ACARI RTM-LP SERIES PART LIST:
DESCRIPTION
(QTY)
LP SERIES
(1)
PLATFORM
LOWER EXTRUSION
(1)
WINDSEAL VINYL
(1)
VEHICLE SPECIFIC
(1)
BEZEL
METAL CLAMPS
(2)
ADHESIVE CLAMP
(2)
PADS
VEHICLE SPECIFIC
(2)
BEZEL
FOAM STRIPS
(2)
FASTENER BAG
(1)
ACARI RTM-01 SERIES PART LIST:
DESCRIPTION
(QTY)
01 SERIES
(1)
PLATFORM
LOWER EXTRUSION
(1)
WINDSEAL VINYL
(1)
VEHICLE SPECIFIC
(1)
BEZEL
PLASTIC ENDCAPS
(2)
W/ GASKETS
METAL CLAMPS
(2)
ADHESIVE CLAMP
(2)
PADS
VEHICLE SPECIFIC
(2)
BEZEL
FOAM STRIPS
(2)
FASTENER BAG
(1)
*Fastener Bag Contents*
E1. (2) 1 ½" Hex Bolt
E2. (6) 1" Button Socket Cap, Black Oxide Finish
E3. (2) ¾" Pan Head Screw
**KIT PACK #'s 12-1, 13-1, 23-1, & 33-1 will contain a piece of adhesive strip foam**
ACARI RTM Part Breakdown
*CONTENTS LISTED BELOW*
*CONTENTS LISTED BELOW*
E4. (4) Lock Washers
E5. (2) Flat Washers
PART NUMBER
REFERENCE
NUMBER
LP-101-A
1
ACE-7
2
W-BM
3
Located on box
4
ACE-8
A
CP-FORD
B
N/A
C
FI-COM
D
F-KIT-23
E
PART NUMBER
REFERENCE
NUMBER
ACE-2.1
1
ACE-7
2
W-BM
3
Located on box
4
EC-UR (RIGHT)
5
EC-UL (LEFT)
ACE-8
A
CP-FORD
B
N/A
C
FI-COM
D
F-KIT-23
E
Advertisement
Summary of Contents for ACARI RTM-LP Series
- Page 1 ACARI RTM Part Breakdown ACARI RTM-LP SERIES PART LIST: DESCRIPTION (QTY) IMAGE PART NUMBER REFERENCE NUMBER LP SERIES LP-101-A PLATFORM LOWER EXTRUSION ACE-7 WINDSEAL VINYL W-BM VEHICLE SPECIFIC Located on box BEZEL METAL CLAMPS ACE-8 ADHESIVE CLAMP CP-FORD PADS VEHICLE SPECIFIC...
-
Page 2: Safety First
The ACARI RTM is designed to provide a mounting platform for lighting, antennas, GPS, and other accessories. In no way is the ACARI RTM to be used as a load bearing rack for ladders or other equipment or supplies. The recommended weight restriction of the ACARI RTM is 30 lbs. - Page 3 1. Open ACARI RTM package and remove all parts. Confirm proper mounting kit # on front of box for your vehicle model type. Lower Mount Preparation : Remove Aluminum components from shipping position inside the box. Remove the Lower Extrusion from its shipping position by removing screw.
- Page 4 Installation of the Lower Mount: Pull all harness wires and CHMSL lead though the access hole between the clamps while easing the clamps up and into the cab body. In some cases, the clamp bolts must be pulled back while installing to insure the clamps slide up along the interior of the roof and not get hung up on interior roll bar structure.
- Page 5 This warranty gives you specific rights, and you may also have other rights which vary from state to state. ACARI products are covered by a direct warranty for up to a maximum one year from date of purchase (not to exceed two years from the date of manufacture), with proof of purchase.
