NBV27CB22

CURVED MONITOR

USER MANUAL

In order to continue serving our customers and providing the best products, our product information

including our user manuals may receive updates from time to time. Please check our website for the latest

user manuals and product materials.

Table of Contents

Need help?

Do you have a question about the NBV27CB22 and is the answer not in the manual?

Questions and answers

Summary of Contents for Viotek NBV27CB22

Page 1 NBV27CB22 CURVED MONITOR USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
Page 3: Table Of Contents
Table of Contents Section 1: Safety Precautions ..........4 Section 2: Box Contents ............. 5 Section 3: Product Overview ..........6 3.1 – Monitor Buttons ............6 3.2 – Monitor Ports ............6 Section 4: Stand Installation ..........7 Section 5: Mount Installation ..........8 Section 6: Basic Operation ..........
Page 4: Section 1: Safety Precautions
VIOTEK shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted hereafter.
Page 5: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stem Mounting Plate x 1 Stand Base x 1 NO.1 Screws x 2 NO. 2 Screws x 4 Cushion x 1 HDMI Cable x 1 (for Stand Installation) (for Mounting) Power Adapter x 1 Headphone Clip x 1 User Manual x 1...
Page 6: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. E Exit Button: Press to exit. Power Button: Press to turn the monitor on/off.
Page 7: Section 4: Stand Installation
Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. 1. Open the package and take out the monitor with foam still attached. Gently place it on a desktop or table. 2. Remove the extra parts and the foam covering the back of the monitor. Take out the stem mounting plate and stand base.
Page 8: Section 5: Mount Installation
Section 5: Mount Installation This monitor ONLY includes screws that may be used when attaching the monitor to a VESA 75x75mm type mount. No VESA mount or mounting accessory is included. Keep the foam underneath the monitor before attaching the stand to a mount or accessory.
Page 9: Section 6: Basic Operation
It is compatible with GPUs that use AMD® FreeSync™ or NVIDIA® G-Sync™. The feature is off on VIOTEK monitors by default and must be manually enabled in the monitor’s OSD (see Section8: OSD). To use this feature, the connecting device must be compatible with adaptive sync (FreeSync and/or G-Sync);...
Page 10: Section 8: Osd Setup
Section 8: OSD Setup The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s configuration.
Page 11: Osd Menu Functions
8.2 – OSD Menu Functions 1. Press the button TWICE to enter the OSD menu. BRIGHTNESS BRIGHTNESS CONTRAST STANDARD 2. Press to browse functions. • Highlight the desired function and press M to enter the sub-menu. • Press to browse sub-menus and press M to highlight the desired function. to highlight an option.
Page 12 Main Menu Sub-Menu Options Description BRIGHTNESS Brightness 0~100 Adjust display brightness Contrast 0~100 Adjust display contrast Standard, Game, Set the ECO mode RTS, FPS, Movie, Text Turn on DCR function Turn off DCR function IMAGE Aspect Wide, Auto, 4:3 Set the display aspect COLOR TEMP.
Page 13: Section 9: Eco Modes And Gameplus Switching
Section 9: ECO Modes and GAMEPLUS Switching 1. Press any one of the buttons (M, , , E, ) to activate the Quick-Nav menu. 2. Press button to cycle through GAMEPLUS modes. According to the needs of your game, choose the corresponding game icon. These game icons are primarily designed to optimize your aim during shooting games, though they can be used for other scenarios.
Page 14: Section 10: Troubleshooting
Section 10: Troubleshooting The screen is blank • Press the power button to turn the monitor on. • Confirm the brightness and contrast settings are set normally. • Check if the indicator light is flashing. If so, this indicates there is no signal from your video source.
Page 15 Dim image • Adjust the brightness and contrast ratio. Image jitter/moire pattern • Nearby electric equipment may interfere with the monitor. The light indicator is on or ﬂashing, but there is no image displayed on the screen • Check if the monitor power is on. •...
Page 16: Section 11: Specifications
Section 11: Speciﬁcations Item Detail Model Number NBV27CB22 Screen Size 27’’ Model Type Curvature R1500 Viewing Angle 178° (H)/178° (V) Aspect Ratio 16:9 Resolution 1920x1080 Backlight E-LED LED Indicator Power on: Blue (LED); Power saving : Red (LED) Typical Brightness...
Page 17: Resolution Compatibility For Hdmi
11.1 – Resolution Compatibility for HDMI The below requirements are the minimum for your NBV27CB22 monitor. These requirements are recommended in order to properly use all of the monitor’s features and ensure a high- quality picture. Minimum Requirements Operating System: Windows® 7 / Windows® 8 / Windows® 10 64-bit (latest service pack) or higher Processor (CPU): Intel®...
Page 18: Section 13: Three-Year Limited Hardware Warranty
Warranty services are provided by Viotek Warranty Pro (“WP”). If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, WP will: (1) repair the hardware defect by using new or refurbished parts that are equivalent to new in performance and reliability;...
Page 19 DECLARATION OF CONFORMITY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
