ReadyNAS Pro Business Edition User Guide
Introducing the Status Displays, Ports, and Drive Bay
This section introduces the ReadyNAS Pro display, ports, and drive bay.
Front and Side Panel
1
2
3
4
5
6
Figure 1-1
1. OLED display, including the disk activity status light
2. CPU exhaust vent
3. Power button/power status
4. USB backup status light
5. Backup button
6. Front USB port
7. Drive bay door
1-4
7
v1.2, October 2008
Getting Acquainted
