Edelbrock VICTOR Series General Instructions

PLEASE study these instructions carefully before installing
your new water pump. If you have any questions or problems,
do not hesitate to contact our Technical Hotline at:
(310) 782-2900.
• DESCRIPTION
The Edelbrock aluminum water pump #8842 is a heavy duty
water pump for both street and racing applications. The pump is
a direct replacement for the original equipment pump (Ford
#C5AZ-8501-K) to provide compatibility with all accessories
and pulleys. It offers weight savings along with increased
durability and cooling potential. #8842 is a standard rotation
water pump for 289 high performance engines. Not for standard
production 289 V8s or reverse rotation 1986-93 5.0 Litre V8s
with serpentine drive belt.
Polished Aluminum Water Pump #8847 fits the same
applications as #8842.
• PLEASE complete and mail your warranty card. Be sure to write the model number of this product in the "Part #____" space.
• THANK YOU.
©1994 Edelbrock Corp.
PLEASE study these instructions carefully before installing
your new water pump. If you have any questions or problems,
do not hesitate to contact our Technical Hotline at:
(310) 782-2900.
• DESCRIPTION
The Edelbrock aluminum water pump #8842 is a heavy duty
water pump for both street and racing applications. The pump is
a direct replacement for the original equipment pump (Ford
#C5AZ-8501-K) to provide compatibility with all accessories
and pulleys. It offers weight savings along with increased
durability and cooling potential. #8842 is a standard rotation
water pump for 289 high performance engines. Not for standard
production 289 V8s or reverse rotation 1986-93 5.0 Litre V8s
with serpentine drive belt.
Polished Aluminum Water Pump #8847 fits the same
applications as #8842.
• PLEASE complete and mail your warranty card. Be sure to write the model number of this product in the "Part #____" space.
• THANK YOU.
©1994 Edelbrock Corp.
VICTOR SERIES ALUMINUM WATER PUMPS
For 1965-67 289 c.i.d. HP Ford V8s
Catalog #8842 (unpolished), #8847 (polished)
• INSTALLATION
Installation is the same as for original equipment water pumps.
Consult service manual for specific procedures, if necessary.
CAUTION: Be sure that fan bolts don't protrude through the
hub so far that they hit the water pump housing.
NOTE: Check clearance between water pump body and
crankshaft dampner. Clearance pump body or change dampner
if necessary.
• SPECIAL NOTES:
Check closely for any interference with drive belts; some filing
for clearance may be necessary with some applications.
• SPECIFICATIONS
Dimension from flange surface to hub:
#8842— 5.1"
VICTOR SERIES ALUMINUM WATER PUMPS
For 1965-67 289 c.i.d. HP Ford V8s
Catalog #8842 (unpolished), #8847 (polished)
• INSTALLATION
Installation is the same as for original equipment water pumps.
Consult service manual for specific procedures, if necessary.
CAUTION: Be sure that fan bolts don't protrude through the
hub so far that they hit the water pump housing.
NOTE: Check clearance between water pump body and
crankshaft dampner. Clearance pump body or change dampner
if necessary.
• SPECIAL NOTES:
Check closely for any interference with drive belts; some filing
for clearance may be necessary with some applications.
• SPECIFICATIONS
Dimension from flange surface to hub:
#8842— 5.1"
