Redmon 5453 Assembly Instructions

Refer to the parts list below followed by instructions for easy assembly.
Slatted Front Panel (quantity 1)
Lid Assembly (quantity 1)
Small Screw (quantity 10)
Assembly Instructions:
If you need assistance call (765) 473-6683 Monday thru Friday 7 am to 5 pm EST. Or, you may email us at
info@RedmonUSA.com.
By the way, thanks for the trust you have placed in our company by purchasing a Redmon product ... now in business for over
130 years and serving families around the globe!
www.RedmonUSA.com
Model #5453 Bamboo Hamper Assembly Instructions
Back Panel (quantity 1)
1/8" Bottom Panel (quantity 1)
Large Hamper Screw (quantity 8)
STEP 1. Attach the two Side Panel Assemblies to the Back Panel Assembly with the
bottom 1/8" slot to the inside on all three panels (this slot is used to 'capture' the 1/8"
NOTE: Do not fully tighten the Large Hamper Screws (the screws will be fully tightened
STEP 2. Slide the 1/8" Bottom Panel into the three panel slots until it is fully seated into
STEP 3. Set the Slatted Front Panel in place and fully tighten all the Large Screws.
STEP 4. Attach the two hinges to the Back Panel Assembly with Hinge Slots using the
Small Screws (Phillips head). Flip the lid side of the hinges to the up position.
STEP 5. Lay the hamper flat on the floor on its back with the lid aligned under the hinges
(line up the pre-drilled hinge holes of the lid). Attach the hinge to the lid using the Small
STEP 6. Attach the Chain Lid Stop to the hamper and the lid using the pre-drilled holes
Ships From: Peru, IN 46970
Bottom Panel in STEP 2).
in STEP 3).
the Back Panel Assembly and both Side Panels.
Screws (Phillips head).
and Small Screws.
Side Panel (quantity 2)
Hinge (quantity 2)
Chain Lid Stop (quantity 1)
Ph: 765-473-6683
