Summary of Contents for fine fixtures ST1W
- Page 1 206 Wembly Road New Windsor, NY 12553 Phone: 718.602.6060 Fax: 718.963.2082 info@finefixtures.com www.finefixtures.com USER MANUAL REMOTE CONTROL ENERGY NOZZLE SAVER CLEANING MASSAGE STOP AUTO TEMPERATURE WATER SEAT...
- Page 2 CONTENT INSTALLATION PREPARATION Remote control installation USAGE INSTRUCTIONS Remote control illustration Rear/Front cleaning operation Massage operation Dry operation Auto function Energy saver Spray nozzle position adjusment Water pressure adjustment Automatic deodorization Temperature adjustment Full flush Open/close by remote controller Nozzle cleaning Combination button AUTOMATIC FUNCTION SETTING Setting rear cleaning...
- Page 3 USAGE REMOTE CONTROL ILLUSTRATION Front Flush button Rear Nozzle cleaning Energy saver Massage Drying U R E P R E S S Auto rear/front cleaning Auto Front cleaning Auto rear cleaning Water pressure adjustment Temperature adjustment Adjustment of nozzle position Water temperature,Dry temperature, Seat temperature Lid close / seat close Lid open / seat open...
- Page 4 REMOTE CONTROL INSTALLATION Drill two holes, which are parallel to the floor, on the wall with depth of 35mm, and center distance between two holes of 106mm. Make sure end-user be able to reach the remote control when sitting on the seat. Insert expansion tube into the hole on the wall, install the hanger to the wall with a screw, Hole...
- Page 5 USAGE INSTRUCTIONS REAR/FRONT CLEANING Press “Rear”/“Front” button, the water comes out of wand to clean the rear/front portion of body. It automatically stops after a cycle of cleaning. If press “STOP” button when using, the function will stop immediately. Massage Press “MASSAGE”...
- Page 6 USAGE INSTRUCTIONS AUTO FUNCTION Full-automatic function can be achieved by three “AUTO” buttons, convenient and practical. User can pre-set the suitable nozzle position, water pressure and temperature and save the setting. Full-automatic function will be activated by pressing the related function button when using afterwards. Auto rear cleaning Rear cleaning 90s Dry 180s...
- Page 7 USAGE INSTRUCTIONS ENERGY SAVER Press “ENERGY SAVER” button, LCD screen shows energy saver and figures. It shows three options of energy saver period as 3-6-9-off, which can be selected accordingly. For example, user can set from 9:00 to 15:00 as energy saver according to following operation. energy saver icon A.
- Page 8 USAGE INSTRUCTIONS Spray nozzle position adjustment During “REAR” or “FRONT”, press spray nozzle button of “ ” and “ ”, to move the position forward and backward by adjusting 5 levels. Water pressure adjustment During “REAR” or “FRONT”, press water pressure button of “+” and “-”, to adjust pressure for rear and front cleaning.
- Page 9 USAGE INSTRUCTIONS TEMPERATURE ADJUSTMENT Water temperature adjustment: Press “TEMPERATURE” button one time, “WATER ” light is on,icon on the screen lights on, then adjust WATER TEMPERATURE water temperature by “+”, “-” button. It is regarded as WATER SEAT operation completed if there is no operation in 5 seconds, PRESSURE POSITION and then “WATER ”...
- Page 10 USAGE INSTRUCTIONS FULL FLUSH Press “FLUSH” button to activate full flushing. Auto lid open/close (Only for toilet with this function) Press “ ” button to close seat cover. Press “ ” button to open lid and close seat. Press “ ”...
- Page 11 USAGE INSTRUCTIONS NOZZLE CLEANING Nozzle self-cleaning by quick press: Quick press “NOZZLE CLEANING” button, the nozzle self-cleans for a while and moves to the front position (no spray). People can continue to clean nozzle manually. SELF-CLEAN FOR Nozzle self-cleaning by long press： 90 SECONDS.
- Page 12 USAGE INSTRUCTIONS COMBINATION BUTTON Night light Press “STOP” button, then “DRY” button, night light will be often in the off state; Repeat the process, night light will switch to intelligent state. Repeat above process constantly, the night light will switch between off state and intelligent state. Quiet mode Press “STOP”...
- Page 13 SET AUTO FUNCTION SET AUTOMATIC REAR CLEANING FUNCTION The default setting of automatic function is water pressure on level three, nozzle position on level three, water temperature, wind temperature and seat temperature on level three, the massage function is in the off state. User can re-set based on personal preference.
- Page 14 SET AUTO FUNCTION SET AUTOMATIC FRONT CLEANING FUNCTION (1)Press spray nozzle position adjustment button to adjust nozzle to suitable position; Press “+”, “-” to adjust water pressure; set temperature level; open/ close massage function. (2)Press “ ” front cleaning automatic button for 3 seconds, see below picture, and save the setting.
- Page 15 SET AUTO FUNCTION SET AUTOMATIC REAR AND FRONT CLEANING COMBINATION FUNCTION Note: During using toilet, user can find the suitable level and temperature after comparing repeatedly. Please set the automatic Rear and Front cleaning combination function during using toilet. The first stage: rear cleaning 90s (1)Automatic Rear and Front cleaning combination function includes rear cleaning 90s, front cleaning 90s and drying 180s.
- Page 16 F I N E F I X T U R E S 206 WEMBLY ROAD - NEW WINDSOR, NY 12553 P: 718.602.6060 F: 718.963.2082 - E: INFO@FINEFIXTURES.COM TOLL FREE: 1.877.8FIXTURES FINEFIXTURES.COM RETAIN THIS INSTALLATION MANUAL FOR FUTURE REFERENCE.
