on the camera’s Audio Level Meter, or if using 0VU as reference level, a mixer output level that aligns a reference tone signal to the 0VU (-16dBFS) reference mark.
Page 16 Example of HDMI Monitor Output in MENUS mode. RED LCD / BOMB EVF ® The optional RED LCD and BOMB EVF are specialized video monitors that provide the user with a variety of tools to assist framing, focus and exposure, including: Surround View™, which is an additional look around area, visible outside of the recorded image.
Page 17: Redmote
REDMOTE ® REDMOTE is a camera control unit for RED’s family of DSMC cameras that attaches to the rear of the camera Brain or rearmost expansion module. REDMOTE may also be detached from the camera or rearmost module and provide wireless remote control of the camera over proprietary REDlink™ protocol. Whether attached or operating via wireless, REDMOTE supports all controls necessary to operate the camera, including Record Start / Stop, Shutter Speed, White Balance, ISO and programmable User Keys.
Page 18: Metadata
Typical Magazine Folder and clip structure For additional information about digital magazines, refer to APPENDIX B: MANAGING DIGITAL MEDIA. METADATA RED’s family of DSMC cameras record extensive Metadata, which is data that describes all the characteristics of the picture and sound signals in every frame of the recording. This includes camera setup information, project and RGB color management information, Clip Name, Time Code, Date and GMT, lens and shutter speed / angle parameters, audio configuration, plus any externally provided metadata.
Page 19: Smpte Timecode
MULTI CAMERA SHOOTS The scheme provides flexibility to uniquely identify Clips from different cameras on a multi-camera shoot. For example three cameras, slated as camera A, camera B, and camera C respectively, can generate these easily recognizable clips on their respective digital media Magazines. A001_C001_0502**.RDC B001_C001_0502**.RDC C001_C001_0502**.RDC...
Page 20: Camera Operational Controls
CAMERA OPERATIONAL CONTROLS This section describes the available operational controls on the RED DSMC camera Brain, Side SSD Module, Side Handle and REDMOTE accessories. BRAIN Power Status LED Power / Record Button Record Status LED Power / Record Button / Status LEDs •...
Page 21: Side Ssd Module
o LED Red Blinking = Power present. Battery Below 5% • Record Status LED: Indicates record status: o LED Off = No Media present. o LED Green = Ready to Record o LED Red Constant = Recording o LED Red Slow Blink = Recording, 25% Media Left o LED Red Fast Blink = Recording, 5% Media Left o LED Yellow = Finalizing •...
Page 22 • SSD Slot: Slot for REDMAG 1.8” SSD digital media Magazine. • User Key 1: Initiates user defined camera function. Undefined by Default. • User Key 2: Initiates user defined camera function. Undefined by Default. • User Key 1 + User Key 2 : Press both keys to Eject (unmount) REDMAG 1.8” SSD Magazine. •...
Page 23: Side Handle
SIDE HANDLE Battery Release LCD Menu Keys Focus / Record Button LCD Display Adjustment Ring LCD Backlight Button RED Side Handle Controls - Top • Battery Door Release Button: Releases Side Handle battery door to permit battery exchange. • Focus / Record Button: Touch for Auto Focus, fully depress to Start or Stop Record. •...
Page 24: Front
FRONT Stills / Movie Slider Side Handle Controls - Front • Stills / Movie Slider: Selects between STILLS and MOVIE modes of operation. NOTE: This switch is not active at this time. Default camera operation is MOVIE Version 3.0 COPYRIGHT © 2012 Red.com, Inc. 955-0002_v3.0, Rev-B...
Page 25: Rear
REAR RED Side Handle Controls - Rear MENU Button User Keys A-D Rocker Switch System Keys 1- 3 Navigation Group Thumbwheel Lock • Menu Button: Press to access / camera setup menus. • Rocker Switch: Increases or decreases selected value based on parameter selected in USER KEYs. Version 3.0 955-0002_v3.0, Rev-B COPYRIGHT ©...
Page 26 • Navigation Group: Allows navigation through camera menus, selection of camera parameter for adjustment, and adjustment of selected camera parameter. Side Handle Navigation Group Scroll Wheel Direction Keys Enter Button o Scroll Wheel: Selects and adjusts camera parameter value. o Direction Keys: Navigates camera menus and may select parameter for adjustment. o Enter Button: Confirms selected parameter value adjustment.
Page 27: Installation / Removal
INSTALLATION / REMOVAL WARNING: THE SIDE HANDLE IS NOT HOT SWAPPABLE - MEANING YOU CANNOT REMOVE OR INSTALL WHILE THE CAMERA IS POWERED ON. BEFORE INSTALLING OR REMOVING THE SIDE HANDLE, YOU MUST POWER DOWN THE CAMERA. FAILURE TO DO SO MAY RESULT IN DAMAGE TO THE SIDE HANDLE AND / OR CAMERA BRAIN THAT IS NOT COVERED BY WARRANTY.
Page 28 To remove the side handle: 1. Power down the camera if necessary. 2. Rotate the thumbscrew downwards until detached from camera body. Disengage lip from top of camera brain. Rotate side handle upwards to remove. Rotate thumbscrew downwards until loose. 3.
Page 29: Quad Battery Module
QUAD BATTERY MODULE Quad Battery Module – Shown with REDVOLT batteries Installed Battery Status LED Battery Eject Button • Battery Status LED: Indicate current charge status of corresponding battery. • Battery Eject Button: Ejects corresponding battery to permit battery exchange. INSTALLATION / REMOVAL WARNING: THE QUAD BATTERY MODULE IS NOT HOT SWAPPABLE - MEANING YOU CANNOT REMOVE OR INSTALL WHILE THE CAMERA IS POWERED ON.
Page 30 3. Install the Adapter Plate. a. Place the adapter plate over the v-mount on the rear of the camera brain. b. Using a T-20 Torx, lightly tighten the four screws. Do not overtighten. Version 3.0 COPYRIGHT © 2012 Red.com, Inc. 955-0002_v3.0, Rev-B...
Page 31 c. Tighten the screws again in a cross pattern until tight. 4. Install the Quad Battery Module a. Insert the lip at the top of the battery module into the recess at the top of the adaptor plate. Insert Lip At Top of Adaptor Plate Rotate Battery Module Down Until Flush with Adaptor Version 3.0...
Page 32 b. Rotate battery module down flush with the rear of the adaptor plate. c. While applying steady pressure to hold the battery module against the adaptor plate, use a T-20 Torx screwdriver to rotate the lock on the adapter plate clockwise to secure the battery module. Press Battery Module Flush with Adaptor Rotate Lock Clockwise...
Page 33: Redmote
4. Remove battery module from adapter plate. 5. Use a T-20 to loosen the screws attaching the adaptor plate the camera brain. 6. Remove the adaptor plate from the camera brain. REDMOTE This section describes the physical controls on the REDMOTE. For complete details on REDMOTE control, refer to APPENDIX E: REDMOTE OPERATION.
Page 34 • User Keys: Press to initiate camera functions as defined in USER KEY menu. Default settings for User Function Keys A-D are as follow: User Key A – Toggles Focus Assist Indicator User Key B – Toggles False Color > RAW Check User Key C –...
Page 35: Bomb Evf
BOMB EVF BOMB EVF Focus Ring Brightness Control EVF Tally Light • Focus Ring: Adjusts optimal subject focus for your eye. Available diopter range is +2.0 to -5.0. • EVF User Key (B): Increases EVF display brightness. • EVF User Key (C): Decreases EVF display brightness. NOTE: The specific function of EVF user keys (B/C) may be programmed by the user.
Page 36: Touchscreen Lcd
TOUCHSCREEN LCD RED Touchscreen LCD Backlight Adjust LCD User Key C LCD User Key D • Backlight Adjust: Adjusts LCD backlight intensity. Upper button +, Lower button - • LCD User Key C: Press to execute user defined function. Default: Toggles False Color > 1:1 Magnify. •...
Page 37: Basic Operation
BASIC OPERATION This section describes basic operation, starting from power up, Viewfinder layout and Menu navigation. WARNING: THE SIDE HANDLE, SIDE SSD MODULE, REAR MODULES AND LENS MOUNT ARE NOT HOT SWAPPABLE – MEANING YOU CANNOT REMOVE OR INSTALL THEM WHILE THE CAMERA IS POWERED ON.
Page 38: Quad Battery Module
QUAD BATTERY MODULE The optional QUAD BATTERY MODULE accepts up to four REDVOLT or up to two REDVOLT XL batteries, which can power the camera and typical accessories. Quad Battery Module REDVOLT AND REDVOLT XL REDVOLT and REDVOLT XL Note: When multiple batteries are installed in the Quad Battery Module, the power management circuit will select the lowest charged battery to supply power to the camera.
Page 39: Quickplate
BACKPACK QUICKPLATE The optional BACKPACK QUICKPLATE attaches directly to the back of the DSMC BACKPACK to provide a compact REDBRICK configuration for EPIC or SCARLET-X. Note: DSMC BACKPACK is required for use of the BACKPACK QUICKPLATE BACKPACK QUICKPLATE REDBRICK Version 3.0 955-0002_v3.0, Rev-B COPYRIGHT ©...
Page 40: Ac Power Adaptor
AC POWER ADAPTOR - (DSMC) AC POWER ADAPTOR - (DSMC) When powering from the Module it is called in the lower UI as Rear Module (RM Bx) Bay number on lower UI, and identified as Rear 1-4 in the POWER status menu. In use, an LED on the Quad Battery Module will flash to show the battery currently powering the camera.
Page 41: External Dc Power
Battery location and status are displayed in the lower UI. In this case RM B1 (Rear Module,Bay 1). Battery location and status are also displayed on REDMOTE. In this case RM B3 (Rear Module, Bay 3). The POWER menu also shows all installed batteries and their state of charge. EXTERNAL DC POWER RED DSMC Cameras accept input voltages between 11.5V - 17V D.C and can draw a maximum current of 12 Amps.
Page 42: Power Up
POWER UP Locate the camera’s Power / Record button on the right face of the Brain. NOTE: This button also serves as a Record Start / Stop button once the camera is powered up. Power Status LED Power / Record Button Media Status LED Power / Record Button / Status LEDs When an appropriate power source is connected to the Brain, the Power Status LED will illuminate Red.
Page 43: Power Down
NOTE: Once powered up, if the Power Status LED illuminates Red, it indicates low remaining battery capacity and a battery exchange or switch over to external DC power is recommended. POWER DOWN The camera can be powered down in two ways: 1.
Page 44: Graphical User Interface And Navigation
GRAPHICAL USER INTERFACE AND NAVIGATION RED LCD/TOUCHSCREEN LCD, BOMB EVF, EXTERNAL MONITORS The following is a general description of the structure of the camera’s Graphical User Interface (GUI) which overlays the video monitor signal on the Viewfinder output(s) of the camera. SHUTTER SPEED WHITE BALANCE ISO RATING...
Page 45 • • Frame Guide: Record or Projection area Genlock: Indicates presence of valid Genlock signal / sensor sync to genlock • Next Clip Filename: Filename of the clip that • will be shot next Jam Sync: Timecode Jam Sync status / time code jam •...
Page 46 The GUI is broken down into the following three main sections: the Upper Status Row, the Live Action Area, and the Lower Status Row. On VIEWFINDER output(s), all three sections are visible, on PREVIEW outputs only the Live Action Area and associated graphic overlays are visible. On PROGRAM outputs, none of the graphic overlays are visible, i.e.
Page 47 LIVE ACTION AREA Contains the recorded image area plus Surround View™ look around area, plus overlays for Frame Guide, Safe Action / Safe Title and the current Clip Name and Timecode values. Each overlay may be color coded in one of 5 colors to maximize the contrast between the guide(s) and scene being captured. LOWER STATUS ROW The Lower Status Row provides feedback on key systems level camera values, including: •...
Page 48 • GEN Green - A genlock signal compatible with the current project and monitor rates has been locked SYNC • SYNC Gray - The sensor sync mode is not Genlock. • SYNC Red - The sensor sync mode is Genlock, but it is not locked to any genlock signal. •...
Page 49 RAW CLIP METER The RAW Clip meter looks a traffic light style meter and indicates if either of the Red, Blue or Green channels of the RAW sensor data are clipping. This meter is unaffected by White Balance, ISO, VIEW or LOOK settings and therefore represents a true measurement of the exposure levels of the sensor at all times.
Page 50: Side Handle
SIDE HANDLE As you navigate and adjust settings on the camera (main menu settings only), they will be reflected on the Side Handle LCD display. The display elements include: • • Power: Camera power status (DC Shown) ISO Rating: Camera sensitivity •...
Page 51: Navigating Menus
• • Frame Rate: Current frame capture rate Gen: Indicates presence of valid Genlock signal • Shutter Speed: Exposure Time (or Degrees) • Sync: Timecode Jam Sync status • White Balance: Color Temp • RIG: Indicates 3D rig metadata is present •...
Page 52: Using Touchscreen Lcd
USING TOUCHSCREEN LCD If operating a Touchscreen LCD, camera menu navigation may be made through finger gestures. • To adjust a parameter value, simply touch it, and then swipe the finger left / right to adjust its value. • To access an advanced parameter settings display, press and hold down on the parameter icon. •...
Page 53: Power Down
• Touching the Audio Meter will display the Audio Input menu. Refer to SECONDARY MENUS > SETTINGS > AUDIO/VIDEO for complete information. POWER DOWN NOTE: Camera will automatically power down if supply voltage drops to 11.5 Volts. POWER MENU 1. Select the MENU icon in the right corner of the Upper Status Bar to reveal the Secondary Menus.
Page 54: Touchscreen Opreration
LOCK / UNLOCK TOUCHSCREEN OPRERATION LOCK To lock out the touchscreen operation, touch and hold the MENU icon until the LOCK icon displays; indicating the touchscreen has been locked out. When locked, the main menu will be displayed. UNLOCK To unlock out the touchscreen and allow normal operation, touch and hold the LOCK icon until the MENU icon displays;...
Page 55: First Time Use - Setting Up Your Red Epic
FIRST TIME USE – SETTING UP YOUR RED EPIC 1. ATTACH POWER SOURCE If a REDVOLT battery is installed in the Side Handle and DC power is connect through the DC IN connector, the DC IN power supply has priority and will power the camera instead of the battery. BATTERY Connect a RED battery to the camera in one of the following ways: SIDE HANDLE...
Page 56: Quad Battery Module
REMOVE 1. Press the battery door release button (A). 2. Open battery door (B). 3. Press upwards on retainer (C) to release battery. 4. Remove battery from side handle. QUAD BATTERY MODULE Attach a Quad Battery Module and insert one or more REDVOLT batteries. INSTALL Insert battery into desired location and press until a click is heard and battery is seated.
Page 57: Red Brick
RED BRICK Attach to the camera using a V-Plate and 2B-to-1B Power Adapter Cable P/N 790-0138 to the DC IN connector. DC POWER Connect a DC power source to the camera in one of the following ways: • Plug the RED AC Power Adapter into AC power, and the LEMO connector to the DC IN connector. •...
Page 58 NOTE: When fully inserted, the SSD media protrudes slightly from the SSD slot as indicated above. When SSD media is inserted into the camera, the camera will recognize if the media is unformatted: On LCD, EVF and external monitors, in the media section of the GUI, NONE will be displayed twice (as opposed to when no media is inserted, the GUI displays NONE with three dashes below “---“).
Page 59: Perform A Black Shading Calibration
PERFORM A BLACK SHADING CALIBRATION Refer to SECONDARY MENUS > SETTINGS > MAINTENANCE > CALIBRATION for complete details for performing a Black Shading Calibration. ADJUST PROJECT SETTINGS TIME BASE To adjust the project TIME BASE, press the MENU button on the Side Handle or REDMOTE. Then use the Scroll Wheel or Direction Keys to navigate to SETTINGS >...
Page 60: Recording
RECORD RESOLUTION To adjust Record Resolution, navigate the Cursor to the RESOLUTION icon in the Upper Status Row and press the Navigation Group ENTER key. Adjust to the desired value using the Scroll Wheel and press ENTER a second time to confirm. If using a Touch Screen, press the RESOLUTION ICON, adjust RESOLUTION by sliding your finger left / right, or tap on the desired resolution, and then press anywhere else on the touch screen to confirm.
Page 61: Record Indicator
Fully depress again to stop recording. The camera will automatically create a unique and sequential file name for each clip recorded on the SSD based on the Camera’s I.D set in the MEDIA menu. REDCODE RAW data recordings store the Color Temperature and Exposure (ISO) and any RGB color processing values you use in the monitor path as metadata.
Page 62: Playback
SMPTE-RP188 timecode VITC-2 HANC metadata record flag will be enabled on HD-SDI outputs. If enabled in the USER KEYS menu, the GPO trigger output in the CNTL connector will pulse. 5. PLAYBACK Playback is available on the RED DSMC Camera by going to SECONDARY MENUS > SETTINGS > PLAYBACK or by touching the Playback arrow icon in the upper Left corner of the GUI.
Page 63: Menu Controls
MENU CONTROLS Displayed in the Upper Display Group of the VIEWFINDER output(s), are FRAMERATE (FPS), EXPOSURE (ISO), _._ (F/Stop), WHITE BALANCE, RESOLUTION, and QUALITY (REDCODE). These parameters are adjustable directly through this screen. When using the touchscreen, directly to the right of these parameters is the MENU icon which when pressed will take you to the secondary camera set up menus.
Page 64: Advanced Setting Menus
• To close an alpha numeric keypad when entering information directly, tap anywhere on the screen outside the keypad. ADVANCED SETTING MENUS At this time, only FRAMERATE, F-STOP, SHUTTER SPEED and WHITE BALANCE on the MAIN MENU have advanced settings and SIDE HANDLE / REDMOTE 1.
Page 65: Main Menu
MAIN MENU Available options under the MAIN MENU are FRAMERATE (FPS), ISO (SENSATIVITY), F STOP, 1/SEC (EXPOSURE), WHITE BALANCE, RESOLUTION, and QUALITY (REDCODE). Used to select an image capture frame rate that differs from the Project’s TIME BASE frame rate. Ranges are as follows: •...
Page 66: Basic Settings
If you press record with a frame rate set too high for the selected record quality, you will be prompted to allow the camera to change the REDCODE setting to the maximum quality that enables that frame rate. REDMOTE will also display this message. BASIC SETTINGS Provides quick selection of the most common VARISPEED frame rates.
Page 67: Iso (Sensitivity)
ISO (SENSITIVITY) Adjusts the camera’s ISO rating. The sensitivity value is adjustable in 1/3 stop increments. When the ISO rating is adjusted, the camera logs the change as metadata and the monitor path reacts accordingly. Higher ISO values lead to brighter images in the monitor path, and vice versa. Range is ISO 250 –...
Page 68 BASIC SETTINGS Allows adjustment of the aperture (F stop) of the attached lens. The range will vary depending on the attached lens. ADVANCED SETTINGS When selected, the advanced settings menu allows fine control over the f-stop value under APERTURE and focal distance under FOCUS. APERTURE (F STOP) Provides the ability to enter the F stop value directly.
Page 69: Exposure
FOCUS Provides the ability to enter the focal distance directly. Range depends on attached lens. Default depends on attached lens. EXPOSURE BASIC SETTINGS Adjusts the exposure of each frame captured by the MYSTERIUM X sensor. Shutter speed presets are provided for all common speeds (and shutter angles) for 24 / 25 fps and 50 / 60 fps project frame rates. Decreasing Shutter Speed increases the amount of time over which light falls on the sensor, increasing exposure and motion blur on any objects moving within the frame.
Page 70: Advanced Settings
ADVANCED SETTINGS When selected, the advanced settings menu allows fine control over the Exposure value, and permits entry in any of the three following common units – EXPOSURE (Shutter Speed), INTEGRATION TIME or ABSOLUTE ANGLE (Shutter Angle). EXPOSURE (SPEED) Provides the ability to enter the Exposure value as a Shutter Speed (1/xx sec). Range is 2 –...
Page 71 INTEGRATION TIME Provides the ability to enter the Exposure value as a Shutter Integration Time (xx milliseconds). Range is 0.125 to 41.708 mS (milliseconds) Default is 20.833 MS ABSOLUTE ANGLE Provides the ability to enter the Exposure value as a Shutter Angle (xx Degrees). Range is 1.000 to 360.000 Degrees Default is 180.0 Degrees As you adjust any of these three parameters, the camera will automatically calculate the equivalent value...
Page 72: White Balance
To Convert Shutter Speed to Angle Equivalent: Equivalent Degrees = (Shutter Speed x Frame Rate x 360) E.g. = (1/48 x 24 x 360) = (8640/48) = 180 SHUTTER DEGREES SHUTTER DEGREES 1/32 1/120 1/48 1/192 1/50 172.8 1/348 22.5 1/60 1/696 1/96...
Page 73: Advanced Settings
ADVANCED SETTINGS When selected, allows additional adjustment of the White Balance. Available options are PRESET, COLOR TEMP, TINT, and CALCULATE WHITE BALANCE. Press APPLY PRESET for settings to take effect. PRESET Available preset options are: SHADE DAYLIGHT FLOURESCENT INCANDECENT Preset to 9,000K Preset to 5,600K Preset to 4,500K Preset to 2,800K...
Page 74 TINT Color Temperature calculations assume a pure light source that may not be true in the specific scene the camera is imaging. To compensate for any residual colorcast, the TINT parameter can adjust the RGB color balance with a compensating Magenta - Green color component. Default is 0.000. When selected, a secondary keypad will appear allowing you to enter the desired Tint value directly.
Page 75: Resolution
RESOLUTION Allows adjustment of resolution. Default is 5K 2:1 The following Resolution options are available: • • • 5K ANA • • • 5K 2:1 • • • 5K WS 4K HD 2K WS Current RED EPIC resolutions listed below with their respective size (in pixels). For a visual reference, see APPENDIX L: RESOLUTION CHART.
Page 76: Redcode Options For Various Frame Rates
REDCODE OPTIONS FOR VARIOUS FRAME RATES Minimum frame rate is 1 sec per frame; maximum frame rate is a function of REDCODE setting, and record resolution: 10:1 12:1 12:1 11:1 12:1 2.4:1 10:1 10:1 12:1 10:1 2.4:1 SECONDARY MENUS Press the Menu button on the REDMOTE / Side Handle or touch the MENU icon on the LCD to access the Secondary Menus.
Page 77: Hdr On / Off
HDR ON / OFF By default, HDRx is OFF (HDR button is illuminated Blue). In the Lower Status Group of the Viewfinder screen, the HDR text is Gray, indicating HDRx is inactive. To turn HDRx on, navigate to the HDRx button using the Nav Group and press ENTER, or from the touchscreen directly touch the HDRx button.
Page 78: Mode
MODE MANUAL FOCUS To adjust the MODE parameter, select the Menu box and use the UP / DOWN arrows to adjust. Available options are MANUAL and CONFIRM. Default is MANUAL. MANUAL When selected all focus operations are manual. CONFIRM Enables the Center or Spot focus square for use with manual focus. This mode provides additional focus assistance to the photographer using RED, YELLOW, and GREEN color changes to the focus spot window.
Page 79 Performance of Auto Focus may be reduced under the following conditions: • The subject is dark or distant. • There is inadequate contrast between the subject and background. • The scene has reflective highlights. • The subject is backlit. • There is inadequate surface contrast/detail inside the window.
Page 80 CONTINUOUS Once engaged with half-press, will attempt to keep objects in AF window in focus. Works best with good lighting and contrast. Works with both Center and Spot Zones. TOUCH TRACK Dynamically updating positionable AF using touschscreen. Works with Spot Zone only. Keep AF Spot on subject while moving across frame, will continuously focus on spot.
Page 81: Dsmc Canon Mount Electronically Supported Lenses
DSMC CANON MOUNT ELECTRONICALLY SUPPORTED LENSES Canon EF 100-400mm f/4.5-5.6L IS Canon EF 70-300mm f/4-5.6 IS USM Canon EF 100mm f/2.0 USM Canon EF 70-300mm f/4.5-5.6 DO IS USM Canon EF 100mm f/2.8L Macro IS USM Canon EF 800mm f/5.6L IS Canon EF 135mm f/2.0L Canon EF 85mm f/1.2L II Canon EF 135mm f/2.8 Soft Focus...
Page 82: Zones
ZONES Available options are CENTER and SPOT. Default is CENTER. This control allows selection of the boxes used to indicate objects in/out of focus. CENTER Provides a large, square target for focus. When objects located in the circle are in focus, the square will be Yellow or Green.
Page 83 SPOT Provides a small, square target for precise focus (similar to Center focus, only smaller). When objects located in the square are in focus, the square will be Yellow or Green. When objects located in the square are out of focus, the square will be Red. SPOT FOCUS INDICATOR Moving The spot focus square can be moved around the screen.
Page 84 Side Handle / REDMOTE 1. Navigate to the focus menu. 2. Press the down arrow on the Navigation Group. 3. The spot focus square line weight will increase and the Red cursor under FOCUS will dim slightly. 4. Press the ENTER button. 5.
Page 85: Lens Information Display
LENS INFORMATION DISPLAY RED DSMC TI PL MOUNT + LENS When a RED DSMC Ti PL Mount is installed and a Lens equipped with Cooke’s S4/i system (or equivalent is attached, the Focal Length and Focal Distance is displayed on the LCD, EVF and external monitors.
Page 86: Exposure Menu
EXPOSURE MENU Not implemented at this time. PRESETS MENU Presets are stored inside the camera. They can be imported / exported to the SSD. The Presets menu is used to create, save and import presets. Available options are APPLY, CREATE, IMPORT/EXPORT and DELETE.
Page 87 PRESET NAME Press the Enter button on the New Name field, a keyboard will appear allowing you to enter the desired preset name. Use the arrow keys and Enter button, enter the desired name. When finished, press the Menu button to close the keyboard.
Page 88: Export / Import Preset
When successfully completed, “Preset Applied Successfully” will appear. REDMOTE will also display this message. EXPORT / IMPORT PRESET When selected you will be able to export presets from the camera to external memory (1.8” SSD), import presets from the external memory (1.8” SSD) to the camera, or apply available RMD presets. NOTE: Exported presets will be located in a folder labeled “Presets”...
Page 89 NOTE: If no media is connected or no presets are saved to the media, this selection will remain Grayed out (until a preset is exported of course). You will then be asked if you want to apply the imported preset. If No is selected, the preset will be imported and listed in the available Camera Presets.
Page 90: Delete Preset
RMD PRESETS If an RMD file exported from REDCINE-X or REDCINE-X PRO is on the SSD it can be imported from the SSD to the camera. When APPLY is selected, the RMD file is transferred to active system memory. DELETE PRESET When selected will delete the selected preset from the camera.
Page 91: Media Menu
MEDIA MENU The Media Menu is used to format media (SSD) prior to use on the camera as well as to Eject (unmount) the media prior to removal from the camera. Available options when selected are SELECT MEDIA, FORMAT MEDIA, EJECT MEDIA, and UTILITIES. IMPORTANT: Media MUST be ejected from the camera before removal to prevent corruption and/or loss of data on media.
Page 92: Eject Media
REEL NO. When selected a keypad will appear allowing you to enter a value between 1 and 999. CAMERA ID (SLATE) Identifies the camera with a letter A through Z. Default is A. CAMERA POS (POSITION) Identifies the camera position as Right, Left or Center. Default is Center. FORMAT When selected, formats the media and adds the selected properties.
Page 93: Utilities
UTILITIES Options are SECURE FORMAT. SECURE FORMAT Secure Format is a low-level format the rebuilds the SSD file system. It should only be used if the performance of the SSD is in question. NOTE: If clips are present on the media, you will be informed of how many clips will be erased when you secure format the media.
Page 94: Settings Menu
SETTINGS MENU This section describes the various secondary controls available to configure the camera. Menu options are DISPLAY, LOOK, SENSOR, PROJECT, MODES, AUDIO/VIDEO, SETUP, MAINTENANCE, and PLAYBACK. DISPLAY Available options are TOOLS, ZEBRA, OVERLAY, MODES, FRAME GUIDE, AREA GUIDES, and MONITOR.
Page 95 EXPOSURE This will show areas of under exposure (Purple) or over exposure (Red) on top of a monochrome image. The color is based on RAW data so over/under exposure refers to data actually close to clipping in the sensor. When selected, the icon “E√” will be displayed in the Lower Status Group. The EXPOSURE meter’s color bands provide the following information: PURPLE Minimum Exposure...
Page 96 FOCUS This will emphasize edges in the image without changing brightness/image content so it is easier to judge if the image is in focus. By adjusting your lens zoom and focus you can see which objects are coming into and falling out of focus. When selected, the icon “F √” will be displayed in the Lower Status Group.
Page 97 ORANGE Super White (IRE 105-107) Super White (IRE 108-109) At all other values, the monochrome image displayed represents the luminance value of the ISO adjusted image. EDGE EDGE displays a color overlay that outlines the edges of objects in an outline mode. By adjusting your lens zoom and focus you can pinpoint focus.
Page 98 MAGNIFY Magnify displays the central region of the sensor in 1:1 pixel resolution. When enabled, the 1:1 text in the Lower Status Group will change to Green. If in Magnify mode, when the Record button is pressed, the system will automatically exit this mode. When using a touchscreen you can also perform this function by pinching your fingers together and apart.
Page 99 RAW displays the image without any ISO correction. When selected, OFF will be highlighted in the Lower Status Group. ZEBRA Zebras enable and adjust the upper and lower values for two independent Zebra indicators. One zebra may be used for highlight exposure, and the other for mid tone or shadows. Zebras will be visible when in 1:1 zoom.
Page 100 ZEBRA 1 To enable, select ZEBRA 1 check box. Areas of the image exposed within these ranges will be indicated by crosshatched overlays at - 45 degrees relative to vertical. Zebra 1 is shown in the image below. High IRE Change the desired setting between 93 and 109 (default is 108).
Page 101 Low IRE Change the desired setting between 0 and 84 (default is 44). OVERLAY Allows you to enable and color code graphic overlays visible the on the Viewfinder and Preview outputs. SHOW Check the box adjacent to each overlay type to show. Overlays available are AF Zones, Center and Grid. Look Around is always enabled.
Page 102 Grid The Grid display is shown below. The grid may be used as a “rule of thirds” indicator. Look Around Highlights the look around area. Version 3.0 COPYRIGHT © 2012 Red.com, Inc. 955-0002_v3.0, Rev-B...
Page 103 MODES Available GUI display mode adjustments are Exposure, Shutter Mode, Aperture, and Focal Distance. EXPOSURE Selects GUI display of Shutter Exposure on Main screen as Time (1/xx sec) or Angle (Degrees). Default is Time. Angle is shown below. SHUTTER Enables one of two shutter timing (duration) modes: Absolute or Relative. Default selection is Absolute. Absolute Shutter Speed is defined exclusively by the Shutter Speed setting.
Page 104 APERTURE Selects GUI display of f/stop as 1/4 f Stop or 1/3 f Stop. Default is 1/3. FOCAL DISTANCE Allows you to set the Lens Info to display in Metric or Imperial measurements. Default is Imperial. FRAME GUIDE This sub-menu provides a selection of frame guides and safe action and safe title guides. User definable safe action and safe title guides may be saved as a USER PREFERENCE, thereby permitting the camera guides to be fully customized for any application.
Page 105 User Frame guides can be set to your own preferences through the User Settings. Available options are Aspect Ratio, Scale X/Y and Offsets X/Y. Note that the selected size will be displayed in the bottom of the Frame Guide box. COLOR Sets the frame guideline color to White, Gray, Teal, Purple, Yellow, Green, Blue, Red, or Black.
Page 106 Solid Line Style shown below. ASPECT RATIO For both Title Guide and Action Guide, available options are OFF, 16:9, 14:9, 4:3, 2.4:1, 1.85:1, and User. Default is OFF. User Title Guide and Action Guide can be set to your own preferences through User Settings. Available options are Aspect Ratio and Scale.
Page 107 COLOR Sets Title Guide and Action Guide line color to White, Blue, Yellow, Green, Red, or Black. Select the color that provides maximum color contrast with the scene you are shooting. TRANSPARENCY Sets Title Guide and Action Guide transparency. Options are 0%, 25%, 50%, 75% and 100%. LINE STYLE Sets Title Guide and Action Guide line style.
Page 108: Look
Double-Click Right 25% to Record When selected, the right 25% of the screen can be double-tapped to start and double-tapped again to stop recording. Double-Click Left 25% to Start AF When selected, the left 25% of the screen can be double-tapped to start the Auto focus (when DSMC Canon Mount and compatible lens are installed).
Page 109 BRIGHTNESS Adjusts brightness without crushing highlights. Available range is – 10.0 to +10.0. Default is 0.0. GAIN The GAIN sub-menu permits adjustment of RED GAIN, BLUE GAIN and GREEN GAIN. Adjusts the gain of the RED channel only. Range is 0.0 (no Red) to 10.0. Default is 1.0. BLUE Adjusts the gain of the BLUE channel only.
Page 110 FLUT FLUT (Floating Point Lookup Table) adjusts mid-range tone values. Range -8.0 to +8.0. Default is 0.0. EXPOSURE Adjusts exposure compensation. Available exposure range is –7.0 to +7.0. Default is 0.0. SHADOW Shadow adjusts the toe value of the FLUT or in other words, the tone near Black. Range is -2.0 to +2.0. Default is 0.0.
Page 111: Project
ENABLE USER CURVE When checked will open more options allowing you to adjust the X and Y values for Black, Toe, Center, Knee, and White of the curve. PROJECT The project menu sets the operating parameters the camera will use for a given project. Options available are TIME BASE and TIME CODE.
Page 112 TIME BASE Sets the TIME BASE (fps) to be used for the project - the primary acquisition frame rate, time code count and playback & editing frame rate. Setting is displayed in the lower left corner of VIEWFINDER output(s). Available options are 23.98, 24.00, 25.00, 29.97, 47.96, 48.00, 50.00, and 59.94. Default is 23.98. TIME CODE Selects the TIME CODE source to be used.
Page 113 TIME CODE DISPLAY Allows you to choose between TOD and Edge display. TIME CODE SOURCE Available options are EXTERNAL and USER-PROVIDED. User-Provided The three numerical boxes below allow you to set hours, minutes and seconds (in that order). Use RTC Time When selected the camera uses the cameras Real Time Clock as the timecode counter source (snapshot of the RTC.) Set Manually...
Page 114: Audio/Video
CAMERA ID (SLATE) Identifies the camera with a letter A through Z. Default is A. CAMERA POS (POSITION) Identifies the camera position as Right, Left or Center. Default is Center. AUDIO/VIDEO Menu adjusts AUDIO INPUT, AUDIO OUTPUT, AUDIO CHANNELS, MONITOR CONTROL, and TEST SIGNALS.
Page 115 You can also directly input your desired audio levels. Audio channel level inputs are displayed in the lower section of the UI. When audio is enabled and an audio jack is plugged in (detected by the camera), the circle next to CH1, CH2 etc…...
Page 116 AUDIO OUTPUT Allows adjustment of audio output levels fed to the outputs. Available options for each channel are ON and MUTE. Default is ON at -9 dB. AUDIO CHANNELS Allows selection of audio inputs and operational modes. Version 3.0 COPYRIGHT © 2012 Red.com, Inc. 955-0002_v3.0, Rev-B...
Page 117 INPUT Available inputs are CH 1/2 and CH 3/4. NOTE: For cameras not equipped with a PRO I/O module, options are CH 1/2. Source Available options are NONE, CAM ANALOG, PRO I/O ANALOG, PRO I/O AES A, and PRO I/O AES B. NOTE: For cameras not equipped with a PRO I/O module, options are NONE or CAM ANALOG.
Page 118 Mode Available options are UNBALANCED and BALANCED. Link Enables linkage between Channel Gain controls. Limiter Enables signal limiter circuit. Limiter enabled adds 10dB of headroom for Microphone level inputs, or 4dB for Line Level inputs. OUTPUT Link Enables linkage between Output Channel Attenuation controls. MONITOR CONTROL This sub-menu allows the monitor outputs settings to be modified.
Page 119 MODE Allows you to choose the output for the LCD/EVF, HDMI and HD-SDI monitors. LCD/EVF Options are MENUS, PREVIEW, CLEAN, OVERLAY, 3D LEFT, and 3D RIGHT. If anything other than MENUS is selected on the LCD (such as CLEAN), to return to displaying the MENUS, perform a double-tap on the LCD screen.
Page 120 HD-SDI Options are OFF, MENUS, PREVIEW, CLEAN, OVERLAY, 3D LEFT, and 3D RIGHT. Allows you to choose the output resolution for HD-SDI monitors. Available options are AUTO, 720p and 1080p. FREQ Allows you to choose the output frequency in Hertz (Hz) for HD-SDI monitors. Available options are AUTO, 23.976/24, 25, 29.976, 47.952/48, 50, and 59.94.
Page 121: Setup
SETUP This menu permits a variety of system setup tasks to be accomplished. Options available are KEYS / SHORTCUTS, DATE / TIME, NETWORK, SERIAL, REMOTE, GPIO, and SYSTEM. KEYS / SHORTCUTS Keys / Shortcuts display the USER KEY and KEY ACTION sub-menus. These options allow selected menus or functions to be mapped to specific User Keys on the camera body and accessories.
Page 122 WARNING: IT IS NOT ADVISABLE TO REMAP THE NAVIGATION KEYS (UP, DOWN, LEFT, RIGHT, SELECT (ENTER), OR MENU) ON THE SIDE HANDLE AS IT IS THEORETICALLY POSSIBLE TO GET INTO A SITUATION WHERE IT IS NOT POSSIBLE TO RESTORE THE FACTORY KEY PRESET ANYMORE IF NO TOUCH SCREEN IS ATTACHED TO THE SYSTEM.
Page 123 • Side Handle Center Key Down Menu Select • Side Handle Rotary Front CCW Rotary Next Value • Side Handle Rotary Jog CW Rotary Next Value • Side Handle Rotary Front CW Rotary Previous Value • Side Handle Rotary Jog CCW Rotary Previous Value Bottom Handle •...
Page 124 • LCD Function 1 Button Down Toggle Magnify • LCD Function 2 Button Down Exposure Check • LCD Arrow Up Button Down Brain LCD Br. Up • LCD Arrow Down Button Down Brain LCD Br. Down • EVF Function 1 Button Down Brain LCD Br.
Page 125 KEY ACTION When the desired User Key is selected, this setting allows the desired action for that User Key to be defined by the user. Available actions are as follow: • Activate ISO • Shutdown • Open ISO List • Toggle Display Mode •...
Page 126 GATEWAY. Using the serial port or a direct Ethernet interconnect, two cameras, or one camera and one external device can be connected. If the camera is connected via Ethernet to a hub or router, multiple cameras and devices can communicate to each other. NAME Allows the user to create a unique camera NAME that will be used in network communications, including wireless communications to REDMOTE.
Page 127 Group names (like camera Names) can be used to uniquely address commands to a specific group of networked cameras. Note: the group name is limited to 8 characters, default name is DEFAULT. When Group is selected the following keyboard will appear. TARGET Using TARGET the user can specify if this camera can send commands to ALL devices on the network, to NONE of the devices on the network (meaning the camera will only listen to messages and not...
Page 128 SERIAL PROTOCOL The camera can communicate to external devices via RS232 Serial Port and / or the Gigabit Ethernet Port. This selection allows the user to specify the serial communications PROTOCOL. Available options are NONE, ELEMENT TECHNICA, 3ALITY SPC 7100 and 3ALITY SPC 7000. Default is NONE. NETWORK If the Gigabit Ethernet port is used, additional settings are required.
Page 129 DHCP If a DHCP-server is available in the communications network the DHCP option can be checked and the camera will obtain an IP Address, Subnet Mask and Gateway address automatically from the DHCP - server. If the camera-to-camera (C2C) check box is checked, changes to the settings on this camera will be sent out via the network as UDP packets as a SET command (Which then sets the property on other cameras).
Page 130 REDMOTE This function is used to pair the camera to a REDMOTE for wireless operation. SCAN FOR REDMOTES When selected, the camera will look for an attached REDMOTE, plus any REDMOTEs that are turned on with REDlink wireless enabled. Searching will display. Version 3.0 COPYRIGHT ©...
Page 131 After scanning, recognized REDMOTEs will be listed by their MAC address in the drop down menu. PAIR REDMOTE Select the desired REDMOTE that you want the camera to communicate with from the drop-down menu list and select Pair REDMOTE. This means the camera remembers the identity of the selected REDMOTE.
Page 132 CURRENTLY PAIRED Displays the MAC address (identity) of the REDMOTE paired with the camera. UNPAIR REDMOTE When selected will deselect the currently paired REDMOTE from the camera. Following this operation a different REDMOTE may be selected for pairing to the camera if desired. MANUAL CHANNEL SELECT The Manual Channel Select option allows the user to change the communication channel for the REDLink wireless connection in the event of interference from other wireless devices.
Page 133 Sync In Accepts an Input Sync signal to control Shutter Start timing. General Purpose In Accepts an Input Trigger signal to act as a General Purpose Input. CAMERA OUTPUT Permits the function of the SYNC OUT / GPO pin in the CNTL connector to be defined as: Sync Out Provides an Output Sync signal to act as a Shutter Start tally.
Page 134 SYNC MODE Allows the shutter timing (scan start) to be synced to an external signal. Available options are OFF, GENLOCK, SHUTTER, INTERNAL, PROXY, and SLAVE. Default is Off. OFF – Shutter start time is defined by internal camera timing. GENLOCK – Shutter start time is slaved to an external RS170A tri-level sync signal .a.k.a “Genlock”. SHUTTER –...
Page 135 SYSTEM Available options are FAN CONTROL, RECORD SPEED and STANDBY SPEED as well as BEEP SPEAKER and EVF TALLY LIGHT. FAN CONTROL Specifies cooling fan operation. Available options are AUTO and MANUAL. Manual will run the fan at the speeds specified in RECORD SPEED and STANDBY SPEED. Default setting is AUTO. Auto This setting selects VARIABLE speed fan operation in standby based on the camera core temperature.
Page 136: Maintenance
INDICATORS Beep Speaker Available options are OFF and RECORD/STOP. When RECORD/STOP is selected, an audible beep will be heard when record is started and another when record is stopped. EVF Tally Light When checked, enables the Record Tally Red LED on the front of the EVF. MAINTENANCE The maintenance menu allows the user to check system status and information, save the camera diagnostic LOG to attached media, perform a software update, calibrate the sensor, perform a camera...
Page 137 SYSTEM STATUS When selected the Viewfinder output(s) will display the System Status screen. This screen provides a summary of all operational settings currently applied to the camera. SYSTEM INFO When selected the Viewfinder output(s) will display the camera Model, current firmware Version, installed and camera P.I.N.
Page 138 SAVE LOG Select to write camera’s .LOG file to the REDMAG 1.8” SSD. The .LOG file is a diagnostic tool that can assist RED with camera troubleshooting. After capture, upload the .LOG file to the RED customer service team contactable at www.RED.com/support.
Page 139 CALIBRATION Sensor calibration is a process where the camera generates a calibration map to correct for pixel defects and offsets based on current system and environmental settings. This allows you to perform a Black Shading calibration of the MYSTERIUM X sensor two (2) different ways; Default (at 24 FPS @ 1/48 SEC) or using your current FPS/Exposure settings.
Page 140 CURRENT CALMAP Calibration maps are stored in the camera. Due to the nature of the camera, different calibration maps are needed for different situations. Factory This the calibration map generated during production. This map is always present and selected as default on first use after performing a system restore under SETTINGS >...
Page 141 BLACK SHADING PROCEDURE The calibration procedures are the same for both BLACK SHADING options. The calibration procedures are the same for both Black Shading (24 FPS @ 1/48 SEC) and Black Shading (Current FPS/Exposure) options. When selected, a screen will appear asking if you wish to proceed with Black Shading calibration. REDMOTE will also display the following messages.
Page 142 6. Once Analyzing is complete, a status screen will show progress of the Erasing step. 7. Once Erasing is complete, a status screen will show progress of the Programming step. 8. The camera will perform this procedure twice. 9. After Programming, CALIBRATION SUCCESSFUL will be displayed. Select OK to complete Black Shading calibration.
Page 144 TOUCHSCREEN When selected allows you to perform a touchscreen self-test. When the touchscreen self-test is on, you can verify all areas of the touch screen respond to touch. Simply touch each box using your finger. The touchscreen responds to the touch and the Green box turns Blue.
Page 145 When selected, you will be asked to confirm if you want to delete all settings and restore the factory default settings. After settings are restored, “DEFAULT SETTINGS RESTORED, INITIALIZING RESTART…” Camera will automatically power down and will require you to manually power it up. NOTE: User key settings will be reset as well as any other changes from the cameras default settings.
Page 146: Playback
PLAYBACK Playback allows you to view clips on media currently attached to the camera. It also allows you to change the look of the playback clips be changing settings available when in playback mode. NOTE: SCARLET-X™ menus shown, EPIC menus similar. UPPER CONTROLS From Left to Right are ISO, WHITE BALANCE, VIEW, PRESETS, MEDIA, SEETINGS, and META.
Page 147 WHITE BALANCE Allows you to change the White Balance in the clip during playback. Advanced Menu Opens the advanced White Balance settings without the ability to Calculate. VIEW Allows you to select the items to be displayed in the playback window. Available options are Center, File Name, Time Code, Frame Guide, Action Guide, and Title Guide.
Page 148 PRESETS Allows you to apply presets to the clip during playback. MEDIA When selected will list all available clips on the attached media. Version 3.0 COPYRIGHT © 2012 Red.com, Inc. 955-0002_v3.0, Rev-B...
Page 149 Touchscreen 1. Double-Tap the desired clip to open in the playback window. 2. Load will also highlight. You can also select LOAD to load the clip in the player and allow playback. Side Handle / REDMOTE 1. Select the desired clip to playback and press the ENTER button. 2.
Page 150 SETTINGS Available options are DISPLAY, LOOK and RECORD. Display Available options under Display are TOOLS and ZEBRA. Tools Allows you to toggle ON/OFF Exposure, Focus, Video, Edge, and RAW. Refer to SETTINGS MENU > DISPLAY > TOOLS for complete details about these options. Zebra Allows you to toggle ON/OFF Zebras.
Page 151 Look Allows you to adjust the Color, Gain, FUT, and Curve of the image during playback. Refer to SETTTINGS MENU > DISPLAY > LOOK for complete details about these options. Record (Exit) When selected will exit playback to the main menu. META Displays current clip META information.
Page 152 CLIP PLAYBACK STATUS BAR Displays the progress of the clip during playback. Touchscreen When using the touchscreen you can swipe your finger Left or Right to open and allow playback of the previous or next clip on the media. Side Handle / REDMOTE When using the Side Handle or REDMOTE you can use the navigation group to highlight the clip playback status bar.
Page 153 LOWER CONTROLS From Left to Right, PLAYBACK SPEED, IN POINT MARKER, FRAME-BY-FRAME REVERSE, PLAY/PAUSE, FRAME-BY-FRAME FORWARD, OUT POINT MARKER, PLAY ONCE/LOOP, and PLAYBACK DIRECTION RESOLUTION / PROJECT FRAMERATE / QUALITY Display clip Resolution, Framerate and Quality (REDCODE). When using the touchscreen, touch the Resolution, Framerate and Quality (REDCODE) to display the METADATA for the clip.
Page 154 IN / OUT POINT MARKER Allows you to set In and Out Points during clip playback. This allows you to playback only a certain portion of the clip as desired. Helps when the clip is rather long and you want to focus on a particular segment.
Page 155: Power
PLAYBACK DIRECTION Allows you to play the clip forward or backwards. Reverse playback is shown. ADDITIONAL CLIP/CAMERA INFORMATION Will indicate if clip was recorded in HDRx and current camera power status as well as audio input signals. POWER The power menu displays the current power status of all attached power sources as well as allows you to shutdown the camera.
Page 156: Shutdown
SHUTDOWN Power OFF controls are interlocked to prevent accidental powering down of the camera. For details on the different ways to power down your RED DSMC Camera, refer to BASIC OPERATION > POWER DOWN. 1. Enter the Secondary Menu using the touch screen, REDMOTE or Side Handle. 2.
Page 157: Appendix A: Upgrading Camera Firmware
APPENDIX A: UPGRADING CAMERA FIRMWARE Your RED DSMC camera functionality may be upgraded by installing the latest firmware. Camera firmware is identified by Version and SVN number, which will be displayed by the camera on the LCD display when SYSTEM INFO is selected. A higher number reflects a later release. www.RED.com/support Make a habit of frequently visiting to check for later versions of camera...
Page 158: Appendix B: Managing Digital Media
APPENDIX B: MANAGING DIGITAL MEDIA MEDIA REDMAG 1.8” SSD is available with capacities of 64GB, 128GB or 256GB. Record duration is dependent on resolution, quality and frame rate, but a 64GB SSD will typically provide 24 minutes of 24fps 5K RAW recording. On MAC computers with REDCINE-X PRO installed, RED Watchdog will mount the SSD as “READ- ONLY”...
Page 159 On REDMOTE, NONE will be displayed twice (as opposed to when no media is inserted, the GUI displays NONE with three dashes below “---“). On the Side Handle, NA will be displayed (same as if no media is present). 3. To format the media select SECONDARY MENUS > MEDIA > FORMAT MEDIA. 4.
Page 160: Media Capacity Remaining Status
MEDIA CAPACITY REMAINING STATUS The Viewfinder output(s) will display the remaining media capacity in the MEDIA indicator (100% is shown). At 10%, remaining capacity the media status will turn yellow, at 5% it will turn red. At 2%, remaining the camera will cease recording.
Page 161: Using Side Handle
3. When media is ejected, Viewfinder output(s) will display “MEDIA EJECTED SUCCESSFULLY“. 4. Media can now be removed from the camera. USING SIDE HANDLE 1. By default, the lower of the three (3) SYSTEM KEYS is set to Eject Media when pressed. 2.
Page 162: Erasing Media
ERASING MEDIA NOTE: If the media was formatted using SECURE FORMAT, you cannot erase the media using an external source. Erasing of the media must be performed by formatting on the camera. MACINTOSH OS X 1. Connect the REDMAG 1.8” SSD via RED STATION REDMAG 1.8". 2.
Page 163: Appendix C: Input / Output Connectors
APPENDIX C: INPUT / OUTPUT CONNECTORS CAMERA BRAIN FRONT MIC-1 3.5mm Audio Jack MIC-2 3.5mm Audio Jack Camera Brain Connectors - Front Version 3.0 955-0002_v3.0, Rev-B COPYRIGHT © 2012 Red.com, Inc.
Page 164: Microphone Audio)
MIC-1, MIC-2 (MICROPHONE AUDIO) Two 3.5mm phone jacks on the front of the brain support two independent channels of balanced or unbalanced microphone level analog audio inputs. Microphone Input Connector SIGNAL DESCRIPTION DIRECTION A (TIP) IN + Mic Input (+48V Phantom Power) B (RING) IN - Mic Input (+48V Phantom Power)
Page 165: Camera Brain Rear
CAMERA BRAIN REAR HD-SDI Headphone SYNC (Video Sync) CTRL (RS232 Control) GIG-E (Ethernet) DC IN (Power Input) HDMI Camera Brain Connectors - Rear Version 3.0 955-0002_v3.0, Rev-B COPYRIGHT © 2012 Red.com, Inc.
Page 166: Hd-Sdi
HD-SDI A standard 75 Ohm BNC connector provides a broadcast specification high definition video output. SIGNAL DESCRIPTION DIRECTION Center HD-SDI SMPTE-292M HD-SDI Shield/Screen GROUND Camera ground HD-SDI Output The HD-SDI output provides a 720p progressive scan video feed operating at 50.00 or 59.94 Hz or a 1080p 10-bit 4:2:2 progressive scan video feed operating at 23.98, 24.00, 25.00 or 29.97 Hz when in 1.5GHz HD-SDI mode, or a 1080p 10-bit 4:2:2 progressive scan video feed operating at a 50.00 or 59.94 Hz when in 3GHz HD-SDI mode.
Page 167: Headphone
HEADPHONE A 3.5mm stereo jack provides two channels of adjustable level analog audio for monitor headphones. Headphone Output Connector SIGNAL DESCRIPTION DIRECTION A (TIP) LEFT Left channel audio B (RING) RIGHT Right channel audio C (SLEEVE) Camera ground The camera’s four audio channels may be monitored in pairs: either 1L - 2R or 3L - 4 R or as a quad mix of 1+3L –...
Page 168 The Video Genlock input may be used as a vertical interval reference signal for the sensor and HD-SDI outputs when precise synchronization is required between cameras, such as for 3D and live broadcasts. Note: When GENLOCK is selected as the sensor shutter reference, shutter start timing (SHUTTER PHASE) may still be adjusted.
Page 169 NOTE: A pre-fabricated SYNC interface cable is available from RED Digital Cinema. • P/N 790-0154 – Video Sync – Camera to 3 BNC – 3 ft. (1m) • White BNC: Shutter Sync / GPI • Yellow BNC: SMPTE Timecode • Green BNC: RS170A Genlock Version 3.0...
Page 170: Ctrl (Rs232 Control)
CTRL (RS232 CONTROL) A 4-pin LEMO connector supports RS232 remote control for 3D camera communication, and third party metadata ingest applications. The shutter Sync Output signal acts as an immediate response hardware tally of a scan. This is useful for 3D or motion control applications where a slave camera or lighting device needs to be synchronized to a master camera.
Page 171: Gig-E (Ethernet)
GIG-E (ETHERNET) A 9-pin LEMO connector provides a Gigabit Ethernet port for remote camera setup, master / slave camera communication and external metadata ingest. View into Ethernet Interface connector Mating connector: FGG.0B.309.CLAD32Z SIGNAL DESCRIPTION DIRECTION B1_DC + Data Pair C+ B1_DC - Data Pair C- B1_DD+...
Page 172: Dc In (Power Input)
DC IN (POWER INPUT) The 6-pin LEMO connector accepts DC input power between +11.5 V and +17 V DC. Power conditioning provides protection against reverse-polarity connection, ESD, under and over voltage, and over current. View into camera DC IN Power Input connector Mating Connector: LEMO FGJ.1B.306.CWLD72Z SIGNAL...
Page 173: Hdmi Out
HDMI OUT The HDMI output supports an HDTV and PC monitor compatible 10-bit 4:2:2 progressive scan video signal (with embedded audio) at 720p and 1080p resolution. The HDMI output may be specified as a PROGRAM output (clean feed video) or as a PREVIEW output (including SurroundView™...
Page 174: Side Ssd Module
SIDE SSD MODULE REAR FRONT SSD Slot VIEWFINDER (LCD/EVF) Side SSD Module The Side SSD Module mounts to the left side of the camera Brain. On the rear face of this module is a slot for inserting a REDMAG 1.8”SSD digital Magazine. Do not attempt to insert any other media type, or any foreign objects into this slot, as damage to the Side SSD Module and / or the camera Brain may occur.
Page 175: Redmote
REDMOTE This section describes the physical connectors on the REDMOTE. Mini USB Camera Interface REDMOTE Connections The REDMOTE interface connector allows communication between the REDMOTE and the camera Brain or any expansion module. Make sure these contacts are kept clean and free of any contaminants that may interfere with a reliable electrical contact.
Page 176: Appendix E: Redmote Operation
APPENDIX E: REDMOTE OPERATION CONTROL, CONNECTORS AND DISPLAY This section describes the REDMOTE physical controls, connectors and color LCD display. CONTROLS REDMOTE Controls Stills/Motion Switch User Function Keys A-D Menu Buttons 4-8 Release Latch - Left MENU Button Power/Lock Switch Record Status LED Menu Buttons 1-3 Release Latch –...
Page 177 LEDS There are two status LED indicators located above the rockers switch on the left side of the LCD display. The upper LED is used to signal camera readiness and camera record status. • Red – Camera Startup / Camera Recording. The lower LED is used to signal camera readiness and REDMOTE communication status to the camera.
Page 178 REDMOTE Navigation Group Scroll Wheel Direction Keys Enter Button The Navigation Group has three separate operational capabilities. SCROLL WHEEL The Scroll Wheel allows the operator to select and adjust the values of selected camera parameters. DIRECTION KEYS The Direction Keys allows Left / Right / Up / Down navigation thru the camera menus to select a desired parameter for adjustment.
Page 179: Operation
SOFT MENU BUTTONS 4-8 To the right of the LCD are five Soft Menu Buttons. These buttons select a variety of camera status pages. For complete information refer to OPERATION > REDMOTE MENUS > SOFT MENU BUTTONS 4-8. Note: In Version 3.x software, Soft Menu Buttons 7 and 8 are undefined. POWER / KEY LOCK SWITCH If the REDMOTE is powered OFF, moving and holding the switch in the down (POWER) direction for 2 seconds will power UP the REDMOTE and if the REDMOTE is powered ON, moving and holding the...
Page 180: Power Up / Down
Note: For illustration only: rear surface of REDMOTE should face towards camera 2. Slide the REDMOTE down until a click is heard which indicates the REDMOTE is securely attached. UNDOCKING 1. Depress the two latch release buttons located on each side of the REDMOTE. 2.
Page 181 POWER UP CONNECTED TO CAMERA If the REDMOTE is physically attached to a camera, when the camera is powered up the REDMOTE will automatically power up along with the camera. NOT CONNECTED TO CAMERA To manually power up the REDMOTE, slide and hold the Power / Key Lock Switch in the down direction for 2 seconds, then release.
Page 182: Recording
RECORDING • To record, press the Red REC (record) button. If media is connected and properly formatted, the upper LED will illuminate Red and the Timecode value displayed in the LCD will change to Red text. To stop recording, press the REC button a second time. After recording to media is completed, the upper LED will go out and the Timecode value displayed in the LCD will change back to White text.
Page 183 CHANGING CAMERA SETTINGS USING CAMERA LCD / EXTERNAL MONITOR AS REFERENCE To adjust a parameter value displayed on the camera’s Upper Status Group, first note the red colored bar (located under 24fps in this example), indicating the currently active parameter for instant adjustment.
Page 184: Menus
ADVANCED OPERATION: REDMOTE MENUS SOFT MENU BUTTONS 1-3 Located below the main LCD display are three Soft Menu Buttons, who access advanced function menus identified by text in the LCD directly above the corresponding button. These menus control wireless connection (CONNECT), camera or local menus (REMOTE/LOCAL) and system setup (SETUP). WIRELESS CONNECT: SOFT MENU BUTTON 1 Note: This Button is hidden if REDMOTE is attached to the camera or rear-most camera module.
Page 185 4. Select the desired camera to connect to for REDMOTE wireless operation and press the ENTER button in the Navigation Group. The REDMOTE will connect to the selected camera. 5. Once connected, the REDMOTE will display the key operating parameters of the selected camera. The wireless signal strength will be shown in the lower Right corner of the REDMOTE screen.
Page 186 Note: Once this procedure has occurred once, the REDMOTE will automatically search for the camera each time it is undocked, until the paired camera selection is changed. CANCEL If you wish to exit the CONNECT menu at any time press CANCEL. Version 3.0 COPYRIGHT ©...
Page 187 DISCONNECT To stop communicating wirelessly with the camera, select Soft Menu Button 1 Connect, then select DISCONNECT and press the ENTER key in the Navigation Group. RECONNECTING IF SIGNAL IS LOST On loss of wireless communication REDMOTE will scan for the camera it was last paired with. If the REDMOTE is unable to re-connect after 30 seconds, it will enter the manual SCAN menu, follow the procedure outlined about to scan and identify camera(s) that you wish to connect to.
Page 188 OPERATING WITH MULTIPLE CAMERAS FROM A REDMOTE To control more than one camera from a single REDMOTE, first pair the REDMOTE with each camera. After pairing REDMOTE to the desired cameras, press Soft Menu Button 1: CONNECT. Available cameras will be listed. Select the camera you wish to control and press the ENTER button.
Page 189 REMOTE Allows the user to adjust camera settings from REDMOTE, by navigating the camera menus appearing on the VIEWFINDER output of the camera, with summary data only appearing on the REDMOTE LCD LOCAL Allows the user to adjust camera settings from REDMOTE, by navigating camera menus appearing on the REDMOTE LCD, with summary data only appearing on the VIEWFINDER output of the camera.
Page 190 6. Select “Setup Slot” and press the ENTER button. 7. A new Setup window will appear displaying available parameters to display. 8. Select the desired parameter and press the ENTER button. 9. You may now control this parameter directly from the REDMOTE. REDMOTE SETUP: SOFT MENU BUTTON 3 When pressed SETUP provides the option of forcing the REDLINK wireless link ON or OFF and selecting the following REDMOTE Setup menu.
Page 191 Adjustable parameters include LCD screen brightness; beep speaker Volume and Auto Shutdown time. In the lower section of the display is the MAC address and the current firmware build of the REDMOTE Brightness The BRIGHTNESS control adjusts the LCD backlight intensity. Set value to maximum for daylight visibility, set value lower for nighttime operation or for maximum battery run time when operating in wireless mode.
Page 192: Maintenance
MAINTENANCE INTERNAL BATTERY CHARGE STATUS An icon shows the charge status of the REDMOTE battery in the lower right corner of the LCD. When REDMOTE is operating in wireless mode, the icon indicates current charge capacity. When satisfactory the icon is displayed in Green. When battery charge becomes marginal, the icon turns Yellow.
Page 193 CHARGING CHARGE TIME A fully discharged REDMOTE battery will be fully charged in approximately 6 hours. USING CAMERA While connected to the camera, the REDMOTE will automatically recharge its internal battery. Charge status is indicated by the Green Battery Icon at the top-right of the REDMOTE LCD display screen. A fully discharged REDMOTE battery will be re-charged in approximately 6 hours if connected to a powered camera or a USB based power source such as laptop P.C.
Page 194: Upgrading Redmote Firmware
UPGRADING REDMOTE FIRMWARE 1. Verify the current REDMOTE firmware version by selecting SETUP > SETUP SYSTEM on the REDMOTE. 2. REDMOTE upgrade is complete. You can now reconnect to the camera. Version 3.0 COPYRIGHT © 2012 Red.com, Inc. 955-0002_v3.0, Rev-B...
Page 195: Appendix F: 3D Setup / Operation
APPENDIX F: 3D SETUP / OPERATION OVERVIEW The following information outlines basic procedures to connect two RED DSMC cameras together in a Master / Slave configuration for 3D operation, operation of cameras in Master / Slave configuration and clip naming conventions for clips recorded on those cameras. The MASTER camera will control only the METADATA parameters of both cameras.
Page 196: Clip Naming Conventions
1. Go to SECONDARY MENUS > SETTINGS > SETUP > COMMUNICATION > NAME and give the camera a unique NAME (CAM B, RIGHT, etc…). 2. Under TARGET select NONE. 3. Give the Slave camera a unique IP address different from the Master. CLIP NAMING CONVENTIONS REEL NO.
Page 197: Connecting Cameras
Slave: S001_R001_0503R7.R3D Where 0503 represents 05 March, B6 and R7 are examples of camera generated wildcard characters. Note: If both Master and Slave cameras are accidentally left in default settings of CENTER and CAM A ID, the clips recorded on each camera will have the same file structure, with the exception of the camera generated wildcard characters which protect against exact file name duplication: Master: A001_C001_0503B6.R3D...
Page 198: Operation
5. Verify the camera’s project frame rate matches the Genlock and Timecode generator(s) framerate(s). 6. When properly connected and synchronized, TC, GEN and SYNC will illuminate Green on the UI. OPERATION CHANGING SETTINGS When changes are made to the Master camera settings, the Slave camera setting will also change, but not in real-time.
Page 199: Appendix G: Exposure - Using False Color And
APPENDIX G: EXPOSURE – USING FALSE COLOR AND ISO NOTE: The following section uses a RED ONE camera display to illustrate exposure tools; however, the same principles apply to RED DSMC camera systems. RED DSMC cameras provide several advanced exposure indication tools. In the following examples, we will show how these tools respond to a reference scene that is under-exposed, over-exposed and then correctly exposed.
Page 200 ISO 800 - False Color: Exposure Select False Color – Exposure: note the √ E icon in the GUI when active. This mode allows us to visualize where in the image underexposure is taking place. These areas are indicated in purple. It is clear those areas are under the matchbox and coin, and between the bottle and cigar holder.
Page 201: Overexposure (~ 2 Stops)
Select False Color – Video: note the √ V icon in the GUI when active. This mode allows us to check the RGB video levels of the scene. As the peak white chips on the test chart are showing up in green and the underexpose areas are showing up in dark blue, this says the monitor path video levels are only ranging between 44 IRE and 1 IRE.
Page 202 ISO 800 - False Color: Exposure Select False Color – Exposure: note the √ E icon in the GUI when active. This mode allows us to visualize where in the image over exposure is taking place. These areas are indicated in red. It is clear those areas are on the highlight on coin, and at the top right edge of the color chip test chart.
Page 203 ISO 800 - False Color: Video Select False Color – Video: note the √ V icon in the GUI when active. This mode allows us to check the RGB video levels of the scene. As all the white chips on the test chart are Yellow, this suggests that a significant portion of the monitor path video is at the maximum legal 100 IRE value.
Page 204: Appropriate Exposure
APPROPRIATE EXPOSURE ISO 800 - Monitor Output In this image, the camera is appropriately exposed for this scene. The monitor is neither very dark nor very bright and the histogram is spread evenly given that there are bright highlights on the coin we wish not to blow out.
Page 205 ISO 800 - False Color: Exposure Select False Color – Exposure: note the √ E icon in the GUI when active. This mode allows us to visualize where there is under exposure (purple) or over exposure (red) in the image. In this case, there is a very small area of purple under the cracker box, and just a suggestion of red on the highlight on the coin, which suggested that the sensor is appropriately exposed for this scene.
Page 206 ISO 800 - False Color: Video Select False Color – Video: note the √ V icon in the GUI when active. This mode allows us to check the RGB video levels of the scene. The two green squares in the upper right corner of the color chart and green in the background indicate that the scene’s mid grey and skin tone elements, plus peak white and blacks are all at appropriate levels.
Page 207: Adjusting The Iso Rating
ADJUSTING THE ISO RATING In the following two examples, the image exposed at ISO 800 rating have had the ISO rating adjusted first to ISO 6400 and then to ISO 100. NOTE: Although the image and Histogram both adjust to changes in the ISO rating, the sensor RAW meters do not change –...
Page 208 ISO 100 - No Exposure Adjustment In these extreme examples, it is clear that the RGB domain images are respectively very bright and very dark. The histogram data reflects that, however you can also see that the sensor RAW meters are unchanged.
Page 209: Appendix H: Post Production
APPENDIX H: POST PRODUCTION RED workflow is quite easy to understand, especially if you have experience with photographic RAW image processing, or shoot 16mm or 35mm film followed by a telecine transfer to video for non-linear video editing and on-line conform. The RAW data captured by RED cameras has wide dynamic range and color space, so you can freely change the white balance, adjust exposure and alter highlight and shadow tonality in post-production.
Page 210: Redcine-Xpro
REDCINE-X ® REDCINE-X PRO is available for Intel based Mac OSX and Windows XP platforms. The application performing white balance and one light color correction, image pan/scan, crop and scaling operations. The application can export either a single clip, or a sequence of clips, as 4K or 2K resolution 10-bit DPX or 16-bit TIFF files.
Page 211: Maintenance
APPENDIX I: MAINTENANCE WARNING: DO NOT attempt to modify, dismantle or open your camera, lens or other accessory as doing so may expose you to electric shock and serious injury. There are no user-serviceable parts inside. Alteration or repairs made to the camera, lens or other accessory, except by a RED authorized service facility, will void the Limited Warranty.
Page 212: Evf
DO NOT USE any other solvents, chemicals or third party cleaning kits because they have not been tested on RED TOUCH LCD displays and can possibly damage them. Not approved for use on RED TOUCH LCD displays: • Rubbing Alcohol •...
Page 213: Back Focus Adjustment
BACK FOCUS ADJUSTMENT WARNING: THERE IS A SCREW-IN METAL PLUG INSTALLED IN THE CAMERA BODY COVERING THE BACK FOCUS SCREW. THIS PLUG MUST BE REMOVED BEFORE TO PERFORMING A BACK FOCUS ADJUSTMENT. TO REMOVE THE PLUG, USE A T-10 TORX SCREWDRIVER. NOTE: To be able to perform this procedure as written, you must have a PL mount and RED Focus™.
Page 214 RED Focus Properly Installed on Camera 4. Power up the camera. 5. Power up RED Focus. Refer to POWER UP / DOWN. NOTE: Remember that RED Focus will AUTOMATICALLY power down after 3 minutes. Press the Red button on the front to power back up. 6.
Page 215 Turning COUNTER-CLOCKWISE moves the sensor rearward. NOTE: The center of the image will never be in perfect focus as the lines are less than 1/3 of a pixel in size. 9. The back focus adjustment mechanism is self-locking, and does not require a supplementary locking screw.
Page 216: Troubleshooting
APPENDIX J: TROUBLESHOOTING NO MEDIA ATTACHED Displayed if media is not present or not formatted when pressing the record button. Connect media to camera if necessary. If media is already connected, format media and attempt to record again. Refer to APPENDIX B: MANAGING DIGITAL MEDIA for detailed information.
Page 217: Appendix K: Technical Data
APPENDIX K: TECHNICAL DATA TECHNICAL SPECIFICATIONS SENSOR 14 MEGAPIXEL MYSTERIUM X PIXEL ARRAY 5120 (h) x 2700 (v) S/N RATIO 66db DYNAMIC RANGE 13.5 stops, up to 18 stops with HDRx MAX IMAGE AREA 5120 (h) x 2700 (v) LENS COVERAGE 27.7mm (h) x 14.6mm (v) x 31.4 mm (d) Equivalent to S35mm (Motion) / APS-H (Still) lenses DEPTH OF FIELD...

Epic Red Epic-X Operation Manual

Table of Contents

Disclaimer

Compliance

Before You Start

Theory of Operation

Camera Operational Controls

Basic Operation

First Time Use - Setting up Your Red Epic

1 Attach Power Source

2 Power up

3 Preparing to Record

4 Recording

5 Playback

Menu Controls

Main Menu

Secondary Menus

Appendix A: Upgrading Camera Firmware

Appendix B: Managing Digital Media

Appendix C: Input / Output Connectors

Appendix E: Redmote Operation

Appendix F: 3D Setup / Operation

Appendix G: Exposure - Using False Color and

Appendix H: Post Production

Appendix I: Maintenance

Appendix J: Troubleshooting

Appendix K: Technical Data

Appendix L: Resolution Chart

Appendix M: Menu Maps

Quick Links

Need help?

Questions and answers

Related Manuals for Epic Red Epic-X

Summary of Contents for Epic Red Epic-X

Table of Contents
