RF μTUNING KIT I
Congratulations on your purchase of the RF μTUNING KIT.
Before installing the kit, please read this manual carefully. After installation, please keep this manual in a safe place for future reference.
Do not modify or adapt the μ-TUNE-UNIT
Damage to precision mechanical or electronic components
may occur.
Be careful in handling the small parts
Do not place small parts in the mouth. Choking or suffo-
cation could occur.
Screw A
Screw B
Screw C
( M3 x 6 )
( M3 x 8 )
( M4 x 6 )
8 pcs
10 pcs
8 pcs
Leg
Model Plate
RX-TUNE-UNIT
4 pcs
3 pcs
1 pc
Top Case
Side Case F
1 pc
1 pc
Bottom Case
1 pc
R
T
EQUIRED
OOL
Phillips Screwdriver
Pliers (used for installing the Spacers)
M
NSTALLATION
ANUAL
N
OTICE
Be careful while using tools and assembling the parts
to avoid pinched fingers and other injuries
Do not stretch, pinch, or otherwise damage the cables
Do not apply incorrect voltage to the μ-TUNE-UNIT
Severe damage may occur.
P
L
ACKING
IST
Screw D
Screw E
Spacer S
( M4 x 16 )
( M3 x 6 with washer )
( 8 mm )
4 pcs
2 pcs
4 pcs
Jumper Plug
RF Cable (RCA - RCA)
CNTL Cable (DIN - DIN)
1 pc
Gray 1 pc
1 pc
Black 1 pc
Side Case B
Shield Cover S
Shield Cover L
1 pc
1 pc
1 pc
Main Frame
μ-TUNE-UNIT
1 pc
1 pc (Separate pack)
E
A
Spacer L
( 18 mm )
2 pcs
E
9
7
X
7
1
0

Advertisement

loading
Need help?

Need help?

Do you have a question about the RF UTUNING KIT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Yaesu RF UTUNING KIT

  • Page 1 RF μTUNING KIT I NSTALLATION ANUAL Congratulations on your purchase of the RF μTUNING KIT. Before installing the kit, please read this manual carefully. After installation, please keep this manual in a safe place for future reference. OTICE Do not modify or adapt the μ-TUNE-UNIT Be careful while using tools and assembling the parts Damage to precision mechanical or electronic components to avoid pinched fingers and other injuries...
  • Page 2 NSTALLATION 1. Attach the Spacer S to the back side of the Main Frame with 4. Affix the Model Plate to the recessed area on the Top Case, 7. Place the Main Frame upside down. Attach the RX-TUNE- 9. Confirm the μ-TUNE-UNIT Model Number (for example: four Screws (Screw A: M3 x 6).
