Page 1: Wine Cooler
Wine Cooler E150WSCS E360WSCS E430WSCS EURO APPLIANCES BY EUROSTYLE GROUP... - Page 2 The information in this document is subject to modification without any prior notice. Euro Appliances offers no guarantee for our wine cooler if it is being used for any purpose other than that for which it was specially designed. Euro Appliances cannot be held responsible for any error in this manual.
- Page 3 - Have a surge protector fitted to the electrical outlet - Away from microwave. Certain microwave ovens do not have wave interference shield. When place within 1 meter vicinity of the wine cooler, they may affect the operation of the wine cooler. The wine cooler should be placed where the ambient temperature is between 5 ºC to 43 ºC.
- Page 4 *Levelling your wine cooler Wine cooler must be levelled before loading your wines. Your wine cooler is equipped with 4 adjustable feet to facilitate easy levelling. Euro Appliances recommends that you tighten the back feet to the maximum and adjust the...
- Page 5 *Products & Specifications 1) E150WSCS Type Dual Temperature Zone Item Number E150WSCS 48 Bottles Bottle Capacity 595*595*798mm Dimension (W*D*H) 48KG Weight Refrigerant R600a/45g Cooling System Compressor Cooling 60-90 Ambient Temp ºC Upper: 5-10 Temperature Range ºC/ Lower: 10-18 ºC 220 - 240V...
- Page 6 3) E430WSCS Dual Temperature Zone Type Item Number E430WSCS 168 Bottles Bottle Capacity 595*680*1871mm Dimension (W*D*H) 113KG Weight R600a/65g Refrigerant Cooling System Compressor Cooling 60-90 Ambient Temp ºC Temperature Range Upper: 5-10 ºC/ Lower: 10-18 ºC Rated Voltage 220-240V 50HZ Rated Frequency Input Power 220W...
- Page 7 6 bottle arrangement so as to avoid” all on top” or “all below” type loads. - Do remove or relocate wooden shelves in the model E150WSCS to accommodate large type of bottles or increase the capacity of the cabinet by stacking the bottles up when necessary.
- Page 8 - Avoid obstructing the internal fan (located inside on the back panel of the wine cooler) - Do not try to slide the shelves outwards beyond the fixed position to prevent the bottles from falling. - Do not pull out more than one loaded shelf at a time as this may cause the wine cooler to tilt forward.
- Page 9 2.5 ºC range, the actual temperature of the wine will only fluctuate 0.5 ºC to 1 º 1) Factory preset Temperature Chart: The upper compartment: 5 ºC The lower compartment: 12 ºC 2) Control panel of wine cooler: The LED displays the internal air temperature. The “ set ” temperature automatically appears by pressing either set button for upper compartment or set button for lower compartment.
- Page 10 Cooling Indicator light: When the light is on, the cooling mode is currently in operation. Interior Light: You can turn on/off the interior light by pressing the “Globe” button. The light will be turned off automatically if it remains ON for 10 minutes. You have to press the “Globe”...
- Page 11 - When removing a shelf from the rail compartment in E150WSCS, make sure to remove all items first, then move the shelf to the stop position and lift over to take the shelf out.
- Page 12 All Euro wine coolers are equipped with a double glazed glass door to minimize condensation on the glass door. The unit is not totally sealed, fresh air admission is permitted through the drainpipe. Air is circulated through the wine cooler by means of a fan /fans and the hollow shelves.
- Page 13 Remove the two screws from the door bottom at right side and install them to the door bottom at left side. (Fig.3) Use the new bottom hinge provided in the plastic bag inside the wine cooler and installs it at the designated position on the left side, and installs the door shaft (3) assembly accordingly.
- Page 14 * Installing Stainless Steel Handle This wine cooler includes a stainless steel handle that is required to operate this unit. To install the handle please follow the below instruction: 1. Pull away the door gasket in the area where the handle is to be installed –...
- Page 15 Check Fuse, if any. Make sure that the door is closed properly. If your wine cooler appears to be malfunctioning, unplug it and contact EURO after sales service on 1800 440 335. Any intervention on the cold circuit should be performed by a refrigeration technician who should carry out an inspection of the circuit sealing system.
-
Page 16: Troubleshooting Guide
*Troubleshooting Guide PROBLEM POSSIBLE CAUSE Wine Cooler does not operate. Not plugged in. The appliance is turned off. The circuit breaker has tripped or a fuse has blown Wine Cooler is not cold enough. Check the temperature control setting. External environment may require a higher setting. - Page 17 The door was reversed and not properly installed. The gasket is dirty. The shelves are out of position. Eurostyle Group trading as Euro Appliances No. 6 Pattinson Road, Newton SA 5073 Service Line: 1800 440 335 Fax: (08) 8462 9127...
