Specifications AccuSync LCD52VM Monitor
Monitor Specifications
LCD Module
Viewable Image Size: 38 cm/15 inches
Native Resolution (Pixel Count): 1024 x 768
Input Signal
Display Colours
Analog input: 16,2 M
Synchronization Range
Viewing Angle
Resolutions Supported
Landscape: 720 x 400*
Active Display Area
Horizontal: 304.1 mm
Speakers
Practical Audio Output: 1.0 W + 1.0 W
Power Supply
Power Consumption
Dimensions
Landscape: 344.6 mm (W) x 352.7 mm (H) x 165.0 mm (D) (with stand)
Weight
Environmental Considerations
Operating Temperature: 5 °C to 35 °C
Storage Temperature: -10 °C to +60 °C
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE:
Technical specifications are subject to change without notice.
AccuSync LCD52VM Monitor
Diagonal: 38 cm/15 inches
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync.TTL Level (Positive/Negative)
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Horizontal: 31.5 kHz to 61 kHz
Vertical: 55 Hz to 76 Hz
Left/Right: -60°/+60°(CR>10)
Up/Down: -45°/+45°(CR>10)
1
: VGA
1
640 x 480*
@ 60 Hz to 75 Hz
800 x 600*
1
@ 56 Hz to 75 Hz
832 x 624*
1
@ 75 Hz
1024 x 768 @ 60 Hz to 75 Hz..................... optimal display performance.
Vertical: 228.1 mm
100 - 240 V ~ 50/60 Hz
23 W
344.6 mm (W) x 285.0 mm (H) x 57.5 mm (D) (without stand)
3.3 kg
Humidity: 30% to 80%
Altitude: 0 to 3,048 m
Humidity: 10% to 85%
Altitude: 0 to 12,192 m
Notes
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.297 mm
dot pitch; 250 cd/m
400:1 contrast ratio, typical.
Depends on display card used.
Automatically
Automatically
Some systems may not support all
modes listed.
Recommended resolution is 75 Hz for
English-11
2
white luminance,
